Mercado Medic 805192 Assembly instructions

PINCH PROTECTION FOR
REAL 9000 PLUS BASE
ENG
Translation of original assembly instruction
Instructions for assembly & handling
Dok.nr: 20-07045
Rev: 01
Skapad: 2020-05-01
Uppdaterad: 2020-05-01

2
Pinch protection for REAL 9000 PLUS base
20-07045-01
Table of content
1. Item list .......................... 3
2. Warnings .......................... 3
3. Assembly instructions ............... 4
3.1. Preparations for retrofitting.............. 4
3.2. Apply the base’s brake .................. 5
3.3. Install the pinch protection.............. 6
3.4. Release the brake ...................... 6
3.5. Tighten the screws ..................... 7
3.6. Check ................................ 7
4. Care instructions .................... 8
5. Destruction and recycling ............ 8

3
Pinch protection for REAL 9000 PLUS base Item list
20-07045-01
1. Item list
2. Warnings
Warning!
Risk of crushing between brake cam and base during assembly of the pinch protection.
A 805192 Pinch protection R+L kit f brake cam f PLUS base black
805193 Pinch protection R+L kit f brake cam f PLUS base white
A

4
Pinch protection for REAL 9000 PLUS base Assembly instructions
20-07045-01
3. Assembly instructions
The pinch protection should be retrofitted when it is missing on an existing base. It is especially important to have
the pinch protection installed a base with backward brake. Most of the instructions shown will be for a base with
backward brake, but the instructions also apply for bases with forward brake.
3.1. Preparations for retrofitting
Remove existing screws. These are not needed and can therefore be destroyed or recycled.
Base with backward brake Base with forward brake

5
Pinch protection for REAL 9000 PLUS base Assembly instructions
20-07045-01
3.2. Apply the base’s brake
Ensure that the plastic bushing does not fall out; see the information
panelbelow.
Note the risk of crushing
between brake cam and
base.

6
Pinch protection for REAL 9000 PLUS base Assembly instructions
20-07045-01
3.3. Install the pinch protection
Ensure that the pinch protection covers the opening for the brake cam in the
base. Theorientation for installing the pinch protection differs depending on
whether the basehas forward brake or backward brake.
Push the pinch protection on fully until it stops.
3.4. Release the brake
Note the risk of crushing
between brake cam and
base.

7
Pinch protection for REAL 9000 PLUS base Assembly instructions
20-07045-01
3.5. Tighten the screws
Ensure that the plastic bushing is in position
before tightening the screws; see step 3.3.
3.6. Check
Now verify that the pinch protection is securely fastened and that the brake cam is covered by the
pinch protection. Test the brake to ensure it is working and check that the brake legs move freely.
Base with backward
brake
Base with forward
brake

8
Pinch protection for REAL 9000 PLUS base Care instructions
20-07045-01
4. Care instructions
No specific care instructions for this item. Follow the instructions in the manual.
5. Destruction and recycling
1. Sort as metal
2. Sort as plastic
1 2
