SM5 & SM7 – V4 08/18 MJ - MCE
Installation
Unpacking
Unpack the mixer immediately after receipt. Please inspect the mixer to ensure no damage and all parts
i.e. Bowl, Beater, Whisk & Dough Hook have been provided. If the machine is found to be damaged,
keep all the packaging material and contact us immediately or contact your source of theequipment.
You should receive with your mixer:
-1 x Instruction Manual - 1 x Beater
-1 x Stainless Steel Bowl - 1 x Whisk
- 1 x Dough Hook
If any of the above items were not received with your slicer, please refer to page 14 for contact details
and inform us immediately for replacements.
Please ensure that you complete the product information section on page 7.
Operation
1.
Before using the mixer please read this manual thoroughly. DO NOT proceed with any installation
nor operation if you have any questions or do not understand anything within this manual. Please
see contact details for telephone number for assistance.
2.
The machine works off 230V 50Hz 1PH supply and comes fitted with a 13amp 3-pin fused plug.
Select a location for the mixer keeping these key points in mind:
•
Floor or counter must be level
•
Easy access for maintenance and servicing
•
Clearance for operating controls, installing and removing attachments or bowl
•
Sufficient space for adding ingredients during mixing periods
3.
Please read the electrical information found on the data plate located at the rear of the machine.
The incoming power should match the rating on the data plate.
4.
After ingredients have been placed in the bowl, lower the head and tighten the securing handle,
turn speed control switch to lower setting, turn on machine by pressing green “start” button, and
then set required speed gradually after attachment is lowered. When operation is complete, turn
speed control switch to lower setting, then press red “off” switch.
Fitting the Bowl
NOTE: Install the bowl BEFORE attaching an attachment.
1. Place bowl on bowl seat and turn bowl to lock into position.
Fitting Attachment (i.e. Beater, Whisk & Dough Hook)
NOTE: It is easier to install the attachments prior to adding the ingredients into the bowl.
1. Loosen securing handle on side by rotating counter clockwise.
2. Raise the head and lock in place rotating the securing handle clockwise.
3. Place attachment on shaft and turn 45° counter clockwise.
4. Complete steps 1 and d in reverse.
