METHVEN Amio Shower Mixer With Divertor User manual

TECHNICAL SPECIFICATIONS
Operating Pressure:
Min kPa, Max kPa.
Recommended installation of a pressure limiting
valve if supply exceeds 500 kPa.
Operating Temperature:
Hot: Min °C (at mixer), Max °C.
Cold: Min .
NB: New Zealand Building Code Clause -
Water Supplies specifies all outlets used
primarily for personal hygiene shall deliver
water at a safe temperature
Inlet Connections:
All ½" BSP.
AMIOSHOWER MIXERWITHDIVERTOR
INSTALLATION GUIDE
Ceramic Cartridge Adjustment
Do not remove the ceramic cartridge from the body assembly while carrying
out the following adjustments.Note, the cartridge is factory set for maximum temperature.
Mix temperature limiting adjustment
-
+
Remove half-dome
(if attached)
Methven warrants this product against manufacturing defects and that it is suitable for use
under the operating conditions specified in this instruction sheet.
For your warranty please refer to www.methven.com or call Customer Service
New Zealand Australia USA UK
Issue B

Max 87mm (optimum)
Min 82mm
Ø100mm
50mm
Ø25mm
Hot
Cold
1
2
3
4
5
7
Distance from
mounting stud to
front of lining
Body assembly
Foam seal
Half-dome
Faceplate
Grub screw
Screws
Lever handle
O-ring
Do not discard screws
IMPORTANT
Please read all of the instructions before installation
Avoid restrictive piping, fitting or sharp angled bends when plumbing the mixer.
The maximum working pressure of the ceramic cartridge is 1000kPa. Do not hydrostatic
test the installation with this mixer installed. Damage to the ceramic cartridge may occur.
All pipework must be thoroughly flushed prior to installation of the mixer. Inline
filters must be installed on both hot and cold supplies to prevent foreign particles damaging
the ceramic cartridge.
NOTE - It is recommended to apply a bead of clear silicon sealant on the back of the
faceplate before fixing to the finished wall surface.
Dish seal
2.5mm Allen key
6
