MAXSA 40220 Quick reference guide

MOTION-ACTIVA TED
SECURITY LIGHT
ASSEMBLY & OPERATING INSTRUCTIONS
Solar Motion-Activated Security Light - 10W Halogen
Model #40220
o
IMPORTANT: READ ALL INSTRUCTIONS CAREFULLY BEFORE USE
ABOUT YOUR SOLAR SECURITY LIGHT
During the day, the solar cell charge panel included with this MAXSA
Solar Security Light converts sunlight into electricity recharging the pre-
installed battery. Using this stored energy, the 10 watt halogen light
(included
in this Solar Security Light) turns on automatically at night when
motion is detected. This MAXSA Solar Security Light has
an adjustable
TIME dial that allows light duration of up to 60 seconds. When the battery
is fully charged, this Solar Security Light can light up for up
to 2.5 hours,
which is equivalent
to 150 times when the TIME dial is set to the
maximum
(+) position.
The battery included
in this unit is asealed lead-acid 6V, 4Ah
rechargeable battery and will need to be replaced when the charging
ability is decreased. This battery should last for approximately 3years
before it will need
to be replaced.

Carefully remove and identify all the parts from their protective packaging and lay them
out in front of you.
Included Parts:
4 screws and anchors /
for mounting solar panel
15 foot power cable
Light cover
Motion sensor
Solar panel
angle pivot
Solar panel
mounting bracket
AUTO/OFF switch
Duration time adjusting knob
Motion sensitivity adjusting knob
Light sensitivity adjusting knob
Once you have identified all parts, connect the solar
charge panel to your Solar Security Light by plugging ==:;;:;:;:3
1
0::) lIT) [) =r) ](TI((TIO;;:;:;:;;:;:;::;;:;:;=
the 15 foot cord into the cord attached to the front of =
the Solar Security Light. Firmly turn and twist the ~ ..
cords while pressing together for a tight connection.
2

CHOOSING ALOCATION FOR YOUR SOLAR SECURITY LIGHT
This Solar Security Light comes complete with a solar cell charge panel attached to a 15
foot power cord. For optimum sun exposure and longer light output, place the solar
panel, when attached to the Security Light, in a position that receives at least 6-8 hours
of direct sunlight per day. Ideally, it should face south. Placing the solar cell charge
panel in a shaded location will not allow the battery to charge fully. This will reduce the
number of hours the Solar Security Light will operate per evening. In choosing a location
for your Solar Security Light, ensure that the solar cell charge panel is not placed near
night time light sources such as porch lighting or street lighting.
This Solar Security Light is ideal for areas where electricity is not available, including
driveways, carports, garages and entrance doors, for safety and security around your
home. In addition to the safety and security benefits of this Solar Security Light, it can
also be used for convenience lighting and is ideal for use on backyard sheds, farm
sheds, RV's and other remote areas where electricity is not available.
When deciding where to mount the light, keep in mind that the motion sensor that
activates this light has a field of vision of 180
0
(horizontal) at a distance of 40 feet when
the surrounding temperature is 75
0
F.
HOW TO INSTALL YOUR SOLAR SECURITY LIGHT
1. Mount the Security Light onto a solid surface, using the two (2) wood/sheet metal
screws supplied. You may mount the Security Light vertical or more horizontal.
SOUTH
WALL
~SOUTH
~
"
2. Use the four (4) wood/sheet metal screws supplied to mount the solar cell charge
panel onto a solid surface. You can adjust the angle of the solar cell by gently rotating
the solar cell to a different locking position. Remember to face the panel south for
direct sunlight exposure.
3

BEFORE FIRST TIME USE OF YOUR SOLAR SECURITY LIGHT
1. Ensure the power switch on the main body of your Security Light is in the OFF
position. In this position, the solar cell will charge the battery without activating the
unit.
2. Leave the switch in this position for up to 3 days and make sure the solar cell charge
panel is placed in direct sunlight. This will ensure that the battery in your Solar
Security Light has a full charge prior to motion sensor adjustment and normal
operation.
OPERATING YOUR SOLAR SECURITY LIGHT
After the initial 3 day charge of your Solar Security Light, move the switch on the main
body to the AUTO position. Your Solar Security Light is now ready for use.
Underneath the motion sensor, there are 3 adjustment dials: TIMEISENS/LUX. All 3 of
these adjustment dials have been preset to the following conditions:
TIME - Set at 30 seconds
SENS - Set at 20 feet (When the surrounding temperature is 75° F).
LUX - Set for your Security Light to activate at dusk when motion is detected.
If the above settings are not suitable for your application, then these may be adjusted
using the steps below.
•Time Period Adjustment (TIME)
The time period control sets the duration that the Solar Security Light will be illuminated,
when activated. The time period is adjustable over a range of 10 seconds to 1 mnute.
The shortest time period is with the TIME control set fully clockwise(-).
To adjust the time period, set the TIME control at a random position, trigger the sensor
unit and measure the time period the light illuminates. Increase or decrease the time
period by adjusting the TIME dial and re-trigger the sensor unit. Continue with this
process until the desired time period is obtained.
•Motion Sensor Adjustment (SENS)
The sensitivity of the motion sensor on this Solar Security Light will be affected by
temperature. The cooler the temperature the more sensitive the motion sensor will
become. Use the SENS dial to adjust the sensitivity of the motion sensor to compensate
for environmental temperature changes. The motion sensor is most sensitive when the
SENS dial is turned fully counter-clockwise (+).
•Light Level Adjustment (LUX)
The LUX dial controls the natural light level that initiates operation and prevents the
security light from operating during daylight hours.
Your solar security light comes preset and will be activated when motion is detected at
dusk. To adjust the light level control, turn the LUX control fully clockwise (J». Wait until
the natural light falls to the required level that you wish to activate your solar security
light. Rotate the LUX control slowly counter-clockwise until the Solar Security Light
illuminates.
4

IF YOU WANT TO TEST THE COVERAGE
Point the motion sensor in the direction you want to detect motion and set the TIME dial
to minimum (-) position and the LUX dial to "light" (~) position.
Test the coverage of the area by walking slowly around the area of detection and adjust
sensitivity if needed. If the Solar Security Light does not come on, you may need to
adjust the angle of the sensor unit. Readjust the TIME and LUX dials when finished.
REPLACING THE LEAD ACID RECHARGEABLE BATTERY
When the charging ability of the battery decreases, you can replace the battery with a
new 6V, 4Ah lead acid battery. Follow the steps below when replacing the battery.
1. First remove the main unit from its mounted surface.
2. Move the power switch on the main body to the OFF position.
3. Remove the four (4) screws on the back of the main unit that hold the halves
together.
~
Bracket
Wires to Battery
,
Bracket
Battery
Wires to Light
4. Once the unit is open, carefully remove the two (2) brackets holding the battery in
place by unscrewing the four (4) screws as indicated in the diagram above.
5. Carefully unplug the positive and negative cords.
6. Carefully remove the battery from its compartment and replace with a new 6V, 4Ah
rechargeable lead acid battery. Ensure that the red cord is re-attached to the red-
colored battery terminal. (WARNING: Connecting these in the opposite direction
could damage the unit.)
7. Replace the two (2) brackets to hold the battery in place by using the four (4) screws
removed in step 4, taking care not to damage any cables.
8. Re-assemble the main unit by screwing the two (2) halves of the main body
together, using the four (4) screws removed in step 3, ensuring the two halves click
together securely.
9. Once assembled, mount your Solar Security Light to its original surface location.
10. Repeat the steps in the "Before first time use of your Solar Security Light" section on
page 4 to ensure your new battery is fully charged.
5

NOTE: Do not dispose of battery in general household trash or into a fire since the
battery may explode. Consult your local regulations for correct disposal of
batteries. The battery may also be returned to MAXSA Innovations at 8412
Cathedral Forest Dr., Fairfax Station, VA 22039. Do not take apart the battery
since it contains corrosive chemicals.
REPLACING THE 10 WATT HALOGEN BULB
NOTE: Bulb gets hot. Do not touch. Wait for the bulb to cool and use a clean soft
cloth to remove or change the bulb.
1. Turn the power switch to the OFF position and wait for the light to cool down.
2. Remove the light cover using a small flat head screwdriver.
3. Gently remove the old bulb, taking care and ensuring that the bulb is cool to touch.
4. Using a clean soft cloth or tissue, replace the bulb with a new 10W halogen bulb by
inserting the prongs into the holes. DO NOT TOUCH THE HALOGEN BULB DIRECTLY
WITH FINGERS SINCE ANY OIL OR DIRT WILL DAMAGE THE BULB.
5. Replace the light cover back onto the main unit.
6. Turn the power switch to the AUTO position.
MAINTENANCE TIPS
To keep your Solar Security Light looking new, keep the lens free of dust and deposits by
wiping occasionally with a dry cloth or with warm soapy water if necessary.
Importantly, ensure that the solar cell charge panel is kept free of dirt and debris at all
times. A dirty solar panel will not allow the battery to fully charge and this will shorten
the life of the battery and may cause the light to malfunction.
STORAGE
If you wish to store your light indoors for more than two or three days, turn the power
switch to the OFF position to prevent damaging the battery. Battery capacity may be
reduced during prolonged storage. For optimal performance, we recommend that you do
not store your Solar Security Light for prolonged periods of time.
6

TROUBLESHOOTING
Problem
Possible Solutions
Light will not switch
•
Ensure that the power switch on the main body has been turned to
on when there is
the AUTO position.
movement in the
•
Ensure that the motion sensor has been positioned to face
detection area.
oncoming movement.
•
Ensure that the battery has been fully charged in direct sunlight for
3 sunny days - Refer to the "Before First Use of Your Solar Security
Light" section on page 2.
•
Check to see that the solar cell charge panel is facing south so that
it receives direct sunlight for most of the day, enabling the battery
to fUlly charge.
•
Check to see that the LUX control has not been set too far towards
(:»). Setting the LUX control too far towards C») will cause your
Solar Security Light to turn on only in complete darkness.
•
Check to see that the solar panel is not near night time light
sources such as street lights.
•
The halogen bulb may not be working and may need to be
replaced.
Light switches on
•
The LUX control may be set too far towards the (01)) position.
during the day.
•
Reposition the motion sensor.
Light switches on for
•
The SENS control may be set too far towards the (+) position.
no apparent reason.
•
Moving trees, traffic, pets or birds may be getting in the area of
detection. This may be unavoidable, however the sensor could be
redirected to a height where this is less likely to occur.
•
If there are reflective objects in the detection area such as
windows, water, or white walls, you may need to redirect or
possibly reposition the motion sensor.
•
Test the motion sensor by covering it completely with cardboard
and waiting several minutes to make sure it does not detect motion.
If the light still switches on, please contact MAXSA for further
assistance.
Light quickly flashes
•
Battery charge may be low. Turn the power switch to the OFF
on and off.
position and charge the battery for three (3) sunny days, ensuring
the solar cell charge panel has been placed in direct sunlight.
•
Move the LUX control more to the (01)) position.
Light is not as bright
•
Battery charge may be low. Turn the power switch to the OFF
as normal.
position and charge the battery for three (3) sunny days, ensuring
the solar cell charge panel has been placed in direct sunlight.
•
The halogen bulb may need to be replaced.
7

90 DAY LIMITED WARRANTY
This Solar Motion-Activated Light is warranted against faulty material and/or
workmanship for a period of 90 days from date of original purchase.
The obligation of the manufacturer, under this warranty, is limited to servicing and
replacing defective parts when the unit is returned to MAXSA Innovations, freight
pre-paid during the warranty period. To obtain warranty repair, the purchase receipt
should be returned with the product.
This warranty becomes void on any unit which has been tampered with, damaged
by accident, or damaged otherwise by improper operation.
This guarantee is in addition to any guarantees implied by State or Federal
Legislation.
Please save these instructions for future reference.
MADE IN CHINA
8
®
MAXSA Innovations
8412 Cathedral Forest Drive
Fairfax Station, VA 22039
Tel: [phone]
www.maxsainnovations.com
v6-1
©2006 MAXSA Innovations, LLC
