MedViron Guardian Rise Bassinet Manual
Corporate Headquarters:
9380 Pentatech Drive, Zeeland, MI 49464
Website: medviron.com
Email: customerservice@medviron.com
Toll free: 844.633.8476 M06-BOMM-0000 (Rev 1 )
Operations & Maintenance Manual
Guardian Rise Bassinet
Height-Adjustable Bassinets
2
Symbols used in this manual:
Warning. The warning symbol is used to identify critical hazards.
Pinch Point. This symbol is used to identify a location where an injury may occur.
Important Note. This symbol is used to identify important information that should
be remembered.
Height-Adjustable Bassinets
3
Contents:
Symbols used in this manual ________________________________________________________________________2
Bassinet Description ________________________________________________________________________________ 4
Purpose _____________________________________________________________________________________________ 4
Features ____________________________________________________________________________________________ 5
Specifications________________________________________________________________________________________ 6
Contraindications____________________________________________________________________________________ 6
Operating Instructions:
Moving the Bassinet ________________________________________________________________________ 7
Trendelenberg Positioning _________________________________________________________________ 8
Serial Number Location_____________________________________________________________________________ 9
Manufacturer Contact Information_________________________________________________________________ 9
Safety and Risks ___________________________________________________________________________________ 10
Cleaning Instructions_______________________________________________________________________________ 12
Preventative Maintenance List _____________________________________________________________________ 13
Service Part List ____________________________________________________________________________________ 14
Warranty ___________________________________________________________________________________________15
Height-Adjustable Bassinets
4
Description
The MedViron Guardian Rise Bassinets have two distinct parts, a plastic tub with mattress which sits
on top of a mobile storage cabinet with drawers with height adjustment columns at each end. The
bassinet’s warm modern design conveys the warmth of home and also implies competent, current,
modern healthcare.
Purpose
The functional design of the bassinet accommodates the care and transport of an infant patient, the
capability of Trendelenberg positioning of the bassinet tub, and the storage of care items for the
infant.
The bassinet is intended to be sold to and for use by professionally licensed staff and facilities caring
for the labor and delivery of children.
The bassinet has been designed and manufactured under and to all pertaining ISO 13485 standards.
The bassinet is intended for indoor use only.
THE IMPROPER USE OF THE BASSINET CAN LEAD TO INJURY TO THE INFANT OR
TO THE HEALTHCARE PROFESSIONAL OPERATING THE BASSINET. USE THE
BASSINET ONLY AS INTENDED, AS DEFINED IN THIS MANUAL.
CHANGES MADE TO THE BASSINET OR ITS PARTS CAN LEAD TO INJURY TO THE
INFANT OR THE HEALTHCARE PROFESSIONAL OPERATING THE BASSINET.
MAKING ANY CHANGES TO THE BASSINET ALSO VOIDS ITS WARRANTY.
Height-Adjustable Bassinets
5
Features:
Two design goals for the bassinet were lower cost of ownership for the hospital and improving the
experience of mother, caregiver, and family.
1. Four height-adjustment handles, one in each corner, can be used independently to raise or
lower the bassinet’s height.
2. One or two optional drop-leaf documentation trays are available upon request. The trays
have spill containment to capture spilled liquids.
3. The bassinet’s stainless steel push handles and all surface areas are easily accessible and
easy to clean. The tub and handle design allow a clear view of the infant.
4. The base panel has been designed to reduce the chances of caregivers hitting their shins
while the bassinet is in motion and also to get closer while caring for the infant.
5. KYDEX®thermofilm has been used for impact resistance and durability.
Height-Adjustable Bassinets
6
Specifications:
Contraindications:
1. The bassinet tub is not intended to be used without the mobile storage cabinet beneath.
2. The bassinet’s plastic drawer is not intended to be used for anything other than as a
drawer.
3. The bassinet is not intended to be used for infants that can sit, stand or roll over.
4. The bassinet tub or drawer boxes are not intended to be used for bathing.
Width 37.5in (95 cm)
Depth 21.5in (55 cm)
Surface low height 29.5in (75 cm)
Surface high height 39in (99 cm)
Drawer dimensions 23in W x 15in L x 6in D
Height-Adjustable Bassinets
7
Operation: Moving the Bassinet
1. Stand at either the left or right side of the bassinet.
2. Make certain the bassinet tub is secure and that drawers or doors are closed.
3. Place both hands on the bassinet push handle and push forward gently.
4. Make certain that the bassinet is always in front of you. Do not pull the bassinet
behind you.
5. Make certain that the floor is free of obstruction and beware of transitions in the
floor.
NEVER PUSH THE BASSINET FROM THE FRONT OR REAR.
NEVER PULL THE BASSINET BEHIND YOU.
TRANSPORT OF AN INFANT MUST OCCUR IN THE LOWEST HEIGHT POSITION ONLY.
Rightside
Leftside
Push
onl
y
in this direction
Height-Adjustable Bassinets
8
Operation: Trendelenberg Positioning
To put the bassinet tub into the Trendelenberg or Reverse Trendelenberg position, simply raise
either end of the tub and then lower it so that the hook on the side of the tub engages the metal rail
that bisects the push handle.
DO NOT LET GO OF THE TUB UNTIL YOU ARE CERTAIN THE TUB HOOK IS FIRMLY
SEATED ON THE RAIL.
NEVER PLACE ANY FOREIGN OBJECTS INSIDE OR ON TOP OF THE BASSINET TUB.
Lift this side
and engage the
hook
for the
Trendelenberg
Position.
Lift this side and
engage the
hook
for the Reverse
Trendelenberg
Position.
Height-Adjustable Bassinets
9
Serial Number Location
The serial number and cleaning instructions are on a label beneath the lower pass-thru
drawer. Stand in front of the bassinet and push the lower drawer inward, away from you,
to reveal the label.
Contact Information
Medviron LLC Toll free: 1-844-633-8476
9380 Pentatech Drive
Zeeland, Michigan 49464 USA Website: medviron.com
Mailing address:
Medviron LLC
P.O. Box 286
Zeeland, Michigan 49464 USA
Serial number label
is beneath drawer.
Height-Adjustable Bassinets
10
Safety and Risks:
TRANSPORT OF AN INFANT SHOULD OCCUR IN THE LOWEST HEIGHT POSITION
ONLY.
WHEN PUTTING THE BASSINET TUB INTO THE TREDELENBURG OR REVERSE
TRENDELENBERG POSITION, ALWAYS VERIFY THAT THE TUB HOOK IS SECURE AND
SEATED FIRMLY ON THE RAIL.
OBJECTS SHOULD NOT BE LEFT IN OR ON TOP OF THE BASSINET INFANT TUB AT
ANY TIME.
THE MAXIMUM WEIGHT LOAD OF EACH OF THE BASSINET DRAWERS IS 15 POUNDS
(7 KG). OPEN ONLY ONE DRAWER AT A TIME ON THE SAME SIDE. THIS IS
NECESSARY TO AVOID TIPPING OF THE BASSINET WHEN THE DRAWERS ARE OPEN.
THE MAXIMUM WEIGHT LOAD OF THE FLIP-UP WORK SURFACE IS 10LBS (4.5 KG).
THIS IS NECESSARY TO AVOID TIPPING THE BASSINET.
NEVER PLACE AN INFANT ON THE FLIP-UP WORK SURFACE.
WHEN MOVING THE BASSINET, THE OPERATOR SHOULD PUSH ONLY FROM THE
EITHER END USING THE BASSINET HANDLES.
Height-Adjustable Bassinets
11
TO AVOID TIPPING HAZARDS OF THIS DEVICE, MAKE CERTAIN THAT THE BED
COMPONENT FITS FIRMLY IN THE BASE, AND THAT DRAWERS AND CASTERS ARE
SECURE.
PINCH POINTS EXIST AT THE LOCATIONS INDICATED IN THE DRAWINGS BELOW.
PLEASE BE CAREFUL.
Height-Adjustable Bassinets
12
Product Care and Disinfection
Clean with a damp cloth or mild detergent solution. MedViron furniture can withstand a wide
range of hospital cleaners and disinfectants. When using any of these products, read and follow
the manufactures directions carefully. Do not use abrasive or solvent cleaner. A CDC
recommended chlorinated bleach solution of 5.25% -6.15% sodium hypochlorite (i.e., household
bleach) diluted in water at 1:100 also can be used.
Infant tub: Always use a soft cloth or sponge on the bassinet’s infant tub for washing and rinsing.
Liquid dish detergent is an acceptable cleaner. Never use abrasives or solvent cleaners. Always
follow up the application of any cleaning solution with a warm water rinse.
Clean the tub and mattress after each patient. Do not immerse the mattress in cleaning solution.
Make certain the mattress and tub are completely dry after each cleaning.
After cleaning, it is important that the bassinet is rinsed with warm water using a
clean damp cloth and then wiped with a clean dry cloth to remove any moisture.
Height-Adjustable Bassinets
13
Preventative Maintenance List:
_____ Casters: Casters should turn smoothly and should be free of any debris. Caster brakes
should hold firmly, the wheel should not turn when brake is applied.
_____ Plastic drawers: Should be clean and free of damage.
_____ Drawer slides: Drawers should open smoothly and quietly.
_____ Bassinet tub: Trendelenburg hooks must be intact and firmly attached to the tub. Bassinet
tub should be free of damage.
_____ Warning labels must be intact and legible.
_____ Check mattress for tears, punctures, or wear.
_____ Verify that the optional flip-up work surface is secure.
Serial number Date PM Completed
Completed by
Height-Adjustable Bassinets
14
Height-Adjustable Bassinet Service Parts
Part Name Part Number
Bassinet Tub 523-0150-0000
Mattress 516-0000-0000
Inset Pull Handle 557-0105-0000
Plastic Drawer Liner 558-0063-0000
Caster Replacement Kit (4 casters w/hardware)
556-0305-0000
Drop Leaf Support 555-0097-0000
Drop Leaf Hinge 555-0055-0000
Drawer Front 530-M009-
K
xxx
Drop Leaf Work Surface 510-M011-Kxxx
Please contact your dealer or sales representative to order service parts.
Height-Adjustable Bassinets
15
Limited Lifetime Warranty
MedViron®warrants the products it manufactures against defects in material and workmanship
under normal use and service for the expected useful life of the product from the date of
shipment. This limited warranty is valid only to the original purchaser using the product for its
intended purpose. This warranty does not apply to expected changes resulting from normal
wear and tear, use and aging of the product. Specifically excluded from this limited warranty are
defects and damage resulting from abuse, neglect, misuse, or excessive use. Product alteration,
substitution of components or materials, improper cleaning or repair, and installation and
handling damages are also not covered by this warranty. All other express or implied warranties
made by agents, dealers, sales representatives or any other representatives, including any
warranty of merchantability or fitness for a particular purpose, are hereby excluded.
There are no representations as to the capacity or performance of the products sold
hereunder except as set forth in the price list or quotation specifications, if any, and such
representations are expressly conditioned upon the correctness of the data furnished by
purchaser and upon the products being properly installed and maintained.
MedViron’s sole obligation shall be to repair or replace any defective product or product
component covered under this warranty, including shipping and labor, during the warranty period.
In no event shall MedViron be liable for any consequential or incidental damages, including lost
profits or revenues incurred by the purchaser with respect to any goods furnished by MedViron.
Expenses incurred by purchaser in repairing or replacing MedViron product must be pre-approved
in writing by MedViron
In the event a product has to be returned to the factory for verification of a defect and/or repair,
it must be pre-approved in writing by MedViron freight pre-paid, and include a copy of the
original invoice with the date and name of original purchaser.
MedViron hereby assigns to the original owner any and all warranties offered by its component
suppliers. To the extent the terms of these warranties differ from the terms of the Limited
Warranty, the terms of the suppliers’ component warranties shall apply. However, MedViron does
not guarantee that the component supplier will comply with any terms of the warranty of such
supplier.
Any MedViron products with the serial number removed or altered are excluded from this
warranty.
MEDVIRON WILL NOT BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES INCLUDING
ANY LOSS, EXPENSE, OR DAMAGE OTHER THAN TO THE PRODUCT ITSELF THAT MAY RESULT FROM
A DEFECT IN THE PRODUCT. SOME STATES DO NOT ALLOW FOR THE EXCLUSION OR LIMITATION OF
CONSEQUENTIAL AND INCIDENTAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY
NOT APPLY.
MEDVIRON MAKES NO IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. THESE AND ALL OTHER IMPLIED WARRANTIES ARE SPECIFICALLY
DISCLAIMED. SOME STATES DO NOT ALLOW AN EXCLUSION OR LIMITATION ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY.
THIS WARRANTY GIVES YOU, THE ORIGINAL PURCHASER, SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO
HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. EXCEPT FOR SUCH OTHER RIGHTS, THE
REMEDIES PROVIDED UNDER THIS WARRANTY STATE THE LIMIT OF MEDVIRON’S RESPONSIBILITIES.
Height-Adjustable Bassinets
16
NOTES:
Table of contents
Other MedViron Medical Equipment manuals
Popular Medical Equipment manuals by other brands
Ormed
Ormed ARTROMOT-K4 Operation manual
Electrotherm
Electrotherm Shenpaz Gemini LT user manual
Controls Solutions
Controls Solutions VFC300 instructions
Squirrel Medical
Squirrel Medical Dormir Digital MRS Instructions for use
Gendex
Gendex Dentsply AcuCam Concept IV PC Operation manual
Ventec Life Systems
Ventec Life Systems VOCSN Clinical and Technical Manual
Braun
Braun Aesculap PROSPACE PEEK SN002R Instructions for use/Technical description
MedPro
MedPro DEFENSE COMFORT PLUS Assembly instructions
OCULUS
OCULUS GramaDerm Instructions for use
CardiacSense
CardiacSense CS System 3 user manual
FSN
FSN FM-A2701D Instructions for use
Asko
Asko ASMedi ASM-100 user manual
