METHVEN 01-8840 User manual

Methven Australia Pty Ltd
ABN 15 104 813 390
Melbourne, Australia
www.methven.com
WMKA21005
IMPORTANT
Please read all of the instructions before installation
MA018840
Maku Wall Top Assembly
01-8840 (Pair)
Use of this product is recommended for domestic and commercial applications.
All pipework must be thoroughly flushed prior to the installation of the mixer.
Inline filter washers must be installed on both hot and cold supplies to prevent foreign particles
damaging the ceramic head works.
Do not remove the ceramic head works from the wall top assemblies when installing.
Methven recommends a licensed plumber carry out all installations in compliance with
the requirements of AS/NZS 3500. This product complies with AS/NZS 3718 regulations.
JUNE 2012
Installation Guide
www.methven.com
Customer Care Hotline: 1300 METHVEN (638 483)
Email: [email protected].com
Note: It is the responsibility of the installer to ensure a water proof seal is achieved between the
faceplate and the finished surface of the wall. If in any doubt about the quality of the seal, the
faceplate should be removed and then reinstalled using silicone to ensure a seal is achieved.
Installation
Ø 35mm
Ø 35mm
1.
2.
3.
5.
6.
Distance from mounting stud to
front of wall lining: Std - 54-62mm
Ext - 62-74mm
Hot
Cold
Do not discard screws
(Available seperately)
4.
For deeper
installations, remove
short threaded head
works collars and
replace with optional
04-9646 Spindle
Extension Kit (kit
sufficient to extend
two headworks)

Technical Specification
Inlet Connections: All 1/2" BSP
Operating Pressure: 150kPa - 500kPa
For optimum performance hot and cold water pressures should be equal.
AS/NZS 3500 stipulates a 500kPa maximum operating pressure at any outlet
within a building. Where normal pressure exceeds 500kPa, a pressure limiting
valve must be installed.
Operating Temperature: Recommended hot water supply 50°C, maximum 70°C. AS/NZS 3500 requires all
hot water supplies to any sanitary fitting to be tempered to 50°C.
Ceramic Head Works: The ceramic head works can be damaged due to the presence of the following
within the water supply:
Copper tube pieces
Plastic pieces
Sand, dirt or stones
Thread tape
Other objects not normally present in the potable water supplies
www.methven.com
Customer Care Hotline: 1300 METHVEN (638 483)
Email: [email protected].com
Care and Cleaning
Never use abrasives to clean this product. Clean regularly with contamination free warm soapy water and a damp
soft cloth.
Cold Handle
Grub Screws
Locking Nut
Basering
Headworks
Headworks Body (not supplied)
Hot Handle
