MICRO-EPSILON optoNCDT 1220 User manual

ILD 1220-10
ILD 1220-25
ILD 1220-50
ILD 1220-100
ILD 1220-200
ILD 1220-500
Operating Instructions
optoNCDT 1220

MICRO-EPSILON
MESSTECHNIK
GmbH & Co. KG
Königbacher Straße 15
94496 Ortenburg / Germany
Tel. [phone] / 168-0
Fax [phone] / 168-90
e-mail [email protected]
www.micro-epsilon.com
Intelligent laser optical displacement measurement

optoNCDT 1220
Contents
1. Safety ........................................................................................................................................ 7
1.1 Symbols Used ................................................................................................................................................. 7
1.2 Warnings.......................................................................................................................................................... 7
1.3 Notes on CE Marking ...................................................................................................................................... 8
1.4 Intended Use ................................................................................................................................................... 9
1.5 Proper Environment......................................................................................................................................... 9
2. Laser Class............................................................................................................................. 10
3. Functional Principle, Technical Data ..................................................................................... 12
3.1 Short Description........................................................................................................................................... 12
3.2 Auto Target Compensation (ATC) ................................................................................................................. 13
3.3 Technical Data ............................................................................................................................................... 14
4. Delivery ................................................................................................................................... 16
4.1 Unpacking, Included in Delivery.................................................................................................................... 16
4.2 Storage .......................................................................................................................................................... 16
5. Installation .............................................................................................................................. 17
5.1 Instructions for Installation............................................................................................................................. 17
5.1.1 Reflection Factor of the Target Surface........................................................................................ 17
5.1.2 Error Influences ........................................................................................................................... 17
5.1.2.1 Light from other Sources ........................................................................................... 17
5.1.2.2 Color Differences ........................................................................................................ 18
5.1.2.3 Temperature Influences .............................................................................................. 18
5.1.2.4 Mechanical Vibration .................................................................................................. 18
5.1.2.5 Movement Blurs ......................................................................................................... 18
5.1.2.6 Surface Roughness .................................................................................................... 19
5.1.2.7 Angle Influences ......................................................................................................... 20
5.1.3 Optimizing the Measuring Accuracy ........................................................................................... 21
5.2 Mounting, Dimensions .................................................................................................................................. 22
5.3 Indicator Elements at Sensor ........................................................................................................................ 24
5.4 Electrical Connections................................................................................................................................... 25
5.4.1 Connection Possibilities for Parametrization................................................................................ 25
5.4.2 Pin Assignment............................................................................................................................. 27
5.4.3 Supply Voltage ............................................................................................................................. 28

optoNCDT 1220
5.4.4 Laser on........................................................................................................................................ 28
5.4.5 RS422 Connection with USB Converter IF2001/USB.................................................................. 29
5.4.6 Analog Output .............................................................................................................................. 29
5.4.7 Multifunctional Input ..................................................................................................................... 30
5.4.8 Digital Output................................................................................................................................ 31
5.4.9 Sensor Cable................................................................................................................................ 32
6. Operation ................................................................................................................................ 33
6.1 Getting Ready for Operation ......................................................................................................................... 33
6.2 Parameterizing via Web Interface.................................................................................................................. 34
6.2.1 Preconditions................................................................................................................................ 34
6.2.2 Access via Web Interface ............................................................................................................. 35
6.3 Timing, Measurement Value Flux .................................................................................................................. 37
7. Set Sensor Parameter ............................................................................................................ 38
7.1 Preliminary Remarks to the Adjustments ...................................................................................................... 38
7.2 Overview Parameter....................................................................................................................................... 38
7.3 Inputs ............................................................................................................................................................. 39
7.3.1 Overview Functions ...................................................................................................................... 39
7.3.2 Zeroing ......................................................................................................................................... 39
7.3.2.1 Zeroing with Select Key .............................................................................................. 40
7.3.2.2 Zeroing with Hardware Input....................................................................................... 41
7.4 Signal Processing.......................................................................................................................................... 42
7.4.1 Preliminary Remark ...................................................................................................................... 42
7.4.2 Measuring Rate ............................................................................................................................ 42
7.4.3 Error Handling .............................................................................................................................. 42
7.4.4 Triggering...................................................................................................................................... 43
7.4.4.1 General........................................................................................................................ 43
7.4.4.2 Value Output Trigger .................................................................................................. 44
7.5 Outputs .......................................................................................................................................................... 45
7.5.1 Overview ....................................................................................................................................... 45
7.5.2 Analog Output Scaling ................................................................................................................. 46
7.5.2.1 Output Scaling ............................................................................................................ 46
7.5.2.2 Output Scaling with Key Select................................................................................... 47
7.5.2.3 Output Scaling via Hardware Input............................................................................. 48
7.5.2.4 Calculation of Measuring Value using Analog Current............................................... 49
7.5.2.5 Characteristics Distance Value and Analog Output.................................................... 51
7.5.2.6 Zeroing and Teaching Analog Output......................................................................... 53
7.5.3 Switching Output.......................................................................................................................... 54

optoNCDT 1220
7.6 System Settings............................................................................................................................................. 55
7.6.1 General ......................................................................................................................................... 55
7.6.2 Unit, Language ............................................................................................................................ 55
7.6.3 Keylock ......................................................................................................................................... 55
7.6.4 Load, Save.................................................................................................................................... 56
7.6.5 Import, Export............................................................................................................................... 58
7.6.6 Access Authorization.................................................................................................................... 59
8. Digital Interface RS422 .......................................................................................................... 61
9. Cleaning.................................................................................................................................. 61
10. Liability for Material Defects.................................................................................................. 62
11. Decommissioning, Disposal .................................................................................................. 62
12. Service, Repair ....................................................................................................................... 62
Appendix
A 1 Optional Accessories..................................................................................................................................... 63
A 2 Factory Setting............................................................................................................................................... 64

optoNCDT 1220

Page 7
Safety
optoNCDT 1220
1. Safety
Sensor operation assumes knowledge of the operating instructions.
1.1 Symbols Used
The following symbols are used in this operating instructions:
Indicates a hazardous situation which, if not avoided, may result in minor or moderate
injury
Indicates a situation that may result in property damage if not avoided.
Indicates a user action.
iIndicates a tip for users.
Measure Indicates hardware or a software button/menu.
1.2 Warnings
Avoid unnecessary laser radiation to be exposed to the human body.
Switch off the sensor for cleaning and maintenance.
Switch off the sensor for system maintenance and repair if the sensor is integrated into a system.
Caution - use of controls or adjustments or performance of procedures other than those specified may cause
harm.
Connect the power supply and the display/output device according to the safety regulations for electrical
equipment.
> Risk of injury
> Damage to or destruction of the sensor
Avoid shocks and impacts to the sensor.
> Damage to or destruction of the sensor

Page 8
Safety
optoNCDT 1220
Mount the sensor only to the existing holes on a flat surface. Clamps of any kind are not permitted.
> Damage to or destruction of the sensor
The supply voltage must not exceed the specified limits.
> Damage to or destruction of the sensor
Protect the sensor cable against damage. Attach the cable load-free, hold the cable after appr. 25 cm e.g. zip
tie.
> Destruction of the sensor
> Failure of the measuring device
Avoid constant exposure of sensor to splashes of water.
> Damage to or destruction of the sensor
Avoid exposure of sensor to aggressive media (detergents, cooling emulsions).
> Damage to or destruction of the sensor
1.3 Notes on CE Marking
The following apply to the optoNCDT 1220:
- EU Directive 2014/30/EU
- EU Directive 2011/65/EU, “RoHS“ category 9
Products which carry the CE mark satisfy the requirements of the EU directives cited and the European
harmonized standards (EN) listed therein. The EU Declaration of Conformity is available to the responsible
authorities according to EU Directive, article 10, at
MICRO-EPSILON MESSTECHNIK
GmbH & Co. KG
Königbacher Straße 15
94496 Ortenburg / Germany
The sensor is designed for use in industrial environments and meets the requirements.

Page 9
Safety
optoNCDT 1220
1.4 Intended Use
- The optoNCDT 1220 system is designed for use in industrial and laboratory applications.
- It is used
for measuring displacement, distance, position and thickness
for in-process quality control and dimensional testing
- The sensor must only be operated within the limits specified in the technical data, see Chap. 3.3.
- The sensor must be used in such a way that no persons are endangered or machines and other material
goods are damaged in the event of malfunction or total failure of the controller.
- Take additional precautions for safety and damage prevention in case of safety-related applications.
1.5 Proper Environment
- Protection class: IP 65 (applies only when the sensor cable is plugged in)
Lenses are excluded from protection class. Contamination of the lenses leads to impairment or failure of the
function.
- Temperature range:
Operation: 0 °C ... 50 °C (+32 up to +104 °F)
Storage: -20 °C ... 70 °C (-4 up to +158 °F)
- Humidity: 5 - 95 % (non-condensing)
- Ambient pressure: Atmospheric pressure
iThe protection class is limited to water (no penetrating liquids, detergents or similar aggressive media).

Page 10
Laser Class
optoNCDT 1220
Never deliberately look
into the laser beam!
Consciously close
your eyes or turn away
immediately if ever the
laser beam should hit
your eyes.
2. Laser Class
The optoNCDT 1220 sensors operate with a semiconductor laser with a wavelength of 670 nm (visible/red).
The sensors fall within Laser Class 2 (II). The laser is operated on a pulsed mode, the average power is
≤1mW.Thepulsefrequencydependsontheadjustedmeasuringrate(0.25...1kHz).Thepulseduration
of the peaks is regulated depending on the measuring rate and reflectivity of the target and can be 0.3 up to
3999.6 µs.
iObserve the laser protection regulations!
Although the laser output is low looking directly into the laser beam must be avoided. Due to the visible light
beam eye protection is ensured by the natural blink reflex. The housing of the optical sensors may only be
opened by the manufacturer, see Chap. 10. For repair and service purposes the sensors must always be sent
to the manufacturer.
Lasers of Class 2 (II) are not subject to notification and a laser protection officer is not required.
The following warning labels are attached to the sensor cable.
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
IEC 60825-1: 2014
P 1mW; =670nm
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR CONFORMANCE WITH IEC 60825-1
ED. 3., AS DESCRIBED IN
LASER NOTICE NO. 56, DATED MAY 8, 2019.
LASERSTRAHLUNG
NICHT IN DEN STRAHL BLICKEN
LASER KLASSE 2
nach DIN EN 60825-1: 2015-07
P 1mW; =670nm
Fig. 1 Laser warning labels on the sensor cable
Fig. 2 Laser warning labels on the sensor housing

Page 11
Laser Class
optoNCDT 1220
During operation of the sensor the pertinent regulations acc. to IEC 60825-1 on „radiation safety of laser
equipment“ must be fully observed at all times. The sensor complies with all applicable laws for the manufac-
turer of laser devices.
Laser operation is indicated by LED, see Chap. 5.3.
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
IEC 60825-1: 2014
P 1mW; =670nm
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR CONFORMANCE WITH IEC 60825-1
ED. 3., AS DESCRIBED IN
LASER NOTICE NO. 56, DATED MAY 8, 2019.
Fig. 3 True reproduction of the sensor with its actual location of the warning labels, ILD 1220
iIf both warning labels are covered over when the unit is installed the user must ensure that supplemen- tary labels are applied.

Page 12
Functional Principle, Technical Data
optoNCDT 1220
3. Functional Principle, Technical Data
3.1 Short Description
The optoNCDT 1220 uses the principle of optical triangulation, that is, a visible, modulated point of light is
projected onto the target surface.
The diffuse part of the reflection of this point of light is displayed depending on distance on a position-resolv-
ing element (CMOS) by an receiver optic which is arranged to the optical axis of the laser beam in a defined
angle.
A signal processor in the sensor calculates the distance of the point of light on the measuring object to the
sensor by means of the output signal of the CMOS elements. The distance value is linearized and output by
means of the analog interface.
SMRMR
optoNCDT
Current output
3 mA
4 mA (SMR)
12 mA (MMR)
20 mA (EMR)
3 mA
MR = Measuring range
SMR = Start of measuring range
MMR = Midrange
EMR = End of measuring range
Fig. 4 Definition of terms

Page 13
Functional Principle, Technical Data
optoNCDT 1220
3.2 Auto Target Compensation (ATC)
The Auto Target Compensation (ATC) enables stable compensation independent of color and brightness of
the measuring object. Also small objects can be detected reliably thanks to the small measuring spot.

Page 14
Functional Principle, Technical Data
optoNCDT 1220
3.3 Technical Data
Available for OEM series
Model ILD1220-10 ILD1220-25 ILD1220-50 ILD1220-100 ILD1220-200 ILD1220-500
Measuring range 10 mm 25 mm 50 mm 100 mm 200 mm 500 mm
Start of measuring range SMR 20 mm 25 mm 35 mm 50 mm 60 mm 100 mm
Mid of measuring range MMR 25 mm 37.5 mm 60 mm 100 mm 160 mm 350 mm
End of measuring range EMR 30 mm 50 mm 85 mm 150 mm 260 mm 600 mm
Measuring rate 1 0.25 kHz / 0.5 kHz / 1 kHz
Linearity < ± 10 µm < ± 25 µm < ± 50 µm < ± 100 µm < ± 200 µm < ± 750 µm
... 1500 µm
Repeatability 2 <3.7 µm <9.2 µm <18.4 µm <37 µm <74 µm <185 µm
Temperature stability ± 0.03 % FSO/°C
Light spot diameter
(±10%), [µm]
SMR 90 x 120 100 x 140 90 x 120
750 x 1100 750 x 1100 750 x 1100MMR 45 x 40 120 x 130 230 x 240
EMR 140 x 160 390 x 500 630 x 820
smallest
diameter
45 x 40
with 24 mm
55 x 50
with 31 mm
70 x 65
with 42 mm - - -
Light source semiconductor laser < 1 mW, 670 nm (red)
Laser safety class class 2 in accordance with IEC 60825-1: 2014
Permissible ambient light 3 20,000 lx 7,500 lx
Supply voltage 11…30 VDC
Power consumption < 2 W (24 V)
Analog output 4 ... 20 mA (freely scalable within the measuring range)

Page 15
Functional Principle, Technical Data
optoNCDT 1220
Switching output 1x limit monitoring or error output, npn, pnp, push pull
Connection integrated cable 2 m, open ends, minimum bending radius 30 mm (fixed installation)
Mounting screw connection via two mounting holes
Temperature range Storage -20 … +70 °C (non-condensing)
Operation 0 … +50 °C (non-condensing)
Shock (DIN-EN 60068-2-29) 15 g / 6 ms in 3 axes
Vibration (DIN-EN 60068-2-6) 20 g / 20 … 500 Hz
Protection class (DIN-EN 60529) IP65
Material aluminum housing
Weight approx. 30 g (without cable), approx. 110 g (incl. cable)
Control and display elements key operation for zero / teach / factory settings; web interface for setup 4,
2 x 3 color LEDs for power and status
Specifications apply for a diffusely reflecting matt white ceramic target.
FSO = full scale output, SMR = start of measuring range, MMR = mid of measuring range, EMR = end of measuring range
1) Factory setting 1 kHz; modifying the factory settings requires the IF2001/USB converter (optionally available)
2) Measuring rate 1 kHz, median 9
3) Illuminant: light bulb
4) Connection to PC via IF2001/USB (optionally available)

Page 16
Delivery
optoNCDT 1220
4. Delivery
4.1 Unpacking, Included in Delivery
- 1 Sensor ILD 1220
- 1 Assembly instruction
- 1 Calibration protocol
- Accessories (2 pieces screw M2 and 2 pieces washer)
Carefully remove the components of the measuring system from the packaging and ensure that the
goods are forwarded in such a way that no damage can occur.
Check the delivery for completeness and shipping damage immediately after unpacking.
If there is damage or parts are missing, immediately contact the manufacturer or supplier.
See Appendix for further accessories, see Chap. A 1
4.2 Storage
Storage temperature: -20 up to +70 °C (-4 °F up to +158 °F)
Humidity: 5 - 95 % (non-condensing)

Page 17
Installation
optoNCDT 1220
5. Installation
5.1 Instructions for Installation
5.1.1 Reflection Factor of the Target Surface
In principle the sensor evaluates the diffuse part of the reflected laser light.
Laser beam
Ideal diffuse reflection Real reflectionDirect mirror reflection
Laser beam Laser beam

2
Fig. 5 Reflection factor of the target surface
A statement concerning a minimum reflectance is difficult to make because even a small diffuse fraction can
be evaluated from highly reflecting surfaces. This is done by determining the intensity of the diffuse reflection
from the CMOS signal in real time and subsequent compensation, see Chap. 3.2. Dark or shiny objects being
measured, e.g. black rubber, may require longer exposure times. The exposure time is dependent on the
measuring rate and can only be increased by reducing the sensor’s measuring rate.
5.1.2 Error Influences
5.1.2.1 Light from other Sources
Thanks to their integrated optical interference filters the optoNCDT 1220 sensors offer outstanding perfor-
mance in suppressing light from other sources. However, this does not preclude the possibility of interference
from other light sources if the objects being measured are shiny and if lower measuring rates are selected.
Should this be the case it is recommended to use suitable shields to screen the other light sources. This ap-
plies in particular to measurement work performed in close proximity to welding equipment.

Page 18
Installation
optoNCDT 1220
5.1.2.2 Color Differences
Because of intensity compensation, color difference of targets affect the measuring result only slightly. How-
ever, such color differences are often combined with different penetration depths of the laser light into the
material. Different penetration depths then result in apparent changes of the measuring spot size. Therefore
color differences in combination with changes of penetration depth may lead to measuring errors.
5.1.2.3 Temperature Influences
When the sensor is commissioned a warm-up time of at least 20 minutes is required to achieve uniform
temperature distribution in the sensor. If measurement is performed in the micron accuracy range, the effect
of temperature fluctuations on the sensor holder must be considered. Due to the damping effect of the heat
capacity of the sensor, sudden temperature changes are only measured with delay.
5.1.2.4 Mechanical Vibration
Ifthesensoristobeusedforresolutionsintheμmtosub-μmrange,specialcaremustbetakentoensure
stable and vibration-free mounting of sensor and target.
5.1.2.5 Movement Blurs
If the objects being measured are fast moving and the measuring rate is low, it is possible that movement
blurs may result. Always select a high measuring rate for high-speed operations, therefore, in order to prevent
errors.

Page 19
Installation
optoNCDT 1220
5.1.2.6 Surface Roughness
Laser-optical sensors detect the surface using an extremely small laser spot. They also track slight surface
unevenness. In contrast, a tactile, mechanical measurement, e.g. using a caliper, detects a much larger area
ofthemeasurementobject.Incaseoftraversingmeasurements,surfaceroughnessesof5μmandmorelead
to an apparent distance change.
Suitable parameters for the averaging number may improve the comparability of optical and mechanical
measurements.
h > 5 µm
Max. Min.
Ceramic reference surface Structured surface
Recommendation for parameter choice:
- The averaging number should be selected in such a way that a surface area the size of which is compa-
rable to those with mechanical measurements is averaged.

Page 20
Installation
optoNCDT 1220
5.1.2.7 Angle Influences
Tilt angles of the target in diffuse reflection both around the X and the Y axis of less than 5 ° only have a
disturbing effect with surfaces which are highly reflecting.
These influences have to be explicitly considered when scanning profiled surfaces. Basically the angle be-
havior of triangulation is liable to the reflectivity of the measuring object surface.
Angle
X-axise Y-axis
Fig. 6 Measurement errors through tilting with diffuse reflection
