MEKANIKA DUST SHOE Installation instructions manual

DUST SHOE
MOUNTING GUIDE 43 MM

M4x25
M6x40
M3x16
1
2
3
Assemble the PMMA parts with the
two M4x20 screws as shown. Place
the two M4 locknuts in the triangular
holes so that they lock when
tightened.
Attach the two chamfered washers
with the M3x16 screws as shown.
Use the M3 lock nuts to tighten them
Place the M6 rectangular nuts in
the provided pin. Tighten the M6x40
screws with the tooth lock washers.
Do not fully tighten at this stage
DUST SHOE
MOUNTING GUIDE

M3x10
4
5
6
Place the plastic adaptator into the
clamping ring and tighten it.
Insert the brush* part in the slot as
shown.
*You might have to cut the brush to
make it t the slot perfectly
Assemble the magnets on the last
PMMA part as shown with the two
M3x10 screws.
DUST SHOE
MOUNTING GUIDE

7Place the xed part of the dust shoe on
the spindle and tighten it with the 5mm
Allen key.
DUST SHOE
MOUNTING GUIDE

8Place the bottom part of the dust
shoe. The magnets should t into the
notches.
Try to manually pull down the
bottom part of the Dust Shoe
If you feel that the magnets
attraction is not strong enough, it
probably means that the magnets
are not touching the chamfered
washers. Slightly loosen the
locknuts to solve that problem.
Repeat the pull down test.
USE THE DUST SHOE ONLY IF THE MAGNETS STICK
CORRECTLY TO THE WASHERS
(if it’s not the case, refer to the note above)
!
