Maxtor Maxtor OneTouch FireWire User manual

For detailed instructions, refer to the User’s Guide located on the OneTouch III Mini Edition
Red
Connector
Black
Connector
Small
Connector
Connect the OneTouch III Mini Edition
Install the Software
Enable the OneTouch Feature
OneTouch Button
Need Help? Refer to the Knowledge Base at support.seagate.com
for in-depth help and answers to frequently asked
questions. To contact Seagate, please visit seagate.com
and choose Contact Us.
Push the button on the front of your OneTouch III Mini
Edition. The OneTouch Manager software will open to
the Backup Settings menu. Follow the onscreen steps
to configure your backup.
Highly Recommended – Copy all files on the OneTouch
III Mini Edition to your local hard drive. When your
OneTouch III Mini Edition is attached, the software
installation will start. Select your language from the
list. If the installer does not launch, click Start ÆRun,
browse to the drive letter used for the OneTouch III Mini
Edtion, and open Launch.exe. Windows Vista will prompt
you with User Account Control to proceed; click Continue.
Follow the onscreen prompts to complete the installation.
1. Plug the Power + Data connector into an available
USB port on your system.
2. Plug the Power Only connector into an available USB
port on your system.
3. Connect the Type "B" connector to the OneTouch III
Mini Edition Drive.
If both ports fail to supply enough power to the drive,
an optional power supply should be purchased from
Maxtor at www.maxstore.com.
© 2007 Seagate, Seagate Technology, Maxtor, OneTouch, and the Maxtor stylized logo are trademarks or registered trademarks of Seagate Technology LLC or one of its affiliates. All other trademarks or registered
trademarks are the property of their respective owners. Seagate reserves the right to change, without notice, product offerings or specifications. One gigabyte, or GB, equals one billion bytes when referring to hard
drive capacity. Your computer’s operating system may use a different standard of measurement and report a lower capacity. In addition, some of the listed capacity is used for formatting and other functions, and thus
will not be available for data storage. Seagate Technology, 920 Disc Drive, Scotts Valley, CA 95066 U.S.A.
PN: 100476795
Windows Quick Start Guide (Macintosh instructions on reverse side)
MAXTOR ONETOUCH™III MINI EDITION

For detailed instructions, refer to the User’s Guide located on the OneTouch III Mini Edition
Red
Connector
Black
Connector
Small
Connector
Connect the OneTouch III Mini Edition
Install the Software
Enable the OneTouch Feature
OneTouch Button
Need Help? Refer to the Knowledge Base at support.seagate.com
for in-depth help and answers to frequently asked
questions. To contact Seagate, please visit seagate.com
and choose Contact Us.
Push the button on the front of your OneTouch III Mini
Edition. The OneTouch Manager software will open to
the Backup Settings menu. Follow the onscreen steps
to configure your backup.
Highly Recommended – Copy all files on the OneTouch
III Mini Edition to your local hard drive. Double-click the
Mac OneTouch Mini.dmg file to mount it to your desk-
top. Open the Mac OneTouch Mini desktop icon and
double-click the Mac OneTouch Mini installer icon to
install the software. When finished, launch the Apple
Disk Utility to format the drive for your Mac.
1. Plug the Power + Data connector into an available
USB port on your system.
2. Plug the Power Only connector into an available USB
port on your system.
3. Connect the Type "B" connector to the OneTouch III
Mini Edition Drive.
If both ports fail to supply enough power to the drive,
an optional power supply should be purchased from
Maxtor at www.maxstore.com.
Macintosh Quick Start Guide (Windows instructions on reverse side)
MAXTOR ONETOUCH™III MINI EDITION
