Maxview MXR0024 User manual

Assembly instructions
Contact:
Helpline: [phone]
Email: [e-mail]
Web: www.maxview.co.uk
Maxview reserve the right to change specifications without prior notice
9111308 Iss 2
MXR0024/KIT TV Aerial - 18 Element Kit
Model:

Pack contents check
A. Reflector Plate x 1
B. Support Arm x 1
C. Dipole x 1
D. Joining Plate x 2
E. Support Arm Bracket x 4
F. Washer x 4
G. M5 Nut x 4
O. Coaxial Plug x 1
P. M5 x 35mm Bolt x1
Q. M5 25mm Bolt x 2
R. Screw x 4
S. Wall Plug x 4
T. Cable Clip x 8
U. M5 Nut x 3
H. M5 x 25mm Screw x 4
I. Screw x 1
J. Mast Clamp x 1
K. Rear Boom Assembly x 1
L. Front Boom Assembly x 1
M. Crank Mast x 1
N. 10m Coaxial Cable
O
B
A
D
J
F
G
HI
E
M
L
P Q R S T U V
N
K
C
V. Fixing Bracket

1.
Join the 2 pieces of boom together using the
joining plate, M5 x 25mm screws M5 nuts and
5mm Shake Proof Washers.
2.
3.
Assembly
Screw the Dipole firmly to the Boom.
Fit the support arm to boom of the aerial using the four joining plates. Secure with nuts and bolts.
4.
Slide on and firmly push down the Reflector onto
the groove of the Reflector Bung.

Connecting Coaxial Cable
1.
Using a sharp knife prepare the Coaxial Cable as
shown. Loosen the screws on the 2 terminals in the
Dipole. Feed the inner core to one of the
terminals and the twisted braid into the other.
Tighten screws and close Dipole Cap.
2.
12mm
18mm
28mm

1.
1. Cut cable to required length.
2. Unscrew coaxial plug and slide screw cap over cable.
3. Strip away approximately 23mm of outer insulation.
4. Gather strands of shielding braid together and wind back around the outer insulation. Remove foil shield.
5. Strip away about half of the inner insulation around inner core. Check that none
of the shielding braid is touching the inner core.
6. Open claw, slide over screening braid and pinch to tighten.
7. Re-assemble connector and cut off inner core wire flush with plug.
Fitting Coaxial Plug
Inner core
Braid
Outer insulator
Screw cap
Plug
Claw
Inner insulator

1.
Insert Mast into Fixing Bracket. Make sure the holes
in the Mast align with the holes in the bracket. Insert
nuts & bolts as shown and securely tighten using a
8mm spanner
Mount bracket to a secure solid external wall or
internal wooden beam using the screws and wall plugs
if required.
A 6mm drill bit will be required if using wall plugs.
Fixing Kit Installation
2.

Attach aerial to mast using the Mast Clamp.
3

Turn on your TV set. Refer to manufacturers instructions to tune your TV into the available digital/HD/3D
channels. Select a tuned-in channel. Next, carry out the following procedures:
1. Turn your aerial to the LEFT until you lose the picture (if alone turn the volume up and turn until you hear a
reduction in sound quality).
2. Remember this position and turn your aerial to the RIGHT until you lose the picture/sound again.
3. Now point the aerial in the centre of these two points and you will receive optimum reception.
Digital & HD reception:
Reception of digital terrestrial TV (DTT) signals is subject to:
1. Use with a DTT set top box or integrated TV with digital tuner/receiver
2. Satisfactory signal quality from DTT transmitter
To receive terrestrial HD channels you will require the following:
1. An HD ready TV
2. Freeview HD receiver or TV with integrated Freeview HD tuner/receiver
3. HD signals must be transmitted in your local area. Visit www.freeview.co.uk for more information.
Safety warnings:
> Before starting installation check structure is sound and check for hidden electrical wiring or plumbing.
> When working on installations outside, beware of overhead power lines.
> Observe safe working practices, tread carefully and ensure adequate lighting is available in loft/roof space.
> Always follow manufacturer’s operating and safety instructions before using tools and/or equipment.
> Ladder safety - always read and follow the manufacturer’s instruction label affixed to the ladder.
> Ensure cable is correctly routed before fixing into position, taking care not to over tighten cable clips.
> This product may contain small parts - keep out of reach of children.
> After installation make regular maintenance checks.
> If in doubt consult a qualified or professional aerial installer.
Aligning your aerial
Polarisation
Tip: Look at outdoor aerials
in your area to see which
direction to point your
aerial for best reception.
(Note different
model illustrated for
example only)
Vertical mounting
recommended for
Relay TV transmitters.
Horizontal mounting
recommended for
Main TV transmitters.
