Mercia Garden Products 05DTOVAX0307DD-V1 User manual










 
















  



2mm Drill bit
x2 





























































 

















































ANY QUESTIONS?
Scan the QR code to
contact us via our customer
portal.
PLEASE SCAN HERE:


 

8
Some steps within this set of instructions come with an added video guide for your
convenience. These can be accessed via the QR code and used to aid you in constructing that
step. See below for how to use.
You can also nd all the videos on our youtube channel:
https://www.youtube.com/@merciagardenproducts8716/videos
ACCESSING VIDEO GUIDES...
1.Find the QR code within the instruction step...
2. Open camera app...
3. Scan QR code...
4. Watch the video...
On your personal smart device (phone, tablet etc), open your camera app or QR code scanner
app.
To scan the QR code, hold the camera over the QR code so that it can be seen on the screen.
Once the QR code has been registered, follow the prompts on your device to open the video.
(This will vary depending on your device.)
Please note: Ensure to use the back camera of your smart device as this will scan the QR code more
accurately.

The video guide will now be displayed on your smart device.
Parts Needed- No. QTY 1
No. QTY 1
No. QTY 1
Step..... 
Within the instruction step, there will be an icon in the top right that has a QR code in. This
is where the video can be accessed from.
Please note: not every step has a video guide.
Disclaimer: The garden building constructed in the video guides may be
constructed dierently to your building. Please ensure to read your instructions
carefully to avoid error.
ACCESSING VIDEO GUIDES...

 

Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Overall Dimensions:
Width = 2101mm
Depth = 863mm
Height = 1789mm
Base Dimensions:
Width = 1980mm
Depth = 795mm
Content
456
Door QTY 2
AI-R11FBMBZBD781X1320-V1
Roof Sheet QTY 2
PI-03-0001-V1
Floor QTY 2
AI-R11OSBF990X795-V1
7
Fascia - 7x60x1095mm QTY 4
S760-1095MM
8
Cover Trim - 7x45x1324mm QTY 4
S745-1324MM
10
Eaves Frame - 28x28x825mm QTY 2
F2828-825MM
11
Ridge Bar - 28x28x744mm QTY 1
F2828-744M
9
Door Trim - 12x27x1261mm QTY 2
S1227-1261MM
23
1
Door Gable QTY 1
AI-05R11OVAGDD1922X1692-V1 Plain Side QTY 2
AI-R11OVPP800X1327-V1
Plain Gable QTY 1
AI-05R11OVAGP1922X1692-V1
Bolt Block 28x28x132mm QTY 2
F2828-132MM
12
13 14 15
16 18
Finial QTY 2
SHED DIAMOND FINIAL
T-hinge QTY 4
PI-07-0021
Hasp and Staple QTY 1
PI-07-0207
Turn Button QTY 2
PI-07-0034
L Bracket QTY 2
PI-07-0012
Felt
PI-01-0025
17
Nail Bag
There may be extra screws present in the nail bag
50mm Screw x 28
Felt Tacks x 30
30mm Screw x 105

 

Pre Assembly
Before assembling remove the transportation blocks from the bottom of each
panel.
Take care removing the blocks as to not damage the panels. Tap with a at headed
screwdriver and hammer.
Dispose of the blocks once removed.
PLEASE SCAN HERE:
Parts Needed - No. 1 QTY 1
No. 4 QTY 2
No. 14 QTY 4
Place the door gable (No. 1) on to
a at surface and place both doors
(No. 4) into the door apeture.
Locate the four t hinges (No. 14)
onto the doors and door gable
ensuring they sit over the door
framing. Fix the hinges to the door
and door gable using 7x30mm
screws per hinge.
28x30mm Screws
Step 1
1
4
14
30mm
screw Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
PLEASE SCAN HERE:
Parts Needed - No. 6 QTY 2
Place the oors (No. 6) on a rm and
level base, ensure the base has suitable
drainage, free from areas where water
can collect (see front page for base
requirements).
Position the oors side by side as shown
in the diagram. Fix together using 4 x
50mm screws alternating the xing
poisiton along the length of the oor.
4x50mm Screws
Step 2
Pre drill
hole
50mm
screw
6
6
IMPORTANT: Pre-drill before xing screws.
Step 3 IMPORTANT: Pre-drill before xing screws.
Parts Needed - No. 2 QTY 1
No. 3 QTY 1
Locate the Plain Gable (No.3) and the
Plain Side (No.2) on top of the oor as
shown.
Fix the panels together at the corner
using 3x50mm screws, as shown in
diagram.
Do not secure the building to the oor
until the roof is tted.
3x50mm Screws
3
2
Pre drill
hole
50mm
screw a
a
a
a

 

IMPORTANT: Pre-drill before xing screws.
1
2
Pre drill
hole
50mm
screw
11
Step 4
Parts Needed - No. 1 QTY 1
No. 2 QTY 1
Locate the Assembled Door Gable
(No.1) and the Plain Side (No.2) on top
of the oor as shown.
Fix the panels together at the corner
using 3x50mm screws, as shown in
diagram.
Do not secure the building to the oor
until the roof is tted.
9x50mm Screws
a
a
a
a
a
a
a
a
a
a
Step 5 IMPORTANT: Pre-drill before xing screws.
Parts Needed - No. 11 QTY 1
No. 17 QTY 2
Place the Ridge Bar (No. 11) in
between the door and plain gables.
Ensure the top corner of the ridge
bar sit ush with the top of the
gables.
Fix the ridge bar to both gables
using one L Bracket (No. 17) for each
end. Secure in place using 4x30mm
screws per L Bracket.
8x30mm Screws
Pre drill
hole
50mm
screw
17
11
17
Step 6 IMPORTANT: Pre-drill before xing screws.
Parts Needed - No. 5 QTY 2
No. 10 QTY 2
Attach the Eaves Frame (No. 10) to the
roof sheets (No.5) using 3x30mm
screws per eaves.
Place the assembled roof sheets onto
the building and, ensuring the roof
sheet sits square over the building.
Secure the in place using 8x30mm
screws ensuring the screws go through
the sheet into the panel framing below.
22x30mm Screws
Pre drill
hole
30mm
screw 10
5
Step 7 IMPORTANT: Pre-drill before xing screws.
Pre drill
hole
50mm
screw
Secure the building to the oor
internally using 12x50mm
screws.
12x50mm Screws
b
b
bb
b
b
b

 

18
Step 8
Parts Needed - No. 18 QTY 1
Cut one strip of felt (No. 18) to 2350mm
and lay onto the roof as shown in the
diagram, ensuring there is 50mm of
overhang around each side
Fix the felt in place using felt tacks spaced
100mm apart.
30 x Felt Tacks
Felt
tacks
100mm
HANDLE
WITH CARE
1 2
3
4
Step 9
Parts Needed - No. 7 QTY 4
No. 13 QTY 2
Attach the fascias (No. 7) to the front
and back of the building, ensuring to
trap the felt between the gable and
the fascia. Use 3x30mm screws per
fascia ensuring to x through to the
panel framing behind.
Attach the Finial (No. 13) to the
fascias at the front and the back of
the building using 2x30mm screws
per nial.
16x30mm Screws
IMPORTANT: Pre-drill before xing screws.
30mm
screw Pre drill
hole
7
13
13
7
7
7
Step 10
Parts Needed - No. 8 QTY 4
Locate the cover trims (No.8) to the
front and back of the building as shown
in the illustration.
Fix in place using 3x30mm screws per
cover trim ensuring to x through to the
panel framing behind.
12x30mm Screws
IMPORTANT: Pre-drill before xing screws.
30mm
screw Pre drill
hole
8
8
8

 

Step 11
Parts Needed - No. 12 QTY 2
Attach the bolt blocks (No. 12) to the
doors using 2 x 30mm screws, in the
positions illustrated. Screw through the
door cladding into the blocks using
30mm screws.
4x30mm Screws
30mm
screw Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
12
12
Step 12
Parts Needed - No. 16 QTY 4
Fix the turn buttons (No. 16) to the bolt
blocks at the top and bottom of the
door using a 30mm screw per turn
button.
2x30mm Screws
30mm
screw Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
16
16
16
Step 13
Parts Needed - No. 9 QTY 2
Locate the Door Strips (No.9) onto the
door gable and x into place using
3x30mm screws. ensure that the screw
is parallel withthe door frame when
xing, as shown in the close up view.
6x30mm Screws
30mm
screw Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
9
9
9
Step 14
Parts Needed - No. 15 QTY 4
Screw the Staple (No.15) to the left
Door, make sure the Hasp (No.15) is in
line with the staple and screw into the
right Door.
7x30mm Screws
30mm
screw Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
15

 

It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.

