Maxview Target Sky QMXL017/85Q Manual

Installation & operating instructions
MXL017/65Q/85Q Target Sky Q™ & Auto Skew
UK contact:
Helpline: [phone]
Email: suppor[email protected]o.uk
Web: www.maxview.co.uk
Maxview reserve the right to change specifications without prior notice
9111330SKYQ Iss 3

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates
Contents:
Introduction 2
Proper use & operation 2
Safety precautions 3
Application example 4
Connections & features 5
Product contents 5
Required tools and equipment 5
Selecting an installation location 6
Positioning Control Box 6
Attaching Antenna Mount Plate 7
and LNB Park Plate
Electrical installation 8
Attaching Antenna Unit to 9
Mount Plate
Installing cables 9
Installing Cable Entry Plate 10
Installing Control Box 10
Introduction:
Please read these instructions fully before using the antenna for the first time. The operation of the antenna has
been designed to be as simple as possible however should you require any technical assistance please contact
Maxview customer service on [phone] or visit www.maxview.co.uk.
Proper use & operation:
The Target is designed to be installed in a motorhome, caravan or horsebox to automatically locate a television
broadcast satellite when the vehicle is stationary. The system comprises of 2 main components.
1. The Antenna which is to be permanently mounted externally to the roof structure of a motorhome/caravan
horsebox. The construction of the roof structure should be suitably robust and have no protruding obstacles
2. The Control Box is designed to be mounted internally in a cupboard. This controls the antenna unit through a
cable connection and is powered by 12v DC only.
Use of the equipment for any other purpose than the one specified is not permitted and will invalidate the
warranty.
All instructions and models are subject to change. In accordance with policy of progressive product, the company
reserve the right to alter specifications.
Copyright© these instructions are the sole property of Maxview Ltd and may not be reproduced.
Please keep these instructions safe for future reference.
Recycle packaging where facilities exist.
Page 2
Connection diagram 11
Attaching Satellite Dish to Unit 12
Finding a satellite 12
Reference 12
Interface details 13
How to operate your system 13
Ignition mode 14
Connecting to a Satellite Receiver 14
Power consumption 14
Software update 15
Fault finding 16
Error modes 16-17
Skew adjustment 18
Guarantee 19
Environmental 19
Specifications 20

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates
Safety precautions:
Read this manual carefully and become familiar with your satellite antenna. Understand its applications, its
limitations and any hazards involved. Failure to follow all instructions listed below may result in electric shock,
fire and/or serious injury. Maxview declines all responsibility in the event of incident or accident if they are due
to a non observation of the installation instructions or the way the product is used.
No modifications are permissible to the Antenna Unit & Control Box.
Installation
• Installation should be carried out by a competent person
• Take care when working at heights keeping work area clean and tidy to avoid trip hazards
• Use creeper boards where necessary to ensure roof construction can support your weight
• Use a recommended adhesive from page 10 to bond the antenna unit to vehicle roof and follow the
manufacturer’s instructions during application
• Do not travel until adhesive has cured noting that curing times vary with weather conditions
• Power tools should be used in accordance with manufacturer’s instructions
• All electrical work should be carried out by a competent person. If in doubt seek advice from a
qualified electrician
• The Control Box is for internal use only and is not waterproof
Operation
• Before starting your journey check that antenna is in the park position
• The maximum speed of vehicle with antenna mounted on roof is 81mph (130km/h)
• Never operate the antenna if someone is in close proximity of the antenna
• Disconnect power to the antenna before installation or adjusting LNB skew angle
• If high winds or electrical storms are anticipated lower antenna to park position
• Maintain adequate ventilation around the Control Box to avoid overheating
• Do not allow children to operate the antenna unit
• Remove Control Box fuse before accessing the roof space around the antenna unit
• Do not operate the Target with snow or ice on the antenna
Servicing
• If in the event that you do experience a problem with the system call Maxview
Customer Service [phone] with your model & serial number to hand
• Any inspection or repair must be carried out by Maxview or an appointed representative of the manufacturer
• No regular maintenance required on the system
• Do not remove cover on Antenna or Control Box
• Do not use solvent or abrasive cleaning agents on the system
• Use a soft damp cloth to clean the Control Box
• Use a suitable mild detergent to clean the Antenna Unit
• Do not pressure wash the Antenna Unit
• Check the Antenna Unit fixings for mechanical integrity at least once a year
Page 3

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates
Page 4
A. Antenna
The Antenna is mounted to the roof. It uses electric motors to scan for satellite signals.
The system has 3 cable connections; 1 for controlling the motors and 2 satellite signal cables from the twin LNB.
B. Control Box
The Control Box requires wired connections for power, antenna control and satellite signal.
It can be mounted discretely in a cupboard and can be fixed vertically and horizontally.
You need to install the Splitter for SKY Q™ - See page 11
Application example:

A
B

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates Page 5
Connections and features:
Control Box:
1. Fuse 4A
2. Power Switch
3. Power LED

1 2
3
4
6
5

7 8 9 11
10
Product contents:
> Antenna Unit / Control Box
> 65/85cm Antenna (separate carton)
> Accessory Pack
> LNB Park Plate x 1
> Control Box bracket x 2
> No.10 Screws x 6
> No.6 Screws x 4
> Cable Clips x 6
x 12 for quad
> M6 Button Head Screw x 4
> M6 Locking Nut x 4
> 6mm Plastic Washer x 4
> Cable Entry Plate x1
Required tools and equipment (not supplied):
> 32mm hole saw
> 2.5mm twist drill
> Power Drill
> No.2 Phillips screwdriver
> Weather Resistant Elastic Adhesive* and Applicator gun
> Surface Cleaner
> 10mm spanner
> Hexagonal socket key 4mm
> Deburrer/Round File/Emery paper
> Conduit (recommend method for securing cables)
> Automotive 2.5mm² cable
> Electrical connector block
> Flylead (for connection to satellite receiver)
*Maxview recommends the following adhesives:
> Sikaflex®-512 Caravan
> Geocel® Geobond HM
> Sikaflex®-252
Reference page 13 for
interface information
4. Sync Button
5. Status LNB
6. USB update port
7. Receiver
8. LNB in
9. Antenna Connectors
10. Installation Button
11. Power Input

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updatesPage 6
Key dimensions (cm) and weights. Target/Target Skew
65cm: System weight 10kg
A: 17
B: 100
C: 67
D: 65/66
E: 96
F: ø43*
85cm: System weight 11kg
A: 17
B: 117
C: 85
D: 87/88
E: 113
F: ø43*
E
A
D
B C
H
G
F
I
G: 52/53
H: 15
I: 110
G: 64/65
H: 14
I: 125
*Mounting plate
Direction of travel
(front of vehicle)
Selecting an installation location:
Positioning the Antenna Unit
> Check for obstructions such as roof lights and vents.
> Check for electrical cables beneath screw fixing points.
> Check Antenna Unit cables will reach Control Box
(Maxview can supply extended cables).
> Do not allow the dish to overhang the edge of the vehicle
> Clearance around antenna system when in use is shown with reference I
Positioning Control Box:
Site the Control Box in a convenient location where:
> User can control the unit with the control box
> Front and rear connections are accessible
> Cables can be routed and concealed neatly
> There is an electrical supply of 12V dc permanent and ignition
> There is adequate ventilation
> The Control Box is not encased with metal
> Material construction and thickness is suitable for fixings

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates
Attaching Antenna Mount Plate & LNB Park Plate:
1. Remove Antenna Unit from wooden transit packaging
2. Remove mounting plate from Antenna Unit by removing 6 x M6 nuts using 10mm spanner
3. Clean roof, Mounting Plate and LNB Park Plate in accordance with adhesive manufacturer’s guidelines
4. Mark a centre line for the antenna making sure dish will not overhang vehicle
5. Align notches on plate with centre line
6. Mark the position of 6 screw fixing holes
7. Mark position of LNB Park Plate
8. Drill 6 x 2.5mm pilot holes into the roof
Note:
• Follow manufacturer’s instructions when applying adhesive. Do not travel until adhesive has
cured noting that curing times vary with weather conditions
• Take care when working at heights. Always follow ladder manufacturer’s safety advice
• Use creeper boards where necessary to ensure roof construction can support your weight
• Power tools should be used in accordance with manufacturer’s instructions
230mm 65cm (MXL017/65 all variants)
350mm 85cm (MXL017/85 all variants)
Direction of travel
Central Line
Antenna Mount Plate
LNB Park
Plate
Page 7
9. Apply adhesive to entire surface of Antenna
Mounting Plate and LNB Park Plate and firmly
place them into position
10. Place a small amount of adhesive into each hole
before screwing plate to roof
11. Wipe off excess adhesive with a cloth
6 x No. 10
screws

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates
Caravans
Power can be taken directly from the leisure battery on the caravan. The ignition cable should be connected to
the ignition key circuit which can be traced using the charts below. The caravan will either be fitted with the
13 Pin Euro Connector or have two 7/8 Pin connectors.
Caution: All electrical work should be carried out by a competent person.
If in doubt seek advice from a qualified electrician.
Electrical installation:
Whilst the adhesive is curing prepare the electrical connections for the Control Box. The Control Box requires
a permanent 12V supply and a secondary 12V supply that provides power when the engine of the vehicle is
running. Note: the brake light circuit is not suitable.
It is recommended to create a new circuit direct to the battery using a minimum cable cross sectional area of
2.5mm2 and an inline fuse of 5A. Do not connect to existing circuits that supply high power devices such as
water pumps, air conditioning units or sources of interference such as electric igniters for gas stoves. Route
cables carefully avoiding areas of excessive heat such exhaust systems and any moving parts in the engine
compartment or drive shafts.
Power Cable colours:
Black Negative Earth
Green Ignition (+12V)
Red +12V
Join Power Cable to new circuit using a
robust connection method such as...
• Crimp connectors
• Screw terminal connector block
• Snap fit automotive tap connectors




13 Pin Euro Connector
1
2
3
4
5
6
7
8
9
10
11
12
13
12S 7 Pin Connector
1
2
3
4
5
6
7
Left Hand Indicator
Rear fog light(s)
Earth for contacts 1 to 8
Right Hand Indicator
Right Hand Side lights, marker lights & number plate light.
Brake lights
Left Hand Side lights, marker lights & number plate light.
Reversing light(s)
Positive direct from battery (Power)
Positive ignition key on (Fridge)
Earth return for contact 10
Signalling connection to trailer
Earth return for contact 9
Reversing light(s)
Positive ignition key on (Battery Charging)
Earth
Positive direct from battery (Power)
Reverse Sensor (Optional)
Positive ignition key on (Fridge)
Earth return for contact 6
Yellow
Blue
White
Green
Brown
Red
Black
Pink
Orange
Grey
White/Black
White/Blue
White/Red
Yellow
Blue
White
Green
Brown
Red
Black
Page 8
Terminal No. Function 13 core wire colour

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates


Page 9
Attach antenna unit to mounting plate:
Carefully lower the Antenna Unit onto the Mounting Plate and re-attach the M6 Nuts and Washers that
were previously removed.
Caution:
Replace Nylon locking nuts if they have been removed more than twice. The locking action of the Nylon
becomes less effective if repeatedly assembled and disassembled.
Installing cables:
1. Check there are no hidden cables in the roof structure and that the hole location is clear of obstructions both
internally and externally.
2. Turn over for Cable Entry Cover installation instructions
Application example:
Note: To prevent trip hazards it is recommended that cables are concealed in PVCu conduit (not supplied)
where access is required to the roof of the vehicle.
Use extra Cable Entry Plate
to route 2nd Sat feed to a
different location.
Available to order from
Maxview MXL018
Direction of travel
(front of vehicle)
Note: LNB image shows
different model.
Note: LNB image
shows different model.
For quad variants you
may need a 2nd cable
entry plate.

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates





Page 10
Installing Cable Entry Cover
1. Plan your installation carefully
2. Drill a 32mmø hole in roof
3. Prepare surface for adhesion
4. Apply sealant as shown in A,B,C
(we recommend Sikaflex-512 Caravan)*
5. Position top hat
6. Position cable entry cover
7. Wipe excess sealant with a dry cloth
Applying sealant example:
Installing Control Box
Having previously chosen a suitable location
1. Clip the mounting brackets onto the Control Box.
2. Place Control Box on the horizontal or vertical surface and mark the 4 holes.
3. Depending on material drill a pilot hole or use a bradawl.
4. Attach cables to Control Box refer to page 11 for details.
5. Screw Control Box into position using 4 x No. 6 Screws.
Mounting positions:
Position the Control Box in one of the 4 ways shown left.
Make sure that the front is easily accessible.
Fitting the Control Box Brackets:
The brackets snap fit to the Control Box casing
!!
!= Generously apply
wet seal adhesive
!
Vehicle roof
Top hat
Hole location
tabs
Cable
32mm ø
A B
C
Direction of travel
(front of vehicle)

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates Page 11
+
Sky Q™ Receiver
Not required Ignition
5A Fuse
Key:
A: Satellite Signal Cable
B: Satellite Signal Cable
C: Antenna Control Cable
D: Flylead from Splitter to LNB on Control Box
E: Flylead from splitter to SAT IN 2 SKY Q™ Receiver
Connectivity:
The system is for use only with a Sky Q™ Receiver only.
It is important that the 2 Coaxial cables are connected correctly as per the diagram
to ensure function of the system.
The Coaxial Cables have been labelled V (Vertical Signal) and H (Horizontal Signal).
Please ensure that the cable marked H is connected to the splitter input labelled IN.
The 2 x Fly Leads to be connected to the splitter outputs labelled OUT.
1 output from the splitter connects to the Control Box LNB Input
1 output from the splitter connects to the Sky™ Receiver SAT IN 2 Input
Coaxial cable labelled V connects directly to the SKY™ SAT IN 1 input
Sky Q™ Box Set Up:
The Sky™ Box should already be set to Wideband LNB Type as default.
If you find the Target locks onto the Satellite and the SKY™ Receiver has no signal we
suggest you check connections and ensure the LNB type is on Wideband NOT SCR.
S C
Connection diagram:
TV
A
C
SAT 1 (Cable marked V)
E
D
SAT 2 (Cable marked H) B
SAT 2 IN
Splitter

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updatesPage 12
Finding a satellite:
Before starting check there is a clear line of sight to the southern sky. All television broadcasting satellites have
a geostationary orbit which means their location is fixed above the earth’s equator. Satellites also have a limited
range of transmission so use the Zone maps included in the appendix to check your location is suitable for
reception. If your location is near the limit of reception it is recommended to adjust the skew angle of the LNB
to maximise signal quality and strength (see page 18 for details)

Reference
Please Note: The system is for receiving signal using the Wide Band LNB and is specifically designed for use
with SKY Q™ Receivers only.
Therefore LED 2 is the only satellite that is programmed to Astra 2 for SKY Q™ connection.
LED 1, 3, 4 & 5 have no function.

Attach Satellite Dish to Antenna Unit
1. Ensure Antenna Unit is free from obstacles.
2. Press installation button on reverse of Control Box to elevate
antenna. Once elevated turn off power to Control Box and
remove fuse.
3. Fix Satellite Dish to Antenna Arm using M6 Button
Head Screws, M6 Nuts and 6mm Plastic Washers.
The 65cm and 85cm satellite dishes have different fixing hole
positions. Therefore 4 of the holes will be unused.
4. Remove all tools, packaging and obstructions from roof.
5. Replace fuse and turn power switch on. Antenna will
automatically retract into the park position.
Caution:
Replace Nylon locking nuts if they have been removed more
than twice. The locking action of the Nylon becomes less
effective if repeatedly assembled and disassembled.
Testing Antenna Unit:
Position the vehicle so that there is an unobstructed view of the southern sky. Connect a TV and Satellite Receiver
and follow instructions on page 12 to search for a satellite.
Caution:
Before driving vehicle on a highway ensure adhesive has cured. Check all fasteners are secure.

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates Page 13
Interface details
A. Select satellite
B. LED shows you which satellite is selected
C. SEARCH - Press and release
PARK - Press and hold for 3 seconds
D. Satellite found LED (green FOUND)
A B DC
How to operate your system
1. Turn on
Switch the power on. The LED flashes green on the last satellite you selected.
Flashes greenPower on
2. To change satellite*
*If required. Press SAT to scroll through satellite selection. Eg. New selected SAT LED will flash green.
Press Flashes green
3. Search
SEARCH - Press and release to begin. Both the OK LED and LED selected will flash during search.
SearchFlashes green Flashes green

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates
4. Satellite Found
Once the satellite has been found the OK LED and the satellite selected will show solid green.
Solid green Solid green
5. Park System
PARK - Press and hold for 3 seconds. LED’s 1 to 5 flash green to indicate system is collapsing.
Once fully collapsed, control panel can be powered off.
Flashes green Park
Page 14
Ignition mode:
The ignition mode is a safety feature that automatically lowers the antenna and prevents accidental operation
whilst travelling. When the Target has detected an active ignition circuit in the vehicle the antenna is
automatically lowered.
Note: The Control Box must be wired to a 12v DC electrical circuit that is live when the vehicle’s ignition is on.
This not only provides a safety benefit but also refreshes the Control Box memory which allows the Target to
perform correctly.
Connecting to a Satellite Receiver:
The satellite cables must connect to the Control Box. The Control Box will then output this signal through the
F connector marked ‘RECEIVER’. In order for the satellite signal to pass through the Control Box the power must
be on.
Power consumption:
The Target has been designed to minimise power consumption.
When the Target is not used for long periods of time it is recommended to switch off the Control Box.
The Ignition Mode will still activate even with the Control Box power switch in the off position.
When power is restored to the system the antenna will automatically lower into the park position.

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates
Software update:
To keep your Target up to date with the latest satellites Maxview has
incorporated a USB port on the front of the Control Box. The Target has
the ability to update its satellite data and its operational software from
a simple USB flash memory stick.
Please visit www.maxview.co.uk - search: Target - Downloads
for latest software and a guide to installation.
Preparing a USB Flash Memory Stick:
1. Use a blank USB flash memory stick formatted to FAT or FAT32
2. Format USB stick:
3. In Windows XP, Vista or Windows 7
4. Insert USB key in PC, find device in ‘My Computer’, right click and
5. Select ‘Format...’
6. Select options as shown below press start.
Update Control Box software:
1. Obtain a update-xxxx.hex file from Maxview and copy onto a
formatted USB flash memory stick.
2. Turn on Control Box.
3. Press and hold the SYNC button on the front of the Control Box for 7 seconds until SYNC LED illuminates RED.
4. Insert the USB flash memory stick. The SYNC LED will flash GREEN whilst data is been transferred.
5. When the SYNC LED goes out turn off the Control Box power and remove the USB flash memory stick.
6. Turn power on, SYNC LED will flash RED and GREEN whilst data is written to Control Box memory.
7. When SYNC LED goes out update is complete.
Note: If status LED does not flash RED and GREEN when power is restored after update then the software has
not been loaded successfully. Check the read me file created by the Control Box on the USB flash memory stick
for details. An update will not be successful if the file to be loaded is the same as the one already stored in the
Control Box. If you experience difficulties please contact Maxview Customer Service.

Page 15

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates
Problem
No power
Fuse blows
repeatedly
USB update failed
Antenna stuck
in elevated position
Actions
Check Fuse
Check Power cable connection
Leisure battery voltage is low
Check Fuse rating is 4A
Check antenna unit is not obstructed
Contact Maxview Customer Service
Check file was added to a blank FAT formatted USB memory stick
After update check text file added to USB memory stick
Contact Maxview Customer Service
DO NOT TRAVEL UNITIL ANTENNA UNIT IS REMOVED
Contact Maxview Customer Service
Antenna Control Box
Fault finding:
Error modes:
A.No SAT found. If searching and no satellite found the ‘flashing green’ LED will go solid RED
After 5 seconds the dish will then move to park position
Page 16
Solid red
B.No SAT found - system parked. Once parked the Search LED stays solid RED and SAT LED searched continues to
flash green
Flashes green Solid red

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates Page 17
All flashes green
C. Ignition mode parking. When the antenna is parking using the Ignition (green wire) all sat LEDs flash green
D. Ignition mode parked. When system parked during ignition mode all the SAT LED’s stop flashing green
and ALL 5 LED’s go solid RED.
During Ignition mode ALL control buttons have no function (locked).
Once ‘Ignition off’ last satellite found LED start to flash and ready to search (keys active again).
All solid red
E. Azimuth Error. If rotation motor stops the above LED sequence will occur, please contact Customer Services.
F. Elevation Error. If elevation motor stops the above LED sequence will occur, please contact Customer Services.
Solid orange Flashes red
Solid orange Flashes red
Solid green

Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates
Page 18
Skew Adjustment:
Skew adjustment requires rotation of the LNB in order to improve signal quality at the edge of a satellite
footprint. If you have purchased a manual skew product variant, this LNB rotation adjustment must be
completed by hand* using the appropriate skew angle map.
*Caution: Follow general safety advice on page 3 when carrying out manual skew adjustment.
If you have purchased an automatic skew variant the above is not applicable. Your system will use GPS to
automatically rotate the LNB to the correct skew for your given location, therefore maximising satellite
reception. This process is completely automatic when the search command
is started. It requires no further input from the customer.
With Automatic Skew, you can rest assured that your
system has maximised the signal quality for your
location.
If you have any further questions regarding
manual or automatic skew adjustment,
please contact Maxview Customer
Services on [phone] or
visit www.maxview.co.uk.

Astra 2 - 28.2°
Page 18
Environment:
Information for users on collection and disposal of old electrical equipment and used batteries
These symbols on the products, packaging, and/or accompanying documents mean that used
electrical and electronic products and batteries should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take them
to applicable collection points, in accordance with your national legislation and the Directives
2002/96/EC and 2006/66/EC.



Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates Page 19
Guarantee:
All Maxview products come with a guarantee whether you have purchased your product directly from Maxview
or one of our authorised stockists.
Your new Target system is thoroughly inspected and tested before leaving the factory and is covered by our 3
year guarantee.
How do I claim on my guarantee?
In the unlikely event that you have an issue with your product please contact our Customer Services Team on
[phone] or email [e-mail]. You will need to retain your proof of purchase as we will
ask for this along with the model and serial number of your product.
In no event shall Maxview be liable for any indirect, incidental or consequential damages from the sale or use
of the product. This disclaimer applies both during and after terms of the guarantee. This does not affect your
statutory rights.
Terms and Conditions of the Guarantee
a) Your guarantee starts from the date you purchased your item. Your guarantee will be valid from date of
manufacture if you are unable to provide a proof of purchase.
b) A guarantee authorisation must be obtained from Maxview prior to work commencing.
c) Maxview is responsible for the cost of a replacement part if the original part is determined to be defective
under the terms of the guarantee.
d) Any replacement parts required will be supplied, by return, on receipt of the faulty part.
e) Any work requiring replacement parts will only be sanctioned on receipt of proof of the broken part.
The customer is responsible for the cost of replacement parts after the guarantee period has expired.
f) Our guarantee is “Back To Base.” No travelling costs will be paid.
g) Parts that suffer breakdown and/or failure due to flooding/water ingress or abrasive cleaning caused by
solutions and/or Pressure Washers are not covered under our guarantee.
h) Our guarantee does not cover installation or external wiring
i) Our guarantee does not apply where:
- The product has been abused, misused, improperly installed or improperly maintained
- Repairs have been made or attempted by a third party other than Maxview.
- Repairs are required due to normal wear and tear
- Modifications have been made to the product
- Circumstances beyond the control of Maxview that have caused the product to no longer operate correctly
- Customer cannot provide proof of purchase
- The ignition cable is not installed
- The antenna unit or control box has been opened
Full terms and conditions of our guarantee can be found on our website www.maxview.co.uk

Operating:
Average search time 30-60 seconds typical
Future proof with free software updates via a USB stick - see page 15
Low stream line profile, only 17cm in park position
1 pre-programmed satellite, Astra 2
Power:
Powering: 12V operation
Power Consumption: Maximum 2A consumption during search
Standby Current: 0.2A
Fuse Type: 4A Mini Blade Automotive (In Control Box)
System:
Elevation Range: 10º to 70º
Azimuth Range: 380º
Skew Angle: ±45º (Manual or Automatic, dependant on variant)
Operating Temp: -15º to 40º C
Safety System: Automatic lowering ignition
Cable Type: CAI approved 100 coaxial cable
UV Protection: All external plastic parts are UV stabilised
Testing: Fully weatherproof and watertight construction
System has passed extensive water ingress test
LNB:
Type: High Quality 10.41GHz Wideband LNB
Output: Twin H & V
Typical Gain: 65cm - 36dB 85cm - 38.1dB
Frequency Range: 10.7-12.75GHz
Arm Cable: RG179
Antenna:
Material: Aluminium
Reflector Thickness: 1mm
Finish: Powder coated with U.V. inhibited polyester-based
Outside Dims: 65cm dish: 67.0 x 71.5 cm 85cm dish: 85.0 x 90.5 cm
Reflecting Dims: 65cm dish: 63.0 x 67.5 cm 85cm dish: 81.5 x 87 cm
Mounting:
Plate Material: Aluminium
Fixing Method: Recommended adhesive (Sikaflex, Geocel or equivalent)
Fixing Studs: 6 x M5 studs for system removal
Cable Entry: Coaxial cable joining cover under antenna system
Specifications:
CE Declaration of Conformity
The Target Satellite Antenna has been designed, constructed and marketed in compliance with
safety requirements of EEC Directive 2006/95/EEC (Low voltage) and requirements of EMC Directive
2004/108/EEC.
Sky Q™Contract:
It is the responsibility of the end user to understand the contractual agreement between themselves and
SKY Q™ and any limitations of equipment this may have. In no event shall Maxview be liable for any indirect,
incidental, or consequential damages pertaining to this document.
