Maxfield CS1.0 User manual

MAXFIELD
Operating Manual
W I R L E S S C H A R G I N G
STATION C.S1.0

Pr o d u c t overview
Charging station
AC/DC Adapter Cablemount with screws
Hex Keys

intrOductiOn
DIMEnsIon
12 cm
8,5 cm
REquIRED TooLs
3 mm
JIgsAw scREw DRIvER HEX kEys

1. Cut out a hole in the table
Fi r s t s tePs
Mounting the CS1.0 station
2. Insert the station
3. Fix the screws 4. If needed attach the cable mount
5. Connect the cables, bolt them down and connect to energy

saFety N o t e
ATTENTION!
For your own safety, please read the construction manual carefully. Af-
ter opening the package please check it on its completness. The disre-
gard of the safety note may lead to heat, re, burn or frequent electric
shocks. Wrong handling may lead to martial as personelle damage
and in worst cases it may also lead to death.
- The instalation of the device should be done by an specialist.
- Do not open or repair the device on your own. Only by an authorised
rm.
- Do not install the device underneath an electric conductive surface.
- Do not use the device if it is damaged or wet.
- Keep sufcient distance to hot and wet elements while installation.
- Do not use the device outdoors.
- Remove dust and wood deposits out of the milled hole before instal-
ling the device.
- Make sure that there are no metal parts between the station and the
charging device.
- Make sure that all electrical connections and supply cables connected
to other devices are in accordance with safety guidelines and with the
instruction manual
- Pay attention, that you do not overcharge the plug socket and extensi-
on cord. This may lead to re and electric shock.
- Keep all parts out of reach of children.
- Please avoid strong shocks or impacts. It may lead to electric circuit
breakdown.
- Never replace damaged power supplies yourself! Disconnect the de-
vices and contact a specialist.

LiabiLity e x c L u s i o N
Maxeld GmbH
Albert-Einstein-Str.1 . 74722 Buchen, Germany
Telefon: [phone] / 56435-0 . Fax: [phone]
info@maxeld.de . www.maxeld.de/en
Because we aren‘t abble to control the charging, the usa-
ge and the observance of the safety notes Maxeld can‘t
take liability for loss, damage and expences. Any claim on
compensation caused by operation, breakdown, failure or
coherent in any way will be declined. For personal injurys
as well as property damage caused by our supply, we won‘t
take liability. Insofar compulsory authorised, our commit-
ment to pay damages, for whatever legal foundation, will be
dened on the invoice value of the product wich is affected
in the incidence. This does not apply when we have to liable
for gross negligence or because of statutory provisions.
IMPORTANT!
• Status 09/2014 • Technical changes reserved • No accountability for falsity and misprint
