MAYHEM STRENGTH Lateral Rear Delt Raise Combo User manual

Lateral Rear Delt Raise Combo
1
Lateral Rear Delt Raise Combo
ASSEMBLY INSTRUCTIONS

Lateral Rear Delt Raise Combo2
Please take the time to carefully read the instruction manual before starting the
process of assembling your machine. If you have any inquiries or complications,
please call us at 662-GYM-BROS, or email us at [email protected].
Ensure to tighten all nuts and bolts, lubricate any sliding parts, bearings, and moving
mechanisms. We also suggest applying Loctite or any kind of thread locking adhesive
to anything that does not thread into a Teflon nut. It is also important to ensure that
every movement arm is properly aligned prior to frequent use, and that the machine
that you are assembling is fully functional.
Tools Required for Installation:
Rubber Mallet
Level
Ratchet and Socket Set
Snap Ring Pliers
Adjustable Wrench
2 People Required

Part Number
Part Description
Quantity
1
Support Upright
1
2
Cross Assembly
1
3
Cross Assembly
1
4
Arm Assembly (1)
1
5
Arm Assembly (2)
4
6
Foot Plate
1
7
Weight Holder
5
8
Hexagon Head Bolts M12x80
2
9
Hexagon Head Bolts M12x125
2
10
Hexagon Head Bolts M10x70
2
11
Hexagon Head Bolts M10x35
2
12
Hexagon Socket Countersunk Head Screws M8x16
3
13
Hexagon Socket Button Head Screws M10x25
11
14
Hexagon Head Bolts M12x75
10
15
Plain Washers
28
16
Spring Lock Washers
26
17
Hexagon Nuts M12
14
18
Bearing
8
19
Bearing Washer
11
20
Plain Washers
4
21
Upper Pad Assembly
1
22
Lower Pad Assembly
1
Lateral Rear Delt Raise Combo3
PARTS/HARDWARE LIST

Lateral Rear Delt Raise Combo4
Frame Assembly

Lateral Rear Delt Raise Combo5
Foot Plate and Force Arm Installation

Lateral Rear Delt Raise Combo
6
Cushion Installation

Lateral Rear Delt Raise Combo7
