Maxon M-KIT112 User manual

M-KIT112/113/114
Assembly Instructions
Document Number: 181-03005
Revision Date: November 2008
®
Maxon Furniture Inc.
An operang company of the HNI Corporaon
www.maxonfurniture.com
Customer Service 1-800-876-4274
These instrucons must be followed exactly. Failure to
follow these instrucons could damage the product or
result in injury to persons using or assembling the product.
Maxon Furniture Inc. shall not be liable for any costs, loss,
damage, expenses or injuries resulng from failure to
properly assemble the product in accordance with these
instrucons.

Page 2 of 13 M-KIT112/113/114 Assembly Instrucons 181-03005
These instrucons must be followed exactly. Failure to follow these instrucons could damage the product or result in injury to persons
using or assembling the product. Maxon Furniture Inc. shall not be liable for any costs, loss, damage, expenses or injuries resulng from
failure to properly assemble the product in accordance with these instrucons.
Maxon Furniture Inc. Customer Service: 1-800-876-4274
Quanty Part Number Descripon
2PL6624 Raceway Panel, 66H x 24W
4 PL6636 Raceway Panel, 66H x 36W
3PLCP66 Raceway Corner Post, 66” High
1UCS2436TM Corner Worksurface, 24D x 36W*
1UPCS36 Steel Overhead Shelf, Corner, 36” Wide+
2UWR2436TM Rectangular Worksurface, 24D x 36W*
1SYP20B-R Systems Pedestal, 20” Deep
2EC1E Raceway End Cover, 6” High
* The Worksurface cartons contain one Right-hand and one Le-hand Canlever screwed to the worksurface.
+ The Corner Shelf carton contains one Corner Shelf, one Le-hand End Panel, one Right-hand End Panel, and two Back Strips.
PL6624
PL6624
PL6636
PL6636
UPCS36
UCS2436TM
UWR2436TM
SYP20B-R
EC1E
EC1E
PLCP66
PLCP66
PLCP66
For installaon assistance or to report missing parts, please contact Customer Service at 1-800-876-4274

Page 3 of 13 M-KIT112/113/114 Assembly Instrucons 181-03005
These instrucons must be followed exactly. Failure to follow these instrucons could damage the product or result in injury to persons
using or assembling the product. Maxon Furniture Inc. shall not be liable for any costs, loss, damage, expenses or injuries resulng from
failure to properly assemble the product in accordance with these instrucons.
Maxon Furniture Inc. Customer Service: 1-800-876-4274
Tools Required for Assembly
Hardware Kits
Please ensure all required pieces are present before beginning assembly. Some steps may require a second
person for assistance.
Panel Hardware (PL6624 & PL6636)
Corner and Rectangular Worksurface Hardware (UCS2436TM & UWR2436TM)
End Cap
Provided: 6
Used: 2
Top Cap Spacer
Provided: 6
Used: 4
Lock Bar
Provided: 6
Used: 2
#8 x 1/2” Phillips Flat Head
Provided: 12
Used: 4
I-Beam Panel Connector
Provided: 48
Used: 48
Straight Alignment Bracket
Provided: 6
Used: 2
#10 x 3/4” Panhead Screw
For Corner Worksurface:
Provided: 16
Used: 11
For Rectangular Worksurface:
Provided: 32
Used: 20
Aaching Bracket
For Corner Worksurface:
Provided: 2
Used: 0
For Rectangular Worksurface:
Provided: 2
Used: 2
RH Corner Bracket
For Corner Worksurface:
Provided: 1
Used: 1
For Rectangular Worksurface:
Provided: 2
Used: 1
LH Corner Bracket
For Corner Worksurface:
Provided: 1
Used: 0
For Rectangular Worksurface:
Provided: 2
Used: 1
Phillips Screwdriver
Level
Drill/Screw Gun
with Phillips bit
Rubber Mallet
Boxcuer
Tape Measure
1/2” Box End or
Adjustable Wrench
1/4” Socket Wrench
Wire Cuers

Page 4 of 13 M-KIT112/113/114 Assembly Instrucons 181-03005
These instrucons must be followed exactly. Failure to follow these instrucons could damage the product or result in injury to persons
using or assembling the product. Maxon Furniture Inc. shall not be liable for any costs, loss, damage, expenses or injuries resulng from
failure to properly assemble the product in accordance with these instrucons.
Maxon Furniture Inc. Customer Service: 1-800-876-4274
Hardware Kits
Corner Post Hardware (PLCP66)
Corner Shelf Hardware (UPCS36)
Systems Pedestal Hardware (SYP20B-R)
#8 x 1/2’’ Washer Head Screw
Provided: 16
Used: 6
Overhead Joining Bracket
Provided: 1
Used: 0
LH Corner Bracket
Provided: 1
Used: 0
Bridge Support Bracket
Provided: 1
Used: 0
Standard Pedestal Screw
Provided: 4
Used: 4
Standard Pedestal Spacer
Provided: 4
Used: 4
Wedge Bracket
Provided: 9
Used: 6
Angle Alignment Bracket
Provided: 9
Used: 3
Note: Brackets are shipped in
strips of 3 and must be broken
apart before using.
Raceway Corner End Cap
Provided: 3
Used: 3
Raceway 3-Way End Cap
Provided: 3
Used: 0
Corner Post Cap
Provided: 3
Used: 3
Top Cap Spacer
Provided: 9
Used: 0
Straight Alignment Bracket
Provided: 3
Used: 3
I-Beam Panel Connector
Provided: 24
Used: 16

Page 5 of 13 M-KIT112/113/114 Assembly Instrucons 181-03005
These instrucons must be followed exactly. Failure to follow these instrucons could damage the product or result in injury to persons
using or assembling the product. Maxon Furniture Inc. shall not be liable for any costs, loss, damage, expenses or injuries resulng from
failure to properly assemble the product in accordance with these instrucons.
Maxon Furniture Inc. Customer Service: 1-800-876-4274
Installing the Panels 1. Slide/pry the Top Cap from each Panel end
being careful not to damage the parts (Figure
1).
CAUTION! The following steps may
require assistance to complete.
2. Posion the PL6636 Panels in their
approximate installed placement and level by
turning the glides on the boom of the Panel
Frame with a 1/2 inch wrench.
3. On one PL6636 Panel, insert one Straight
Alignment Bracket into the notch located on
the panel’s edge at the boom of the Panel
Frame (Figure 2).
4. Place one PLCP66 Corner Post on top of the
Straight Alignment Bracket.
5. Connect the PLCP66 Corner Post to the
PL6636 Panel by sliding plasc I-Beam Panel
Connectors down the grooves in between the
Corner Post and the Panel’s edge (Figure 3).
TIP! You will need 4 I-Beam Panel
Connectors to ll each groove.
6. Using wire cuers or snips, trim the excess
I-Beam Panel Connector length so that the
grooves are completely lled and ush with
the Panel Frame top.
7. Place one PL6636 Panel against the Corner
Post at a 90 ° angle from the rst Panel.
8. Insert one Angle Alignment Bracket (Figure 2
& Figure 4) into the slots of the two Panels
being connected.
Tip! Use two slots near the boom to
help eliminate interference with future
accessory installaons.
9. While holding the Angle Alignment Bracket in
place, connect the second Panel by inserng
the I-Beam Panel Connectors as directed in
Steps 5 - 6.
Figure 1
Panel end
Top Cap
Figure 2
PL6636
Panel
PL6636
Panel
I-Beam Panel Connectors
PLCP66
Corner Post
Top View
Figure 3
Figure 4
Angle Alignment
Bracket
Straight Alignment
Bracket
Corner
Post
Glide
90
Exterior
Assembly View
Angle
Alignment
Bracket
I-Beam Panel Connectors

Page 6 of 13 M-KIT112/113/114 Assembly Instrucons 181-03005
These instrucons must be followed exactly. Failure to follow these instrucons could damage the product or result in injury to persons
using or assembling the product. Maxon Furniture Inc. shall not be liable for any costs, loss, damage, expenses or injuries resulng from
failure to properly assemble the product in accordance with these instrucons.
Maxon Furniture Inc. Customer Service: 1-800-876-4274
10. Add the two remaining PL6636 Panels
by inserng a Straight Alignment Bracket
between the adjoining panels and connecng
with the I-Beam Panel Connectors (Figure 5).
11. Trim the excess I-Beam Panel Connector length
with wire cuers or snips as in Step 6.
12. To secure the PL6636 Panels, center the Lock
Bar over two Panels (Figure 5) and aach
with two (2) #8 x 1/2” Flat Head Self Drilling
Screws (Figure 6).
13. Repeat Step 12 to secure the last two PL6636
Panels.
14. Repeat Steps 3 - 6 to aach the two PLCP66
Corner Posts to the PL6636 Panels (Figure 7).
15. Repeat Steps 7 - 9 to aach two PL6624
Panels. This completes the installaon of the
Raceway Panels.
PL6624
Corner Posts
Top View
#8 x 1/2" Phillips
Flat Head
Lock Bar centered
over panels.
Figure 7
Figure 6
Figure 5
Straight Alignment
Bracket
#8 x 1/2" Phillips
Flat Head Screws
Lock Bar
I-Beam Panel Connectors
Glides

Page 7 of 13 M-KIT112/113/114 Assembly Instrucons 181-03005
These instrucons must be followed exactly. Failure to follow these instrucons could damage the product or result in injury to persons
using or assembling the product. Maxon Furniture Inc. shall not be liable for any costs, loss, damage, expenses or injuries resulng from
failure to properly assemble the product in accordance with these instrucons.
Maxon Furniture Inc. Customer Service: 1-800-876-4274
Installing Panel Trim 1. Pull down all of the Raceway Covers on the
outside of the Panels by gently pulling on the
top of the Raceway Covers (Figure 8).
2. Install one Corner End Cap onto each of the
three corners (Figure 8).
3. Install one EC1E Raceway End Cover onto the
end of each PL6624 Panel inside the Raceway
Covers (Figure 9). Two EC1E End Covers will
be installed.
4. Close the Raceway Covers.
Flanges at top of
Corner End Cap
Raceway Covers
Corner
End
Caps
EC1E
Tab at top
Figure 9
Figure 8

Page 8 of 13 M-KIT112/113/114 Assembly Instrucons 181-03005
These instrucons must be followed exactly. Failure to follow these instrucons could damage the product or result in injury to persons
using or assembling the product. Maxon Furniture Inc. shall not be liable for any costs, loss, damage, expenses or injuries resulng from
failure to properly assemble the product in accordance with these instrucons.
Maxon Furniture Inc. Customer Service: 1-800-876-4274
5. Install metal Wedge Brackets at all panel-
to-corner-post connecons by inserng the
bracket ange between the Panel and the
Corner Post (Figure 10). Six Wedge Brackets
will be installed.
6. Install one Corner Post Cap onto each of the
three PLCP66 Corner Posts (Figure 11.a).
Three Corner Post Caps will be installed.
7. Install one End Cap into each of the two
PL6624 Top Caps (Figure 11.b).
8. Snap the Top Caps onto the two PL6624
Panels. The End Cap tab should t into the
Panel frame.
9. Install one Top Cap Spacer into the end of
each of the four PL6636 Panel Top Caps
(Figure 11.a).
10. Snap the four Top Caps onto the PL6636
Panels with the Spacer end next to the Corner
Posts (Figure 11.c).
Figure 11.b Figure 11.c
Figure 11.a
Corner Post Cap
Top Cap Spacer
on 36” Panel
ends next to
Posts (4 places)
Top Cap Spacer
Wedge
Brackets
Top View
Figure 10
Wedge Bracket
End Cap
End Caps
on 24” Panel
ends opposite
Posts (2 places)
Top Cap

Page 9 of 13 M-KIT112/113/114 Assembly Instrucons 181-03005
These instrucons must be followed exactly. Failure to follow these instrucons could damage the product or result in injury to persons
using or assembling the product. Maxon Furniture Inc. shall not be liable for any costs, loss, damage, expenses or injuries resulng from
failure to properly assemble the product in accordance with these instrucons.
Maxon Furniture Inc. Customer Service: 1-800-876-4274
Adding the Corner Shelf The Corner Shelf will be installed onto the two
PL6636 Panels in the back corner of the cubicle.
Each P anel has a vercal row of slots on the end
for aaching components (Figure 12).
1. Install the Le-hand Shelf End Panel with the
top tooth at 5 slots down on the le PL6636
Panel. The Shelf End Panel will drop down
into the slots on the PL6636 Panel (Figure
13).
2. Repeat for the Right-hand Shelf End Panel.
ATTENTION! Ensure that the Shelf End
Panel Teeth are fully engaged with the
Panel slots.
3. Insert a Back Strip into the Le PL6636 Panel
by lng the boom of the Back Strip up
towards you. Allow the top tooth to go into
the exposed panel slots at the boom of
the Shelf End Panel (Figure 14). At the back
corner, insert the top tooth so the Back Strip
is level with the Shelf End Panel.
4. Rotate the Back Strip down to lock in place.
5. Repeat Steps 3 - 4 to install the Back Strip on
the right PL6636 Panel (Figure 15).
Left-hand
End Panel
Back Strip
Bottom View
Figure 14
Figure 13
Top tooth in
5th slot from
the top
End
Panel
Figure 15
Back Strips
Left-hand
End Panel
Right-hand
End Panel
Left PL6636
Panel
Right PL6636
Panel
Figure 12

Page 10 of 13 M-KIT112/113/114 Assembly Instrucons 181-03005
These instrucons must be followed exactly. Failure to follow these instrucons could damage the product or result in injury to persons
using or assembling the product. Maxon Furniture Inc. shall not be liable for any costs, loss, damage, expenses or injuries resulng from
failure to properly assemble the product in accordance with these instrucons.
Maxon Furniture Inc. Customer Service: 1-800-876-4274
6. Install the Shelf by placing the sides of the
Shelf into the Shelf Holding Brackets [on the
Shelf End Panels] and pushing it down into
place.
7. Make sure that the Shelf is fully seated and
ush with the Holding Brackets.
TIP! Pushing down by hand is usually
sucient, but light taps with a rubber
mallet may be necessary.
8. Use three #8 x 1/2 “ Washer Head Screws to
aach each Back Strip to the Shelf.
CAUTION! Hold down the Shelf while
installing the screws. Otherwise, the
upward force may li the Shelf and End
Panels o the Panels.
Figure 16
Figure 17
Shelf
Bottom View
Shelf Holding
Bracket
Left-hand
End Panel
Shelf
#8 x 1/2" Washer
Head screw
(3 in ea. Back Strip)
Back Strip
Insert Shelf flange into
Shelf Holding Bracket

Page 11 of 13 M-KIT112/113/114 Assembly Instrucons 181-03005
These instrucons must be followed exactly. Failure to follow these instrucons could damage the product or result in injury to persons
using or assembling the product. Maxon Furniture Inc. shall not be liable for any costs, loss, damage, expenses or injuries resulng from
failure to properly assemble the product in accordance with these instrucons.
Maxon Furniture Inc. Customer Service: 1-800-876-4274
Adding the Worksurfaces 1. Unpack the UCS2436TM Corner Worksurface
and unscrew the Canlever Brackets from the
worksurface.
2. Posion the Le-hand Canlever Bracket into
le hand panel slots in the Back Le Panel at
about 28” from the oor (Figure 18).
3. With the Canlever lted up about 45 degrees,
slide the top tooth into the panel slot, then
rotate the canlever down to engage the
other teeth (Figure 19).
4. Repeat Steps 2 - 3 to install the Right-hand
Canlever Bracket on the right hand slots of
the Back Right Panel.
5. Add one RH Corner Bracket in the back corner
at the same height as the Canlever Brackets
(Figure 20). The RH Corner Bracket is shown,
but you can use either the LH or RH Corner
Bracket.
6. Place the UCS2436TM Corner Worksurface
into posion on the Canlevers and Corner
Bracket.
7. Secure the UCS2436TM Corner Worksurface
with three #10 x 3/4” Panhead Screws in each
Canlever and one #10 x 3/4” Panhead Screw
in the RH Corner Bracket (Figure 21).
Figure 20
Figure 19
Figure 21
Figure 18
RH Corner
Bracket
#10 x 3/4" Panhead Screw
(3 in ea. Cantilever,
1 in RH Corner Bracket)
28"
Left-hand
Cantilever
Right-hand
Cantilever
RH Corner
Bracket
Back Left
Panel
Back Right
Panel
Left-hand
Cantilever

Page 12 of 13 M-KIT112/113/114 Assembly Instrucons 181-03005
These instrucons must be followed exactly. Failure to follow these instrucons could damage the product or result in injury to persons
using or assembling the product. Maxon Furniture Inc. shall not be liable for any costs, loss, damage, expenses or injuries resulng from
failure to properly assemble the product in accordance with these instrucons.
Maxon Furniture Inc. Customer Service: 1-800-876-4274
8. Unpack one UWR2436TM Rectangular
Worksurface and unscrew the two (2)
Canlever Brackets from the worksurface.
9. Install the Le-hand and Right-hand Canlever
Brackets onto the PL6636 Panel [to the le
of the UCS2436TM Corner Worksurface] at
the same height as the UCS2436TM Corner
Worksurface (Figure 22).
10. Install one LH Corner Bracket at the same
height as the Canlevers into the le PL6624
Panel on the inside of the staon.
11. Posion one UWR2436TM Rectangular
Worksurface onto the Canlevers and Corner
Bracket and secure with three #10 x 3/4”
Panhead Screws in each Canlever and one
#10 x 3/4” Panhead Screw in the Corner
Bracket (Figure 23).
12. Posion the Aaching Bracket near the front
at the adjoining edges of the Corner and the
Rectangular Worksurfaces. Secure with four
(4) #10 x 3/4” Panhead Screws in the pre-
marked worksurface holes (Figure 23).
13. Repeat steps 8 - 12 with the second
UWR2436TM Rectangular Worksurface using
the RH Corner Bracket in the right side of the
PL6624 Panel.
Figure 23
Figure 22
#10 x 3/4" Panhead screws
(3 in each Cantilever,
1 in the LH Corner Bracket,
4 in the Attaching Bracket)
Attaching Bracket
Right-hand
Cantilever
Bracket
LH Corner Bracket
Left-hand
Cantilever Bracket

Page 13 of 13 M-KIT112/113/114 Assembly Instrucons 181-03005
These instrucons must be followed exactly. Failure to follow these instrucons could damage the product or result in injury to persons
using or assembling the product. Maxon Furniture Inc. shall not be liable for any costs, loss, damage, expenses or injuries resulng from
failure to properly assemble the product in accordance with these instrucons.
Maxon Furniture Inc. Customer Service: 1-800-876-4274
Adding The Pedestal 1. Unpack the SYP20B-R Systems Pedestal and
remove the drawers.
2. Insert four Standard Spacers into the holes on
the Pedestal top (Figure 24).
3. Posion the Pedestal under the Rectangular
Worksurface.
4. Insert a 1/4” Socket Wrench through the
Glide Access Holes to adjust the four Leveling
Glides unl the Standard Spacers touch the
boom of the UWR2436TM Rectangular
Worksurface (Figure 24).
5. Install four Pedestal Screws inside the
Pedestal, through the Spacers, and into the
boom of the Rectangular Worksurface
(Figure 24).
6. Replace the Pedestal drawers (Figure 25).
Figure 25
Figure 24
Standard Pedestal Spacer
Standard
Pedestal Screws
Glide Access Holes
