Mec JOE-100IM User manual

phone: [phone] / 55 100 | fax: - 11 | e-mail: [e-mail] | Web: www.mec-energietechnik.com
-- Instruction manual --
Joe-100IM Battery Charger
Waterproof Lead-based battery charger
for Wet-, Gel-, AGM- and CA- batteries
+ Power supply mode
Version / MEC Art-No.
12V 7A / 121-06702-530IM 24V 4A / 121-12402-530IM
Dear Customer!
Thank you very much for your trust in us and our product.
Please read these operating instructions carefully before start of operation.
MEC-Energietechnik GmbH
1. Safety Rules and General Warnings
Persons, which are not able to use the device in a safe way, because of their physical, sensory or mental competence, or
because of their inexperience, should not use the charger without control or instruction of a skilled person.
100-240 Volts alternating current, device is not suitable for children –Danger of life!!!
Avoid explosive gases, open flames and sparks –ensure for enough air ventilation while charging!
Explosion Risk!
The charger is exclusively designed for rechargeable Lead-based batteries and must not be used for other purposes.
Please consider the charging instructions from the battery manufacturer before charging!
Do not open! Repair work must only be accomplished by authorized companies or specialized technical staff.
If the mains connection of the device is damaged, it must be replaced with an original wire which is available at the manufac-
turer or costumer service.
Never place the device on top of the battery while charging!
Protect against direct solar radiation and temperatures over 40°C.
In case of obvious damage or malfunction disconnect the device from mains supply and protect against unintended reconnec-
tion.
The DC cable must not be cut or shortened.

MEC –Energietechnik GmbH INSTRUCTION MANUAL Joe-100IM
Rev.2.0 –18/04/2014 Page 2 of 4 www.mec-energietechnik.com
2. General Information
This microprocessor based waterproof Lead Acid Battery Charger was especially developed for the outdoor use and for situations
where water may be present. It can be used to charge any lead-based battery –including GEL, AGM, WET and CA. With the 5-
step charging program the battery will be charged safely in a fully automatic mode. The output of the charger is electronically
protected against short circuit, reverse polarity connection. The charger is able to recover deep-discharged batteries.
Coloured LEDs on the top case are used to indicate charging status, errors, and selected mode of charging. Additional it includes
a power supply mode.
The chosen battery type could be changed on the control panel. The previously selected mode will be saved as standard setting.
The integrated metal hook allows fixing the charger in different ways.
3. Special Features
Convection cooled IP68 housing
Short circuit and reverse polarity protection
LED’s to indicate operation and charging status
5-Step charging technology with automatic restart
Selectable battery type (Gel, AGM, Wet or CA) and power supply mode
Battery temperature sensor
Automatic Shut-off at too high temperature
Indicating a non-chargeable (‘dead battery’) condition
4. Product Figure
1 DC cable 4 Yellow Charge-LED 7 Press Button 10 Wall brackets
2 Green Power-LED 5 Green Full-LED 8 AC cable
3 Red Error-LED 6 Battery type-LED 9 Extractable hook
9
1
2
3
4
5
6
7
10
8

MEC –Energietechnik GmbH INSTRUCTION MANUAL Joe-100IM
Rev.2.0 –18/04/2014 Page 3 of 4 www.mec-energietechnik.com
5. Operation
ATTENTION:
Before operating please make sure that the power cable and the charger including the charging cable show no damages and
make sure that the mains supply complies with the specification.
Please consider the charging instructions from the battery manufacturer before charging.
If you want to connect the charger to the battery, please have a look to the following points:
Make sure that the charger is disconnected from the battery.
Connect the charger to mains supply.
Select a suitable battery type
Connect the charging cable to the battery.
Charge-profiles: After connecting charger to mains, the charger will signal the actual charge-profile by LEds on the top case.
To change the actual charge-profile press the “Press-button” for 5 seconds, the led turns from fast to slow flashing. Now you can
change the charge-profile by pressing the “Press-Button” shortly. To confirm a charge-profile you have to press the “Press-Button”
again for 5 seconds, the LED will change from flashing to constant shine.
Power supply mode: For power supply mode follow the same instructions for chose a charge-profile, the power supply mode is
selected when all charge-profiles LEDs are flashing.
The used charge-profile will be saved and automatically used after restart the charger.
6. Charging the battery
The charging process starts automatically and runs through the following five charging phases:
1. charging phase: recovery
This charging step is indicated by blinking alternately of the Charge- LED (4) and Full LED (5).
Explanation: The recovery phase starts automatically at deeply discharged batteries (2-6V at 12V batteries and 8-15V at 24V
batteries). During the recovery phase, the charger use controlled current pulses. That tries to push the battery to a voltage level,
where a charging process is possible. When battery voltage is still under 6V (12V battery) or under 15V (24 V battery) after 70
pulses, the charger will stop working because the battery maybe is damaged.
2. charging phase: soft start
This charging step is indicated by constant lighting of the Charge- LED (4).
Explanation: During the soft start phase, at a battery voltage between 6V and 12V for 12V batteries and between 15V and 24V
for 24V batteries, the charger reduces charging current to, in order to extend battery lifetime.
3. charging phase: constant current
This charging step is indicated by blinking slowly of the Charge- LED (4).
Explanation: During the constant current phase, the battery is being charged to 80% of its capacity.
4. charging phase: constant voltage
This charging step is indicated by blinking quickly of the Charge- LED (4).
Explanation: During the constant voltage phase the battery is being charged to its maximum capacity.
5. maintain phase: float charging
This charging step is indicated by constant lighting of the Full- LED (5).
Explanation: The battery has reached it’s full capacity. The charger can now be disconnected from the battery (see pt. II discon-
nection the charger) or remain at the battery in float-charge mode.
Disconnect the charger from the battery:
a) Disconnect the charger from the mains supply;
b) Disconnect the charger from the battery;
Charging advice:
If the charger is disconnected from the battery during the charging process, the charge current will be interrupted immediate-
ly. In that case please disconnect the charger from the mains supply. For starting a new charging process please comply with
the relevant points (see pt.5)
For increasing the lifetime of the battery please do not stop a charging process before the battery is fully charged. The
charger will automatically stop the charging process
Recommend Battery Size
Version
12V/7A
24V/4A
min
23 Ah
13 Ah
max
88 Ah
50 Ah

MEC –Energietechnik GmbH INSTRUCTION MANUAL Joe-100IM
Rev.2.0 –18/04/2014 Page 4 of 4 www.mec-energietechnik.com
7. Errors and Troubleshooting
Table 1: General errors:
Error description
Solution
No LED lighting or blinking after connecting mains
Check if charger is connected to mains supply
Check function of mains supply
Red Power- LED is on, charger is connected to battery
and the charging process don’t start
Check connection to battery
Check if battery is damaged or deeply discharged
Error- LED blinking (N x blinking / 2 sec pause)
Please see the table below for error description
Table 2: Error- LED blinking signals:
Blinking signal
Error description
1 x
Battery damaged
2 x
Battery voltage is too high or wrong battery connected
5 x
Charger temperature is too high as charging
6 x
Button-short-circuit
8. Technical Specifications
Version
12V 7A
24V 4A
MEC Art.-no.:
121-06702-530IM
121-12402-530IM
Charge Characteristic
5-Step Charge Profile with Temperature Compensation
Input
AC 100…240V / 50-60Hz
AC Cable
1.5m ±0.1m CEE 7/16
Charging Current max.
7A
4A
Nominal Voltage
12V
24V
Output Power max.
109W
109W
Start charging voltage
2V
4V
Restart Charging Voltage
12.8V
25.6V
Back Current
<1mA
Power- Supply Mode
13.6V / 5A
27.2V / 3A
Efficiency
>87%
>89%
DC-Cable
Length: 1.6m ±0.1m / Alligator Clamps + Ring Terminals (Ø6.5mm)
Indicators
8 LEDs
Cooling
Convection cooled
Operating Temperature Range
-10°C…40°C
Device Protection
Over Temperature, Reverse Polarity, Short Circuit, Over load
Temperature Sensor
Internal and External inside DC-Cable
Certification
CE
Enclosure
Plastic Housing
Protection Class
2
IP- Code
IP68
Dimensions / Weight
174 x 84 x 45 mm / ~ 850g
9. Advice for Disposal
It is prohibited to dispose the charger into the house- and residual waste removal (WEEE-Richtlinie
2002/96/EG und EAG-VO) , it must be disposed at the according collection points. For the protection of
our environment please inform yourself at your communal adminstrative agency about your nearest
disposal point.
The charger equates to the RoHS-directive 2002/95/EG, for the restriction of the use of certain
hazardous substances in electrical and electronic equipment.
10. Disclaimer of Warranty
MEC-Energietechnik GmbH guarantees replacement or repair of chargers that are recognized as defective under common
environmental conditions. The validation of the warranty time starts with the delivery date from the manufacturer. MEC-
Energietechnik GmbH is limiting the free guaranteeing to working hours and spare parts only.
For damages caused by non-observance of the operating instructions, inappropriate start up or handling as well as recon-
structions and modifications of the device, the warranty claim expires and MEC-Energietechnik GmbH assumes no liability for
consequential damage to property or persons!
Repair work must only be accomplished by authorized companies or professional staff!
Subject to technical modifications. We assume no liability for misprints.
MEC-Energietechnik GmbH, Energiestrasse 3, A-9500 Villach
E-Mail: [email protected] http:// www.mec-energietechnik.com
