MBO T700 Installation instructions

Originaloperatingmanual
T700/T800.1
Continuous Feeder
Preserve forfuture appliance
BuckleFoldingMachines

Seite 2
Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
Contents
Prologue............................................................................................................................ 6
1.0 Specifications............................................................................................................ 6
1.1 Manufacturer ............................................................................................................. 6
1.2 Type ............................................................................................................................ 6
1.3 Technical data............................................................................................................ 7
1.3.1 Sizes ................................................................................................................................................. 7
1.3.2 Electrical data................................................................................................................................... 7
1.3.3 Speed ............................................................................................................................................... 7
1.3.4 Weightsin kg..................................................................................................................................... 7
1.3.5 Floor plan .......................................................................................................................................... 8
1.4 Documentation.......................................................................................................... 9
1.5 Supplementary Documents ................................................................................... 10
1.6 Information to user/Functioning description........................................................11
1.7 Buckle fold ............................................................................................................... 12
1.8 Knife fold .................................................................................................................. 12
2.0 BASIC SAFETY INSTRUCTIONS ..............................................................................13
2.1 Warnings and symbols .............................................................................................13
2.2 Safety at working place - destined use of the folding machine..........................13
2.3 Safety devices - machine ....................................................................................... 15
2.3.1 Protective hoods- Checklist of parallel unit/feeder and mobilefolding units................................15
2.3.2 Protectivehoods - Chartof parallel unit and feeder.......................................................................16
2.3.3 Protectivehoods - Chart of mobilefolding units.............................................................................17

Seite 3Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
3.0 Transportation/Erection/Installation .................................................................... 18
3.1 Transportation ......................................................................................................... 18
3.1.1FoldingunitI ....................................................................................................................................18
3.1.2 Feeder .............................................................................................................................................19
3.1.3Folding unitsII and III ......................................................................................................................19
3.1.4 Cleaning ..........................................................................................................................................19
3.2 Erection/Installation of machine............................................................................ 20
3.2.1FoldingunitI ................................................................................................................................... 20
3.2.2 Feeder .............................................................................................................................................21
3.2.3 Pressure-/vacuum pump ............................................................................................................... 22
3.2.4 Double sheet control ...................................................................................................................... 22
3.2.5Noisedamping hoods(optional) .................................................................................................... 23
3.2.6 Guard above the slitter shafts........................................................................................................ 23
3.2.7 Guards ............................................................................................................................................ 24
3.3 Electrical connection .............................................................................................. 25
3.3.1Installation of main control panel ................................................................................................... 25
3.3.2 MCC Counter ................................................................................................................................. 26
3.3.3 Main Power Connection ................................................................................................................. 27
4.0 Maintenance ............................................................................................................ 28
4.1 Exchange and/or tensioning of belts/tapes ........................................................ 29
4.1.1 Register belt at register table ........................................................................................................ 29
4.1.2 Drive beltfor suction wheel/Vacu-Infeed....................................................................................... 30
4.1.3 Vacu-Infeed-Tape (Option) ............................................................................................................ 30
4.1.4 Drivetape for foldrollers and slitter shaftsat parallel unit ..............................................................31
4.1.5Main drive of the folding units..........................................................................................................31
4.1.6Drive beltfor register tableon mobilefolding units........................................................................ 32
4.1.7 Chain of feeder ............................................................................................................................... 32
4.1.8 Feeder - upper transport tape ....................................................................................................... 33
4.1.9 Feeder - Lower transport tapes ..................................................................................................... 33
4.2 Lubrication / Cleaning............................................................................................. 34
4.2.1 Feeder ............................................................................................................................................ 34
4.2.2 Register table ................................................................................................................................. 34
4.2.3 Folding units ................................................................................................................................... 35
4.2.4 Cleaning roller ................................................................................................................................ 35
4.2.5Cleaning of foldrollers..................................................................................................................... 36
4.2.6 Pressure/Vacuum Pump .................................................................................................................37
4.2.7 Maintenance Report ...................................................................................................................... 39
5.0 Operation of the machine....................................................................................... 40
5.1 Main control panel - Standard control ”MC” ........................................................ 40

Seite 4
Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
5.2 Main control panels (Options) ................................................................................41
5.2.1 Push button control.........................................................................................................................41
5.2.2 Rapidset ......................................................................................................................................... 42
5.3 Feeder ...................................................................................................................... 43
5.3.1 Upper pile table............................................................................................................................... 43
5.3.2 Drum............................................................................................................................................... 44
5.3.3 Lower table ..................................................................................................................................... 45
5.3.4 Transport control ............................................................................................................................ 46
5.3.5 Areation/air support ....................................................................................................................... 48
5.3.7 Vacu-Infeed (Option).......................................................................................................................51
5.3.6 Suction wheel ..................................................................................................................................51
5.4 Register table .......................................................................................................... 52
5.4.1 Ball rail (standard) .......................................................................................................................... 52
5.4.2 Vacu-Alignment (Option)................................................................................................................ 53
5.4.3 Double sheet control ...................................................................................................................... 54
5.5 Sheet infeed control ............................................................................................... 55
5.5.1Automatic learning of suction lengthand sheet gap ..................................................................... 55
5.5.2 Photocells (Standard) .................................................................................................................... 56
5.5.3Photocellsin folding units II and III (option) ....................................................................................57
5.6 Parallel folding unit.................................................................................................. 58
5.6.1 Setting of foldrollers and slitter shafts ........................................................................................... 58
5.6.2 Buckle plates .................................................................................................................................. 59
5.6.3 Sheet deflectors ..............................................................................................................................61
5.6.4 Slitter shafts ................................................................................................................................... 62
5.6.5 Photocell atexitof folding unit ....................................................................................................... 62
5.6.6 Perforating...................................................................................................................................... 63
5.6.7 V-shaped special perforating knife(optional)............................................................................... 65
5.6.8 Scoring............................................................................................................................................ 66
5.6.9 Cutting............................................................................................................................................ 66
5.6.10 Guard above the slitter shaft........................................................................................................ 67
5.7 Mobile buckle folding units.................................................................................... 68
5.7.1 Installation...................................................................................................................................... 68
5.7.2 Electricalconnection ...................................................................................................................... 69
5.7.3 Control panel (Standard) ............................................................................................................... 70
5.7.4 Controlpanel - Push button control (Optional) ..............................................................................71
5.7.5 Main Control Panel (Option Rapidset) ........................................................................................... 72
5.7.6Set-up modeof bucklefolding machines........................................................................................73
5.7.7 Sheet transportation.......................................................................................................................74
5.7.8Exitoffoldingunit ........................................................................................................................... 77
5.7.9 Guard above the slitter shaft.......................................................................................................... 78
5.7.10 Miscellaneous............................................................................................................................... 78
5.7.11 Double Stream Device (Optional)................................................................................................. 79
5.7.12 Two-up productionat onesidelay .................................................................................................81

Seite 5Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
5.8 Noise damping device (option).............................................................................. 82
6.0 Instructions to the user.......................................................................................... 83
6.1 Setting instruction for the most commonly folds ................................................ 83
6.1.1 Parallelfold ...................................................................................................................................... 83
P 1 1 xparallel fold, i.e. 4pages ............................................................................................................ 83
P 2 2 xparallel fold, i.e. 8pages ............................................................................................................ 83
P 3 2 xparallel fold (letterfold), i.e. 6pages ......................................................................................... 83
P 4 2 xparallel fold (accordian fold), i.e. 6pages.................................................................................. 84
P 5 3 xparallel fold (accordian fold), i.e. 8pages.................................................................................. 84
P6 4 xparallel fold (accordian fold), i.e. 10 pages ................................................................................ 84
P7 3 xparallel fold (1 parallel + 2 letter folds),i.e. 12pages ................................................................ 84
6.1.2 Crossfold ........................................................................................................................................ 85
K 1 1 x parallel and 1 x crossfold (double folding), i.e. 8 pages ............................................................ 85
K 2 2 x parallel and 1x crossfold,i.e. 16pages..................................................................................... 85
K 3 2 x parallel (letterfold) and 1x crossfold, i.e. 12 pages.................................................................. 85
K 4 2 x parallelfold (accordian) and 1x crossfold, i.e. 12 pages .......................................................... 86
6.1.3 Threefold ........................................................................................................................................ 86
K 5 1x parallel, 1xcross and 1x threefold, i.e. 16 pages ..................................................................... 86
K 6 1 xparallel, 1x crossand 2 xthreefold (2x 32 pp two-up production)........................................... 86
7.0 Options ..................................................................................................................... 87
7.1 Batch counter .......................................................................................................... 87
7.2 Gully cut.................................................................................................................... 87
7.3 Edge trim .................................................................................................................. 88
7.4 Punch Perforation ................................................................................................... 89
7.5 Special buckle plates.............................................................................................. 91
7.5.1Combination buckleplate KFT (optional) .......................................................................................91
7.5.2Electronicallycontrolled buckle plates........................................................................................... 92
7.5.3 Gatefold devices ............................................................................................................................. 92
7.6 Other options........................................................................................................... 92
8.0 Peripherical units..................................................................................................... 92
9.0 Final remarks............................................................................................................ 92

Seite 6
Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
Prologue
With the MBO folding machine you have purchased a valuable product. However, it is
absolutely imperative to comply with all Safety Regulations and Safety Instructions. This
Operating Manual should also instruct you to correctly operate the MBO folding machine
and to comply with the Safety Regulations and to maintain the machine properly.
1.0 Specifications
1.1 Manufacturer
MBO Binder& Co., Maschinenbau Oppenweiler
Grabenstrasse 4, 71570 Oppenweiler
P.O. Box 1169, 71567 Oppenweiler
Tel.: [phone]
Fax.: [phone]
1.2 Type:
Buckle folding machines T 700 and T 800.1 with continuous feeder

Seite 7Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
1.3 Technical data
1.3.1 Sizes T 700 T 800.1
Maximum sheetsize: 69 x 130 cm (200) cm (26 x 39 ½”) 78 x 130 cm (200 cm)(30 x 42 ½”)
Minimum sheet sizes: 15 x 18 cm (6 x 8 ”) 15 x 18 cm (6 x 8 ”)
1.3.2 Electrical data
Feeder: 0,18 kW 0,18 kW
Pump: 2,60 kW 2,60 kW
Folding units each 0,75 kW 0,75 kW
1.3.3 Speed:
10 - 205 mtrs./mte.
1.3.4 Weights in kg: Net Gross
Feeder : 856 1.134
Foldingunit I68cm (26inch) 635 874
Foldingunit I78cm (30inch) 765 955
Folding unit II 68 cm (26 inch) 617 913
Folding unit II 78 cm (30 inch) 650 957
Folding unit III 56cm: 541 777
(*)OptionT800.1
(*)

Seite 8
Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
1.3.5 Floor plan (measurements in cms):
T 700
T 800.1

Seite 9Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
1.4 Documentation:
Customer:
Machineconfiguration:
Machine-/Serial No.:
Type of feeder: Continuousfeeder
Type of pump:
Electrical data:
Wiringdiagram no.:
Foldingunit:
Feeder:
Delivery:
Operating voltage (V/Hz):
Control voltage(V/A):
Control voltage(V/A):
Total rated current (A):
Fuse at power supply (A):
ConformityCertificate:
Noise level (dB/AI):
GS CertificateNo.:

Seite 10
Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
1.5 Supplementary Documents:
Operating Manual
batch counter:
air pump:
auxiliary units:
auxiliary units:
other manufacturers:
Spare parts lists
machine:
feeder:
pump:
peripherical units:
other manufacturers:
Knife list: TM 32/2

Seite 11Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
1.6 Information to user/Functioning description
FOLDING MACHINE TO FOLD FLAT SHEETS
The foldingmachineisdesignedto foldflat sheetsonly. Folding of any other material shouldnot be
attempted. The manufacturer or supplier would not be liable for any damage caused as a result.
Furthermore,the manufacturer would also not beliable for anymalfunctionsordamages of additional
installations or alterationswhich were not delivered or installed by him.
The construction of your machine may differ from the pictures in some details. However, thisdoes
not have any influence to its safe operation. Since we are continuously working on further
developments, alterationsare reserved.
The production speed can be varified between 10 and 205 mtrs./mte. However, the efficiency
depends on the type of paper, size and type of fold as well as to the different circumstances of the
user which cannot be influenced by the manufacturer.
In order to provide a general understanding of the machine function to the operator the following
description has been carried out from the feeder to the machine.
Please be advised that due to technical reasons and for better understanding certain options
are already described in the standard machine description.
The MBO Combination Folding Machine works exclusively in accordance with the principle of
buckle folding. It may be coupled with mobile knife folding unitswhich work in accordance withthe
principle of knifefolding.
The basic machineconsistsof a combinationof aparallel unit with continuousfeeder, register table
and stream delivery. Additional buckleplateunits II, III, andIV, mobile knife foldingunits, suchas
Z 2, Z 5, andZ 6, special folding units or variousother MBO deliveriesmay beattached, if necessary.
Standard buckle folding units consist of two, four or six buckle plates with swing deflectors, spiral
foldrollers which can be adjustedthrough quick settingelements ontheside frameof themachine,
and quickly removeable slitter shafts with plug bearings.
Please bear in mind that a simultaneous folding with all buckle plates is not possible!

Seite 12
Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
1.7 Buckle fold:
The principle of buckle foldis that
the sheet is always pushed into
the buckle plate.
Three foldrollers and one buckle plate
are necessary to prepare a buckle fold.
Foldrollers 1and 2 carry the sheet into
the buckle plate 4to the sheet stop.
A buckle occurs during transporation
through these foldrollers to the direction
of foldrollers 2and 3by which the sheet
is folded through its passage.
1.8 Knife fold:
Two foldrollers 1and 2as well
as one knife 3are necessary
to preparea knife fold.
The sheet is transported under
the knife to a sheet stop and aligned.
After the knife has been released
it moves the sheet between
the foldrollers where it is folded
during its passage.

Seite 13Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
2.0 BASIC SAFETY INSTRUCTIONS
2.1 Warnings and symbols
The following designations respectively signsare used for very special instructions
> NOTICE < Special instructions with respect to the economical use of the machine.
>ATTENTION < Special instructions respectively requirementsand prohibitions to avoid injuries
and damages.
> DANGER < Instructions respectively requirementsand prohibitions to prevent personal injuries
or extensive damages.
2.2 Safety at working place - destined use of the folding machine
2.2.1 MBO folding machines correspond to their stipulated Safety Technical Requirement at the time of
their shipment. Therefore, any moveable and rotating parts are covered with protective hoods and
are mechanically and electrically interlockedto suchan extent asto not unreasonably detract from
the operation.
2.2.2 At all safety technical preventions it isextremely important that the operating personnel achieves
sufficient safety experience and is advised of all dangerous sources. The use of the delivery does
not exclude danger to life and limb of the operator or third parties, respectively doesnot exclude
the detraction of the machine and any other material assets.
2.2.3 The machine should only be operated when in good working order.Any malfunctions which may
impair thesafetymustbe removed immediately bytrained personnel or themanufacturer/supplier.
2.2.4 The foldingmachineisdesignedto foldflat sheetsonly. Foldingof any other material shouldnot be
attempted. The manufacturer or supplier would not be liable for any damage caused as a result.
2.2.5 Carefully read thecomplete Operating Manual beforeyou operate themachine, including the Safety
and Service Requirements.
2.2.6 The Operating Manual should be kept with the machine at all times.
2.2.7 Complete the Operating Manual, if necessary with internal Safety Instructions as well as with the
legal Regulations for Prevention ofAccidents.
2.2.8 If more than one operator, ensure that all operators are trained and informed.
2.2.9 Never remove guards or safety interlocks as the machine will no longer be protected.

Seite 14
Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
2.2.10 Never use any tools which are not in a perfect condition and make sure that no tools are left on the
machineafter completionof settingsandmaintenance.Toolswhichfall intothemachine maycause
serious injuries and damages.
2.2.11 Note that all Safety Instructions arekept in a legible and visible condition.
2.2.12 Any audible and visible change on the machine in relation to the safety must be reported to the
supervisor or manager of your company immediately.
2.2.13 The operating personnel should be aware that loose clothing, jewellery or hair can cause serious
injuriesif caught in the machine.
2.2.14 It isabsolutelyprohibitedto cleanrollers,eliminate malfunctions, orto undertakeadjustmentswhile
the machine is on operation.
2.2.15 Make sure that no other person starts the machine while you are working on it.
> DANGER < Always activate the EMERGENCY-STOP button or turn OFF the main switch.
2.2.16 Check all the machine stoppages prior to starting the machine. You should never switch on the
machine without first checking that the machine is in good working order and that no other person
is making adjustments.
2.2.17 Turn off the main switch and secure it, if necessary, with a lock if you are required to undertake
extensive mechanical or electrical maintenance and repair works.
2.2.18 Never open the main or sub-control panel! Only authorized personnel should gain accesss to the
electronic control cabinets as there are no user serviceable parts.
> DANGER < if control cabinet is open! All main terminals could be alive even though the main
switch has been turned off.
2.2.19 Any damaged cables or electrical connections must be reported to the competent authorities of
your company.
2.2.20 According to the latest Safety Regulations the machine must stop if the protective hood above the
slitter shafts is opened.They are equipped with electrical switches. Any removal or bridging of
these switches may cause > DANGER < to life and limb of the operating personnel.
> DANGER < Make sure that during the works with opened noise hood it is completely opened to
its limit to avoid any self-locking.
2.2.21 Machine connections must be installed in such a manner that no cables,
tubes or hoses are left trailing.

Seite 15Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
2.3 Safety devices - machine
2.3.1 Protectivehoods - Checklist of parallel unit/feeder and mobile folding units

Seite 16
Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
2.3.2 Protective hoods - Chart of parallel unit and feeder

Seite 17Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
2.3.3 Protective hoods- Chart of mobilefolding units

Seite 18
Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
3.0 Transportation/Erection/Installation
Thispart oftheOperating Manualisdirected tothecompetentservicepersonneland internal
authorized personnel.
3.1 Transportation
Folding units, feeder and delivery
are delivered in separate crates.
Move them to their final destination
as close as possible.
3.1.1 Folding unit I
Unscrew the folding unit I off the pallet
and move it with a fork lift.
Set the fork lift onto the cross bars 1
and 2to the final position.
> DANGER < The unit may fall
or slip off! Secure it, accordingly!

Seite 19Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
3.1.2 Feeder
Unscrew the feeder off the pallet
andlift it witha forklift
at positions 1and 2and
carry it to itsfinal destination.
>ATTENTION < Make sure that flap 3
as well as air tubesand valves
behind it are not damaged!
> DANGER < Risk of injuries!
3.1.3 Folding units II and III
Unscrew the units II and III
off the pallet and lift them
with a forklift at cross bar 1.
>ATTENTION <The unit may fall (tip)
over wherefore two additional persons
are required to brace the unit.
Make sure that machine rollers 2
and castor wheel 3will not be
damaged when dropping the unit.
3.1.4 Cleaning
> ATTENTION < Clean the machine, feeder, and delivery of rust preventing agents.

Seite 20
Alterations reserved Stand 05/2008
Operating manual T700/T800.1 - en
3.2 Erection/Installation of machine
3.2.1 Folding unit I
> DANGER < The unit may fall
or slip off! Therefore, brace the unit,
accordingly! Carry the folding unit
to its final position.
Place plastic feets 2underneath
the setting screws 1. Align the unit
with setting screwsand spirit level.
Horizontal alignment:
Upper foldroller 3
Vertical alignment:
Place spirit level onto
the side panel 4.
