MetaSystem M43J User manual

1
MSM43J(T)UG1902020
M43J(T) Immobiliser
User Guide

2
MSM43J(T)UG1902020
The M43 is a self-arming dual circuit Immobiliser that prevents un-authorised starting of your vehicle.
By using a non-factory immobiliser your vehicle is protected from theft by Relay Attack and/or Key Cloning.
You should have received from your installer:
ID-Tag Service Key Window Stickers
The Red code cards attached the ID-Tags may be discarded
ENSURE the Service Key is kept in a safe place as it will be required should you need new or
additional ID-Tags to be programmed to your immobiliser.

3
MSM43J(T)UG1902020
ARMING:
Approx. 15 seconds after Ignition OFF the immobiliser will ARM and the LED will flash every 2 seconds.
If the Ignition is switched ON without pressing the ID-Tag button the Immobiliser LED will become ON solid to
indicate the immobiliser is still armed.
DISARMING:
Once inside the vehicle press the button of the ID-Tag and start the vehicle within 8 seconds; the immobiliser
LED will flash twice and then extinguish.
In Automatic mode the button of the ID-Tag will flash briefly once every 5 seconds.
ARMING:
Approx. 15 seconds after Ignition OFF and the ID-Tag out of range* the immobiliser will ARM and the LED will
flash every 2 seconds.
*In any case, the ID-Tag will be switched off after 20mins if it is not in motion.
As soon as the ID-Tag detects movement it will automatically switch ON again.
If the Ignition is switched ON without the ID-Tag present the immobiliser LED will be ON solid
DISARMING:
Simply start the vehicle as normal, the ID-Tag will automatically be detected; the immobiliser LED will flash
twice and then extinguish.

4
MSM43J(T)UG1902020
To set the immobiliser into Valet mode insert the service key into the receptable momentarily; the LED will
give one long flash to confirm.
The immobiliser will now remain in a disarmed state until the service key is used again. Thereafter, the
immobiliser will return to automatic arming mode.
If your ID-Tag fails to disarm your immobiliser and does not flash rapidly when the ID-Tag button is pressed,
you should replace the battery. TYPE: CR2032 3V
Praise apart the two halves of the case and remove the PCB from the casing. Slide the battery out and insert
the new battery ensuring the writing is uppermost i.e. you can see it after the battery is inserted.
If your system was configured for Automatic Mode you will now need to switch the ID-Tag back to Automatic
by pressing the button until you see a single bright flash from the LED under the button.
If your ID-Tag fails to disarm your immobiliser you should, in the first instance:
a. Press the button of the ID-Tag twice within 3 secs; this will re-synchronise your ID-Tag to the
immobiliser
Contact your local Meta dealer.
