Mi-Light FUT090 Installation instructions

Remote Control for LED Tracklight
Model No.: FUT090
User Instruction

1. Features
With the widely used 2.4Ghz radio frequency &GFSK method, this remote control has
the features of low power consumption, long distance control, anti-interference, and
high communication speed.
You can save the current status of the track light as a mode, with the LCD screen, you
can see the color rate, kelvin, saturation rate, brightness clearly. One remote can
control many track lights at the same time or individually, totally up to 99 zones.
EDIT
ON
1 2 3 S
4 5 6 0
7 8 9 M
OFF
SHIFT
LCD screen
Color Ring
Saturation
Control
Directions
Color
TemperatureLine
Brightness
Dimming
Mode
Save / Choose

How to Eidt the Groups:
How to save:
Note: You can control all the linked tracklights when you change to ‘CH00’on the
remote control screen.
‘Mode’: You can save and choose RGB color, kelvin, brightness, saturation rate and
the direction of the tracklights.
1. SHIFT is a switch key used for choosing individual track light or group of track lights.
2. Hold any of the number key, when it shows ‘----’, you are ready to choose any
individual track light by typing in its 4 digital ID number on the remote. E.g. when you
press 1111, the track light with ID number 1111 is chosen.
3. Press SHIFT once, hold any of the number key,when it shows ‘CH--’, you are ready
to choose any group of track lights by typing in their group number on the remote.
E.g. when you press 20, the track lights in CH20 are chosen.
1. Link the tracklight with the remote control( see below 4. Link&Unlink)
2. Edit the numbers shown on the remote screen in accordance with the correspond-
ing tracklight( Each tracklight has a 4 digital ID number on it)
3. Press ‘Edit’ on the remote control, enter the Group Editing Mode, on the remote
control, it shows ‘Ed--’, on the tracklight, it shows ‘CH--’), press the numbers on the
remote control, e.g.61, the tracklight will be grouped into group 61.
4. Press any key on the remote control （except for the number keys）to stop editing.
There are no more than 99 groups, and each group can have limitless numbers of
tracklights.
1. Press ‘s’ and then ‘0’,the tracklight will locate itself.
2. Adjust the mode which you want to save
3. Hold ‘S’ when you see ‘Save’ blinking on the screen.
4. Press any number key from 1-9, ‘Save’ will stop blinking, the mode will be saved
on which key you pressed.
Model No.: FUT090
Mode: GFSK
Voltage: 4.5V (AAA * 3PCS)
Control Distance: 30m
Frequency: 2400-2483.5MHz
Power Consumption: 5.5dBm
Standby Current: 30uA
Size: 200mm*72.8mm*18.4mm
2. Parameters
3. Functions
SHIFT ( Switch key for individual and group of tracklights )
EDIT ( Edit key for grouping the tracklights )
S ( Save or Choose the Mode )

Made in China
Link: Switch off the power of the tracklight, switch on again, press ‘ON’ button on
the remote control 3 times within 3 seconds, ON/OFF also shown on the bottom left
of LCD screen, the link is done when the green light blinks three times.
Unlink: Switch off the power of the tracklight, switch on again, press ‘ON’ button on
the remote control 5 times within 3 seconds, ON/OFF also shown on the bottom left
of LCD screen, the unlink is done when the red light blinks 10 times.
How to choose dynamic modes:
Press ‘M’, ‘Mode’ will be blinking on the bottom left of the remote control screen,
‘Motor’ will be shown on the bottom middle of the screen.
Now you can start choosing the 9 dynamic modes by pressing the number key from
1-9, ‘Mode’ will stop blinking and ‘Motor’ will disappear.
How to adjust the directions:
How to choose the mode which you saved:
1. Press ‘S’ when you see ‘Select’ blinking on the screen.
2. Press the number key which you have saved before, ‘Select’ will stop blinking, the
mode which you have saved on this key will show.
4. Link&Unlink
M ( Choose dynamic modes or Adjust the directions )
Press ‘M’, ‘Mode’ will be blinking on the bottom left of the remote control screen,
‘Motor’ will be shown on the bottom middle of the screen.
Now you can also change the directions of the tracklights, up and down, left and
right, ‘Mode’ will stop blinking and icon will show up along with ‘Motor’
