KSZ8463ML/RL Evaluation Board User Guide
Preliminary Revision 1.1 / July 17, 2013

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
2/16
Table of Contents
Introduction....................................................................................................................................................3
1Board Features .....................................................................................................................................3
2KSZ8463ML/RL Evaluation Board Kit...................................................................................................4
3Hardware Description............................................................................................................................4
3.1 Configuration Options....................................................................................................................5
3.1.1 Strap-in Configuration............................................................................................................5
3.1.2 USB Interface (SPI Slave or MDIO).......................................................................................6
3.2 Power Supplies..............................................................................................................................6
3.3 Port 3 Configuration.......................................................................................................................7
3.3.1 MII Port Configuration (KSZ8463ML, KSZ8463FML)............................................................8
3.3.2 RMII Port Configuration (KSZ8463RL and KSZ8463FRL)....................................................9
3.4 GPIO pins ....................................................................................................................................11
3.5 10/100 Ethernet PHY Ports .........................................................................................................12
3.6 100BASE-FX Fiber Port Option...................................................................................................12
3.7 LED Indicators .............................................................................................................................13
3.8 List of Jumpers and Connectors..................................................................................................14
3.9 Board Layout................................................................................................................................15
4Using the KSZ8463ML/RL Evaluation Board......................................................................................15
5Reference Documents ........................................................................................................................16
6Revision History..................................................................................................................................16
List of Figures
Figure 1 KSZ8463ML/RL Evaluation Board ................................................................................................5
Figure 2 Power Supply Section and Related Jumper Locations .................................................................7
Figure 3 GPIO Connectors and Related Jumper Locations......................................................................12
Figure 4 Topside Layout of the Board .......................................................................................................15
List of Tables
Table 1 Strap-In Configuration Jumpers......................................................................................................6
Table 2 Power Supply Related Jumpers.....................................................................................................7
Table 3 MII / RMII Port Configuration Settings............................................................................................8
Table 4 MII Port Configuration Settings.....................................................................................................10
Table 5 RMII Clock Setting........................................................................................................................10
Table 6 RMII Signal Description................................................................................................................10
Table 7 GPIO pin selection for KSZ8463ML .............................................................................................11
Table 8 LED Functions ..............................................................................................................................13
Table 9 List of Jumpers and Connectors...................................................................................................14

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
3/16
Introduction
The KSZ8463ML/RL Evaluation Board provides a platform for testing or exploring the functionally of the
KSZ8463ML and KSZ8463RL IEEE 1588 Precision Time Protocol (PTP) enabled switch products.
The KSZ8463ML, KSZ8463FML, KSZ8463RL and KSZ8463FRL devices are highly integrated 2-port
10BASE-T / 100BASE-TX/FX managed Ethernet switches with MII and RMII interface connectivity to a
host on Port 3. They are the ideal solution in industrial applications where real time clock synchronization
using Ethernet connectivity across a network is desired. The KSZ8463ML/RL includes all the functions of
a 10/100BASE-T/TX/FX switch system that combines switch engine, frame buffers management,
addresses look-up table, queue management, MIB counters, media access controllers (MAC) and PHY
transceiver interfaces. The KSZ8463ML/RL is fully compliant with the IEEE 1588 (Version 2) Precision
Time Protocol and IEEE 802.3 standards (10BASE-T and 100BASE-TX/FX). The KSZ8463ML/FML
devices have Port 3 configured for MII mode, while the KSZ8463RL/FRL devices have Port 3 configured
for RMII mode.
This KSZ8463ML/RL Evaluation Board User Guide provides the information necessary to configure and
set up the board to evaluate or test the KSZ8463ML and KSZ8463RL devices in different environments.
1 Board Features
The KSZ8463ML/RL Evaluation Board encompasses the following features.
•Micrel’s KSZ8463ML or KSZ8463RL Integrated 3-Port 10/100 Managed Ethernet Switch
•Fully compatible with the KSZ8463FML and KSZ8463FRL devices
•Two Ethernet LAN interfaces with RJ-45 jacks and isolation magnetics (Port 1 & 2)
•Auto MDI/MDI-X for automatic detection and correction for straight-through and crossover cables
•MII connector for Port 3 operating in PHY Mode
•Provisioning for MII / RMII connector for Port 3 operating in MAC Mode (optional)
•Provisioning for two 100BASE-FX fiber interfaces (optional)
•Provisioning for line side and chip side over-voltage protection (optional)
•On-board 3.3V and 1.8V/2.5V regulators
•Configurable for VDDIO of 3.3V, 2.5V, or 1.8V operation
•USB access to SPI or MIIM (MDIO/MDC) interface
•LED indicators for link status and activity of the RJ-45 ports
•On-board 25 MHz crystal
•Provisioning for on-board 50 MHz oscillator for RMII (optional)
•Jumpers for power up configuration of the device
•Jumpers for GPIO pins, I/O voltage selection and serial-port connections
•5V DC voltage required for operation
•Reset switch
•Various test points

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
4/16
2 KSZ8463ML/RL Evaluation Board Kit
The KSZ8463ML/RL Evaluation Board kit includes the following:
•KSZ8463ML/RL Evaluation Board
•KSZ8463ML/RL Evaluation Board User Guide (This document, available in the eval kit, on the
Micrel website)
•KSZ8463ML/RL Evaluation Board Schematic (Available in the eval kit, on the Micrel website)
3 Hardware Description
The KSZ8463ML/RL Evaluation board is a small form-factor board (5.2” x 4.75”) with two10/100 RJ-45
ports and one MII/RMII port. There are two methods for configuring the KSZ8463: Strap-in configuration
and serial interface.
Strap-in mode configuration occurs at power-on (and hardware reset) where the voltage level on certain
pins is automatically sampled and used to configure various features in the device. This is accomplished
with on-board jumper options, so that the KSZ8463 powers up in the desired modes. With no additional
programming of registers, the device will start operation as an unmanaged 3-port switch.
The KSZ8463ML/RL has a serial interface which can be either SPI or MIIM (MDIO/MDC). Normally the
SPI interface is used because it provides read/write access to all KSZ8463 registers. In comparison, the
MIIM interface provides access only to the basic PHY registers in the KSZ8463. Full register access is
required for managed operation of the switch, and to utilize the advanced features such as IEEE 1588
PTP. Access to the SPI interface is provided on the 6-pin header J5. SPI (or MIIM) access is also
provided via the onboard USB port interface. An FT2232D chip is used for the USB-to-SPI/MIIM interface.
Configuration options are explained in detail in the following sections. Figure 1 is a picture of the
KSZ8463ML/RL Evaluation board.

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
5/16
Figure 1KSZ8463ML/RL Evaluation Board
3.1 Configuration Options
3.1.1 Strap-in Configuration
Strap-in configuration is used to set the basic modes of operation so that KSZ8463 powers up in the right
modes. This is accomplished by setting available configuration jumpers which are used at device power-
up. Simply set the board’s configuration jumpers to the desired settings and apply power to the board. The
configuration can be changed while power is applied to the board by changing the jumper settings and
pressing the manual reset button for the new settings to take effect. Note that even if no external strap-in
jumpers are set, internal pull-up and pull-down resistors will set the KSZ8463ML/RL to the default
configuration. The following table covers each jumper used for the strap-in option and describes its
function.
JUMPER
FUNCTION
SETTING
DEFAULT
(no jumper)
JP301
PHY/MAC mode select for
MII port
[1]
Pins 1-2 closed: PHY MII mode
Pins 2-3 closed: MAC MII mode
PHY MII

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
6/16
JUMPER
FUNCTION
SETTING
DEFAULT
(no jumper)
JP302
High-speed/Low-speed
SPI selection
Pins 1-2 closed: High speed (up to 50 MHz)
Pins 2-3 closed: Low speed (up to 12.5 MHz)
High speed
Serial Bus Mode Selection
SPI Slave
MIIM (MDIO/MDC)
SPI Slave
JP303
Pins 1-2 closed
Pins 1-2 closed
JP304
Pins 2-3 closed
Pins 1-2 closed
JP305
Input Clock Select[2]
Pins 1-2 closed: 25MHz from X1/X2
Pins 2-3 closed: 50MHz from REFCLK_I
25MHz
Table 1Strap-In Configuration Jumpers
Notes:
1. This mode select applies only to the MII interface, and thus does not apply to the KSZ8463RL and
KSZ8463FRL which have a RMII interface.
2. Mode “50MHz from REFCLK_I” is an option only for the KSZ8463RL and KSZ8463FRL. The
KSZ8463ML and KSZ8463FML must use mode “25MHz from X1/X2.”
3.1.2 USB Interface (SPI Slave or MDIO)
With the Micrel utility software that runs on a PC, it is possible to access the full register set of the device
through the USB port provided on the evaluation board. Download and install the Windows based
MicrelSwitchPhyTools software from the Micrel website. It includes two applications:
MicrelSwitchConfigApp.exe and MicrelMDIOConfigApp.exe, plus associated DLL files.
MicrelSwitchConfigApp has a graphical user interface (GUI) and provides access via USB to many of the
KSZ8463 registers via the SPI interface. MicrelMDIOConfigApp and the MDIO interface are of limited use
on the KSZ8463 and are not described further.
When using the USB-to-SPI interface, ensure that the following jumpers are installed: J14 (either pins 1-2
or 2-3), JP34, JP35 and JP79 (all four pairs). Do not install JP32 or JP33.
3.2 Power Supplies
The board requires a single 5V DC supply, which can be provided through a barrel power-supply jack
(J11) or through the USB port. The current requirement is 200mA. When configured for fiber operation,
expect the fiber modules to draw approximately 250mA of additional current per port.
The pin diameter of jack J11 is 2.5mm on early boards, and is 2.1mm on newer boards. 2.5mm plugs are
recommended because they are generally compatible with both jack sizes. A 2.1mm plug, however,
cannot be used with the 2.5mm jack.
JP400 is used for selecting the 5V source to the board. There is a 3.3V regulator on the board supplying
power for the KSZ8463 and other components. A separate on-board voltage regulator is provided for the
optional 2.5V and 1.8V supplies for KSZ8463’s I/O interface (VDD_IO). JP404 and JP406 are used for
VDD_IO selection. JP403 and JP405 must be in place and other options properly selected before
powering up the board.

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
7/16
JUMPER
FUNCTION
SETTING
JP400
+5V supply source selection
Pins 1-2 closed: Power connector (J11)
Pins 2-3 closed: USB port
JP403
+3.3V supply for KSZ8463 analog circuits
Must be closed
JP405
+1.2V supply for KSZ8463 analog circuits
Must be closed
VDD_IO selection
3.3V
2.5V
1.8V
JP404
Pins 2-3
closed
Pins 1-2
closed
Pins 1-2
closed
JP406
X
open
closed
Table 2Power Supply Related Jumpers
Figure 2Power Supply Section and Related Jumper Locations
3.3 Port 3 Configuration
The board features two Media Independent Interface (MII) connectors, for interfacing the MAC of Port-3
on the KSZ8463ML/FML to either an external PHY or MAC.
The female MII connector (J4, not installed) is used for interfacing to a PHY. For example, it can be
connected to a KSZ8081 eval board. When connecting to a PHY, the KSZ8463ML/FML must be set to
MAC mode. A jumper is provided (JP301) to set Port-3 in PHY or MAC mode of operation at power-up.
The male MII connector (J3) is used for interfacing to any host processor’s MAC interface. Normally this
port connects to a Micrel KSZ9692MII-PTP-EV or KSZ9692PB-PTP-EVAL board for evaluation of the
IEEE1588 PTP functionality. When connecting to an external MAC device such as the KSZ9692, the
KSZ8463ML/FML must be set to PHY mode.
The KSZ8463ML/FML provides a bypass feature in the MII PHY mode. JP27 is used to enable the MII
bypass mode. In the bypass mode, MII (port 3) is shut down and no new ingress frames from either Port 1
or Port 2 will be sent out through Port 3. Only the switch between Port 1 and Port 2 is active for all ingress
packets, and the frames for Port 3 already in packet memory will be flushed out.

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
8/16
Whereas the KSZ8463ML/FML uses the full MII signaling pins of the connectors, the KSZ8463RL/FRL
makes use of a subset of the available pins, as defined by the RMII standard. The RMII standard requires
a 50 MHz clock which can be generated by the KSZ8463RL/FRL chip, or supplied externally. The
KSZ8463ML/RL Evaluation board provides both options. JP28 is connected to EN_REFCLKO (pin 23), to
enable or disable the generation of the 50 MHz clock by the KSZ8463RL/FRL on REFCLK_O (pin 32).
When REFCLKP_O (JP28) is enabled, the Input Clock Select option (JP305) must be set to “25MHz from
X1/X2”.
An on-board 50 MHz oscillator (Y2, not installed) is also provided for the RMII devices. This oscillator
drives a 50 MHz clock both to the J4 connector (pin 12) and to the KSZ8463RL/FRL (REFCLK_I, pin 27).
In this configuration, REFCLK_O (JP28) must be disabled, and JP305 is used to select the “50MHz from
REFCLK_I” option. When installing Y2, it is also necessary to install R181, R187, and to remove R51,
R53 and R58.
JUMPER
FUNCTION
SETTING
DEFAULT
(no jumper)
JP301
MAC/PHY mode
selection for MII on
Port-3
[1]
Pins 1-2 closed: PHY mode
Pins 2-3 closed: MAC mode
PHY mode
JP27
Bypass mode for MII
PHY mode link
[3]
Pins 1-2 closed: Bypass enabled
Pins 2-3 closed: Normal operation
Normal
operation
JP28
50 MHz Reference
clock generation[4]
Pins 1-2 closed: REFCLK_O is enabled
(EN_REFCLKO pin = 1)
Pins 2-3 closed: REFCLK_O is disabled
(EN_REFCLKO pin = 0)
REFCLK_O
disabled
JP305
Input Clock Select[2]
Pins 1-2 closed: 25MHz from X1/X2
Pins 2-3 closed: 50MHz from REFCLK_I
25MHz
Table 3MII / RMII Port Configuration Settings
Notes:
3. The Bypass mode option applies only when in MII PHY mode. When in MII MAC mode, do not
install any jumper on JP27.
4. The 50 MHz reference option applies only to RMII devices (KSZ8463RL and KSZ8463FRL). For
MII devices (KSZ8463ML and KSZ8463FML), do not install a jumper on JP28.
3.3.1 MII Port Configuration (KSZ8463ML, KSZ8463FML)
The Media Independent Interface (MII) is specified in Clause 22 of the IEEE 802.3 standard. It provides a
common interface between PHY layer and MAC layer devices. The MII provided by the KSZ8463ML/FML
is connected to the device’s third MAC (Port 3). The interface contains two distinct groups of signals, one
for transmission and the other for reception. The following table describes the signals used by the MII
interface to connect either external MAC or external PHY.

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
9/16
Signal Name on
MII connectors Description Pin numbers
Signal direction
in PHY mode:
(Connector J3)
Signal direction
in MAC mode:
(Connector J4)
Test Points
TX_EN
Transmit enable
13
input
output
TP6
TX_ER
Transmit error
11
input
GND
TP15
TXD3
Transmit data bit 3
17
input
output
TP18
TXD2
Transmit data bit 2
16
Input
output
TP17
TXD1
Transmit data bit 1
15
Input
output
TP16
TXD0
Transmit data bit 0
14
input
output
TP7
TX_CLK
Transmit clock
12
output
input
TP5
COL
Collision detection
18
output
input
TP1
CRS
Carrier sense
19
output
input
-
RX_DV
Receive data valid
8
output
input
TP2
RX_ER
Receive error
10
GND
input
-
RXD3
Receive data bit 3
4
output
input
TP13
RXD2
Receive data bit 2
5
output
input
TP12
RXD1
Receive data bit 1
6
output
input
TP11
RXD0
Receive data bit 0
7
output
input
TP4
RX_CLK
Receive clock
9
output
input
TP3
MDIO
Data I/O
Bi-directional
Bi-directional
-
MDC
Clock
input
input
-
VCC
1, 20, 21,
40
No connection VCC (+5V)
GND
22 - 39
GND
GND
TP14, TP19
The KSZ8463ML/FML does not provide the RX_ER signal in PHY mode operation and the TX_ER signal
in MAC mode operation. Normally, RX_ER indicates a receive error coming from the physical layer device
and TX_ER indicates a transmit error from the MAC device. Since the switch filters error frames, these MII
error signals are not used by the KSZ8463ML/FML. So, for PHY mode operation, if the device interfacing
with the KSZ8463ML/FML has an RX_ER input pin, it needs to be tied low. And, for MAC mode operation,
if the device interfacing with the KSZ8463ML/FML has a TX_ER input pin, it also needs to be tied low.
3.3.2 RMII Port Configuration (KSZ8463RL and KSZ8463FRL)
The Reduced Media Independent Interface (RMII) specifies a low pin count Media Independent Interface
(MII). RMII provides a common interface between physical layer and MAC layer devices, and has the
following key characteristics:
•Supports data rate either 10Mbps or 100Mbps.
•Uses a single 50 MHz clock reference for both transmit and receive data.
•Provides independent 2-bit wide transmit and receive data paths.
•Contains two distinct groups of signals: one for transmission and the other for reception.
Connector J3 is not configured for use with RMII. RMII interfacing must use connector J4, for connection
to an external RMII PHY such as the KSZ8081RNA, KSZ8081RNB or KSZ8081RND eval board.

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
10/16
As shown in Table 4 and Table 5, JP28 is used for enabling or disabling the generation of 50MHz
reference clock from the REFCLK_O pin of the KSZ8463RL/FRL. The 50MHz reference clock is always
provided to KSZ8463RL/FRL via REFCLK_I (pin 27).
JUMPER
FUNCTION
SETTING
DEFAULT
(no jumper)
JP28
50 MHz Reference
clock generation
Pins 1-2 closed: REFCLK_O is enabled
(EN_REFCLKO pin = 1)
Pins 2-3 closed: REFCLK_O is disabled
(EN_REFCLKO pin = 0)
REFCLK_O
disabled
Table 4MII Port Configuration Settings
JP28 Setting
(EN_REFCLKO pin)
Clock Source
Note
Pins 2-3 closed
(EN_REFCLKO = 0,
REFCLK_O is off)
External 50MHz Ref Clock from oscillator
(or J4 pin 9) is input to REFCLK_I. X1/X2 25MHz clock is not used.
Pins 1-2 closed
(EN_REFCLKO = 1,
REFCLK_O is on)
REFCLK_O output must connect to
REFCLK_I, and also drives to J4 pin 12. X1/X2 25MHz clock is required.
Table 5RMII Clock Setting
The RMII provided by the KSZ8463RL/FRL is connected to the device’s third MAC. It complies with the
RMII Specification. The following table describes the signals used by the RMII interface. Refer to RMII
Specification for full detail on the signal description.
RMII
Signal
Name
RMII
Signal Description
Pin number
on MII
connectors
Direction (with
respect to the
PHY)
Direction (with
respect to the
MAC)
Test
Points
REFCLK
Synchronous 50 MHz clock
reference for receive, transmit
and control interface
12
Input Input or Output
TP5
CRS_DV
Carrier sense/
Receive data valid
8
Output Input
TP6
RXD0 Receive data bit 0
7
Output Input
TP4
RXD1 Receive data bit 1
6
Output Input
TP11
TX_EN Transmit enable
13
Input Output
TP6
TXD0 Transmit data bit 0
14
Input Output
TP7
TXD1 Transmit data bit 1
15
Input Output
TP16
RX_ER Receive error
10
Output Input or not required
TP15
Table 6RMII Signal Description

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
11/16
The KSZ8463RL/FRL filters error frames, and thus does not implement the RX_ER output signal. To
detect error frames from RMII PHY devices, the TX_ER input signal of the KSZ8463RL/FRL is connected
to the RX_ER output signal of the RMII PHY device.
Collision detection is implemented in accordance with the RMII Specification.
In RMII mode, tie MII signals (TXD [3:2], RXD [3:2] and TX_ER) to ground if they are not used.
The KSZ8463RL/FRL can interface to either RMII PHY or RMII MAC devices. The RMII MAC device
allows two KSZ8463RL/FRL devices to be connected back-to-back.
3.4 GPIO pins
The KSZ8463 has up to 12 General Purpose I/O (GPIO) pins which are available on the evaluation board
at connectors J15 and J16. The KSZ8463RL has all 12 GPIO pins available. Three GPIO pins of the
KSZ8463ML are shared with Port1/2 LED activity signals and are user programmable. By default the LED
signals are enabled, therefore 9 GPIO pins are available. If more than 9 GPIO pins are required, the user
needs to program IOMXSEL register (0x0D6) as follows:
IOMXSEL register
(0x0D6)
Description
Setting
Bit 10
Selection of P2LED1 or GPIO9
1 = This pin is used for P2LED1 (default)
0 = This pin is used for GPIO9
Bit 9
Selection of P2LED0 or GPIO10
1 = This pin is used for P2LED0 (default)
0 = This pin is used for GPIO10
Bit 8
Selection of P1LED1 or GPIO7
1 = This pin is used for P1LED1 (default)
0 = This pin is used for GPIO7
Table 7GPIO pin selection for KSZ8463ML
GPIO signals are on the odd numbered pins of connectors J15 and J16. All even numbered pins are GND
connections. GPIO7, 9 and 10 pins are connected to jumpers JP36, 37 and 38 respectfully.
For the KSZ8463RL device, pins 1 and 2 of all three jumpers need to be closed in order to make GPIO7, 9
and 10 available at the GPIO headers. In case of KSZ8463ML, GPIO7, 9 and 10 are Port1/2 LED activity
signals by default and no strapping is needed. If the user enables GPIO functionality instead, pins 2 and 3
of the corresponding jumpers have to be closed.
The GPIO pins can be used for any general purpose I/O as well as to support IEEE1588 PTP
functionality.

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
12/16
Figure 3GPIO Connectors and Related Jumper Locations
3.5 10/100 Ethernet PHY Ports
There are two 10/100 Ethernet PHY ports on the KSZ8463ML/RL evaluation board. The ports can be
connected to an Ethernet traffic generator or analyzer via standard RJ-45 connectors using CAT-5 (or
better) UTP cables. Both ports support auto MDI/MDI-X, eliminating the need for cross-over cables.
Transformers are utilized for proper interfacing to an Ethernet network. In addition, optional over-voltage
protection devices D5 thru D12 may be installed to protect the KSZ8463 in the event of an over-voltage
condition.
For 10/100 Ethernet, the FXSD1 and FXSD2 pins should be pulled low by installing jumpers on pins 3 & 4
of J12 and J13.
3.6 100BASE-FX Fiber Port Option
There are two 100BASE-FX PHY ports on the KSZ8463ML/RL evaluation board, which are not populated
with necessary components. The ports can be connected to an Ethernet traffic generator or analyzer via
fiber transceiver and fiber cable. In 100BASE-FX operation, both fiber signal detect input FXSD1 and
FXSD2 are usually connected to the fiber transceiver SD (signal detect) output pin. This is done by
jumpering pins 1 & 2 of J12 (Port 1) and J13 (Port 2). No jumpers are required on JP77 and JP78 except
as noted below. Capacitors C5 and C6 are also generally not required.
100BASE-FX is supported by the KSZ8463FML and KSZ8463FRL devices. All KSZ8463 devices power
up in copper mode. Fiber Mode is selected by clearing the appropriate bits in the GFCR register (0x0D8 –
0x0D9).

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
13/16
The fiber signal detect threshold is set to 1.7V internally, When FXSD is less than the threshold, no fiber
signal is detected and a far-end fault (FEF) is generated. When FXSD is over the threshold, the fiber
signal is detected. To ensure proper operation, a resistive voltage divider is recommended to adjust the
fiber transceiver SD output voltage swing to match the FXSD pin’s input voltage threshold.
Alternatively, the user may choose not to implement the FEF feature. In this case, the FXSD input pin may
be pulled high via jumpers JP77 and JP78.
3.7 LED Indicators
The KSZ8463ML/RL evaluation board provides two LEDs (PxLED1, PxLED0) for each PHY port. The
LED indicators are programmable to four different states. LED mode is selected through bits [9:8] of the
SGCR7 register (0x00E-0x00F).
The LED mode definitions are specified in Table 7. See Figure 2 for the LEDs’ orientation on the
KSZ8463ML/RL evaluation board in the power supply section.
SGCR7 Control Register (0x00E-0x00F) Bits[9:8]
00 (default)
01
10
11
PxLED1 = Speed
PxLED1 = Active
PxLED1 = Duplex
PxLED1 = Duplex
PxLED0 = Link/Active
PxLED0 = Link
PxLED0 = Link/Active
PxLED0 = Link
Table 8LED Functions
The KSZ8463ML/RL evaluation board also has a power LED (D3) for the 3.3V power supply. When D3 is
illuminated, the board’s 3.3V power supply is “on”.
The activity LED indicators for Port-1 and Port-2 are powered by VDD_IO, which can be set to 3.3V, 2.5V
or 1.8V. In the case of 2.5V and 1.8V selection, these LED indicators will be dimly lit or not illuminated
because of inadequate voltage across the LED.

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
14/16
3.8 List of Jumpers and Connectors
Jumper
Description
Setting
J12-13
FXSD pin connections
Pins 1-2 closed: connect to SD signal
from fiber module
Pins 3-4 closed: ground the FXSD pins,
for copper mode
J14
USB IO voltage selection
Close pins 1-2 or 2-3 to power USB to
serial interface. Either setting will work.
JP2
PWRDN Chip Power-down
Place Jumper for full chip power-down
JP3, 9
Factory Usage
Install no jumpers
JP10, 11
Power selection for the Fiber module
Leave open when no Fiber Module
present
JP27
MII bypass
Pins 1-2 closed: Enable MII bypass mode
Pins 2-3 closed: MII PHY mode normal
operation
JP28
Enable RMII mode reference clock output from
REFCLK_O pin
Pins 1-2 closed: Enable
Pins 2-3 closed: Disable
JP32, 33
Enable MDIO interface through MII connector
Place both jumpers to connect MDIO
signals from MII connector to KSZ8463
serial port.
When using SPI, do not install jumpers.
JP34, 35
KSZ8463 serial port connections
Place both jumpers for USB port access
and SPI interface
JP36-38
GPIO7, GPIO9 and GPIO10 pin source
selection on GPIO Headers
Pins 1-2 closed for KSZ8463RL/FRL
Pins 2-3 closed for KSZ8463ML/FML
JP77, 78
FXSD1, FXSD2 Fiber signal detect input for
Port 1 and Port 2 (not used)
JP79
Enable USB controller interface
Close pins 1-2, 3-4, 5-6 and 7-8 to
connect USB controller to serial bus
JP301-305
Strapping options
See Table 1
JP306
Not used
JP400
5V DC input selection
See Table 2
JP403-406
Power-supply strapping options
See Table 2
Table 9List of Jumpers and Connectors

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
15/16
3.9 Board Layout
The layout of the board is shown in Figure 3. The key areas are indicated.
Figure 4Topside Layout of the Board
The KSZ8463ML/RL Evaluation board, together with the KSZ9692PB SOC board (KSZ9692-MII-PTP-EV),
provides a complete evaluation platform for the IEEE1588 PTP functionality. In this setup, Port 3 of the
KSZ8463 evaluation board is configured in PHY mode and connected to the SOC board through its MII
port. In addition to the MII connection, the SOC accesses the KSZ8463 through the SPI port. An interrupt
line is also used for PTP software functionality. For more details on this configuration, refer to the
KSZ8463ML Evaluation Kit User Guide.
4 Using the KSZ8463ML/RL Evaluation Board
The Evaluation Kit is intended to provide a platform that enables designers to investigate and evaluate the
capabilities of the KSZ8463 device. It is not intended to be a complete development system to be used for
an entire product design effort.

KSZ8463_eval_bd_user_guide_1.1.docx
Micrel, Inc. July 17, 2013
Confidential Rev. 1.1
16/16
5 Reference Documents
KSZ8463ML/RL Datasheet (Contact Micrel for latest Datasheet)
KSZ8463ML/RL Evaluation Board Schematic (Contact Micrel for latest Schematic)
KSZ8463ML/RL Evaluation Board Gerber files
IEEE802.3 Specification
RMII Specification by RMII Consortium
KSZ8463ML Evaluation Kit User Guide
6 Revision History
© Micrel, Inc. 2013
All rights reserved
Micrel is a registered trademark of Micrel and its subsidiaries in the United States and certain other countries. All other trademarks
are the property of their respective owners.
The information furnished by Micrel in this datasheet is believed to be accurate and reliable. However, no responsibility
is assumed by Micrel for its use. Micrel reserves the right to change circuitry and specifications at any time without
notification to the customer. Micrel Products are not designed or authorized for use as components in life support
appliances, devices or systems where malfunction of a product can reasonably be expected to result in personal injury.
Life support devices or systems are devices or systems that (a) are intended for surgical implant into the body or (b)
support or sustain life, and whose failure to perform can be reasonably expected to result in a significant injury to the
user. A Purchaser's use or sale of Micrel Products for use in life support appliances, devices or systems is at
Purchaser's own risk and Purchaser agrees to fully indemnify Micrel for any damages resulting from such use or sale.
Revision
Date
Summary of Changes
1.00
06/16/11
- Initial Release
1.01
08/30/11
- Removed eval kit information
1.02 09/19/11
- Updated text.
- Added new board Figure 1.
1.03
09/23/11
- Changed MLLRLL to MLI/RLI, MLL to MLI, RLL to RLI
1.1 7/17/13
- Changed MLI/RLI to ML/RL, MLI to ML, RLI to RL
- Added FML and FRL device suffixes
- General overhaul
