MELICONI Speedy Operating instructions

Thank you for choosing Meliconi.
This simplified universal remote control contains all the main
functions of most TV remote controls of the brands listed
on the back.
Keep your Instructions and Code Booklet for future
reference.
USING THE KEYS AND FUNCTIONS
GB Use
To select the next
programme or to turn
ON your TV.
Mute key.
Control the volume
using +/-.
ON/OFF to turn OFF
your TV and, in
some cases, to turn
ON your TV.
To select the
previous programme
or to turn ON
your TV.
Press them together to
turn ON your TV on
programme 1.
To select an
external terminal.
FITTING THE BATTERIES
Before programming and using the
remote control, insert batteries.
The remote control requires 2 new
AAA/LR03 alkaline batteries.
Insert the batteries as shown:
• Batteries must be changed once a year.
• Change the batteries if the light indicator starts to flash during use.
The batteries are low.
• When removing batteries, insert the new ones within 5 minutes or
you may have to reprogram your remote control.
• Make a note of the code for your TV on the adhesive label supplied
inside the battery compartment cover. This note will be handy if you
have to reprogram your remote control.

1.Find the code for your TV in
the code list (see middle of
this booklet) . Make a note
of the code found. It has 4
+and -signs, indicated to
the side (e.g. Thomson - +
- +).
2.Make sure that the TV is ON.
3.Hold down the and
keys simultaneously until
the light indicator at the top
starts to flash indicating
that the remote control is
in programming mode.
4.Release the keys. Within 12
seconds, enter the brand
code previously identified
(e.g. - + - +).
5.Point the remote control at
the TV. Press and release
the key slowly several
times. STOP when your TV
goes OFF.
6.When your TV is OFF, press
the and keys
simultaneously. When you
release the keys, three
flashes indicate that the
search operation has been
completed correctly.
SET-UP
Read these instructions carefully before programming
your remote control!
Once you have programmed Speedy, you can turn ON your
TV in three ways:
•Press or .
•Press and simultaneously: this sends the code
for programme 1.
•Press .
To program Meliconi Speedy remote control, follow the
indications in paragraph Aor B.
P
-
+
PP
-
BRAND SEARCH PROGRAMMING
MODE
A
+
P
7. IF YOU DO NOT HAVE THE
PROGRAMME SELECTION
KEYS ON YOUR ORIGINAL
REMOTE CONTROL
If your remote control does
not have the programme
selection keys (e.g. / ,
+/-, CH+/-..etc) once you
have programmed Speedy,
you can still select the
programmes from 0 to 9, as
follows:
•Hold down the and
keys simultaneously until
the light indicator starts to
flash indicating that the
remote control is in
programming mode.
•Release the keys and
press 8 times within
12 seconds.
Three flashes indicate that
the operation has been
completed correctly.
•Make sure you can change
programmes from 0 to 9
using the and keys.
If not, repeat the search
operation, starting from
point 3.
P
-
+
P
P
-
+
P
+
P
NOTE:
When – is indicated, you must press or .
When +is indicated, you must press or .
To return to programme 1 directly, press and simultaneously.
.
P
--
+
+
P
+
PP
-
AV
AV
AV

1.Make sure that the TV is
ON.
2.Hold down the and
keys simultaneously until
the light indicator at the top
starts to flash indicating
that the remote control is
in programming mode.
3.Release the keys, point the
remote control at your TV
and press and release the
key, slowly several
times. STOP when your TV
goes OFF.
4.When your TV is OFF,
press the and keys
simultaneously. When you
release the keys, three
flashes indicate that the
search operation has been
completed correctly.
5.
IF YOU DO NOT HAVE THE
PROGRAMME SELECTION
KEYS ON YOUR ORIGINAL
REMOTE CONTROL
If your original remote
control does not have the
programme selection keys
This operation may take a few minutes.
Identify and take note of the TV code which you have
searched for, following the code noting procedure
(see "PROGRAMMED CODE NOTING" section).
NOTE:
DURING THE SEARCH OPERATION, THE LIGHT INDICATOR
FLASHES MORE QUICKLY.
THE LIGHT INDICATOR STOPS FLASHING.
The remote control leaves the programming mode and the
light indicator stops flashing:
• if no keys are pressed for 12 seconds
• if an invalid brand code is entered
• if you press keys other than those indicated
• if the code search list is completed.
In this case, switch to programming mode B.
(e.g. / , +/-, CH+/-
..etc), once you have
programmed Speedy,
you can still select the
programmes from 0 to 9,
as follows:
•Hold down the and
keys simultaneously until
the light indicator at the top
starts to flash indicating
that the remote control is
in programming mode.
•Release the keys and
press 8 times within
12 seconds.
Three flashes indicate that
the operation has been
completed correctly.
•Make sure you can change
programmes from 0 to 9
using the and keys.
If not, repeat the search
operation, starting from
point 2.
P
-
+
P
AV
GLOBAL SEARCH REMOTE CONTROL
PROGRAMMING
B
Additional check
Check that all 7 keys are operating correctly. If the
commands work incorrectly or erratically, you have probably
entered a code for a similar but different remote control.
In this case, repeat the search procedure from point 3 until
all keys respond correctly to the commands sent.
If you cannot find the right code after several attempts,
switch to programming mode B.
AV
AV
P
-
+
P
+
P

Additional check
Check that all 7 keys are operating correctly. If the
commands work incorrectly or erratically, you have probably
entered a code for a similar but different remote control.
In this case, repeat the search procedure from point 2 until all
the keys respond correctly to the commands sent.
NOTE:
DURING THE SEARCH OPERATION, THE LIGHT INDICATOR
FLASHES MORE QUICKLY.
THE LIGHT INDICATOR STOPS FLASHING
The remote control leaves the programming mode and the
light indicator stops flashing:
•if no keys are pressed for 12 seconds
•if you press keys other than those indicated
•if the code search list is completed. In this case, visit
www.meliconi.it or contact the call center.
Identify and take note of the TV code which you have
searched for, following the code noting procedure
(see "PROGRAMMED CODE NOTING" section).
RE-PROGRAMMING YOUR REMOTE CONTROL
BY ENTERING THE CODE NOTED DOWN
If the remote control is no longer programmed because it has
been left without batteries for a long time or has flat batteries,
you can re-program it quickly as follows:
1.Hold down the and keys simultaneously until the
light indicator at the top starts to flash indicating that the
remote control is programming.
2.Release the keys and, within 12 seconds, using the
and keys, enter the eight-sign code which you noted
down before. At the end, three flashes indicate that the code
has been saved correctly. If not, try the code entry procedure
again from point 1.
When you have programmed Speedy Meliconi, note down the
code on the label in the battery compartment cover.
To find the code for your remote control:
1. Hold down the and keys simultaneously until the light
indicator at the top starts to flash indicating that the remote
control is searching for the code.
2. Release the keys and, within 12 seconds, press and
simultaneously.
3. Release and and pay attention to the flashing of the
LEDs: a long flash corresponds to a +while a short flash
corresponds to a -. Note the sequence of the 8 flashes and
note them down on the label in the battery compartment
cover, from left to right.
PROGRAMMED CODE NOTING
P
-
+
P
P
-
+
P
P
-
+
P
AV
AV

WARRANTY: 2 years
The warranty ceases to be valid if the product is tampered with or
used incorrectly.
Remote control model Speedy
Purchase date
Agent's stamp
PROBLEM
The TV does not respond
and the light indicator does
not light up when you press
a key.
The TV or VCR does not
respond but the light
indicator does light up.
The TV does not respond
and the light indicator
flashes.
Not all remote control
commands are working
correcting.
The code for your TV brand
is not in the Code list.
The and keys do not
select the programmes.
TROUBLESHOOTING
SOLUTION
Check that the batteries are
fitted correctly. If necessary,
replace them with 2 new 1.5 V
AAA/LR03 alkaline batteries.
Check that the batteries are new
and that the remote control is
pointing at the appliance without
any obstacles in the way. If
required, reset the remote
control code, following the
programming procedure
A or B .
Batteries are low. Replace them.
You may have used the wrong
code. Reset the remote control
code, following the programming
procedure A or B .
Set the remote control code,
following the global search
programming procedure B .
The original remote control may
not have had this function. In
this case, set the code (press
8 times) as described in
paragraphs A or B .
If you have any queries about Speedy:
•read this booklet carefully – this will help you to solve
almost all problems
•consult our Internet site www.meliconi.it to answer all
your queries more easily and quickly.
INFO-LINE
