MegaLite Linebot Q480 User manual

Table of Contents
Safety Information 3
Technical Information 4
Main Power Connection 5
DMX-512 Connection 5
Size and Weight 6
Main Control Menu 7
DMX Profile 9
Item List 12
Rigging the Fixture 13
Cleaning & Maintenance 13
USER MANUAL

3
Check that the unit has not been damaged during transport
Protection Against Fire
1. Maintain a minimum of 1 foot distance from any type of flame.
2. For indoor use only do not expose unit to rain or moisture.
3. Replace fuse only with the specified type and rating.
4. Do not install the unit to close to a heat source.
5. Make sure cable are properly secured
6. Maximum surface operating temperature 130º.
Protection Against Electrical Fire
1. Disconnect power before servicing.
2. For connection to main power supply proceed to page 5.
3. This unit must be earthed. (electronically grounded)
4. This fixture must not be left on for long periods of time.
Protection Against Mechanical Hazards
1. Use secondary safety chain when hanging unit.
2. Use quality clamps or bolts when positioning unit
3. Do not open unit while it is on, risk of electrical shock.
Check that the unit has not been damaged during transport
Protection Against Fire
Protection Against Electrical Fire
Protection Against Mechanical Hazards
What is Included
1pc Linebot Q480 Fixture
1pc Power Con to Nema 5-15 Cable
2pc Quick Connect Clamp Mounts
1pc User Manual

Technical Information
4
Part Numbers
Fixture Road Case
1188-Linebot Q480 CAS-1188-4 4 Unit Road Case
Mechanical Specifications
Tilt Angle: 210° 8/16 bit
DMX Connectors: Panel Mounted 5-pin XLR connectors in/out
Power Connections: Panel Mounted Seetronic Type Power in/out connection (Nema 5-15 to Seetronic power Female cable included)
Thermal: Maximum ambient temperature 104°f
Maximum surface temperature 140°f
Display:Digital
Fastening System: 2 Quick Release Clamp Mount
Lens Angle: 3°-54°
Zoom Control: 2 Zoom Sections 1-6 Zoom 1 / 7-12 Zoom 2
Guides: Removable Side Alignment Guides
Electrical Specifications
LED Type: 40watt RGBW
LED Qty: 12
Power Input: Universal 100 - 240V 50/60 Hz
Ballast: Electronic
Power Consumption:
Watts: 590W
Amps: 5.04A
Pixel Control: 12 Pixel Control
Protocol:
DMX Channels:
DMX 512
2 Mode of Operation
Mode 15 Ch: Tilt , Fine Tilt, Dimmer, Red, Green, Blue, White, Shutter Macro, Macro Speed, Color Macro, Macro Speed,
Strobe, Zoom 1, Zoom 2, Control
Mode 63 Ch: Tilt , Fine Tilt, Dimmer, Red, Green, Blue, White, Shutter Macro, Macro Speed, Color Macro, Macro Speed,
Strobe, Zoom 1, Zoom 2, RGBW X 12, Control
Operating Mode: Stand alone 255 step dimmer setting via display
Auto preprogram via display
Control & Programming

5
Main Power Connection
Caution!
1. Do not connect fixture to a dimmer system.
2. This unit has Auto switching power supply. It will respond to 110V or 240V automatically
3. This unit must be earthed. (electronically grounded)
4. Replace fuse only with the specified type and rating.
5. Power Link 3 units at 110V and 6 units at 220V
The occupation of the connection-cable is as follows:
DMX-512 Connection
This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to 60Hz
Caution!
At the last fixture the DMX signal needs to be terminated with a terminator. Solder a 120 Ohm re-
sistor between the (-) and the (+) signal into a 5 pin XLR plug and plug it in to the last fixture on the
signal run. Pre-manufactured terminator plugs are available for purchase from your Mega-Lite
dealer (P-DMXT).
Cable (USA) Cable (EU) Pin 110V
Black Brown
White
Green
Light Blue
Yellow/Green
Live
Neutral
Ground
L
N
220V
L
L
DMX—input DMX—output
1. Shield
2. Signal (-)
3. Signal (+)
5
3
4
2
11
2
3
4
5
4. N/A
5. N/A
The fixture is equipped with 5 pin XLR cable mounted sockets for DMX input and output. The sockets are wired in paral-
lel. Only use a shielded twisted pair cable designed for RS-485 and 5 pin XLR plugs and connectors in order to connect
the controller with the fixture or the fixture with another.

Size and Weight
6
Size 40.15" X 5.12" X 11.75"
Weight 38.3lb
Packaged 41.5" X 7.25" X 13.5" 39.5lb
5.12”
11.75”
8.68”
4.33”
39.76”
40.15” (with guide)

Main Control Menu
The control board on the fixture is your interface to access and control
all the functions on the unit. Its digital display gives you a code view of
the options and functions. The following will explain each function and
its options.
7
18668 Highway 16 N Helotes TX 78023
866-460-MEGA www.mega-lite.com
001
DMX
CH15
DMX Address
Press Home button. Use the up/down to select the DMX Address function
press Enter to engage
Use the up/down arrows to select the desired DMX start Channel. Please con-
sult your DMX Controller's Manual to find the correct DMX Start Channel
Systems Settings
DMX Address
Mode
Settings
System Info
001
15Ch
001
Mode
DMX: Allows you to select from the DMX Channel control method, Linebot offers 2 control methods Standard 15 Ch
and Extended 63 Ch. Please select one
Mode 15 Ch: Tilt , Fine Tilt, Dimmer, Red, Green, Blue, White, Shutter Macro, Macro Speed, Color Macro, Macro Speed, Strobe, Zoom 1, Zoom 2,
Control
Mode 63 Ch: Tilt , Fine Tilt, Dimmer, Red, Green, Blue, White, Shutter Macro, Macro Speed, Color Macro, Macro Speed, Strobe, Zoom 1, Zoom 2,
RGBW X 12, Control
Auto: Allows you to select from the 17 preprogram patterns that are built into the fixture. It also allows you to control
the speed of those programs from 01 to 99
Manual: Allows you to control each of the fixtures functions via the display menu. Control from 000 to 255 for each func-
tion
(note if fixture is powered off and back on the fixture will return to the last set mode function)
Systems Settings
DMX Address
Mode
Settings
System Info
001
16Ch
Press Home button. Use the up/down to select the Mode function press Enter
to engage. Select from the 4 different operating modes.
DMX DMX 63Ch
Auto PRO 01 SP 90
Manual
Slave

8
Settings
Display: Display On will keep the display on for the entire time the fixtures is powered on. Display Off will auto-
matically turn off the display if there is no changes after 30sec.
Display Rev: Allows you to select from the 17 preprogram patterns that are built into the fixture. It also allows you to
control the speed of those programs from 01 to 99
Focus Angle: Sets 3 Options for zoom angle to be used in the auto control mode
DMX Fail: This function will allow you to set a default setting if the DMX signal is ever lost or stops working.
Black Out: Will set all channel to 000 and turn light off
Manual: Will go to the set position set on your manual display setting
Auto: Will go to the selected Auto Preset and speed setting set in your auto option
Hold: Will hold last DMX commend until a new command signal is received
Language: Select ether English or Chinese
Systems Settings
DMX Address
Mode
Settings
System Info
001
16Ch
Press Home button. Use the up/down to select the Settings function press En-
ter to engage. Select from the 5 different setting options.
Display On
Display Rev Off
Focus Angle
DMX Fail
Language
Press Home button. Use the up/down to select the System Info function press
Enter to engage. Receive information on 3 different parameters
Firmware V1.1
Time Info 100H
Temp: A35C B38C
Systems Settings
DMX Address
Mode
Settings
System Info
001
16Ch
System Info
Firmware: Gives you information on the software version being used in the fixture.
Time Info: Provides information on the fixture usage, by counting the hours the fixture is powered on
Temp: Gives you information of the Driver cards A and B temperature.

9
DMX Profile
Linebot Q480 15 Ch Mode
DMX Channel Function Description Value Init
1Tilt Tilt 0-255 127
2Tilt Fine Tilt Fine 0-255 127
3Dimmer Dimmer (off to full) 0-255 255
4LED Color Red LED Intensity 0-255 255
5LED Color Green LED Intensity 0-255 255
6LED Color Blue LED Intensity 0-255 255
7LED Color White LED Intensity 0-255 255
No Function 0-1
Fade 1,2,3,4,5,6,7,8,9,10,11,12 2-12
Snap 1,2,3,4,5,6,7,8,9,10,11,12 13-23
Fade 12,11,10,9,8,7,6,5,4,3,2,1 24-34
Snap 12,11,10,9,8,7,6,5,4,3,2,1 35-45
Fade 1+12,2+11,3+10,4+9,5+8,6+7 46-56
Snap 1+12,2+11,3+10,4+9,5+8,6+7 57-67
Fade 6+7,5+8,4+9,3+10,2+11,1+12 68-78
Snap 6+7,5+8,4+9,3+10,2+11,1+12 79-89
Fade 1+2+3+4+5+6, then 7+8+9+10+11+12 90-100
Snap 1+2+3+4+5+6, then 7+8+9+10+11+12 101-111
8Shutter Macro Fade 1+2+3+4, then 5+6+7+8, then 9+10+11+12 112-122 0
(Select Color) Snap 1+2+3+4, then 5+6+7+8, then 9+10+11+12 123-133
Fade 9+10+11+12, then 5+6+7+8, then 1+2+3+4 134-144
Snap 9+10+11+12, then 5+6+7+8, then 1+2+3+4 145-155
Fade 1,1+2,2+3,3+4,4+5,5+6,6+7,7+8,8+9,9+10,10+11,11+12,12 156-166
Snap 1,1+2,2+3,3+4,4+5,5+6,6+7,7+8,8+9,9+10,10+11,11+12,12 167-177
Fade 12,12+11,11+10,10+9,9+8,8+7,7+6,6+5,5+4,4+3,3+2,2+1,1 178-188
Snap 12,12+11,11+10,10+9,9+8,8+7,7+6,6+5,5+4,4+3,3+2,2+1,1 189-199
Sanp All,-12,-11,-10,-9,-8,-7,-6,-5,-4,-3,-2,-1200-210
Snap All,-1,-2,-3,-4,-5,-6,-7,-8,-9,-10,-11,-12 211-221
Fade Random (1-12) 222-232
Snap Random (1-12) 232-255
9Macro Speed Shutter Macro Speed (slow to fast) 0-255 0
No Function 0-1
Red Chase, Over Green 2-12
Green Chase , Over Blue 13-23
Blue Chase, Over White 24-34
White Chase, Over Blue 35-45
1+2+3+4 Fade, 5+6+7+8 Fade, 9+10+11+12 Fade (different start point) 46-56
1+2+3+4 Snap, 5+6+7+8 Snap, 9+10+11+12 Snap (different start point) 57-67
1+2, 3+4, 5+6, 7+8, 9+10, 11+12 Fade (different start point) 68-78
1+2, 3+4, 5+6, 7+8, 9+10, 11+12 Snap (different start point) 79-89
1+2+3+4+5+6, 7+8+9+10+11+12 Fade (different start point) 90-100
1+2+3+4+5+6, 7+8+9+10+11+12 Snap (different start point) 101-111 0
10 Color Macro Red Center Chase, Over Green 112-122
Green Center Chase , Over Blue 123-133
Blue Center Chase, Over White 134-144
White Center Chase, Over Blue 145-155
Random Color Fade 156-166
Random Color Snap 167-177
1+2 Red, 3+4 White, 5+6 Blue, 7+8 Red, 9+10 White, 11+12 Blue 178-188
1+2+3 White, 4+5+6 Blue, 7+8+9 Green, 10+11+12 Red 189-199
1+2+3+4 Red, 5+6+7+8 White, 9+10+11+12 Blue 200-210
1+2+3+4 Green, 5+6+7+8 White, 9+10+11+12 Red 211-221
Color Snap (all) 222-232
Color Fade (all) 232-255
11 Macro Speed Color Macro Speed (slow to fast) 0-255 0
No Function 0-1
Strobe (slow to fast) 2-127
12 Strobe Strobe Pulse (slow to fast) 128-170 0
Random Strobe All (slow to fast) 171-213
Random 1-12 Strobe (slow to fast) 214-255
13 Zoom 1 Zoom 1 Lens 0-255 0
14 Zoom 2 Zoom 2 Lens 0-255 0
15 Control No Function 0-127 0
Motor Reset (Hold for 5 second) 128-255

10
Linebot Q480 63 Ch Mode
DMX Channel Function Description Value Init
1Tilt Tilt 0-255 127
2Tilt Fine Tilt Fine 0-255 127
3Dimmer Dimmer (off to full) 0-255 255
4LED Color Red LED Intensity 0-255 255
5LED Color Green LED Intensity 0-255 255
6LED Color Blue LED Intensity 0-255 255
7LED Color White LED Intensity 0-255 255
No Function 0-1
Fade 1,2,3,4,5,6,7,8,9,10,11,12 2-12
Snap 1,2,3,4,5,6,7,8,9,10,11,12 13-23
Fade 12,11,10,9,8,7,6,5,4,3,2,1 24-34
Snap 12,11,10,9,8,7,6,5,4,3,2,1 35-45
Fade 1+12,2+11,3+10,4+9,5+8,6+7 46-56
Snap 1+12,2+11,3+10,4+9,5+8,6+7 57-67
Fade 6+7,5+8,4+9,3+10,2+11,1+12 68-78
Snap 6+7,5+8,4+9,3+10,2+11,1+12 79-89
Fade 1+2+3+4+5+6, then 7+8+9+10+11+12 90-100
Snap 1+2+3+4+5+6, then 7+8+9+10+11+12 101-111
8Shutter Macro Fade 1+2+3+4, then 5+6+7+8, then 9+10+11+12 112-122 0
(Select Color) Snap 1+2+3+4, then 5+6+7+8, then 9+10+11+12 123-133
Fade 9+10+11+12, then 5+6+7+8, then 1+2+3+4 134-144
Snap 9+10+11+12, then 5+6+7+8, then 1+2+3+4 145-155
Fade 1,1+2,2+3,3+4,4+5,5+6,6+7,7+8,8+9,9+10,10+11,11+12,12 156-166
Snap 1,1+2,2+3,3+4,4+5,5+6,6+7,7+8,8+9,9+10,10+11,11+12,12 167-177
Fade 12,12+11,11+10,10+9,9+8,8+7,7+6,6+5,5+4,4+3,3+2,2+1,1 178-188
Snap 12,12+11,11+10,10+9,9+8,8+7,7+6,6+5,5+4,4+3,3+2,2+1,1 189-199
Snap All,-12,-11,-10,-9,-8,-7,-6,-5,-4,-3,-2,-1200-210
Snap All,-1,-2,-3,-4,-5,-6,-7,-8,-9,-10,-11,-12 211-221
Fade Random (1-12) 222-232
Snap Random (1-12) 232-255
9Macro Speed Shutter Macro Speed (slow to fast) 0-255 0
No Function 0-1
Red Chase, Over Green 2-12
Green Chase , Over Blue 13-23
Blue Chase, Over White 24-34
White Chase, Over Blue 35-45
1+2+3+4 Fade, 5+6+7+8 Fade, 9+10+11+12 Fade (different start point) 46-56
1+2+3+4 Snap, 5+6+7+8 Snap, 9+10+11+12 Snap (different start point) 57-67
1+2, 3+4, 5+6, 7+8, 9+10, 11+12 Fade (different start point) 68-78
1+2, 3+4, 5+6, 7+8, 9+10, 11+12 Snap (different start point) 79-89
1+2+3+4+5+6, 7+8+9+10+11+12 Fade (different start point) 90-100
1+2+3+4+5+6, 7+8+9+10+11+12 Snap (different start point) 101-111 0
10 Color Macro Red Center Chase, Over Green 112-122
Green Center Chase , Over Blue 123-133
Blue Center Chase, Over White 134-144
White Center Chase, Over Blue 145-155
Random Color Fade 156-166
Random Color Snap 167-177
1+2 Red, 3+4 White, 5+6 Blue, 7+8 Red, 9+10 White, 11+12 Blue 178-188
1+2+3 White, 4+5+6 Blue, 7+8+9 Green, 10+11+12 Red 189-199
1+2+3+4 Red, 5+6+7+8 White, 9+10+11+12 Blue 200-210
1+2+3+4 Green, 5+6+7+8 White, 9+10+11+12 Red 211-221
Color Snap (all) 222-232
Color Fade (all) 232-255
11 Macro Speed Color Macro Speed (slow to fast) 0-255 0
No Function 0-1
Strobe (slow to fast) 2-127
12 Strobe Strobe Pulse (slow to fast) 128-170 0
Random Strobe All (slow to fast) 171-213
Random 1-12 Strobe (slow to fast) 214-255
13 Zoom 1 Zoom 1 Lens 0-255 0
14 Zoom 2 Zoom 2 Lens 0-255 0
15 LED Color 1 Red LED Intensity 0-255 0
16 LED Color 1 Green LED Intensity 0-255 0
17 LED Color 1 Blue LED Intensity 0-255 0
18 LED Color 1 White LED Intensity 0-255 0

19 LED Color 2 Red LED Intensity 0-255 0
20 LED Color 2 Green LED Intensity 0-255 0
21 LED Color 2 Blue LED Intensity 0-255 0
22 LED Color 2 White LED Intensity 0-255 0
23 LED Color 3 Red LED Intensity 0-255 0
24 LED Color 3 Green LED Intensity 0-255 0
25 LED Color 3 Blue LED Intensity 0-255 0
26 LED Color 3 White LED Intensity 0-255 0
27 LED Color 4 Red LED Intensity 0-255 0
28 LED Color 4 Green LED Intensity 0-255 0
29 LED Color 4 Blue LED Intensity 0-255 0
30 LED Color 4 White LED Intensity 0-255 0
31 LED Color 5 Red LED Intensity 0-255 0
32 LED Color 5 Green LED Intensity 0-255 0
33 LED Color 5 Blue LED Intensity 0-255 0
34 LED Color 5 White LED Intensity 0-255 0
35 LED Color 6 Red LED Intensity 0-255 0
36 LED Color 6 Green LED Intensity 0-255 0
37 LED Color 6 Blue LED Intensity 0-255 0
38 LED Color 6 White LED Intensity 0-255 0
39 LED Color 7 Red LED Intensity 0-255 0
40 LED Color 7 Green LED Intensity 0-255 0
41 LED Color 7 Blue LED Intensity 0-255 0
42 LED Color 7 White LED Intensity 0-255 0
43 LED Color 8 Red LED Intensity 0-255 0
44 LED Color 8 Green LED Intensity 0-255 0
45 LED Color 8 Blue LED Intensity 0-255 0
46 LED Color 8 White LED Intensity 0-255 0
47 LED Color 9 Red LED Intensity 0-255 0
48 LED Color 9 Green LED Intensity 0-255 0
49 LED Color 9 Blue LED Intensity 0-255 0
50 LED Color 9 White LED Intensity 0-255 0
51 LED Color 10 Red LED Intensity 0-255 0
52 LED Color 10 Green LED Intensity 0-255 0
53 LED Color 10 Blue LED Intensity 0-255 0
54 LED Color 10 White LED Intensity 0-255 0
55 LED Color 11 Red LED Intensity 0-255 0
56 LED Color 11 Green LED Intensity 0-255 0
57 LED Color 11 Blue LED Intensity 0-255 0
58 LED Color 11 White LED Intensity 0-255 0
59 LED Color 12 Red LED Intensity 0-255 0
60 LED Color 12 Green LED Intensity 0-255 0
61 LED Color 12 Blue LED Intensity 0-255 0
62 LED Color 12 White LED Intensity 0-255 0
63 Control No Function 0-127 0
Motor Reset (Hold for 5 second) 128-255
11

Item List
12
Linebot Q480
Part Number Descripon
1188POW POWER SUPPLY
1188PCBMAI MAIN PCB
1188PCBDRIFCB DRIVER PCB FCB
1188PCBDRIFCD DRIVER PCB FCD
1188MOTZOO ZOOM MOTOR
1188MOTTIL TILT MOTOR
1188SENTIL TILT MOTOR SENSOR
1188SENZOO ZOOM SENSOR
1188CON5PI 5 PIN XLR IN AND OUT PANEL CONNECTION
1188CON3PI 3 PIN XLR IN AND OUT PANEL CONNECTION
1188FAN FAN
1188HOUSPR PRESSURE RELEASE TILT SPRING
1188BANTIL TILT BAND
1188SEALED LED OUTPUT RUBBER SEAL
1188HOUHAR ALUMINUM ARM HOUSING
1188HOUQUI QUICK RELEASE CLAMP MOUTS (SINGLE)
1188LEN GLASS LENS
1188LED 40w RGBW LED
1188HOUGUI BRASS ARM GUIDES

Cleaning and Maintenance
Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and
electronics checked by an expert every 2 years.
The following points have to be considered during the inspection:
1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.
2) There must not be any deformations on the housing, fixation and installation spots (ceiling, suspension, trussing).
3) The electronic power supply cables must not show any damages, material fatigue (e.g. porous cables) or sediments.
Further instructions depending on the installation spot and usage have to be adhered by a skilled installer and any
safety problems have to be removed.
Note: There is no serviceable parts inside the device. Maintenance and service operations are to be carried out by au-
thorized dealers.
Replacing the fuse: When possible only replace the fuse with the same type and rating.
Replacing the power cable: If the power cable of this device becomes damaged, it has to be replaced by authorized
dealers or trained professional only.
Should you have further questions , please contact your dealer.
13
Rigging the fixture
Caution!
1. The installations must be carried out by an authorized dealer or trained professional.
2. Unit may cause severe injures if you have doubts concerning the safety do not install.
3. Unit is to be 24inches away from flammable materials (decoration material)
4. Use high quality installation equipment to hang unit.
When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experi-
ence including but not limited to calculating working loads, material being used and periodic safety inspections. If you
lack these qualifications, do not attempt the installation yourself, instead use a professional structural rigger.
When rigging the unit always be secured with a secondary safety attachment. The installation location of the projector
has got to be built in the way that it can hold 10 times the weight for 1 hour with out any harming. Installation should be
checked at least one time a year by a skilled person.
Unit can be installed in any of these directions

14

Mega-Lite
18668 Highway 16N
Helotes, Texas 78023
Ph 210-684-2600 Fax [phone]
www.mega.lighting / [email protected]g
Customer Support
Mega Lite has a customer support line to provide set up help and to answer any question should you encounter a prob-
lem. Please visit our website for any other related technical documents. For service related issue please contact our
service dept.
Monday—Friday 9am to 6pm CST
Voice: 210-684-2600
E-mail: [e-mail]
Document
Version Date Fixture Soware Notes
1.0 06/01/2021 V1.0
Manual Version
Please Visit www.mega.lighting for the most up to date manual version
