MAYHEM STRENGTH ISO Lateral Row User manual

ISO Lateral Row1
ISO Lateral Row
ASSEMBLY INSTRUCTIONS

ISO Lateral Row2
Please take the time to carefully read the instruction manual before starting the
process of assembling your machine. If you have any inquiries or complications,
please call us at 662-GYM-BROS, or email us at [email protected].
Ensure to tighten all nuts and bolts, lubricate any sliding parts, bearings, and moving
mechanisms. We also suggest applying Loctite or any kind of thread locking adhesive
to anything that does not thread into a Teflon nut. It is also important to ensure that
every movement arm is properly aligned prior to frequent use, and that the machine
that you are assembling is fully functional.
Tools Required for Installation:
Rubber Mallet
Level
Ratchet and Socket Set
Snap Ring Pliers
Adjustable Wrench
2 People Required

Number of Parts
Part Description
Quantity
1
Cross Assembly
1
2
Support Assembly
1
3
Arm Assembly
1
4
Support
1
5
Pivotal Pad Mount
1
6
Front Cross Assembly
1
7
Cross Assembly
1
8
Hexagon Head Bolts M12x65
6
9
Plain Washers
76
10
Hexagon Head Bolts M12x75
24
11
Spring Lock Washers
38
12
Hexagon Nuts M12
38
13
Hexagon Head Bolts M12x85
8
14
Bearing
4
15
Hexagon Head Bolts M10x70
4
16
Plain Washers
8
17
Hexagon Socket Button Head Screws M10x25
2
18
Plastic Washer
2
19
Adjusting Bolt
1
20
Seat Support
1
21
Chest Pad Assembly
1
22
Seat Pad Assembly
1
ISO Lateral Row3
PARTS/HARDWARE LIST

ISO Lateral Row4
Frame Assembly

ISO Lateral Row5
Force Arm Assembly

ISO Lateral Row6
Force Arm Completed

ISO Lateral Row7
Cushion and Frame Installation

ISO Lateral Row8
Hours of Operation:
Monday–Friday 9:00am - 5:00pm (PST)
Saturday 9:00am - 3:00pm (PST)
Sunday CLOSED
Phone: (662)GYM-BROS
Email: [email protected]
Visit Our Website: www.gymbrofitness.com
Have a question about assembly?
Please contact a Gym Bro Fitness Team Member!
