MegaLite Pro Color Strip User manual

Check that the unit has not been damaged during transport
Protection Against Fire
1. Maintain a minimum of 1 foot distance from any type of flame.
3. Replace fuse only with the specified type and rating.
. Do Not install the unit to close to a heat source.
5. Make sure cable are properly secured away from unit movement.
6. Maximum surface operating temperature 80º.
Protection Against Fire
1. Disconnect power before servicing.
2. For connection to main power supply proceed to page 5.
3. This unit must be earthed. (electronically grounded)
. Do not expose unit to rain or moisture.
Protection Against Mechanical Hazards
1. Use safety chain when hanging unit.
2. Use quality clamps or bolts when positioning unit
3. Do not open unit while it is on, risk of electrical shock.
3

Technical Information
Part Numbers
Fixture
3030– Pro Color Strip
Mechanical Specifications
Fixture
FixtureFixture
Fixture Packaged for Shipping
Packaged for ShippingPackaged for Shipping
Packaged for Shipping
Size: 40” x 6” x 3”
Weight: 10 lb
Size: 41” x 7.25” x 5”
Weight: 12 lbs
DMX Connectors: 3-pin & 5 Pin XLR connectors
Power Connection: Neutrix Power Con in/Out
Thermal: Maximum ambient temperature 40°C
Maximum surface temperature 60°C
Fastening System: Single Mounting Yoke & Security Eye bolt
Accessories: 1 / Edison power head to Blue Power Conn cable 1 meter long
1 / White Power Conn head
Electrical Specifications
LED Quantity: 18
LED Type: Tri Colored
LED Watts: 3
LED Lifetime: 60 to 100 thousand hours
LED Angle: 45°( ± 5º)
Power Consumption: 110V-220V50/60 Hz
Ballast: Electronic
Watts: 46
Amps: .61
Protocol: DMX 512
DMX Channels: Mode A 3 Channels R,G,B
Mode P 54 Channels R,G,B X18
Mode F 6 Channels R ,G ,B, Strobe, Macro , Dimmer
Control options: Audio-trigger
Operating mode: Master/Slave
Control & Programming
40”
6”
3”

5
Main Power Connection
Caution!
1. Do not connect fixture to a dimmer system.
2. This unit has Auto switching power supply. It will respond to 110V or 220V automatically
3. This unit must be earthed. (electronically grounded)
. Replace fuse only with the specified type and rating.
The occupation of the connection-cable is as follows:
1
2
3
1
3
2
DMX-512 Connection
This fixture is equipped with an electronic power supply that will let the unit operate from 90V to 2 0V from 50Hz to 60Hz
The fixture is equipped with 3 pin XLR Sockets for DMX input and output. The sockets are wired in parallel. Only use a shielded
twisted pair cable designed for RS- 85 and 3 pin XLR plugs and connectors in order to connect the controller with the fixture or
the fixture with another.
DMX—input DMX—output
1. Shield
2. Signal (-)
3. Signal (+)
Caution!
At the last fixture the DMX signal needs to be terminated with a terminator. Solder a 120
Ohm resistor between the (-) and the (+) signal into a 3 pin XLR plug and plug it in to the
last fixture on the signal run. Pre-manufactured terminator plugs are available for
purchase from your Mega-Lite dealer (HOS-DMXT).
Cable (USA) Cable (EU) Pin 110V
Black Brown
White
Green
Light Blue
Yellow/Green
Live
Neutral
Ground
L
N
L
L
220V
L
L
N
110V
Connection
220V
Connection
N
L
N

DMX Profile
6
Pro Color Strip Mode A (3 Channel)
DMX Chanel Function Description Value
1 LED Color Red LED intensity 0-255
2 LED Color Green LED Intensity 0-255
3 LED Color Blue LED Intensity 0-255
Pro Color Strip Mode P (5 Channel)
DMX Chanel Function Description Value
1 LED Color Red LED intensity 0-255
2 LED Color Green LED Intensity 0-255
3 LED Color Blue LED Intensity 0-255
" " " " " " " "
52 LED Color Red LED intensity 0-255
53 LED Color Green LED Intensity 0-255
5 LED Color Blue LED Intensity 0-255
Pro Color Strip Mode F (3 Channel)
DMX Chanel Function Description Value
1 LED Color Red LED intensity 0-255
2 LED Color Green LED Intensity 0-255
3 LED Color Blue LED Intensity 0-255
Strobe Strobe (slow to fast) 0-255
No Function 0-1
Color fade (slow to fast) 2-19
Color Snap (slow to fast) 20-39
Random (slow to fast) 0-59
Yellow 60-79
Purple 80-99
5 Macro Aqua 100-119
Color Snap (slow to fast) 120-139
Red Pulse 1 0-159
Green Pulse 160-179
Blue Pulse 180-199
Yellow Pulse 200-219
Aqua Pulse 220-229
White Pulse 230-2 9
White LED Full 250-255
6 Dimmer Dimmer Off to Full 0-255

7
Main Control Menu
The control board on the fixture base is your interface to access and control
all the functions on the unit. Its digital display gives you a code view of the
options and functions. The following will explain each function and its options.
Menu
DMX Addre
Red Dimmer
Press Enter to select the mode of operation.
Use the up/down keys to select the required DMX start channel.
This function allows you to dim the red LED’s on the whole strip. Press Enter use the up/down keys to select desired dimmer
settings. Press Enter to confirm the settings.
Up Down Enter
CONTROL BOARD
DMX Address Red Dimmer Green Dimmer Blue Dimmer Flash Fade Scroll Flash Scroll Chase Effect Chase Speed Sound Chase Sound Flash Sound Sensor
1-512 0-15 0-15 0-15 0-15 0-15 0-15 0-15 0-15 Loop Loop 0-15
Mode A (3 Channels) R,G,B
Mode P (5 Channels) R,G,B x 18
Mode F (6 Channels) R,G,B, Strobe, Macro, Dimmer
Green Dimmer
This function allows you to dim the green LED’s on the whole strip. Press Enter use the up/down keys to select desired dimmer
settings. Press Enter to confirm the settings.
Blue Dimmer
This function allows you to dim the blue LED’s on the whole strip. Press Enter use the up/down keys to select desired dimmer
settings. Press Enter to confirm the settings.
Fla h
This function allows you to strobe the LED’s on the whole strip in White color. Press Enter use the up/down keys to select de-
sired flash settings. Press Enter to confirm the settings.

8
Fade Scroll
This function allows you to fade the LED’s on the whole strip from one color to another. Press Enter use the up/down keys to
select desired fade speed settings. Press Enter to confirm the settings.
Fla h Scroll
This function allows you to change the LED’s on the whole strip from one color to another. Press Enter use the up/down keys to
select desired color change speed settings. Press Enter to confirm the settings.
Cha e Effect
This function allows you to select different chase patterns on the whole strip. Press Enter use the up/down keys to select de-
sired chase settings. Press Enter to confirm the settings.
Cha e Speed
This function allows you to select the speed of the chase that was selected on the Chase function . Press Enter use the up/down
keys to select desired chase speed settings. Press Enter to confirm the settings.
Sound Cha e
This function allows you to select the chase pattern that will be triggered via audio. Press Enter use the up/down keys to select
desired Chase settings. Press Enter to confirm the settings.
Sound Fla h
This function allows you to select the flash pattern that will triggered via audio. Press Enter use the up/down keys to select de-
sired dimmer settings. Press Enter to confirm the settings.
Sound Sen or
This function allows you to select the sensitivity of the audio sensor. Press Enter use the up/down keys to select desired dimmer
settings. Press Enter to confirm the settings.

Cleaning and maintenance
In tallation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electron-
ics checked by an expert every 2 years.
The following points have to be considered during the inspection:
1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.
2) There must not be any deformations on the housing, fixation and installation spots (ceiling, suspension, trussing).
3) The electronic power supply cables must not show any damages, material fatigue (e.g. porous cables) or sediments. Further
instructions depending on the installation spot and usage have to be adhered by a skilled installer and any safety problems
have to be removed.
Note: There is no serviceable parts inside the device except for the LED’s. Maintenance and service operations are to be carried
out by authorized dealers.
Replacing the fu e: Only replace the fuse with the same type and rating.
Replacing the power cable: If the power cable of this device becomes damaged, it has to be replaced by authorized dealers or
trained professional only.
Should you have further que tion , plea e contact your dealer.
9
Part Li t
3030-pcb Main PCB card
3000-triled Single Tri Chip LED
3030-ledm LED module
3030-ps Power Supply
050-case 8 Pro Color Strip Road Case
000-fh Fuse Holder
000-dis Display
Rigging the fixture
Caution!
1. The installations must be carried out by an authorized dealer or trained professional.
2. Unit may cause severe injures if you have doubts concerning the safety do not install.
3. Unit is to be 2 inches away from flammable materials (decoration material)
. Use high quality installation equipment to hang unit.
When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experience includ-
ing but not limited to calculating working loads, material being used and periodic safety inspections. If you lack these qualifica-
tions, do not attempt the installation yourself, instead use a professional structural rigger.
When rigging the unit always be secured with a secondary safety attachment. The installation location of the projector has got to
be built in the way that it can hold 10 times the weight for 1 hour with out any harming. Installation should be checked at least
one time a year by a skilled person.

Mega-Lite
5718 Kenwick St
San Antonio, TX 78238
Ph 210-68 -2600 Fax [phone]
www.mega-lite.com / [e-mail]
