Mercia Garden Products 01DTOVAX0406DDNW-V1 User manual







 

 
















  



2mm Drill bit
x2 





























































 

















































ANY QUESTIONS?
Scan the QR code to
contact us via our customer
portal.
PLEASE SCAN HERE:


 
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Building Content:
Door Gable QTY 1
AI-01R11OVAGSD1707X1961-V1
Back Gable QTY 1
AI-01R11OVAGP1707X1961-V1
Plain Panel QTY 2
AI-R11OVPP1180X1567-V1
1 2 3 4
Floor QTY 1
AI-R11OSBF1175X1753-V1
5
Door QTY 2
AI-R11FBMBZBD437X1660-V1
9
7
10
11
Fascia 7x60x1016mm QTY 4
OVLPR60-1016mm
Cover Trims 12x45x1575mm QTY 4
S1245-1575mm
Ridge Bar 28x28x1124mm QTY 1
F2828-1124mm
6
8
Door Beading Strip 7x28x1590mm QTY 2
OVLPR28-1590mm
12
Eaves Frame 28x28x1195mm QTY 2
F2828-1195mm
Door Strip - 12x60x770mm QTY 2
S1260-770mm
Door Block - 28x28x150mm QTY 2
F2828-150mm
Roof Sheet QTY 2
PI-03-0386
19
Finial QTY 2
SHED DIAMOND FINIAL
14
T Hinge QTY 4
PI-02-1043
15
17
18
16
L-Bracket QTY 2
PI-07-0012
13
Turn Button QTY 2
PI-07-0034
Hasp and Staple QTY 1
PI-07-0207
Felt
Nail Bag
There may be extra screws present in the nail bag
Felt Tacks x 60
30mm Screw x 81
50mm Screw x 30
40mm Screw x 34
20mm Screw x 6
Overall Dimensions:
Width = 1233mm
Depth = 1904mm
Height = 1986mm
Base Dimensions:
Width = 1175mm
Depth = 1753mm


 
Pre Assembly
Before assembling remove the transportation
blocks from the bottom of each panel.
Take care removing the blocks as to not damage
the panels. Tap with a at headed screwdriver
and hammer.
Dispose of the blocks once removed.
Step 1
Parts needed - No. 1 QTY 1
No. 5 QTY 2
No. 14 QTY 4
Place the doors (No.5) within the door
gable opening. Fix the T Hinges (No.14)
onto the door and Door Gable as shown.
Ensure that the screws go through the
cladding and into the framing behind.
28x30mm screws
30mm
screw
Pre drill
hole
**PLEASE NOTE** Before tting the
hinges, ensure the inner door framing
is the correct way round as shown in
the illustration below.
IMPORTANT: Pre-drill before xing screws.
14
1
5
The correct positioning of the Double Doors


 
Step 2
Parts needed - No. 4 QTY 1
Place the oor (No.4) on a rm and
level base, ensure the base has
suitable drainage free from areas
where standing water can collect.
See the front page for base
requirements.
4
Step 3
Parts needed - No. 2 QTY 1
No. 3 QTY 1
Fix the corners of the Back Gable (No.2) and
the Plain Panel (No.3) with 3x50mm screws
as shown in the illustration.
Do not secure the building to the oor until
the roof is tted.
Position the panels so there is equal spacing
between the oor and cladding on all sides.
3x50mm Screws
Pre drill
hole
50mm
screw
IMPORTANT: Pre-drill before xing screws.
3
2
Step 4
Parts needed - No. 1 QTY 1
No. 3 QTY 1
Fix the end of the Plain Panel (No.3) to the
Back Panel with 3x50mm screws as shown
in the illustration.
Fix the corners of the Door Gable (No.1) to
the ends of the Plain Panels with 6x50mm
screws as shown in the illustration.
Do not secure the building to the oor
until the roof is tted.
Position the panels so there is equal
spacing between the oor and cladding
on all sides.
9x50mm Screws
1
3
Pre drill
hole
50mm
screw
IMPORTANT: Pre-drill before xing screws.
Step 5
Parts needed - No. 7 QTY 1
No. 17 QTY 2
Attach the L-Brackets (No. 17) to
each end of the Ridge Bar (No.7)
with 2x30mm screws per L-Bracket.
Place the Ridge Bar (No.7) in
between the Gables (No. 1 & 2) in
line with the central uprights within
the gables.
Secure the Ridge Bar (No. 7) to the
central uprights with 2x30mm
screws per L-Brackets (No. 17), as
shown in the illustration.
8x30mm Screws
30mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
7
17
7
7
17


 
30mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
7
19
19
10
19
19
7
Step 6
Parts needed - No. 10 QTY 2
No. 19 QTY 2
Fix the eaves frames (No.10)to each roof
sheet (No.19)using 3x30mm screws per
eave.
6x30mm Screws
Place the Roof Sheets (No.19) on top of
the building making sure the roof sheet
meets the pointed edge of the Gables
(No. 1 & 2) and it sits well on the top of the
Ridge Bar (No. 7).
**The edges of the roof sheets must be
ush with the outer cladding of the
Gables (No. 1 & 2).**
From the top, x directly through the roof
sheets (No.19) and into the ridge bar
(No.7) below using 3x30mm screws per
roof sheet.
It is essential that the ridge bar (No. 7) and
the roof sheet (No. 19) pull together when
xed with 30mm screws. You may require
another person pushing the ridge bar
(No.7) up from below to achieve this.
6x30mm Screws
Pre drill
hole
40mm
screw
IMPORTANT: Pre-drill before xing screws.
Step 7
Use 40mm screws to x the roof sheets
(No. 19) down the sides and at the
bottom being sure that the screws attach
into the framing below.
Ensure there is no more than 300mm
between each screw.
18x40mm Screws
Step 8
Once the roof is xed,
attach the building to the oor
with 50mm screws.
Ensure the screws go through
the panel into the oor faming.
18x50mm Screws
b
50mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.


 
Step 9
Parts needed - No. 16 QTY 1
Cut the felt (No. 16) into three sheets at
1300mm (L) X 1000MM (W).
Lay the sheets onto roof in the orher shown in
diagram, ensuring there is a 50mm overhang
around the sides.
Apply the felt tacks with a 100mm space per
tack.
60x Felt Tacks
16
16
16
Felt
tacks
100mm
HANDLE
WITH CARE
1 2
3
4
12
3
8
8
Step 10
Parts needed - No. 8 QTY 4
Fit the Cover Trims (No.8) over each
corner of the building as shown in the
illustration using 30mm screws. Trim the
length of the cover trims to the required
size before tting if necessary.
12x30mm Screws
8
8
30mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
*Cut down
trims to t
Step 11
Parts needed - No. 6 QTY 4
No. 13 QTY 2
Fit the Fascias (No.6) to the roof
over the felt and secure in place
with 40mm screws as shown.
Followed by adding the Finials
(No.13) over the Fascias using x2
40mm screws per Finial.
16x40mm Screws
13
6
6
6
13
6
40mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.


 
a
12
12
12
IMPORTANT: Pre-drill before xing screws.
Pre drill
hole
30mm
screw
Step 12
Parts needed - No. 12 QTY 2
Attach the Door Blocks (No. 12) to the
framing inside one of the doors (No. 5)
using 2x30mm screws, in the positions
illustrated. Screw through the door
cladding into the blocks using 30mm
screws
4x30mm Screws
9
Step 13
Parts needed - No. 9 QTY 2
No. 15 QTY 2
9
15
Pre drill
hole
30mm
screw
a
b
a
b
*These turn buttons help to
keep your doors straight during
high and low levels of moisture
content on the air.*
IMPORTANT: Pre-drill before xing screws.
Place the door beading strips (No.9)
inbetween the door and door gable as
shown in the illustration and x into
position using 4x30mm screws per strip.
Fix a turn button (No.15) to the top and
bottom inner door blocks with 1x30mm
screw per turn button making sure the
doors can be locked to the framing.
10x30mm Screws
b
a
Step 14
Parts needed - No. 11 QTY 2
No. 18 QTY 1
b
a
11
18
Pre drill
hole
30mm
screw
IMPORTANT: Pre-drill before xing screws.
20mm
screw
Fix the door strips (No. 11) onto the
front of the doors (opposite door to
the turn buttons on the back) securing
each trim with 3x20mm screws.
Fix the Staple (No.18) to one of the
doors making sure that the screws go
into the framing behind.
Check the Hasp (No.18) is in line with
the staple and screw into the Door
making sure that the screws go into
the framing behind.
6x20mm Screws
7x30mm Screws

 

It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.
AFTER TREATMENT:
score around protective
cover on glazing and
carefuly peel
covering back



















¡








¡


¡

 





