Mercia Garden Products 03DTSHPN0409SHPB-V1 Instruction manual

REGISTER FOR YOUR
ANTI-ROT
GUARANTEE TODAY
PLEASE SCAN HERE:
**Protim Aquatan T5 (621)**
Your building has been dip treated with Aquatan.
Aquatan is a water-based concentrate which is diluted with water, the building has been treated by the
correct application of Aquatan solution and then allowed to dry.
Aquatan is a decorative nish to colour the wood, which is applied industrially to timber fence panels and
garden buildings.
Aquatan undiluted contains: boric acid, sodium hydroxide 32% solution, aqueos mixture of sodium dioctyl
sulphosuccinat and alcohols: 2, 4, 6-trichlorophenol.
Measure
under the
head
Measure
overall
length
Screws & Nails Bolts To identify the
xings required
for each step use a
measuring tape.
03DTSHPN0409SHPB-V1
DIP TREATED SHIPLAP PENT 4X9 DOUBLE SHED DOOR PACK B
2mm Drill bit
x2 Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All buildings should be
erected by two adults
For ease of assembly, you
MUST pilot drill all screw
holes and ensure all screw
heads are countersunk.
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied) including a Phillips screw-
driver, Stanley knife, Wood saw, Step ladder, Hammer and a Drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
LOCATION FOR YOUR GARDEN BUILDING
A minimum of 60cm should be left around the perimeter of your garden building to allow access for maintenance,
annual treatment and to allow air ow around the building.
Where possible you should avoid placing your garden building underneath large trees to prevent the tree causing
damage to the building.
TIMBER
As with all natural materials, timber can be aected during various weather conditions. For the duration of heavy
or extended periods of rain, swelling of the wood panels may occur. Warping of the wood may also occur during
excessive dry spells due to an interior moisture loss. Unfortunately, these processes cannot be avoided but can be
helped. It is suggested that the outdoor building is sprayed with water during extended periods of warm sunshine
and sheltered as much as possible during rain or snow.
Once your garden building has been installed it will need to be treated as soon as possible and annually to prevent
the timber from deteriorating and to waterproof it. This is required to maintain the anti-rot guarantee.
Dip Treated buildings - Require a preservative treatment to protect against rot and decay and a waterproof treat-
ment to prevent water ingress
Pressure Treated buildings - Require a waterproof treatment to prevent water ingress
Log Cabins - Are supplied untreated and require a preservative and waterproong treatment.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base
dimensions, The base should be slightly smaller than the external measurement of the building, i.e. The cladding
should overlap the base, creating a run o for water. It is also recommended that the oor be at least 25mm above
the surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens
products independently tested to EN71 level, we cannot accept responsibility for your safety whilst erecting or
using this product.
For ease of assembly, you
will need a tape measure to
check dimensions of
components.
P 1
Please retain product label and instructions for future reference
General Instructions

P 2
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied) including a Phillips screw-
driver, Stanley knife, Wood saw, Step ladder, Hammer and a Drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
LOCATION FOR YOUR GARDEN BUILDING
A minimum of 60cm should be left around the perimeter of your garden building to allow access for maintenance,
annual treatment and to allow air ow around the building.
Where possible you should avoid placing your garden building underneath large trees to prevent the tree causing
damage to the building.
TIMBER
As with all natural materials, timber can be aected during various weather conditions. For the duration of heavy
or extended periods of rain, swelling of the wood panels may occur. Warping of the wood may also occur during
excessive dry spells due to an interior moisture loss. Unfortunately, these processes cannot be avoided but can be
helped. It is suggested that the outdoor building is sprayed with water during extended periods of warm sunshine
and sheltered as much as possible during rain or snow.
Once your garden building has been installed it will need to be treated as soon as possible and annually to prevent
the timber from deteriorating and to waterproof it. This is required to maintain the anti-rot guarantee.
Dip Treated buildings - Require a preservative treatment to protect against rot and decay and a waterproof treat-
ment to prevent water ingress
Pressure Treated buildings - Require a waterproof treatment to prevent water ingress
Log Cabins - Are supplied untreated and require a preservative and waterproong treatment.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base
dimensions, The base should be slightly smaller than the external measurement of the building, i.e. The cladding
should overlap the base, creating a run o for water. It is also recommended that the oor be at least 25mm above
the surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens
products independently tested to EN71 level, we cannot accept responsibility for your safety whilst erecting or
using this product.
03DTSHPN0409SHPB-V1
Overall Dimensions:
Width = 1205mm
Depth = 2913mm
Height = 2157mm
Base Dimensions:
Width = 1133mm
Depth = 2800mm
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Nail Bag
There may be extra screws present in the nail bag
Please retain product label and instructions for future reference
Door Panel QTY 1
AI-01S11SHDD1135X2099-V1
Back Panel QTY 1
AI-S11SHPP1135X1940-V1
Side Panel QTY 2
AI-S11SHPPTOV1375X1687-V1
Floor QTY 2
AI-R11MBF1133X1400-V1
Roof QTY 2
AI-S11MBPR1143X1444-V1
Door QTY 2
AI-S11FBMBZBD479X1680-V1
Front Gable Top QTY 1
AI-S21SHDBPGT1375X451-V1
9
Back Cover Trim - 12x40x1909mm QTY 1
S1240-1909mm
10
Front Cover Trim - 12x40x2055mm QTY 2
S1240-2055mm
11
Fascia Trim - 12x95x1143mm QTY 2
S1295-1143mm
12
Door Cover Trim - 12x60x770mm QTY 2
S1260-770mm
1 2 3 4
5 6 8
13
Roof Framing - 28x28x1143mm QTY 2
FS2828-1143mm
17 19
15
16
Door block - 28x28x140mm QTY 4
FS2828-140mm
Floor Joining block - 28x28x250mm QTY 3
FS2828-250mm
18
14
Gable Framing - 27x44x1345mm QTY 2
F2744-1345mm
Pad Bolt QTY 1
PI-07-0035
T-hinge QTY 6
PI-07-0021
Turn Button QTY 4
PI-07-0034
Felt
PI-01-0013
20
50mm Screw x 72
Felt Tacks x 50
30mm Screw x 78
60mm Screw x 12
40mm Screw x 28
20mm Screw x 6
Rear Gable Top QTY 1
AI-S21SHDBPGT1375X374-V1
7

P 3
Please retain product label and instructions for future reference
Pre Assembly
Before assembling remove the transportation
blocks from the bottom of each panel.
Take care removing the blocks as to not damage
the panels. Tap with a at headed screwdriver
and hammer.
Dispose of the blocks once removed.
1
6
6
17
12
Pre drill
hole
30mm
screw
20mm
screw
17
Step 1
Parts Needed - No.1 QTY 1
- No.6 QTY 2
- No.12 QTY 2
- No.17 QTY 6
Fix the T-hinges (No.17) to each of the Doors (No.6)
with 4x30mm screws per hinge making sure to
screw into the framing on the rear of the Doors.
Once the T-hinges are xed into position lay the
Door Panel (No.1) at on the ground x the door in
position using 3x30mm screws per hinge.
To create a Master and Secondary door x the Door
Trims (No.12) to one of the doors overlapping with
the other door as shown using 3x20mm screws per
trim.
6x20mm Screw
42x30mm Screws
12
Secure the oor (No. 4) to the
Floor Blocks (No.16) using 6x30mm
screws per oor.
6x30mm Screws
Pre drill
hole
30mm
screw
Step 2
Parts Needed - No. 4 QTY 1
- No. 16 QTY 3
4
16
16
16
Pre Assembly
Follow the instructions for the 9x9 Corner
Summerhouse (03DTSHCR0909FGD4TW),
however DO NOT attach the Felt, Rear Cover
Trims or the Fascia Trims.
Not attaching these parts allows the exten-
sion to be xed in place.
Your building should look as shown.

P 4
Please retain product label and instructions for future reference
Step 4
Place the two asembled Floors (No.4)
up against the 9x9 Corner Summer-
house on a at, level surface. Fix into
position using 4x60mm screws as
shown.
**To position the side shed on the
left, position the oor on the left and
x in the same way shown.
4x60mm Screws
Pre drill
hole
60mm
screw
Step 5
Right Side Shed only
Parts Needed- No.23 QTY 1 (9x9
Corner Summer house)
Parts Needed - No.1 QTY 1
Cut down the underhand framing (X)
by 70mm on both ends. It may be
necessary to re-attach the framing
and attach the rest of the side shed
following the same steps.
Fix the side of the Door Panel (No.1)
against the side of the 9x9
Corner Summerhouse Window
Panel as shown using
4x60mm screws.
Do not secure the building
to the Floor until the roof is tted.
4x60mm Screws
Pre drill
hole
60mm
screw
1
X
**To position the side shed on the
LEFT, you do not need to alter the
under hang framing.
Pre drill
hole
60mm
screw
Step 6
Parts Needed- No.2 QTY 1
Fix the side of the Back Panel (No. 2)
against the side of the 9x9 Corner
Summerhouse Back Panel as shown
using 4x60mm screws.
Do not secure the building to the
Floor until the roof is tted.
4x60mm Screws
2
Pre drill
hole
30mm
screw
Step 3
Parts Needed - No. 4 QTY 1
Secure the oor (No. 4) to the assembly
from Step 2, using 6x30mm screws per
oor.
6x30mm Screws
4

P 5
Please retain product label and instructions for future reference
Pre drill
hole
50mm
screw
12
3
3
Step 7
Parts Needed- No. 3 QTY 2
Fix the two Side panels (No.3) together
using 3x50mm screws. Then x the
side panels to the Door (No.1) and
back panel (No.2) using 3x50mm
screws at each corner.
*9x9 Corner Summerhouse not
shown*
Do not secure the building to the
Floor until the roof is tted.
9x50mm Screws
Pre drill
hole
50mm
screw
78
Step 8
Parts Needed- No.7 QTY 1
- No.8 QTY 1
Place the Gable Tops (No. 7 & 8) on top
of the assembled Side Panels (No. 3)
slotting the boarding of the gable over
the top of the boarding of the side
panel as shown.
Fix with 8x50mm screws per gable top
as shown in diagram.
8x50mm Screws
3
Internal Edge External Edge
Step 9
Secure the Gable Tops (No.7 &
No.8) in place against the Door
Panel (No.1) and Back Panel
(No.2) using 2x50mm screws per
Gable Top.
4x50mm Screws
Pre drill
hole
50mm
screw
7 8 1
2
Step 10
Parts Needed- No.14 QTY 2
Place the Gable Framing (No.14)
on the top of the Gables, ensuring
they are ush with either end of the
gables, leaving a gap between the
two piece of framing as shown.
Fix with 3x50mm screws per
Gable Top.
6x50mm Screws
Pre drill
hole
50mm
screw
14 14
14 14

P 6
Please retain product label and instructions for future reference
Step 11
Parts Needed- No.5 QTY 2
Place the two Roof Panels (No. 5) at, in-line
and upside down. Secure them together
along the central bearings using 6x50mm
screws, ensuring to stagger the screws so they
do not collide.
6x50mm Screws
Pre drill
hole
30mm
screw
5
5
Step 12
Parts Needed- No.13 QTY 2
Before placing the Roof (No.5) on the
building, place the roof upside down and
attach the Roof Trim pieces (No. 13) ush
to the end, perpendicular to the roof
bearers. Fix in place as shown with 4x50mm
screws per roof trim.
8x50mm Screws
Pre drill
hole
50mm
screw 5
5
13
13
Step 13
Place the Roof Panel (No.5) on
top of the building, ensure
the Roof Framing (No.13) slot
over each side.
Fix the roof panel onto the
extension using 12x50mm
screws as shown.
Secure the roof to the
Summerhouse roof internally,
using 3x50mm screws through
the roof bearers.
15x50mm Screws
Pre drill
hole
50mm
screw
5
Summerhouse roof
50mm
screw
Pre drill
hole
Step 14
Once the Roof is in position the
extension can be xed in position.
Fix the building in place by using
16x50mm screws.
16x50mm Screws

P 7
Please retain product label and instructions for future reference
Step 15
Parts Needed- No. 20 QTY 1
- No. 30 QTY 1 (9x9 Corner Summer House)
Cut ve strips from the roll of felt, 1X2918mm (5),
1x4475mm (4), 1x5000mm (3), 1x4029mm (2) and
1x2004mm (1) in length. Place felt on top of the roof panels and
align as shown in the diagram, ensuring strip 5overhangs the
front by 50mm and strip 1overhangs the back by 200mm,
with equal spacing at each corner.
Use a Fascia as a guide to mark out the angled cuts, including
50mm overhang.
Cut the sides as shown in the diagram at the dotted lines,
using Fascia width as a cutting guide. Cut the triangle with
50mm overhang, again using a Fascia as a guide.
150x Felt Tacks
Felt
tacks
2004
4029
5000
4475
2918
1000
1000
1000
1000
1000
4
1
2
3
5
*Ensure strip 1 is the rst piece placed down, then lay
sheet 2, then sheet 3, then sheet 4 and nally sheet 5.
Make sure each sheet overlaps the next by at least
100mm, creating a run o.
HANDLE
WITH CARE
12
3
4
9
10
10
Step 16
Parts Needed - No.9 QTY 1
- No.10 QTY 2
Fix the Cover Trims (No.9 and No.10)
plus the remaining cover trims from
the 9x9 Corner Summerhouse into
place using 3x40mm screws per Trim.
Fix the Cover Trim (No.17 & 25) from
the 9x9 Summer House using
3x40mm screws per Trim. Ensure that
they are equally spaced across the
panels, and covering the panel join.
One of the Cover Trims will need to be
cut to t over the gables and side
panels.
15x40mm Screws
40mm
screw
Pre drill
hole
25
17
*Cut down
trims to t
11
11
Step 17
Parts Needed - No.11 QTY 2
Fix the Fascia Trims (No.11) plus the
remaining Fascia Trims from the 9x9
Corner Summerhouse into place
using 3x40mm screws per Trim.
27x40mm Screws
40mm
screw
Pre drill
hole

P 7
Please retain product label and instructions for future reference
P 8
Step 18
Parts Needed- No. 15 QTY 2
- No. 19 QTY 1
Fix two Door blocks (No.15) to the
back of the Doors (internally) with
2x30mm screws per block going
through the front of the door
boards and into the block behind.
Fix the Pad Bolt (No.19) to one of
the Doors (No.6) using 12x30mm
screws.
16x30mm Screws
30mm
screw
Pre drill
hole
19
15 15
18
15
Step 19
Parts Needed- No.15 QTY 2
- No.18 QTY 2
Fix the Door blocks (No.15) to the top
and bottom of the Doors (internally)
with 2x30mm screws per block going
through the front of the door boards
and into the block behind
Fix one Turn Button (No.18) to each of
the Door blocks (No.15) using
1x30mm screw per turn button.
6x30mm Screws
30mm
screw
Pre drill
hole
Step 20
Parts needed - No. 18 QTY 2
Fix the Turn Buttons (No.18) above
each of the Doors using 1x30mm screw
per turn button.
2x30mm Screws
*These turn buttons help to keep
your doors straight during high &
low levels of moisture content in
the air.
Pre drill
hole
30mm
screw
18

Please retain product label and instructions for future reference
It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.
AFTER TREATMENT:
score around protective
cover on glazing and
carefuly peel
covering back

P 8




















































2





1












3
4

































¡




1




2























¡



