MAXSA 40331 Quick reference guide

Model #: 40331
Perfect for flags, signs, gardens, driveways, parking lots, outdoor storage spaces,
decks, porches, or any large outdoor area where lighting is needed.
ASSEMBLY & OPERATING INSTRUCTIONS
IMPORTANT: READ ALL INSTRUCTIONS CAREFULLY BEFORE USE
ABOUT YOUR SOLAR POWERED FLOOD LIGHT
Your MAXSA Solar Powered Flood Light converts sunlight into electricity during the day,
enabling the 12 LED lights to turn on automatically at night. With this light, walking into the
dark will no longer be a problem. You can also save the environment by conserving energy
with these energy-efcient solar powered LED lights.
Your Solar Powered Flood Light will activate automatically when it gets dark and can light
for up to 6 hours at full power and up to 12 hours at half power / brightness when the
battery is fully charged. The unit includes 3.7V 2X2200 mAh rechargeable Lithium Ion
batteries.

2
Carefully remove and identify all the parts from their protective packaging and lay them out in front
of you.
INCLUDED PARTS:
Solar panel (3)
Mounting bracket
Brightness
control switch
On/Off Switch
Photosensor
9foot power cables
Pole Mounting
Straps and
Bracket
12 screws and 12 anchors for
mounting the 3 solar panels
Solar panel angle pivot
Solar panel
mounting bracket
Main flood light unit
HOW TO INSTALL YOUR SOLAR POWERED FLOOD LIGHT
MOUNTING TO AWALL, ROOF OR SIGN
1. If necessary, remove the mounting bracket from your Solar Powered Flood Light by taking
out the two screws on the left and right sides of the main body
2. Take the other two screws supplied with this product and install the mounting bracket
onto a solid surface. Put the mounting bracket and the main body back together by
using the two screws taken out in Step 1.

3
To mount on a agpole, position the agpole mounting
bracket supplied against the agpole and run the two
supplied metal bands through the bracket as shown.
*CAUTION: Do not tighten the metal bands until your Solar
Powered Flood Light is where you want it as they cannot
be re-opened. Put the bracket up to the pole and close
the metal bands around the pole, making sure the bands
are pulled tight so the light is firmly secured.
The 3 solar panels can be mounted to a wall or roof, or set on the ground.
Use four (4) wood/sheet metal screws supplied to mount each solar panel onto a solid
surface. You can adjust the angle of the solar panel by gently rotating it to a different
locking position. Remember to mount the panels facing South, which will maximize the
direct sunlight exposure.
HOW TO MOUNT THE THREE SOLAR PANELS
We recommend the panels be oriented to the south to maximize sunlight all year round.
We recommend this since as the seasons change, the sun’s angle and direction changes
slightly.
Once you have mounted the solar panel in the
desired location, connect the solar panel to your
Solar Powered Flood Light by plugging the 9 foot
cord into the cord attached to the bottom of the
Solar Powered Flood Light. Firmly turn and twist the
cords while pressing together for a tight connection.
TO MOUNT THE SOLAR PANEL TO AWALL OR ROOF
MOUNTING TO AFLAGPOLE

4
BEFORE THE FIRST USE OF YOUR SOLAR POWERED FLOOD LIGHT
1. Charge the batteries without activating the unit. Turn
the power switch on the main body of your Solar
Powered Flood Light to the OFF setting.
2. Leave the switch in this position for 3 days while the
solar panels are in direct sunlight. This will ensure
that the batteries in your Solar Powered Flood Light
have a full charge prior to normal operation.
3. After the initial 3 day charge of your Solar Powered Flood Light, flip the power switch
on the main body to the ON position to make the light turn on automatically after
sundown. Your Solar Powered Flood Light is
now ready for use. Depending on how
long you prefer the light to last, you can double the light duration and reduce the
brightness by pushing the brightness control button labelled "Brightness Full/Half".
NOTE: When you first turn the light on, it should activate immediately regardless of
lighting conditions. This is a test activation to show there is power flowing from the
battery to the light. It should last roughly 5 seconds. After this test activation, the light will
function normally.
MAINTENANCE TIPS
The LED lights in your Solar Flood Light will last up to 30,000 hours and before needing
replacement.
To keep your Solar Flood Light working great, keep the solar panel and light free of dust
and deposits by wiping occasionally with a dry cloth or with warm soapy water if
necessary. A dirty solar panel will not allow the batteries to fully charge thereby
shortening the life of the batteries and possibly causing the light to malfunction.
STORAGE
If you wish to store your light indoors for more than two or three days, turn the power
switch to the OFF position to prevent damaging the batteries. Battery capacity may be
reduced during prolonged storage. For optimal performance, we recommend that you do
not store your Solar Powered Flood Light for prolonged periods of time.
The Solar Powered Flood Light is ideal for signs, flags, gardens, backyards,
driveways, parking lots, entrance doors, decks, porches, sheds, or any large
outdoor area where you need extra light!
Your Solar Powered Flood Light comes complete with (3) solar panels with 9-foot power
cords. For optimum sun exposure and longer light output, place the solar panels where
they will receive 6-8 hours of direct sunlight per day. Placing the panels in a shaded
location or behind a glass window will not allow the batteries to charge fully, thereby
reducing the number of hours the light will operate per evening.
The Solar Powered Flood Light is equipped with a light-sensitive trigger to automatically
turn the light on at dusk. For best performance, ensure that the Flood Light is not placed
near nighttime light sources such as porch lighting and street lighting.
CHOOSING A LOCATION FOR YOUR SOLAR POWERED FLOOD LIGHT

5
TROUBLESHOOTING
PROBLEM POSSIBLE SOLUTIONS
Light will not
switch on.
•Ensure that the on/off switch on the main body has
been turned to the ON position.
•Ensure that the batteries have been fully charged in
direct sunlight for 3 sunny days (refer to the “Before
First Time Use of Your Solar Powered Flood Light”
section on page 4). Artificial light will not charge the
battery. It must charge in sunlight.
•Check to see that the solar panels are facing South
and that they receive 6-8 hours of sunlight per day,
enabling the batteries to fully charge.
•Check to see that the flood light is not near nighttime
light sources such as street lights that cause the photo
sensor to not turn on.
Light quickly
ashes on and off.
•Battery charge may be low. Turn the power switch to
the OFF position and charge the batteries for three
(3) sunny days, ensuring the solar panels have
been placed in direct sunlight, ideally facing the
Southern sky.
Light is not as
bright as normal
•Battery charge may be low. Turn the power switch to
the OFF position and charge the batteries for three
(3) sunny days, ensuring the solar panels have
been
placed in direct sunlight, ideally facing the Southern
sky.
•The brightness control switch might be set to HALF
mode, which is designed to use less power and
keep the light illuminated for a longer time period.
•Check to make sure solar panels are facing South,
and that they receives 6-8 hours of sunlight per day.

MADE IN CHINA
MAXSA Innovations, LLC
8412 Cathedral Forest Drive
Fairfax Station, Va 22039
Tel: 703-495-0661
www.maxsainnovations.com
6
v16-1
©2016MAXSA Innovations, LLC
Please save these instructions for future reference.
ONE YEAR LIMITED WARRANTY
1 YEAR LIMITED WARRANTY: MAXSA Innovations, LLC warrants to the original
consumer/purchaser that this product shall be free of defects in material and workmanship
under normal use and circumstances for a period of one (1) year from the date of original
purchase for use. When the original consumer/purchaser returns the product pre-paid
(consumer pays return shipping) to MAXSA Innovations, LLC, 8412 Cathedral Forest Dr;
Fairfax Station, VA 22039; USA within the warranty period, and if the product is defective,
MAXSA Innovations, LLC will at its option repair or replace such. This warranty shall
constitute the sole liability of MAXSA Innovations, LLC concerning the product. MAXSA
Innovations, LLC expressly disclaims all other warranties INCLUDING, WITHOUT
LIMITATION, THE WARRANTIES OF MERCHANT ABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. NO PERSON, FIRM, OR COPORATION IS AUTHORIZED
TO ASSUME FOR MAXSA Innovations, LLC ANY OTHER LIABILITY IN CONNECTION
WITH THE SALE AND USE OF THE PRODUCT. MAXSA Innovations, LLC and agents
and distributors will bear no liability whatsoever for incidental or consequential damages
or charges of any kind. Some states do not allow the reclusion or limitation of incidental
or consequential damages, so the above disclaimer regarding incidental or consequential
damages may not apply to you. This warranty is void if the product has been damaged
or tampered with or if the product or any such parts have been opened. In all cases of
damage during shipment, a claim must be led with the shipping carrier and not with
MAXSA Innovations, LLC. This warranty gives you specic legal rights; you may also have
other rights which vary from state to state.
EXTENSION CORDS:
A 15-foot extension cord is available for this product for $14.95, or (3) for $29.95, which
covers shipping and handling costs as well. This extension cord allows the solar panel
to be placed higher or further away from the security light to ensure maximum direct
sunlight exposure. For more information, please call 703-495-0661 and ask for
extension cord model
EXT-Black.
SPECIFICATIONS
Power Source: Solar (3 Panels) Amorphous
Lumens: 240 full/120 half
Light Color: 6500K (Cool White or Daylight color)
Function: Dusk-to-dawn
Power Storage: 3.7V 2X2200 mAh rechargeable Lithium Ion battery
Max Runtime: up to 12 hours @ half-power; up to 6 hours @ full-power
Weatherproof Rating: IP44
