Mec TRITASK-300F Series User manual

Mainland Energy Conversion Ltd.
Tel: [phone]
E-mail: [e-mail]
www.mec-powersolutions.com
Instruction Manual
Battery Chargers
TRITASK-300F Series:
Safety Rules and General Warnings
•Persons, who are not able to use the charger in a safe way, because of their physical, sensory or mental incompetence, or because of their
lack of experience, should not use without the control or instruction from a skilled or qualified person.
•The charger runs with 100-240 Volts alternating current, which is not suitable for children – Danger of Life. And beware of risk of electric shock
at all times.
•Ensure sufficient air ventilation; do not cover the vent outlet while charging in progress.
•Avoid flammable gases, solvents or vapours all the time. Prevent open flame or sparks while charging in progress. Explosion RISK!
•The charger is exclusively designed for charging Rechargeable Lead-based Batteries and must not be used for other purposes.
•You should take into consideration of the charging instructions issued by the battery manufacturer before charging. Check also if the charge
profile fits your battery and application.
•DO NOT OPEN or DISMANTLE the charger. Repair work must only be processed by authorized technical staff.
•If the mains connection of the charger is damaged, it must be replaced with an original wire which is available at MEC or authorized dealers.
•NEVER place the charger on top of the battery while charging in progress.
•The charger should be protected against direct solar radiation or temperatures over 40°C.
•In case of obvious damage or malfunctioning, disconnect the charger from the mains supply and protect against unintended reconnection.
•The DC cable must not be cut, shortened or extended under any circumstances.
•Keep the charger in dry room (rel. humidity <80%). Clean with dry cloth only. Avoid fluid of any kind to get into the charger.
Special Features
•IP20 Load-dependent fan cooling; sturdy spray-painted metal housing
•Microprocessor-based 3-Step charging technology with automatic float charging; best for storage maintenance charging
•Optimal and gentle charging for the greatest possiblity of charge cycles guaranteed with high frequent combinatorial circuit technology
•Wide range of input with Active PFC (Power Factor Correction)
•LED indicators showing corresponding charge status and errors
•Protection against short circuit, reverse polarity, over temperature or overload with spark surpression
Product Configuration
1. Mains Socket
2. On / Off Switch
3. Terminal Block
4. Red Mains LED
5. Green Charge LED
6. Yellow Charge LED
7. Red Charge LED
IP20 Load-dependent fan-cooled.
3-Step charging technology with automatic float charging
ensures optimal and gentle charging for the largest
possible number of charging cycles.
1
1
2
1
3
1
4
5
6
7

Instruction Manual TRITASK-300F Series
Version: May 2020 - 2 -Mainland Energy Conversion Ltd.
Tel: [phone]
E-mail: [e-mail]
www.mec-powersolutions.com
Preparation –Before Charging
General Checking
•Check thoroughly the charger itself including all the cables show no damages
•Take into consideration the charging instruction issued by the battery manufacturer
Charging Cable – Polarity Checking
WARNING: Check the polarity before mounting onto a plug:
•Red cable = Plus (+)
•Black cable = Minus (-)
DC Mains Supply Checking
•Make sure the DC cable must not be cut, shortened or extended under any circumstances
•Make sure the mains supply complies with the technical specification requirements of the charger
Before Connecting the Charger to the Battery
•Make sure the charger is switched off and disconnected from the mains supply
•Then connect the terminals of the charger to the battery (Red cable to the positive (+) terminal of the battery; then Black cable to the negative
(-) terminal)
•If the battery is built-in within a vehicle, the Black cable can be connected to the negative (-) terminal of the battery or the body of the vehicle;
make sure the connection is done with a safe distance from the fuel line and take into consideration of the battery and vehicle manufacturer
•Finally connect the power cable of the charger to the mains supply, and switch on the charger
Charging the Battery
Plug in and switch on the charger. The charging process starts automatically and runs through the following stages:
Phase 1: Constant Current Charging
Red Charge LED (7) blinks or lights up. The battery is being charged to 80% of its capacity at this stage.
Phase 2: Constant Voltage Charging
Yellow Charge LED (6) blinks or lights up. The battery is being charged to its maximum capacity. When the Green Full LED (5) turns on, the charger
can now be disconnected from the battery.
Phase 3: Float Charging
Green Full LED (5) keeps on lighting indicate the battery has reached its full capacity. If the battery keeps connecting to the charger, float charge
mode takes place to keep the readiness of the battery at all time.
Disconnect the Charger from the Battery:
1. First, disconnect the charger from the mains supply
2. Then, disconnect the charger from the battery (disconnect the Black (-) cable first then the Red (+) cable)
After disconnecting the charger from the mains, please wait at least 5 seconds to reactivate the charger if in need – otherwise damages may be
resulted.
Charging Advice and Battery Care
Charging Advice:
•If the charger must be disconnected from the battery during the charging process, please FIRST disconnect the charger from the mains supply.
The continuation of the charging process is equal to a new charging cycle; all relevant points of the Operating Instructions have to be considered.
•To lengthen the lifetime of the battery, please do not stop the charging process before the battery is fully charged. The charger will automatically
switch to float charging when the charging process is completed.
Battery Care:
•Never expose the battery to high temperatures, as this causes permanent battery capacity loss.
•Never deep-discharge or overcharge the battery, cells can be damaged irreversibly.
•If possible, always disconnect the battery from the load when being stored over long period of time.
•Store battery in a dry and cool place at about 40-60% of its rated capacity.

Instruction Manual TRITASK-300F Series
Version: May 2020 - 3 -Mainland Energy Conversion Ltd.
Tel: [phone]
E-mail: [e-mail]
www.mec-powersolutions.com
General Errors Description
Solutions
No LED lighting or blinking after connecting to the mains
•Check if the charger is connected to mains supply properly
•Check if there are any problems with the mains supply or mains cable
•Check if the charger is switched on
•
Red Mains-LED is on, charger is connected to the battery,
but the charging process seems not working
•Check the connection to battery and if the polarity has been correctly
connected
•Check if the battery is damaged or has been deeply discharged
Advice for Disposal
It is prohibited to dispose the charger with household or residual waste removal (WEEE-Richtlinie 2012/19/EU und
EAG-VO). The charger must be disposed at designated disposal points. For the protection of our environment, please
check at your communal adminstrative agency of your nearest disposal point.
The charger conforms to the RoHS-directive EU 2015/863, for the restriction of the use of certain
hazardous substances in electrical and electronic equipment.
Disclaimer of Warranty
The warranty period (see our General Terms and Conditions) starts with the charger being dispatched by the manufacturer. The Company accepts
liability by guaranteeing to working hours and spare parts only.
For damages caused by non-observance of the operating instructions, inappropriate start up or handling as well as dismantling, reconstructions or
modifications of the charger, the warranty claim expires and the Company assumes no liability for consequential damages to any properties or persons
in connection with or arising from the purchase and use of the charger.
We reserves the rights to configure the charger as per actual needs and the manual may not reflect the most updated conditions of the product at all
times. Please contact us should you need any technological support.
Errors and Troubleshooting

Instruction Manual TRITASK-300F Series
Version: May 2020 - 4 -Mainland Energy Conversion Ltd.
Tel: [phone]
E-mail: [e-mail]
www.mec-powersolutions.com
Technical Specifications
DC Ausgang | DC Output
Lead-based Batteries
Ladespannung max.
Charge Voltage max.
(+/-1%)
12V
24V
36V
48V
Ladestrom max.
Charge Current max.
(+/-1%)
20A
10A
7A
5A
Wirkungsgrad max. | Efficiency max.
>89% @ 230V
Ausgangsleistung, nom.
Output Power, nom.
350W
Restwelligkeit | Ripple
<1%
Rückstrom | Back Current
<1mA
Ladekabel
Charge Cable
1.2m Kabel mit 4-wege schraube klemmleiste
1.2m cable with 4-way screw terminal block
AC Eingang | AC Input
Eingangsspannung | Input Voltage
100...240VAC / 50...60Hz
Netzkabel & Stecker | Power Cord & Plug
1.2m Länderspezifisch | Country Specific
Gehäuse | Enclosure
Werkstoff
Material
Metallgehäuse, lackiert
Metal housing, painted
Abmessungen / Gewicht
Dimension / Weight
226 x 112 x 52 mm / ca. 1.45kg
LED-Anzeigen
LED-Indicators
Netz-, Laden-, Batt.-Voll Anzeige
Mains-, Charging-, Batt.-Full Indicator
Schutzklasse / Protection Class
1
IP Klasse | IP Code
IP20
Einsatztemperaturbereich | Operating Temp.
0°C to +40°C
Kühlung
Cooling
Leistungsabhängiger Lüfter
Fan Cooling
Besonderheiten | SpecialFeatures
3-Stufen Ladecharakteristik**
3-Step Charge Characteristics**
Abschaltung bei "Batterie-Voll" (Ladestromerkennung)
Charge Cut-off at "Batterry-Full" (Current Detection)
Ladefreigabe (opt.)***
Charge Enable (opt.)***
Kabel f. Ladefreigabe / Ladesperre
Cable f. Charge Enable / Charge Disable
Geräteschutz
Device Protection
Kurzschluss-, Verpolung-, Ü berlastschutz
Short Circuit-, Reverse Polarity-, Overload Protection
Zertifizierungen | Certification
CE
Spezifikationen der Akkuhersteller sind vorrangig zu beachten! | Specifications of the battery manufacturer take priority!
** Abweichende Ladeprofile auf Anfrage | Different charge profiles available on request.
*** Optionale Varianten auf Anfrage | Optional features available on request.
Subject to technical modifications. We assume no liability for misprints.
