MBW F24 User manual

1
F24 Trowel Machine
This manul covers the following serial
numbers for each model listed:
F24…….……………1741219-174999

MBW, Inc.
250 Hartford Rd · PO Box 440
Slinger, WI 53086-0440
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Website: www.mbw.com
MBW (UK) Ltd.
Units 2 & 3 Cochrane
Street
Bolton BL3 6BN, England
Phone: [phone]
Fax: [phone]
L18432 / 04.21.F
© MBW, Inc. 2021
Printed in the USA

2
Table of Contents
INTRODUCTION ..………………...……………………………………………………..………………..4
EC DECLARATION OF CONFORMITY ..............................................................................5
1GENERAL INFORMATION ..............................................................................................6
1.1 GLOBAL ASPECTS ABOUT SAFETY............................................................................................... 7
1.2 SAFETY SIGNS (PICTOGRAMS ON THE MACHINE)..................................................................... 8
1.3 SYMBOLS AND GLOSSARY ............................................................................................................ 9
1.4 SPARE PARTS ORDER.................................................................................................................. 10
1.5 REVISION OF THE MANUAL.......................................................................................................... 10
1.6 GENERAL WARRANTY CONDITIONS........................................................................................... 11
2MACHINE CHARACTERISTICS ....................................................................................12
2.1 IDENTIFICATION DATA OF THE MACHINE .................................................................................. 13
2.2 INTENDED USE............................................................................................................................... 13
2.3 PROHIBITED USE........................................................................................................................... 13
2.4 TECHNICAL AND DIMENSIONAL FEATURES / NOISE / VIBRATION / NON-IONIZING RADIATION
14
2.5 OPERATOR POSITIONS/LAY-OUT/USE AND MAINTENANCE AREA/ ....................................... 15
2.6 GENERAL DESCRIPTION............................................................................................................... 15
2.7 TYPES OF POWER SUPPLY.......................................................................................................... 16
2.8 SAFETY MEASURES ...................................................................................................................... 16
2.9 INFORMATION ON RESIDUAL RISKS........................................................................................... 16
3TRANSPORT AND LIFTING..........................................................................................22
3.1 PACKING AND UNPACKING.......................................................................................................... 23
3.2 LIFTING AND HANDLING ............................................................................................................... 23
3.3 TRANSPORT ................................................................................................................................... 24
3.4 STORAGE........................................................................................................................................ 24
3.5 DAMAGE CONTROL ....................................................................................................................... 25
4MACHINE INSTALLATION ...........................................................................................26
4.1 INSTALLATION................................................................................................................................ 27
4.2 INITIAL TESTS................................................................................................................................. 27
4.3 GENERAL SAFETY INSTRUCTIONS............................................................................................. 28
4.4 STARTING THE WORKING CYCLE ............................................................................................... 28
4.5 TROWEL DRIVE.............................................................................................................................. 29
4.6 TROWEL MACHINE STOP.............................................................................................................. 29
4.7 RESTARTING THE TROWEL ......................................................................................................... 29
5USE OF THE TROWEL MACHINE .................................................................................30
5.1 SURFACE PREPARATION ............................................................................................................. 31
5.2 TROWELING PHASE ...................................................................................................................... 31
5.3 FINISHING PHASE.......................................................................................................................... 31
6MAINTENANCE AND REPAIRS ....................................................................................32
6.1 SCHEDULED MAINTENANCE........................................................................................................ 33
6.2 ROUTINE AND ADDITIONAL MAINTENANCE............................................................................... 37
6.2.1 Blades replacement .................................................................................................................. 37
6.2.2 Unlocking of blades holding arms and pressure plate ......................................................... 37
6.2.3 Trowel disc replacement .......................................................................................................... 37
6.2.4 Replacing the belt ..................................................................................................................... 38
6.2.5 Refill of engine oil ..................................................................................................................... 38
6.2.6 Gear motor oil topping off........................................................................................................ 39
6.2.7 Notes about dismalting ............................................................................................................ 39
6.3 TROUBLESHOOTING ..................................................................................................................... 40
6.4 PARTS LIST..................................................................................................................................... 42

3
MBW, Incorporated (MBW) thanks you for purchasing one of its products and invites
you to read this manual.
This manual includes instructions for use, maintenance and spare parts list for the
MOSKITO trowel machine.
Inside you will find all the information necessary for correct use of trowel machine
purchased; therefore, the user must carefully follow the warnings contained in it and read it
in every part to better understand the machine and avoid incurring problems caused by
improper use.
According to the accident prevention regulations, the operators must be equipped with all
the individual protection devices (P.P.E.) necessary to guarantee their own safety (safety
shoes, safety helmet, gloves, ear protectors, etc.).
Please keep the manual in a suitable place to keep it intact.
The contents of this manual may be changed without notice or further obligation in order to
include changes and improvements to the units already sent.
It is forbidden any reproduction or translation of any part of this manual without prior
written notice and authorization by MBW.
No part of this publication may be reproduced, stored in a system or transmitted to third parties in
any form or by any means, without prior written authorization by the Manufacturer.

4
INTRODUCTION
Operation and maintenance manual is an
integral part of the machine: it is necessary
to keep it intact and in a safe place during
the whole life of the same, even in case of
transfer to another user.
The MACHINE must be used in accordance
with what specified in this manual: it is
therefore recommended to read it carefully
before operating it, not to mention nothing
written and paying particular attention to
messages in the boxes.
This manual has been produced with
reference to the provisions of the Machinery
Directive 2006/42 / EC as amended, with the
aim of providing the user with general
knowledge of the machine and with
information for:
•Proper awareness of SAFETY issues.
•The intended use of the MACHINE, the
characteristics of the user and the residual
risks.
•The handling, installation, use and
maintenance of the machine safely.
•The demolition of the machine and its
disposal in safe conditions and in
compliance with the regulations in force to
protect the health of workers and the
environment.
Compliance with the rules and
recommendations contained in the manual
provide safe and appropriate intervention.

5
EC DECLARATION OF CONFORMITY
(Directive 2006/42/EC-Annex IIA)
(written in the original language)
Name and address of the manufacturer of the machine:
BARIKELL S.r.l.
Via Razzaboni, 118 41122 Modena (Italy) –Tel. [phone] –email [e-mail]
Name and address of the company authorized to the draft of technical file: SEMPREANORMA S.r.l.
Via Turrini, 17 40012 Calderara di Reno Bologna (Italy) –Tel:[phone]
in the person of Pasquale Posa
We hereby declare that the machine: Trowel Moskito 60
Serial number:
Year Built: 2018
Briefly described below:
The troweling machine, equipped with a rotating free wheel, allows the finishing of the edges on concrete
floors, resin floors and substrates
it complies with directive 2006/42 / EC, directive 2014/30 / EU (electromagnetic compatibility) and 2014/35 / EU (low
voltage) and the legislative provisions that transpose them
It is also compliant with the following harmonised standards:
•UNI EN 12100:2010;
•UNI EN ISO 13849-1:2016;
•CEI EN 60204-1:2016;
•ISO 13105-2:2014.
Modena,
In witness thereof
Luca Zivieri
(Legal representative Barikell S.r.l.)

6

CHAPTER 1
1 GENERAL INFORMATION
1.1 Global aspects about safety
1.2 Safety signs
1.3 Symbols and glossary
1.4 Revision of the manual
1.5 Spare parts order
1.6 General warranty conditions

7
1.1 GLOBAL ASPECTS ABOUT SAFETY
Compliance with the rules and
recommendations contained in this
publication allows safe use ofthemachine and
appropriate action.
1) The best performance and maximum life of
the machine will be obtained from the
proper use of the same. It is, therefore,
necessary to scrupulously observe the
instructions contained in this booklet;
2) Any requests for spare parts must be
accompanied by the type of model and
serial number reported in the spare parts
list or applied on the number plates of the
components themselves;
3) The machine installation must be carried
out in compliance with the safety
regulations in force;
4) Do not remove or tamper with the
protections and safety devices, check
periodically their effectiveness;
5) Strictly adhere to the warnings recalled on
the danger postings (pictograms) and keep
the message readable;
6) Operation and maintenance must be
performed by qualified personnel, trained
and authorized to the tasks foreseen.
Intervention procedures and
responsibilities of operators must be clearly
defined to ensure safe and proper use and
maintenance;
7) Before any maintenance or adjustment
work, all the power supplies must be
disconnected and locked, ensuring that
they are not subject to unintentional start-
ups;
8) The maintenance of the machine carried
out in a manner that does not comply with
the instructions provided, with non-original
spare parts or without written authorization
by the company that performed the
maintenance of the used machine or in
any case in such a way as to jeopardize
its integrity or modify its characteristics,
exempts the company itself from any
liability concerning the safety of persons
and the faulty operation of the machine.
•The user shall be required to respect
warning about periodic maintenance
indicated in Chapter 6;
•The user shall be required to respect the
qualifications of the operating
personnel:
OPERATOR / MAINTENANCE
TECHNICIAN: Performs the tasks
necessary for the basic operation
of the machine: execution of the
work cycle, implementation of operator
commands, other interventions strictly
related to normal production, possible daily
cleaning and inspection, execution of
ordinary maintenance operations (CFR.
CHAP. 6). Strictly operates with safety
devices enabled.
MAINTENANCE TECHNICIAN
SPECIALIST (RESELLER)
Involved in all the operating
conditions and levels of
protection. Performs
extraordinary interventions that cannot be
run by the user (See CHAP. 6 about
maintenance).

8
1.2 SAFETY SIGNS (PICTOGRAMS ON THE
MACHINE)
It is absolutely necessary to recognize the
meaning of the indications present on the
machine and keep their message readable.
In case of damage replace them immediately.
The following safety signs (pictograms) are
installed. Residual risks are summarized in
Chapter 2 PAR. 2.7.
!WARNING!
DO NOT REMOVE, DAMAGE OR MODIFY THE
PICTOGRAMS ON THE MACHINE. BEFORE EACH
WORK SHIFT CHECK THEIR PRESENCE AND THE
GOOD STATE OF PRESERVATION. IF DAMAGED,
REPLACE THEM, PREVENTING THE USE OF THE
MACHINE UNTIL REPLACEMENT.
WARNING SIGN
GENERAL "MANUAL READING OBLIGATION"
INDICATION SIGNAL
"USE LIFTING HOOK"
INDICATION SIGNAL
"FIX THE LOAD TO TRANSPORT MEANS"
(if applicable)
WARNING SIGN
"DANGER of MOVING PARTS"
WARNING SIGN
"DANGER of HIGH TEMPERATURES"
OBLIGATION SIGNAL
"OBLIGATION TO USE EAR PROTECTORS"
OBLIGATION SIGNAL
"OBLIGATION TO USE SAFETY SHOES"

9
1.3 SYMBOLS AND GLOSSARY
•DANGER: a potential source of injury
or damage to health;
•HAZARDOUS AREA: any area inside
and/or near the machine in which the
presence of a person constitutes a risk
to safety and health of that person;
•EXPOSED PERSON: any person
wholly or partially in an hazardous
area;
•OPERATOR: the person or persons
given the task of installing, operating,
adjusting, cleaning, repairing, moving
or performing maintenance on the
machinery;
•RISK: combination of the probability
and severity of an injury or damage to
health that can arise in a hazardous
situation;
•INTENDED USE: the use of the
machine in accordance with the
information provided in the operating
instructions (para. 2.2);
•REASONABLY FORESEEABLE
MISUSE: the use of the machine in a
way other than that indicated in the
instructions for use, but which may
result from readily predictable human
behavior;
•HUMAN-MACHINE INTERACTION:
any situation in which an operator
interacts with the machine in any of the
operational phases and at any time of
life of the machine itself;
•OPERATOR QUALIFICATION:
minimum level of competences the
operator must possess to perform the
operation described;
•NUMBER of OPERATORS: number
of operators needed to carry out in the
best way the operation described and
resulting from a careful analysis
carried out by 'Manufacturer', whereby
the use of a different number of
employees might prevent from getting
the
expected outcome or impair the safety of
the personnel involved;
•MACHINE STATUS, means:
the mode of operation: automatic gear,
manual operation, shutdown.
the condition of the safety devices on
the machine: guards included, guards
excluded, emergency stop pressed,
type of sectioning of energy sources,
etc .;
•GUARD: part of the machinery used
specifically to provide protection by a
material barrier;
•SAFE STOP: stopping condition
obtained through security measures
that avoid unexpected start of
hazardous bodies;
•RESIDUAL RISK: risk that it was not
possible to eliminate or reduce
sufficiently through the design, against
which the protections are not (or not
totally) effective.
•The manual gives the information of
its existence and
instructions/warnings to overcome it;
•SAFETY COMPONENT: means a
component used for ensuring a safety
function and whose breakdown or
malfunction affects the safety and/or
health of exposed persons (eg. lifting
device; fixed, mobile, adjustable
guard, etc., electrical, electronic,
optical, pneumatic, hydraulic,
interlocking of a guard, etc.).
•ABBREVIATIONS:
•CHAP. = Chapter
•PAR = Paragraph
•P. = Page
•FIG. = Figure
•TAB = Table
•PPE = Personal protective equipment
•CFR = Compare

10
Symbols are used in this publication with the
following meaning:
! IMPORTANT: Indicates important technical
information which must not be overlooked.
Warning-Caution
!WARNING: Indicates that it is necessary to
adopt appropriate behaviours not to put at risk
the health and safety of persons and not to
cause economic damage.
Generic warning sign that defines the
obligation to read the manual:
1.4 SPARE PARTS ORDER
The order of spare parts should clearly report
the data needed fortheir identification and the
data shown on the machine identification
plate.
For further information we suggest contacting
the manufacturer.
Ex.:
•Machine model
•Type
•Serial number
•Year of build
•Description
•Requested quantity
•Method of delivery
•Address, telephone number and
name of the applicant
1.5 REVISION OF THE MANUAL
We recommend keeping this manual
constantly updated, integrating it with the
comments received by the maintainer. It is
appropriate that any annotations or
comments are inserted in a clear way.
Any amendments, additions or modifications
must be documented using the form shown
on the next page. The update must be
performed on all copies.
The 1st revision of release of the manual is
validated by the manufacturer who takes
note of it and adopts the instructions
contained therein.
See the table below.
REVISION
n.
DATE
AFFECTED
PAGES
SIGNATURE EDITOR
INSTRUCTIONS
NOTES
VALIDATION FOR
ACKNOWLEDGEMENT
OF THE
MANUFACTURER
01
10/2018
ALL
Spin automations
_
!
WARNING
!
IMPORTANT

11
1.6 GENERAL WARRANTY CONDITIONS
The new machines covered by warranty with
regard to the structure and use of suitable
materials, subject to the following conditions:
1) Warranty is valid for a period of twelve (12)
months.
2) The manufacturer undertakes to repair or
replace at its discretion any parts or groups
which have proved to be defective.
3) Repaired or replaced parts are covered
under the same warranty as the original
parts, expiring 12 months after the
implementation of the parts themselves.
4) For completion of the work required and for
delivery of spare parts the manufacturer
reserves adequate time.
5) All transport costs of the parts intended for
replacement covered by this warranty
will be borne by the purchaser.
6) Repairs and interventions carried out during
the warranty period by unauthorized
personnel will void any right to warranty.
7) During the warranty period the replaced
parts become the property of the
manufacturer.
8) For the components not produced by us, the
warranty conditions of the original suppliers
apply. Any claims will be transferred to the
buyer.
9) This warranty is valid and applicable only
to the original purchaser. -
The warranty is void if the following
situations happen:
a) The original owner transfers ownership
of the machine,
b) If any changes have been made to the
machine,
c) If parts and accessories not
manufactured by us on have been added
on the machine.
10) No responsibility is assumed for any
damage caused to the floor by
malfunctioning or stopping of the trowel
machine during the processing phases.
11) The warranty does not include damage
deriving from excessive stress, such as, for
example, the continuation of the machine's
operation after the detection of an anomaly
due to improper use or maintenance, the
use of inappropriate operating materials as
well as the non-observance of the
Instructions for Use. The same applies to
damages caused by normal wear and tear.
12) The manufacturer assumes no liability
arising out of any difficulties related to
resale or use abroad of the machine due
to the application of provisions of the law
relating to the protection of industrial
property in force in the country where the
machine is sold.
13) With regard to the engine warranty, the
conditions of the original suppliers apply.
14) Established warranty conditions are
binding for all sellers of MBW. Any different
agreements will be considered valid only
upon confirmation in writing by MBW.
15) Labor and processes necessary for the
replacement of defective parts under
warranty are charged to the Customer.
IMPORTANT!
Should it be necessary to use the
warranty, please provide the
following information:
•Model and serial number of
both the machine and the
engine
•Date of purchase
•Detailed description of the
problem.

12

CHAPTER 2
2 MACHINE CHARACTERISTICS
2.1 Identification data of the machine
2.2 Intended use
2.3 Use prohibited
2.4 Technical and dimensional features/noise/vibration/non-ionizing radiation
2.5 Layout/operation and maintenance area/operator position
2.6 General description
2.7 Types of power supply
2.8 Safety measures
2.9 Information on residual risks

13
2.1 IDENTIFICATION DATA OF THE
MACHINE
In order to ensure proper identification of the
machine, please refer to the serial number
stamped on the invoice and the data imprinted
on the manufacturer's plate bearing the CE
marking symbol attesting to its conformity to
the applicable directives.
The plate has the following required content:
•Manufacturer’s name & address (1)
•CE marking (2)
•Build year (3)
•Type designation (4)
•Serial number (5)
•Engine serial number (6)
•Power of the engine (7)
•Mass in kg (8)
2.2 INTENDED USE
The trowel machine "Moskito" is meant to
perform finishing of edges of concrete floor,
resin flooring and/or substrates. To make this
process the machine is equipped with a 4 or 6
blades rotor depending on the version,
powered by an internal combustion engine.
The fuel used is unleaded petrol, which comes
from the tank to the carburettor after being
filtered. Only one operator is required to
operate the machine.
He should be able to move freely and
unhindered.
This version of trowel machine (equipped
with internal combustion engines) can be
used exclusively outdoors and finishing
work flush with the wall.
The machine may only be used by
professional operators.
2.3 PROHIBITED USE
Any use other than as expressly set forth in
paragraph (§ 2.2) and implemented in different
ways or contrary to what is stated in this
publication sets up the possibility of misuse.
The manufacturer declines all responsibility
resulting from improper use which can cause
personal injury and for any malfunction of the
system.
THE FOLLOWING PROHIBITED ACTIVITIES
CONFIG. MISUSE:
•USE the MACHINE IN EXPLOSIVE
ENVIRONMENT (THE ABOVE FACILITY IS NOT
IN COMPLIANCE WITH ATEX 2014/34/EU).
•INTEGRATE WITH OTHER SYSTEMS AND/OR
EQUIPMENT NOT CONSIDERED BY THE
MANUFACTURER IN THE FINAL DESIGN.
•CONNECT THE MACHINE TO POWER
SOURCE OTHER THAN THOSE SPECIFIED BY
THE MANUFACTURER.
•USE THE MACHINE FOR A PURPOSE
DIFFERENT FROM THAT EXPECTED AND
SHOWN IN THIS PUBLICATION.
•USE THE MACHINE INDOORS.
•USE THE MACHINE NOT FLUSH WITH THE
WALL.
•INFRINGE THE MAINTENANCE RULES
DESCRIBED IN THIS PUBLICATION.
•USE THE MACHINE IN AIR CONTAINING
SMOKE, DUST, WATER VAPOUR OR
SOLVENTS.
!
WARNING
Do not remove, damage or modify the machine identification data present on
it. In the event that data become unreadable immediately contact the
manufacturer.
Figure 2.1
1
1
2
4
5
6
3
7
8
FIG. 2.1

14
•USE DIFFERENT EQUIPMENT THAN THOSE
EXPRESSLY DESIGNATED BY THE
MANUFACTURER.
•LET THE MACHINE TO BE OPERATED BY A
NUMBER OF OPERATORS DIFFERENT FROM
THAT EXPRESSLY PROVIDED BY THE
MANUFACTURER (see PAR. 2.5 of this
publication) OR DISOBEY THE DIRECTIONS
REGARDING OPERATOR POSITIONING.
2.4 TECHNICAL AND DIMENSIONAL FEATURES / NOISE / VIBRATION / NON-
IONIZING RADIATION
DESCRIPTION
Measurem
ent
Unit
Code 3005
Cod 3012
Cod 3021
Cod 3028
Size:
[Mm]
600x1506x100
0
600x1506x100
0
600x1506x100
0
600x1506x100
0
Packing size
[Mm]
650x910x 800
650x910x 800
650x910x 800
650x910x 800
Operating weight
[Kg]
49
50
51
52
Shipping weight
[Kg]
66,5
66.5
67.5
68.5
Engine:
-
HondaGX160
Robin EX 17
GX160
Robin EX 17
Installed power:
[Kw/HP]
4 (5.5)
4.2 (6)
4 (5.5)
4.2 (6)
Starting:
[Type]
Manual
Manual
Manual
Manual
Cooling:
-
Air
Air
Air
Air
Power supply:
-
Gasoline
Unleaded
Gasoline
Unleaded
Gasoline
Unleaded
Gasoline
Gasoline tank capacity:
[Lt]
2.8
3.2
3.2
3.2
Disc diameter
mm
600
600
600
600
Number of blades
Nr
4
4
6
6
Gearbox lubricant
Type
SYNTHETIC OIL
FOR LONG LIFE
REDUCERS ISO
VG320
GRADING .
SYNTHETIC OIL
FOR LONG LIFE
REDUCERS ISO
VG320
GRADING .
SYNTHETIC OIL
FOR LONG LIFE
REDUCERS ISO
VG320
GRADING .
SYNTHETIC OIL
FOR LONG LIFE
REDUCERS ISO
VG320
GRADING .
Number of drive shaft
revolutions
r/min.
3600
3600
3600
3600
NOISE AND VIBRATION
Residual noise values for machine in work
Sound pressure Level LpA
dbA
79,4
Sound power Level LwA
dbA
95,5
Values of vibration for working machine
Left handle value- increased exposure
A hv sum[m/s²]
< 2,5
NON-IONIZING RADIATION
The MACHINE does not emit non-ionizing radiation dangerous for the operators.

15
2.5 OPERATOR POSITIONS/LAY-OUT/USE
AND MAINTENANCE AREA/
1st level OPERATOR POSITION
A single operator must work with the
machine.
He drives the machine by acting on the
handlebar to move it according to the
needs of the processing and performs
some ordinary maintenance activities.
During use the operator position is adjacent to
the handlebar of the machine.
The operator position is also considered an
inspection position from which it is possible
to oversee the smooth running of the working
cycle.
The first level operator is also responsible for
carrying out cleaning operations at the end of
use.
2nd level OPERATOR (RETAILER-
SPECIALIZED WORKSHOP)
The retailer (expert maintenance
technician) performs maintenance and repair
tasks provided by the manufacturer (compare
Chapter 6 of this publication).
Always intervenes when the machine is
stopped and energy cut.
2.6 GENERAL DESCRIPTION
The Trowel "Moskito" is dedicated to finishing
of the edges on concrete floors, resin floors
and substrates. Operation is manual.
The power supply is supplied by a an
unleaded gasoline fuelled engine.
FUNCTIONAL GROUPS
1
CONTROL LEVER (STOP)
2
LEVER AND ACCELERATOR CA-
BLE
3
HANDLE FIXING KNOB
4
AIR FILTER
5
MUFFLER
6
FUEL TANK CAP
7
INTERNAL COMBUSTION ENGINE
8
FINISHING HEADSTOCK
9
STABILIZING CIRCLE
10
ROTATING PULLEY DRIVE
11
BELT FIXING GUARD
12
TROWEL DISC
13
BLADE ANGLE ADJUSTMENT
KNOB
IMPORTANT!
To define use and maintenance
you need to about 1.5 m on all
sides of the machine (fig 2.3 on
next page).
!
ATTENTION
Only one operator is required to
drive the machine.
Tasks and positions are detailed
in para (§) 2.5 of this publication.
Failure to follow the indications
above conFIG.s the hypothesis of
misuse and releases the
manufacturer from any liability
arising from misuse/abuse.
FIG. 2.2

16
2.7 TYPES OF POWER SUPPLY
The machine must be powered by following
the instructions given by MBW.
For safe operation read the following
information carefully:
•The device is powered byan air-cooled
petrol engine powered by unleaded
petrol..
•The engines fitted to the machine can
be of different types (see technical
characteristics, p. 14).
•The engine is started by pulling.
•The fuel consists of lead-unleaded
petrol that from the tank reaches the
carburetor after being filtered.
•The rotation motion of the trowel
blades is transmitted by the engine to
a centrifugal clutch, connected with a
trapezoidal belt to the rotor gearbox.
2.8 SAFETY MEASURES
The safety measures included are:
1) Stop levers (maintained action
commands)
2) Timing belt fixed guard
3) Fixed guards of blades segregation.
Horizontal distance between
handlebar and dangerous bodies
equal to 900 mm.
2.9 INFORMATION ON RESIDUAL RISKS
Despite the application, in the design phase,
of the precepts contained in the safety
requirements (RESS) provided for by current
legislation and despite the activity of adopting
safety measures, there is a residual risk that
cannot be eliminated. Residual risks are
appropriately reported through the application
of specific SAFETY SIGNALS called
PICTOGRAMS located at the danger zones.
The pictograms have different informative
values, namely:
•WARNING SIGN: BLACK AND
YELLOW TRIANGLE
•PROHIBITION SIGNS: WHITE AND
RED CIRCLE
•SIGNS OF OBLIGATION: BLUE AND
WHITE
RESIDUAL RISKS ARE SUMMARIZED IN
THE TABLES ON THE FOLLOWING PAGES
(from page 17 to page 21).
IMPORTANT!
For more detailed information about the
characteristics of engine refer to the
manual of the component that is an
integral part of this publication.
FIG. 2.3 Use and maintenance Area
3
2
1

17
RISKS
Reference Signs
SI
Residual Risks
Danger
Prohibition
IPD
MECHANICAL +
PNEUMATIC
Inadequate spaces
It is forbidden to start the machine
without connecting the float disc to the
vanes as indicated in the user manual.
There is a risk of entanglement, pro-
hibited use of loose or fluttering cloth-
ing (are banned scarves, scarves, or
ties non-adherent clothing).
In case you need to replace the disc,
you need to use protective gloves as
some components (blades), if worn
out, could be sharp.
In case it is necessary to lift the ma-
chine (operation allowed only through
the lifting hook supplied), first remove
the trowel disk in as it could inadvert-
ently disengage.
It is mandatory to use the devices of
individual protection required for the
employee (safety shoes, gloves,
mask).
Before starting maintenance activities,
carefully read the instructions in the
user manual.
It is prohibited to circumvent the safety
devices implemented on the machine.
Caught, entrapped,
dragged
✔
Crushing of upper
limbs
✔
Crushing of lower
limbs
✔
Shearing
✔
Abrasions, cuts,
punctures and/or
perforations
✔
Collisions, impacts
and/or
compressions with
materials and
equipment
Slip, stumble and
fall
Collisions and/or
impacts with
transport means in
transit
Falling objects
Projection of
materials
✔
Injuries deriving
from poor lighting of
spaces and/or
working stations
Projection of fluids
at high pressure

18
RISKS
Reference Signs
SI
Residual Risks
Danger
Prohibition
IPD
THERMAL
Presence of heated
surfaces, heat and
flames
✔
Necessary to wait for the
cooling of the engine and
muffler surfaces before
conducting maintenance ac-
tivities. Use heat resistant
gloves.
Scalds/burns
caused by contacts
with heated
surfaces
Presence of cold
surface
NOISE
Localized noise
✔
Obligation to use DPI ear
protectors
Background noise
Injuries caused by
interferences in
verbal
communication
VIBRATIONS
Vibrations
transmitted to the
whole body
✔
Obligation to use anti-vibration
gloves. Limit exposure times
Vibrations
transmitted to the
complex hand-arm

19
RISKS
Reference Signs
SI
Residual Risks
Danger
Prohibition
IPD
RADIATION
Ionizing radiation
Not applicable.
Non-ionizing
radiation, heat, light
Laser equipment
Exposure to
Infrared and
Ultraviolet Rays
DIRECT AND
INDIRECT
ELECTRICAL
Electrocution
caused by direct
and indirect
contacts
Not applicable.
Electrostatic
phenomena
Electric arcs
Injuries caused by
failures in power
supply and/or in the
control system
Exposure to
electromagnetic
fields

20
RISKS
Refrence Signs
SI
Residual Risks
Danger
Prohibition
IPD
FIRE AND
EXPLOSION
Fire and explosion
✔
The tank filling operations of
petrol must be carried out in
well ventilated environment
and far from possible sources
of heat or flames.
Presence of
explosive
athmospheres
PHYSICAL
WORKING LOAD
Manual handling of
loads
Not applicable.
Repeated actions
of upper limbs
Incorrect positions
and/or excessive
physical efforts
