Mayline COHERE FIXED HEIGHT & PIN HEIGHT TABLE User manual

ASSEMBLY INSTRUCTIONS
COHERE FIXED HEIGHT & PIN HEIGHT TABLE
1. Place Top (1) face down on a clean flat surface. Attach Leg Assembly (2A-D) onto Top
using 7 Screws (E1) per leg.
COMPONENTS
REF# QTY. DESCRIPTION PART NO.
1 1 Top CALL ~~**
2A 2 Fixed Height Leg Assembly w/Glides CALL ~~**
2B 2 Pin Height Leg Assembly w/Glides CALL ~~**
2C 2 Fixed Height Leg Assembly w/Casters CALL ~~**
2D 2 Pin Height Leg Assembly w/Casters CALL ~~**
HARDWARE BAG (Part No. DS242)
REF# QTY. DESCRIPTION
E1 16 Screw, #12 x 1" PHS
Replacement Part not included in assembly
REF# QTY. DESCRIPTION PART NO.
R1 1 Glide DS131
R2 1 Caster DS108
NOTE:
PLEASE COUNT AND INSPECT ALL PIECES BEFORE DISPOSING OF ANY CARTON OR PACKING MATERIALS.
** Denotes Color Code
~~Denotes Size
When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative. 1-800-822-8037
(1)
P/N REV 02 03/25/14
Recommended tools for Assembly:
#3 Phillips bit for larger screws.
Note: Hat Channel
pre-installed on Tops
60" and above.

(2)
Extra inserts on the underside of the top are for optional Ganging Kit 10GA & Pie Connectors.
Extra pilot holes along edge of top are for optional Modesty Panel
10GA Ganging Kit 30°
Pie Connector
60°
Pie Connector
90°
Pie Connector
OPERATING INSTRUCTIONS FOR PIN HEIGHT
1. Raise Top - Push Leg Pin into leg on each side and raise table to desired height. Make
sure the pins lock into holes at the desired height.
2. Lower Top - Push Leg Pin into leg on each side and lower table to desired height. Make
sure the pins lock into holes at the desired height.
