Merivaara Practico 145000 User manual

Merivaara Corp.
Tarmontie 2-4, Fl - 15860 HOLLOLA, FINLAND
Tel. [phone]
[email protected]
www.merivaara.com
Document ID: DO1141-1-6.en
Version: 1.6 –30.01.2023
Complete: 12.11.2019 Original document
Type: Instructions
Practico 145000 Operating Table User
Manual

3 (108) Document ID: DO1141-1-6.en Version: 1.6 –30.01.2023
Practico 145000 Operating Table User Manual
Contents
Contents
1 Warnings, cautions and notes...................................................................................................................6
1.1 Overview ..........................................................................................................................................6
1.2 General warnings ..............................................................................................................................6
1.3 Mains warnings .................................................................................................................................8
1.4 Internal battery warnings ..................................................................................................................10
1.5 Patient handling warnings ................................................................................................................ 11
1.6 High frequency equipment and EMC warnings...................................................................................12
1.7 Hand control unit warnings ...............................................................................................................13
1.8 Accessories warnings ......................................................................................................................13
1.9 Operating table adjustment warnings ................................................................................................14
1.10 Care and cleaning warnings ...........................................................................................................15
1.11 Recycling warnings ........................................................................................................................16
2 General ...................................................................................................................................................17
2.1 About the user manual .....................................................................................................................17
2.2 Fluent Usability since 1901...............................................................................................................17
2.3 Intended use ...................................................................................................................................17
2.4 Essential performance .....................................................................................................................18
2.5 User identification ............................................................................................................................18
2.6 User training....................................................................................................................................18
2.7 Standards and directives..................................................................................................................19
2.8 Liability ...........................................................................................................................................19
2.9 Operating characteristics..................................................................................................................19
2.10 Table models and configuration.......................................................................................................20
2.11 Package label................................................................................................................................21
3 Use..........................................................................................................................................................23
3.1 Before use ......................................................................................................................................23
3.2 Construction....................................................................................................................................24
3.2.1 Main parts .............................................................................................................................24
3.2.2 Symbols and label markings....................................................................................................24
3.3 Control devices and functions...........................................................................................................26
3.3.1 Main switch............................................................................................................................26
3.3.2 Electrical connections and powering up the table ...................................................................... 27
3.3.3 Recharging of battery and mains use .......................................................................................29
3.3.4 Hand control unit....................................................................................................................30
3.3.5 Locking system ......................................................................................................................31
3.3.5.1 Lock ............................................................................................................................31
3.3.5.2 Unlock .........................................................................................................................31
3.3.5.3 Brake emergency release..............................................................................................32
3.3.6 LED indicator lights and sounds ..............................................................................................33
3.4 Table top configurations ...................................................................................................................35
3.4.1 Practico back sections ............................................................................................................37
3.4.2 Integrated kidney bridge back section ......................................................................................38
3.4.3 Practico beach chair back section............................................................................................39
3.4.4 Eye-ENT back section ............................................................................................................40
3.4.5 Attaching and removing table top sections ...............................................................................40
3.4.5.1 Attach ..........................................................................................................................40
3.4.5.2 Remove .......................................................................................................................41
3.4.6 Mattresses.............................................................................................................................41
3.4.6.1 Visco-elastic foam (VEF) mattresses .............................................................................42
3.4.7 Practico leg sections...............................................................................................................43
3.4.7.1 Motorised and non-motorised leg sections ......................................................................43
3.4.7.2 Undivided one-piece leg sections...................................................................................43
3.4.7.3 Divided leg sections ......................................................................................................44
3.4.7.4 Leg section configurations and SWL ..............................................................................44
3.4.8 Transporting a patient on the table...........................................................................................49

Version: 1.6 –30.01.2023 Document ID: DO1141-1-6.en 4 (108)
Practico 145000 Operating Table User Manual
Contents
3.4.9 Precautions before adjusting the operating table.......................................................................50
3.4.10 Adjusting operating table.......................................................................................................54
3.4.10.1 5th wheel ...................................................................................................................55
3.4.10.2 -0- position adjustment ................................................................................................55
3.4.10.3 Trendelenburg and Anti-Trendelenburg adjustment .......................................................56
3.4.10.4 Height adjustment.......................................................................................................56
3.4.10.5 Lateral tilt ...................................................................................................................57
3.4.10.6 Back section adjustment..............................................................................................57
3.4.10.7 Leg section adjustment................................................................................................58
3.4.10.8 Longitudinal shift (slide)...............................................................................................58
3.4.10.9 Flex and reflex positions ..............................................................................................59
3.4.10.10 Head section adjustment ...........................................................................................60
3.4.11 Position presets....................................................................................................................60
3.4.12 Back-up control panel ...........................................................................................................61
3.4.12.1 Function buttons .........................................................................................................62
3.4.13 Foot control unit ...................................................................................................................63
3.4.13.1 Foot control unit functions............................................................................................63
3.4.13.2 Connect foot control unit..............................................................................................63
3.4.13.3 Disconnect foot control unit..........................................................................................64
3.4.13.4 Using the foot control unit ............................................................................................65
4 Practico operating table accessories ......................................................................................................66
4.1 Operator table accessory warnings ...................................................................................................66
4.2 Recommended accessories .............................................................................................................67
5 Technical data .........................................................................................................................................73
5.1 Identification plate............................................................................................................................73
5.2 Labeling and symbols ......................................................................................................................74
5.2.1 Symbols and label markings....................................................................................................74
5.3 Specifications..................................................................................................................................76
5.3.1 Environmental specifications...................................................................................................76
5.3.2 Electrical specifications...........................................................................................................76
5.3.3 Classification data..................................................................................................................77
5.3.4 Surface materials ...................................................................................................................77
5.3.5 Adjustment ranges .................................................................................................................78
5.3.5.1 -0- position ...................................................................................................................78
5.3.5.2 Approvals.....................................................................................................................79
5.3.6 Weights and dimensions.........................................................................................................79
6 Cleaning..................................................................................................................................................82
6.1 Cleaning warnings and cautions .......................................................................................................82
6.2 Cleaning .........................................................................................................................................83
6.2.1 Cleaning mattresses and plastics ............................................................................................83
6.2.2 Cleaning metal parts...............................................................................................................84
6.3 Disinfection .....................................................................................................................................85
6.3.1 Disinfecting mattresses and plastics ........................................................................................85
6.3.2 Disinfecting metal parts ..........................................................................................................85
7 Recycling ................................................................................................................................................87
7.1 Metals and plastics ..........................................................................................................................87
7.1.1 Gas springs ...........................................................................................................................87
7.1.2 Electronic waste and batteries.................................................................................................88
8 Maintenance and service.........................................................................................................................89
8.1 Safety during maintenance procedures .............................................................................................89
8.2 Before starting any service or maintenance work................................................................................90
8.2.1 Daily maintenance..................................................................................................................90
8.3 Monthly maintenance (by Merivaara trained service personnel only)....................................................92
8.4 Annual maintenance (by Merivaara trained service personnel only) .....................................................94
8.5 Troubleshooting...............................................................................................................................96
8.5.1 Possible situations .................................................................................................................96

5 (108) Document ID: DO1141-1-6.en Version: 1.6 –30.01.2023
Practico 145000 Operating Table User Manual
Contents
8.6 Contact information..........................................................................................................................98
9 Guidance and manufacturer's declaration ..............................................................................................99
9.1 Electromagnetic compatibility ...........................................................................................................99
User training guidelines T404658–2............................................................................................................103
Practico 145000 Service inspection report T404454–2................................................................................ 105

1 Warnings, cautions and notes
1.1 Overview
To ensure optimal patient safety, all users must read this user manual carefully and be
familiar with the correct use of the product as well as all warnings, cautions and notes.
Warnings and notes found in this user manual are indicated with symbols as follows:
WARNING
Please observe to ensure user, maintenance personnel and patient safety.
CAUIN
Please observe in order to avoid causing damage to the equipment or its parts.
Note: Please observe in order to improve equipment properties.
1.2 General warnings
WARNING
Use the Practico table only in facilities made for medical purposes. Read this manual
thoroughly, and be familiar with its content before using this equipment.
WARNING
Any serious incident that has occurred in relation to the device must be reported to the
manufacturer and the competent authority of the state in which the user andor patient is
established
WARNING
ou can adjust the operating table with several active control units: with a cabled hand
control unit, foot switch and back-up panel. The movement of the table stops, if another
control unit is used simultaneously. Only one person can be responsible for adjusting the
table
WARNING
The antistatic properties of the table require the use of original brand mattresses.
Practico 145000 Operating Table User Manual
Warnings, cautions and notes
Version: 1.6 –30.01.2023 Document ID: DO1141-1-6.en 6 (108)

7 (108) Document ID: DO1141-1-6.en Version: 1.6 –30.01.2023
WARNING
Use only permitted table top configurations that are illustrated in this manual.
WARNING
Use only accessories recommended by Merivaara Corp.
WARNING
The table weighs about 225 kg.
WARNING
Note that the safe working load (SWL) of a Practico operating table may vary according to
the chosen leg section.
WARNING
IP 4 classification is valid only when the mains cable is disconnected.
WARNING
No modification of this equipment is allowed.
WARNING
Do not use combustible anaesthetic gases with the Practico operating table.
WARNING
Always follow manufacturer instructions when using electrosurgery devices to ensure
proper precautions and to minimie risks regarding patient burns, explosions and electric
shock to the patient or surgeon.
WARNING
Make sure that the table is used, transported and stored as described in this manual.
WARNING
Make sure there are no exposed metal portions of the operating table (especially the leg
and back section pivots, or accessory rails), that the patient or the surgical personnel can
touch during electrosurgery. Haard of burn injuries when using return electrodes
WARNING
The operating table must only be used in the electromagnetic environment specified in the
EMC guidance. The customer or the user of the operating table must assure that it is used
in such an environment.
Practico 145000 Operating Table User Manual
Warnings, cautions and notes

WARNING
The Practico operating table has been tested according to IECEN 60601-1 to ensure
proper electromagnetic compatibility. Other products used in the vicinity of the Practico
operating table must also comply with this standard. If they do not comply, interference
between products may occur. Please contact the appropriate manufacturer if any
problems arise.
WARNING
Use of accessories, transducers and cables other than those specified or provided by the
manufacturer of this equipment (Merivaara Corp.) can result in increased electromagnetic
emissions or decreased electromagnetic immunity of this equipment. This can result in
inproper operation.
WARNING
Portable and mobile radio frequency (RF) communications equipment can affect the
Practico operating table.
WARNING
Portable RF communications equipment (including peripherals such as antenna cables
and external antennas) must not be used no closer than 30 cm (12 inches) to any part of
the ME equipment or ME system, including cables specified by the manufacturer.
Otherwise, the table may not work properly.
1.3 Mains warnings
WARNING
In case of malfunction, use the main switch to stop all table functions and disconnect the
mains cable from the wall socket. The main switch is located on the table base casing. To
stop all table movements, turn the switch lever to OFF position (the lever tip pointing
downwards) and disconnect the mains cable.
WARNING
Use only mains cables rated as 250 V, 10 A, 5 m.
Practico 145000 Operating Table User Manual
Warnings, cautions and notes
Version: 1.6 –30.01.2023 Document ID: DO1141-1-6.en 8 (108)

9 (108) Document ID: DO1141-1-6.en Version: 1.6 –30.01.2023
WARNING
If the main switch is turned to OFF position (downwards), all table functions are blocked.
WARNING
Do not block mains inlet with external item(s).
WARNING
Disconnect the mains cable from the table and set the main switch to OFF position before
cleaning the table. Haard of electric shock
WARNING
Disconnect the mains cable from the table before any service procedures. 100–240 V is
used in power unit in the table base. Haard of electric shock.
WARNING
When you recharge the battery, first plug the mains cable to the operating table inlet, then
to a wall outlet and turn the main switch on.
WARNING
When recharging is completed, disconnect the mains cable first from the wall outlet and
then from the table inlet.
WARNING
Set the main switch to OFF position (downwards) when the table is not in use or if it is
stored for a longer period of time. This eliminates the possibility of unintended use and
saves the battery capacity.
WARNING
Use of alternative isolation transformer model (for example, transformer is integrated in the
operating room electrical power network) is accepted, if on-site verification is performed
before operating table is used in surgical operation:
 Leakage currents must be measured according to IECEN 62353.
 Measured leakage currents must fulfill limits according to IECEN 60601-1.
WARNING
Do not simultaneously touch the operating table external electrical connections and the
patient during the operation.
WARNING
The antistatic properties of the table require the use of original brand mattresses.
Practico 145000 Operating Table User Manual
Warnings, cautions and notes

WARNING
Use the potential equaliation conductor with patient monitoring equipment. The conductor
terminal is located next to appliance inlet at the back side end of the lower frame. Look at
the Medical Electrical System requirements as specified in standard IEC/EN 60601-1,
Clause 16.
WARNING
When using high frequency surgical equipment, for example, diathermy or defibrillation
equipment, prevent the patient from coming into contact with metal parts of the table or
accessories. Do not place the patient on wet or damp surfaces or electrically conductive
pads. Haard of burn injuries
WARNING
The operator and other personnel must not touch the patient or the operating table or any
other equipment which is in contact with the patient during defibrillation. Always follow the
instructions for use provided by defibrillator manufacturer when you defibrillate a patient
on the operating table.
1.4 Internal battery warnings
WARNING
The operating table must only be operated on its internal battery if the integrity of the
protective earth conductor arrangement is in doubt.
WARNING
If the operating table has been in the cold, allow it to warm up at room temperature for at
least 6 hours before recharging the battery or switching it on, to allow any condensation
formed to evaporate.
WARNING
Recharge the battery before use.
WARNING
When you recharge the battery, first plug the mains cable into the table appliance inlet and
then to the wall outlet and turn the main switch on.
WARNING
When recharging is completed, disconnect the mains cable first from the wall socket, after
that from the table appliance inlet.
Practico 145000 Operating Table User Manual
Warnings, cautions and notes
Version: 1.6 –30.01.2023 Document ID: DO1141-1-6.en 10 (108)

11 (108) Document ID: DO1141-1-6.en Version: 1.6 –30.01.2023
Note: Recharge the battery overnight after a days use. This way the table will be
always ready for use and the battery will have a longer service life. Typical service life for
the battery is about 3 years if recharged properly.
Note: If the main switch is turned to the OFF position (downwards), all table
functions are blocked, including recharging of the battery. When the power is ON, the
green battery status LED on the hand control unit and back-up control unit light up.
1.5 Patient handling warnings
WARNING
Adjust the table top to the horiontal position (-0- position) with the hand control unit before
transporting a patient.
WARNING
Place the patient in the longitudinal centre of the table top only.
WARNING
Use extreme caution when transporting the table with a patient on. Transporting of the
table with a patient on requires two persons. To maximie patient safety utilie proper
restraint methods during transport.
WARNING
When using high frequency surgical equipment, for example diathermy or defibrillation
equipment, take care to prevent the patient from coming into contact with metal parts of
the operating table or accessories.
WARNING
Do not place the patient on wet or damp surfaces or electrically conductive pads when
using diathermy or defibrillation. Haard of burn injuries.
WARNING
Do not transport the table over thresholds higher than 10 mm.
Practico 145000 Operating Table User Manual
Warnings, cautions and notes

WARNING
The instructions for use provided by the defibrillator manufacturer must always be followed
when defibrillating a patient on the operating table. The operator and other personnel must
not touch the patient or the operating table or any other equipment that is in contact with
the patient during defibrillation. The patient must not be in contact with any metal parts of
the operating table during defibrillation.
WARNING
Max. patient weight with the sliding seat or basic section is 280 kg.
1.6 High frequency equipment and EMC warnings
WARNING
Always follow the manufacturers instructions when using high frequency equipment, for
example diathermy or defibrillation equipment.
WARNING
The operating table must only be used in the electromagnetic environment specified in the
EMC guidance. The customer or the user of the operating table must assure that it is used
in such an environment.
WARNING
The operating table has been tested according to IECEN 60601-1 to ensure proper
electromagnetic compatibility. Other products used in the vicinity of the operating table
must also comply with this standard. If they do not comply, interference between products
may occur. Please contact the appropriate manufacturer if any problems arise.
WARNING
Portable and mobile radio frequency (RF) communications equipment can affect the
operating table.
WARNING
When using high frequency surgical equipment, prevent the patient coming into contact
with metal parts of the operating table or accessories. Always follow the equipment
manufacturers instructions. Do not place the patient on wet or damp surfaces or
electrically conductive pads. Haard of burn injuries.
WARNING
Use a potential equaliation conductor with patient monitoring equipment. Place the
connector at the base of the table.
Practico 145000 Operating Table User Manual
Warnings, cautions and notes
Version: 1.6 –30.01.2023 Document ID: DO1141-1-6.en 12 (108)

13 (108) Document ID: DO1141-1-6.en Version: 1.6 –30.01.2023
CAUIN
The operation table has been tested to be compatible with HF surgical equipment.
However, the operating table must be monitored for unwanted movements. If any
unwanted movements occur, turn off the main switch to prevent further movements.
Note: The emissions characteristics of this equipment make it suitable for use in
industrial areas and hospitals (CISPR 11 class A). If it is used in a residential environment
(for which CISPR 11 class B is normally required), this equipment might not offer adequate
protection to radio-frequency communication services. The user might have to move the
operating table to another place or different position.
1.7 Hand control unit warnings
WARNING
Use the back-up control panel (override panel) functions in the case of hand control unit
malfunction.
WARNING
eep the hand control unit on the lever under the head section, especially during
transport.
1.8 Accessories warnings
WARNING
Use only accessories recommended by the table manufacturer.
WARNING
Use of accessories, transducers and cables other than those specified or provided by the
manufacturer of this equipment (Merivaara Corp.) can result in increased electromagnetic
emissions or decreased electromagnetic immunity of this equipment. This can result in
inproper operation.
WARNING
Always follow manufacturer instructions when using electrosurgery devices to ensure
proper precautions and to minimie risks regarding patient burns, explosions and electric
shock to the patient or surgeon.
WARNING
Ensure that all accessories are properly mounted and not damaged or worn.
Practico 145000 Operating Table User Manual
Warnings, cautions and notes

WARNING
Check the function of the accessory locking and adjustments.
WARNING
Use potential equaliation conductors with patient monitoring equipment. The terminal is
on the table base.
See Medical Electrical System requirements as specified in standard IEC/EN 60601- 1,
Clause 16.
WARNING
The head and leg section gas springs can be disposed of as metal waste after nitrogen
gas and oil has been removed. Instructions for gas releasing are available from your sales
representative.
WARNING
Use of the operating table adjacent to or stacked with other equipment can result in
improper operation. If the operating table is used in that way, compatibility with the other
equipment must be observed to verify proper operation.
WARNING
The operator and other personnel must not touch the patient or the operating table or any
other equipment which is in contact with the patient during defibrillation. Always follow the
instructions for use provided by defibrillator manufacturer when you defibrillate a patient
on the operating table.
1.9 Operating table adjustment warnings
WARNING
Activate the floor lock before adjusting the table.
WARNING
Avoid collision between accessories and external obstacles.
WARNING
eep the patients fingers, hands or other parts of the body away from the edges of the
back, leg or seat section frames and pivoting points.
WARNING
Check that the latches of the table top sections lock correctly. Incorrect attachment of table
sections can cause injury or damage the equipment.
Practico 145000 Operating Table User Manual
Warnings, cautions and notes
Version: 1.6 –30.01.2023 Document ID: DO1141-1-6.en 14 (108)

15 (108) Document ID: DO1141-1-6.en Version: 1.6 –30.01.2023
WARNING
Downwards adjusted leg or back section may hit the table base or column casings
depending on the used height, Trendelenburg or tilt angle adjustments. Risk of causing
damage to the operating table and creating pinching haard.
WARNING
Do not place any objects on the base or under table top section. This can damage the
equipment during adjustments.
WARNING
If the table top seat section is adjusted towards the leg section, adjustment of the back
section stops automatically before colliding to the column.
WARNING
If the leg section of the table is pressed down without a patient load, play can be felt on the
operating table top. Under normal operating conditions, a patient is positioned on the table
top which eliminates the play and therefore causes no issues for normal use.
WARNING
Activate the floor lock before adjusting the table. Only Trendelenburg adjustments can be
made if the floor lock is not activated.
1.10 Care and cleaning warnings
WARNING
Disconnect the mains cable from the table and turn the main switch to the OFF position
before cleaning the table.
WARNING
Clean mattresses with neutral detergent (ph 7– 8) only. The antistatic properties of the
operating table require the use of original brand mattresses and antistatic flooring.
WARNING
Clean the Velcro tapes on table top plates with pressuried air. Replace when necessary
spare parts and instructions are available from your sales representative.
WARNING
Do not use pressuried water: the table has been classified as splash proof equipment
only. Cleaning and disinfecting must be done according to this manual.
Practico 145000 Operating Table User Manual
Warnings, cautions and notes

1.11 Recycling warnings
CAUIN
Gas springs can be disposed of as metal waste after nitrogen gas and oil has been
removed. Instructions for releasing the gas is available from your sales representative.
Note:
Batteries contain lithium, and if replaced, need to be recycled in accordance with local
environmental regulations.
Cardboard packing material is recyclable. Wood and plastics are energy waste.
Practico 145000 Operating Table User Manual
Warnings, cautions and notes
Version: 1.6 –30.01.2023 Document ID: DO1141-1-6.en 16 (108)

17 (108) Document ID: DO1141-1-6.en Version: 1.6 –30.01.2023
2 General
2.1 About the user manual
The user manual is intended for healthcare professionals and it provides information about
the use, functions and care of the Practico operating table.
Read the manual in its entirety before using the product. The user manual is regarded as a
part of the product. eep the user manual for future reference.
Information about the maintenance and service of the product is provided in the Practico
Maintenance Manual DO1142.
2.2 Fluent Usability since 1901
Merivaara offers operating rooms a wide range of high-
quality products, solutions, and services. The
functionality and ease of use have been at the heart of
the design since 1901 when the company was founded.
We are proud that the companys values 120 years ago
were so ahead of their time that they can still today be
fully applied to the development of new and innovative
solutions for healthcare professionals. Our user
interfaces are developed together with hospital staff so
that all our products and systems can be used
intuitively. We call this Fluent Usability operating room
staff can focus on patient care, not on managing
complex technologies.
Merivaaras medical products are CE-labelled and the
companys quality management system complies with
EU regulations for medical device. Company is certified
by DNV according to ISO 9001 and ISO 13485
standards. Merivaaras environmental management
system is ISO 14001:2004 certified.
Read more about Merivaaras products and solutions at
www.merivaara.com.
2.3 Intended use
The operating table is intended to be used for supporting a patient during surgical
procedures. The table must be used in an operating room environment by trained health
care professionals only.
Practico 145000 Operating Table User Manual
General

2.4 Essential performance
The operating tables essential performance is to support a patient without unwanted
movements in a single fault condition.
2.5 User identification
The Merivaara Practico operating table and these operating instructions are intended to be
used by:
 medical personnel and qualified technicians working at hospitals or at qualified legal
agencies
 medical surgeries who have acquired working skills by undergoing medical training and
who are in possession of necessary authorisation where required.
Mandatory personnel training for the use of the Merivaara Practico operating table must be
carried out.
Because of importance of personal safety, read the safety precautions in chapter
Warnings, cautions and notes before using the product.
ualified personnel of the product owner must perform the necessary adjustments in
accordance with the safety rules and precautions described in this manual.
In case of malfunctions or loss of essential performance, contact technical personnel
immediately. Nursing staff or the persons involved in treatment or surgical procedures
must not perform maintenance that requires technical training (technical personnel only).
Product cleaning and disinfection must be done by duly trained personnel according to the
best practices in use at the facility, strictly following the instructions given in this manual.
Always disinfect the operating table before use.
Disregarding the guidelines presented in this manual is interpreted as a user error and
results in the loss of the product warranty.
2.6 User training
The end user (nurse, medical doctor or other personnel who is involved in using the
product) must be trained by an authoried trainer before using the product. Also the
relevant technical personnel must be trained (IEC 62366).
The following trainings are available:
 End user training
 Technical personnel training
For more information on user training, refer to document User training guidelines
T4046.
User training guidelines T404658–2, page 103
Practico 145000 Operating Table User Manual
General
Version: 1.6 –30.01.2023 Document ID: DO1141-1-6.en 18 (108)

19 (108) Document ID: DO1141-1-6.en Version: 1.6 –30.01.2023
2.7 Standards and directives
As a manufacturer of medical devices and products for health care, Merivaara Corp. pays
the greatest attention to the quality of both its products and its operational processes.
Merivaaras products are CE-labelled and the companys quality management system
complies with EU directives for medical devices, and is certified according to ISO 9001
and ISO 13485 standards. The companys environmental management system is ISO
14001 certified.
The product meets the following standards: IECEN 60601-1, and IECEN 60601-1-2
(EMC), CANCSA-C22.2 No. 60601-1:2014 and ANSIAAMI ES60601-1:2005 + A1:2012 +
C1:2009 + A2:2010. The table complies with the European Medical Device Regulation,
MDR 2017745 product class I, and bears a CE marking based on this classification.
2.8 Liability
The contents of this manual may be amended by Merivaara, without prior notice or any
further obligations, in order to make changes and improvements. The reproduction,
including partial reproduction, or translation of any part of this manual is forbidden without
the written consent of Merivaara.
Merivaara reserves the right to change, cancel or otherwise amend the data contained in
this document at any time and for any reason without prior notice because Merivaara is
constantly seeking new solutions which lead to product evolution. Merivaara therefore
reserves the right to make changes to the supplied product in terms of shape, fittings,
technology and performances.
With regard to translations into languages other than English, reference must always be
made to the English edition of this manual. To be able to use the product safely and
efficiently, we recommend that you read this manual and inspect the included images.
Merivaara does not take responsibility of the consequences if the system contains other
suppliers material or components. All parts of the system must be tested according to IEC
EN 60601-1.
This user manual is regarded as a part of the product. It must be kept in close vicinity of
the product at all times.
Rights to technical changes reserved. Pictures and technical data in manuals can slightly
differ from the current product due to further development of the product.
Copyright  2023 Merivaara Corp. All rights reserved.
2.9 Operating characteristics
Practico is a transportable electro-mechanical battery and mains-operated operating table.
Its safe working load (SWL) is 280 kg. Product modularity and wide adjustment ranges
make it flexible and easy to use. The table can be connected to a 100– 240 VAC mains
power system. The secondary voltage is 33 VDC. The table electronics are grounded and
equipotential connection provides additional potential equaliation.
The Practico table top consists of a fixed or sliding seat section combined with a back
section selected from the 5 factory-installed options. Different types of head and leg
Practico 145000 Operating Table User Manual
General

sections can be used depending on the surgical concept and operation. The width of the
table top is 594 mm and maximum length is 2086 mm, when standard table top sections
are used. Table top plates are x-ray translucent.
Practico is adjusted using a wired hand control unit. Foot control is an optional accessory.
There is a back-up control panel on the table column to ensure safe operation in the case
of hand control unit malfunction.
Safe and fault-free use and maintenance of the table requires that you read these
instructions carefully. When using and mounting accessories, follow their instructions
carefully. Always keep the instructions of the accessories together with this manual. Use
original Merivaara operating table accessories for maximum performance.
2.10 Table models and configuration
The Practico operating table has been constructed from the modules specified in the table
below. The table top consists of two factory-installed components which are not
interchangeable. These are:
 Back section
 Leg section according to the functionality type
The other modules are presented in the table below. The final product is named with a
model name if it is selected from the pre-selected sales packages. The modules and the
serial number are indicated on the identification plates.
Frame model  Without slide
 With slide (longitudinal shift of the operating table top)
Lifting column  Basic version
 Low version
 High version
2086mm
594mm
Practico 145000 Operating Table User Manual
General
Version: 1.6 –30.01.2023 Document ID: DO1141-1-6.en 20 (108)
