Maxview TARGET MXL017/65Q User manual

Installation Instructions
MXL017/65Q & 85Q
UK contact:
Helpline: [phone]
Email: [e-mail]
Web: www.maxview.co.uk
Maxview reserve the right to change specifications without prior notice
9111340 Iss 1
Target, SKY Q™ Variant

1. Product Installation Schematic Layout
Sky Q™Adaptor
Maxview Control Box
Sky Q™Box DVBT-S Receiver
20V
PSU
240V
3 pin
plug
Input from Quad LNB
Sky Q™Adaptor
Please install your Target system in accordance with the Installation Instructions received with the system.
The following instructions are a guide to install the Global Invacom Sky Q™adaptor.
Installing the Global Invacom Sky Q™Adaptor with your Target SKY Q™.
Safety Notice: Please ensure all equipment that you are installing and systems you are installing
have all power turned off.
Typical installation
Ensure the Maxview Control Box is installed before the SKY Q™ Adaptor.

2. Power Supply
You will need a 20v DC regulated power supply to power the Adaptor.
The unit is supplied with a UK mains powered 20v DC PSU.
3. Location
Decide the location to site the Adaptor.
Please ensure you mount the Adaptor correctly and securely using the screw fixings holes. Ensure you can
route the coaxial and power to the Adaptor in your chosen location.
4. Connectivity – Coaxial Quad Inputs
Please reference the installation diagram in point 1.
It is very important that 3 coaxial cables outputs form the
Target system are connected straight to the Adaptor.
It is very important that 1 coaxial cable runs through the Target
Control Box before entering the Adaptor. Failure to do this will
result in the Target system being unable to locate the Satellite correctly.
Connect Coaxial cable to Dish Input 1.
5. Connectivity – SKY Q™Adaptor Outputs
The adaptor has two outputs so you can run a single Sky Q™receiver from just one output or add a
second for another room or add a single tuner Freesat/Sky HD receiver as well.
6. Powering up your system
Once you have fully installed the Adaptor to the Target you are ready to power up the Adaptor and
test your installation.
7. Operation
- Refer to the Target instruction for operation and select Astra 2 Satellite
- Turn on the Adaptor and ensure LED is on
- Turn your Sky Q™Box on
8. Sky Q™Box Set Up
- Enter SKY Q Menu Settings
- Highlight Settings and Enter 0, 0, 1, ‘select’ on the remote’
- Change LNB type from Dish to SCR
Your Sky Q™box should now be ready to use.
Please note that if you do not have a Wi-Fi connection some of your box function may not work.
Please Note. You must change back the LNB when using the Sky Q™box back at home.
COAXIAL OUT:
To Adaptor
COAXIAL IN:
From Target System
Please install your Target system in accordance with the Installation Instructions received with the system.
The following instructions are a guide to install the Global Invacom Sky Q™adaptor.
Installing the Global Invacom Sky Q™Adaptor with your Target SKY Q™.
Safety Notice: Please ensure all equipment that you are installing and systems you are installing
have all power turned off.

Sky Q Contract:
It is the responsibility of the end user to understand the contractual agreement between themselves and
SKY Q™ and any limitations of equipment this may have. In no event shall Maxview be liable for any indirect,
incidental, or consequential damages pertaining to this document.
9. Adaptor Technical Specification
For full up to date technical data please refer to www.globalonvacom.com
Power, Connectivity and Dimension Summary as below:
