MAYHEM STRENGTH HAVOO Series User manual

Diverging Lat Pulldown
Selectorized
ASSEMBLY INSTRUCTIONS
1 Diverging Lat Pulldown

2 Diverging Lat Pulldown
Please take the time to carefully read the instruction manual before starting the
process of assembling your machine. If you have any inquiries or complications,
please call us at 662-GYM-BROS, or email us at [email protected].
Ensure to tighten all nuts and bolts, lubricate any sliding parts, bearings, and moving
mechanisms. We also suggest applying Loctite or any kind of thread locking adhesive
to anything that does not thread into a Teflon nut. It is also important to ensure that
every movement arm is properly aligned prior to frequent use, and that the machine
that you are assembling is fully functional.
Tools Required for Installation:
Rubber Mallet
Level
Ratchet and Socket Set
Snap Ring Pliers
Adjustable Wrench
2 People Required

3 Diverging Lat Pulldown
PARTS/HARDWARE LIST
Part Number
Part Description
Quantity
1
Balance Weight Frame
1
2
Hexagon Socket Head Cap Screws M10x20
6
3
Universal Connecting Rack
1
4
Hexagon Socket Button Head Screws M10x20
8
5
Side Frame
1
6
Foot Pad
2
7
Linkage
1
8
Linkage Shaft
1
9
Leg Pressing Shaft
1
10
Leg Pressing Frame
1
11
Inner Hexagon Countersunk Head Screws M8x20
8
12
Seat Rocker Arm Cover
8
13
Seat Rocker Arm
4
14
Coil Spring
2
15
Seat
1
16
Nut Cap
2
17
Hexagon Socket Button Head Screws M10x15
8
18
Flat Pad
2
19
Force Arm
2
20
Handlebar
2

Part Number
Part Description
Quantity
21
Universal Flat Pad
6
22
Pull Bar
2
23
Wire Rope
1
4 Diverging Lat Pulldown
PARTS/HARDWARE LIST Continued

5 Diverging Lat Pulldown
Frame Assembly

6 Diverging Lat Pulldown
Cushion Installation

7 Diverging Lat Pulldown
Force Arm Installation

8 Diverging Lat Pulldown
Cable Installation

9 Diverging Lat Pulldown
Cover Installation

10 Diverging Lat Pulldown
