MaxWest MX-100 User manual

Page 1
GSM MOBILE PHONE
User Manual
Model Name：MX-100
Trade name：MAXWEST
FCC ID:ONGMX100

Page 2
Thank you for purchasing this mobile. For the best
performance, we recommend that you read the manual
carefully.
CALL CENTER .........................................................................3
MULTIMEDIA ...........................................................................4
CONTACTS .............................................................................7
USER PROFILES ......................................................................8
MESSAGES...........................................................................10
ORGANIZER..........................................................................13
SETTINGS ............................................................................16
FUN &GAMES ......................................................................20
SERVICES ............................................................................20

Page 3
Call center
You can view your recent call situation.
[Dialed calls]：Show all dialed calls list, select a view after
a dialed calls occurred in the date and time, phone number
and times.
[Received calls]: Show all answered the phone list, select a
view after a phone that has the date and time of occurrence,
telephone number, frequency,
[Missed calls]: Show all missed calls list, select a view after
a missed call occurred the date and time, phone number and
times.
[Rejected calls] Show all refused to answer the phone list,
select a view after a missed call occurred the date and time,
phone number and times.
Press the OK softkey to enter the options menu can be more
than the number of call records in the following:

Page 4
◆Details: View the current record date, time, type.
◆Call: Call the current number.
◆Save: You can save the current record to the phone or
SIM card
◆Write message: send the current record of SMS or MMS
◆Add to contacts: the number of the record the name
added to the existing record which
◆Add to blacklist: the current record to reject a call which
◆Delete: Delete the currently selected record
◆Delete all: Delete all call records
[Delete all]: Delete all call records
[Call times]: Last time zero starting time for last call
statistics, a total of dialed calls, received calls, all calls total,
all the time can also be zero.
[GPRS counter]: Display the SIM card GPRS data.
Multimedia
[Camera] The phone supports photo, so you can capture
your favorite scenes anywhere. Photos will be saved in

Page 5
the phone comes with a file system, photographs as JPG
format, you can phone provides photographs sent to a
computer via USB connection to view, can also be set
Image for the standby
Note：This function can work without driver under Windows XP
by directly connecting your mobile to the computer
[DV] Set the parameter of DV and then use the function
[Image] View the image which in phone memory or T-card
[Audio]
Play audio files, MP3 songs; to play audio files, MP3
songs, press the Up and Down keys to adjust the volume,
press the left and right keys to select the present, the next
song, press the OK button for the on / off Music
[Music list]: Into playlist interface. Can be added to the play
list editing and other operations
[Add]: Add songs or music playlist bookmark
[Set as ringtone]: The song is set to call or alarm tone
[Repeat]: Choose one/all repeat
[Shuffle]: Choose shuffle to play the music

Page 6
[Settings]:
◆ Equalizer: Choose a variety of equalizer effects
◆ BT stereo output: Set the BT output
◆ BT stereo headset: Set the BT headset
[Open review]: Open the function of review
[Video] Use the function of video player
[FM radio]
[Auto search and save]: Channel auto search and save
[Channel list]: View channel list
[Save]: Save the channel to the channel list
[Manual search]: Manually enter the channel and find
[Open speaker] Choose whether to open the microphone
[background play] Choose whether to open the Background
Play
[Record]: Record the FM
[Timing record]: Set the time to record
[Record file list] The list of FM record file
[Storage] Set the location of storage
[Help]: FM Help

Page 7
[Recorder]
[Start recording]: Start recording
[Record file list]: The memory card inside the recording file
list
[Storage]: Set the locate of storage
[File format]: Set the format of record file
Contacts
You have 2 phonebooks in this mobile phone: SIM card and
the mobile. The mobile can store 300 phone numbers and
the SIM card’s capacity depends on its type.
I In standby mode, enter a number, press the call key pieces
to make a call, press the OK key to save
◆ If ‘To SIM 1/2’ is selected, users can edit name and
number.
◆ If ‘To phone’ is selected, the user can edit the name,
mobile number, home number, e-mail address, image,
ringtone, caller groups

Page 8
Into the phone book list, the list on the left displays a small
icon indicates that the record exists SIM card or mobile
phone, the right is the record of the name and number
information.
Standby mode, press the right soft key to enter into the
address book or from the menu
Into the address book, do the following:
[New]: Create a record to phone or SIM
[Delete multiple]: Choose one or more records to delete
[Import/Export]: Copy/Import/Export records to T-Card or
phone
[Others]
[Memory status]: Query the current SIM card and mobile
phone storage capacity
User profiles
[Add]: Add the new profile
[Delete]: Delete the profile
[Settings]: set the selected mode

Page 9
[Rename]: Rename the profile
[Ring settings]
SIM call ring: set the SIM card of the ringing tone
SIM message ring: set the SIM card message tone
[Adjust volume]
Caller ringtone: set the ringing tone volume
Message ringtone: ring volume settings information
Call volume: Set the volume of calls
Alarm & calendar volume; set the alarm tone
Power ringtone: the voice of setting switch
[Ring type]
◆ Call alert: a ring, vibration, quiet, vibration and ringing
and ringing after the first five vibration incoming call
alert for you to choose
◆ Message alert: a ring, vibration, mute, ringing and
message alert vibration four ways for you to choose
◆ Alarm & calendar remind: a ring, vibration, mute,
ringing and message alert vibration four ways for you to
choose

Page 10
[Other alert rings]
◆ Key tone: set the key tone of voice
◆ Battery low alert: Choose open the alert of battery low
◆ Power ringtone: Set the sound is turned Off
◆ Dial tone: Activate dial tone
Messages
The Messaging function is a network service. Sending and
receiving Text can only be used if the service is proposed by
your network operator.
You can send ordinary Text messages, enhanced Text
messages (Text messages containing pictures, ring tones
and animation as attachments, EMS for short). The SMS is
sent to the Text messages center in the network firstly, and
then to the target user. If the receiver’s mobile is power off or
cannot receive messages, the network will store the message
temporarily and the store duration is determined by the user
configuration and the service provider. I
The message will be directly stored in the SIM card if

Page 11
the capacity is not full. A blinking icon at the head row of the
main screen will be displayed if the capacity is full.
Messages unread
If the Text message has been sent to the receiver, a
beep will sound. (If the tone for Text messages and message
report are activated).
[Write message]
[New SMS]
Send: Enter the appropriate number of the recipient or from
the phonebook add
Insert template: to the content of the message currently
being edited into the common language
Add contact info: Insert the contact person
Add phiz: emoticons into the meaning of the
representative
Timing send: Send the message by time
Save as draft: will save the information to Drafts
Exit: Exit message
[New MMS]

Page 12
◆ Send: send MMS to the receiver
Preview: Preview edited MMS content.:
◆ Add new recipients: Enter the recipient's phone
number or e-mail or group
◆ Add: add video/audio/picture to MMS
◆ Set slide time(1s—600s): set the slide time of
MMS
Delete: Delete the message
Save as draft: save as draft
Text layout: move the text above or down
[Inbox]：
◆ Reply: reply to SMS to each other.
◆ Delete: Delete short message
◆ Call: choose a voice call or a call to the sender IP calls
◆ Mark: single marker or markers in whole or in text
messages stored in SIM1/SIM2, mark or unmark after
delete records
◆ Sort: In accordance with time / contact / theme /
message type sort

Page 13
◆ Add sender to: Add the sender to contact
◆ Delete repeated number: choose to delete the same
number of records.
◆ Add to blacklist: Add the sender to blacklist
[Outbox]:Reading or processing stored in the Outbox of the
SIM card message.
[Drafts]：Reading or processing stored in the Drafts of the SIM
card message
[Sentbox]: read and process the mail stored in the SIM card
has been sent information
[Templates]: Use the function of templates
[Voice mail server]: use the function of voice mail server
[Broadcast message]: Use the function of broadcast
message
Organizer
[Alarm]This machine has three alarm times available for
your settings. Access any time, you can set its status to on /
off, ring time, repeat mode, ring tones, alarm clock name, etc

Page 14
[My files]
[MemoryCard]: SD card needs to support T card
[New folder]: Create a new folder.
[Delete]; delete the specified folder.
[Details] View the folder or file for more information
[Edit] the selected folder or rename the file or copy
[Search] Enter the folder name to find out.
[Sort] By the way you choose to sort the files.
[Mark] Select Mark / Unmark single / all
[More]
◆ Memory Card capacity: View the memory card
capacity
◆ Format MemoryCard: Format memory card
[Calculator] Can be continuously mixed arithmetic, the
operation is simple, practical, convenient
[Calendar]
Press the left soft key to access the calendar display
interface, the first line shows the year, month, and the third
line shows the week, the middle section shows the specific

Page 15
date of a month, the last line shows the right and left soft key
in the message. Interface in the calendar, press the arrow
keys on the date forward one week, press the arrow keys to
move one week after the date, press the left arrow key date
forward one day, press the right arrow keys to move the day
after the date, select the date to a dark display
[Add new schedule]: a new agenda
[View schedule]: View the schedule one day save
[All schedule]: View the schedule all day
[Clear tasks today]: Clear the calendar day
[Clear all]: Empty all the schedules
[Go to date]: Enter the dates you want to find, the cursor will
jump to that date quickly
[Weekly]: the week / month display calendar.
[Exit]: Exit menu audio player
[World clock] View the time of countries
[Ebook] Use the function of ebook
[Bluetooth]
[Open Bluetooth]: Choose to activate the Bluetooth

Page 16
[Bluetooth visibility] ;Bluetooth visibility set
[Paired device]; Search and paired Bluetooth devices
[Device name]; Local Bluetooth name
[Bluetooth file storage]; Storage location
[Help]：Help Documentation
[Torch] Choose to open the torch
[STK] Full name of the SIM card application toolkit (SIM
Application Toolkit). It can provide you with flexible
information functions, such as stock information, traffic
information, weather and so on. STK functionality provided
by the network operator decision. The business needs the
support of SIM cards and network
Settings
【Call settings】
[Dual-SIM]
[Standby mode]: Dual SIM standby or standby only SIM1 or
SIM2 only
[Reply by original SIM]: Reply the call/SMS/MMS by

Page 17
original SIM
[Set SIM name] SIM1 and SIM2 in the card slot to set the
display name
[Call divert]: transfer a call, respectively SIM1/SIM2
◆ Call forwarding unconditional: Set a forwarding
number, for forwarding all calls are
◆ Call forwarding on busy: set the forwarding number,
transfer calls when in busy
◆ Call forwarding on no reply: Set a forwarding
number, in case of no response transfer
◆ Diver if unreachable: to set the forwarding number
in the phone unable to connect the case of transfer
◆ Cancel all diverts: cancel all of the transfer
[Call barring]respectively SIM1/SIM2 call for restrictions
[Call waiting]open call waiting, respectively SIM1/SIM2
[Hide ID]respectively SIM1/SIM to hide the machine when
the power numbers.
* SIM card, operators need to support
[Others]

Page 18
[IP prefix] Set the IP number
[Call time minute remind] Select the open or closed during
a voice call has prompted every minutes
[Auto redial] Select whether to open automatically redial
function
[Reply SMS after connected] Choose reply SMS after reject
calling
[Auto record voice call] Set auto record
【Phone settings】
[Date & time]
Set time: set the phone to display the time
Set date: set the phone to display the date
Time format: Set the display time format
Date display type:Set the date display format
[Language settings] Select phone display language..
[Shortcut settings] Set the shortcut
[Auto power on/off] Set the time and frequency of
Automatic Turning
[Restore factory settings] restore the factory settings

Page 19
【Display】
[Wallpaper settings]Set wallpaper
[Idle display settings] Set the display status in idle
[Contrast] adjust the screen's backlight brightness
[Keypad backlight time] Set the backlight time key
[Auto keypad lock] Set the auto keypad lock
【Security】
[PIN] Select open or modify the phone's PIN code
[Modify PIN2] PIN2 choose to modify the phone code
[Phone locked]: Set the phone locked
[Modify the cellphone password]: Modify the password of
phone
[Privacy]set access to enter the password to view
functionality. (Including: call log / messages / camera /
address book / document management / e-book /
calendar schedule / U disk)
[Lock screen by end-key]press the end key to select
whether the off-screen function
[Guardlock] Use the function of Guardlock

Page 20
[Fixed dialing] Set the fixed dialing function
[Blacklist] Set the blacklist
【Connections】
[New connection] Create a new Internet account
[Add from list] from the system built-in Internet account to
add a new account
[Search] from the current logged on to Internet search to the
card account information, which added to the list after the
selected
Fun & Games
Provide an interesting game
Services
Use the function of internet
