METHVEN MINIMALIST MK2 User manual

Methven warrants this product against manufacturing defects and that it is suitable for use
under the general operating conditions specified in this instruction sheet. However, regional
regulations apply and may affect your warranty. Please refer to www.methven.com or call
customer service for full details.
New Zealand
0800 804 222
Australia
13 14 16
UK
0800 195 1602
Never use abrasives or abrasive cleaning agents to clean this product. Clean regularly with
contamination free warm soapy water and a damp soft cloth.
Periodically the stream shaper should be removed as shown below and cleaned under running water.
Care and Cleaning:
IS  ISSUE A www.methven.com
Technical Specifications:
Operating Pressure:
Min: 35kPa/0.35bar
Max: 1000kPa/10bar*
Optimum: 150kPa/1.5bar - 500kPa/5bar
Operating Temperature:
Hot: Max 80°C*
Cold: Min 5°C
Inlet Connections:
All ½" BSP
* Regional specific regulations apply.
Please refer to your warranty statement at
www.methven.com
MINIMALIST MK
WALL MOUNTED BATH SPOUT
Installation Guide

•
Step 1
Wall lining hole should be cut to
25 - 40mm max.
Cut protruding threaded ½ “ nipple to a
maximum of 13mm from the wall finished
surface and remove excess burrs.
Apply thread tape to the nipple to ensure
a good seal.
IMPORTANT: Before you begin, turn off the water supply.
•
•
Step 2
Apply silicon sealant to rear of
faceplate.
Fit faceplate to spout and screw
assembly onto the prepared nipple
until the faceplate contacts the wall
surface and the spout is facing
downwards.
•
•
•
•
•
•
IMPORTANT: Please read all of the instructions before installation.
General:
Methven recommends this product is installed by a licensed plumber in compliance with all
relevant regional regulations.
After installation all connections must be checked for leaks.
All outlets used primarily for personal hygiene shall deliver water at a safe temperature as per
regional regulations.
It is the responsibility of the installer to ensure a waterproof seal is achieved between the
product and mounting surface. If in doubt about the quality of the seal, remove the product and
reinstall using silicone to ensure a seal is achieved. 26mm max
15±2mm
Faceplate
Spout
