Maytronics 8180090 User manual

1
English
Robot Pool Cleaner by Maytronics
EN
FR
ES
User Instructions
Guide d’utilisation
Instrucciones de Uso
8180090

1
English
What You’ll Find Inside the Box
Part X Comment
Base frame for filter elements 2
Filters
2/4 Filters
Depend on
model
Bag for filters storage 1
Power supply unit 1
Robot pool cleaner 1
Optional components available on request
from your robot pool cleaner distributor
Section 1 - Description of Main Components
1. Filters
Base frame + fine or ultra-fine cartridge
Depend on model
2. Brushes
There are three types of optional brushes, each designed to provide optimal traction on different pool surfaces.
Only one type set is provided with your robot pool cleaner.
PVC Brush
For concrete, PVC, fiberglass and liner.
Combined Brush
For rough ceramic surface and mosaic tiles.
Wonder Brush
For smooth ceramics.
Power supply Unit
Robot pool cleaner
Filter and cartridges
click
clickclick
click
click
clickclick
click

2
English
Only use the original supplied power supply unit.
The Power supply unit is splash proof – do not immerse it in water.
Unplug the power supply unit before any servicing activity.
Do not plug the power supply unit in before placing the pool cleaner in the water.
Ensure the mains outlet is protected by a ground fault interrupter (GFI) or an earth leakage interrupter (ELI).
Important: Do not enter the swimming pool while the pool cleaner is working.
Section 2 – Robot pool cleaner Operation
Part 1 – Preparing the Robot Pool Cleaner for Use
Laying out the cable
Unwind minimal required cable to cover the entire pool size, straight the cable along the pool side.
Make sure there are no twists or kinks.
3. Power supply unit
Digital Switch-mode Power Supply
• Input: 100 VAC – 250 VAC
• 50-60 Hz
• 180 W
• Output: <30 VDC
• IP 54
• Bluetooth®/Wi-Fi®max. trans. power 10 mW EIRR, 2.4 GHz frequency
Swivel
3.5 m
12 ft

3
English
Part 2 - Into the water
Inserting the robot pool cleaner into the pool.
Place the robot pool cleaner into the pool
and release the handle.
Note: When using the combined brushes or Wonder brushes, gently squeeze the Wonder brush material until it is totally wet.
LED indications table:
Lights display Meaning
Blue circle Blinks 4 times Occur after connecting the power-supply to the
power outlet.
Blue connectivity light is consistent Bluetooth®connected
Green and Blue connectivity lights blink
alternately
Pairing process is ongoing
Green connectivity light is on Wi-Fi®connected to home network
Using the power supply
Your power supply is designed to provide you with the most
advanced features to improve your experience.
• A single on/off button for an easy operation.
• LED indicators for the advanced features.
Turning the robot pool cleaner ON
1. Plug the floating cable from the robot pool
cleaner into the power supply unit.
2. Plug the electrical cable from the power
supply unit into the mains.
Floating cable

4
English
Part 3 - Taking the robot pool cleaner out of the water
Unplug power supply before any servicing activity.
1. If the robot pool cleaner has not finished its cycle, turn off the power supply
unit and unplug the mains.
2. Pull the floating cable gently until the robot pool cleaner has risen to the
surface, then lift by the handle.
Important: Do NOT lift the robot pool cleaner from the water by its cable.
Section 3 - Routine Maintenance
Part 1 - Extracting and cleaning the filter elements
Unplug power supply before any servicing activity.
2
13
