METHVEN KIRI User manual

Issue D433176
KIRI SHOWER MIXER WITH DIVERTOR
INSTALLATION GUIDE
TECHNICAL SPECIFICATIONS
Operating Pressure:
Min: 150kPa, Max 500kPa
Recommended installation of a pressure limiting valve if supply pressure exceeds 500kPa
Operating Temperature:
Recommended 50°C at the mixer
Hot: Max 80°C
Cold: Min 5°C
NB: New Zealand Building Code Clause G12 - Water Supplies specifies all outlets used primarily for personal
hygiene shall deliver water at a safe temperature.
Inlet Connections: All ½” BSP
Methven warrants this product against manufacturing defects and that it is suitable for use
under the operating conditions specified in this instruction sheet.
For your warranty please refer to www.methven.com or call Customer Service
New Zealand
0800 804 222
Australia
1300 638 483
UK
0800 195 1602
Ceramic cartridge adjustment
Do not remove the ceramic cartridge from the
body assembly while carrying out the following
adjustments. Note, the cartridge is factory set
for maximum temperature.
Remove half-dome (if attached)
Flow limiting adjustment
Mix temperature limiting adjustment
+-
+
-

1
2
3
5
6
7
IMPORTANT
Please read all of the instructions before installation
Avoid restrictive piping, fitting or sharp angled bends when plumbing the mixer.
The maximum working pressure of the ceramic cartridge is 500kPa. Do not hydrostatic test
the installation with this mixer installed. Damage to the ceramic cartridge may occur.
All pipework must be thoroughly flushed prior to installation of the mixer. Inline filters must
be installed on both hot and cold supplies to prevent foreign particles damaging the ceramic
cartridge.
Grub screw
Half Dome
Divertor knob
Faceplate
Foam Seal
O-rings
Lever
handle
Screws
Body assembly
2.5mm allen key
102mm
50mm
25mm
4
Distance from
mounting stud
to front of lining
Max 90mm (optimum)
Min 79mm
Do not discard screws
Outlet for shower
Hot
Cold
