MICRO-EPSILON optoNCDT 1750 User manual

ILD1750-2
ILD1750-10
ILD1750-20
ILD1750-50
ILD1750-100
ILD1750-200
ILD1750-500
ILD1750-750
ILD1750-2LL
ILD1750-10LL
ILD1750-20LL
ILD1750-50LL
Operating Instructions
optoNCDT 1750

MICRO-EPSILON
MESSTECHNIK
GmbH & Co. KG
Königbacher Straße 15
94496 Ortenburg / Germany
Tel. [phone] / 168-0
Fax [phone] / 168-90
e-mail [email protected]
www.micro-epsilon.com
Intelligent laser optical displacement measurement

optoNCDT 1750
Contents
1. Safety ........................................................................................................................................ 9
1.1 Symbols Used ................................................................................................................................................. 9
1.2 Warnings.......................................................................................................................................................... 9
1.3 Notes on CE Marking .................................................................................................................................... 10
1.4 Intended Use ................................................................................................................................................. 11
1.5 Proper Environment....................................................................................................................................... 11
2. Laser Safety............................................................................................................................ 12
3. Functional Principle, Technical Data ..................................................................................... 14
3.1 Short Description........................................................................................................................................... 14
3.2 Real Time Control (RTSC) ............................................................................................................................. 15
3.3 Technical Data ............................................................................................................................................... 16
4. Delivery ................................................................................................................................... 20
4.1 Unpacking, Included in Delivery.................................................................................................................... 20
4.2 Storage .......................................................................................................................................................... 20
5. Installation .............................................................................................................................. 21
5.1 Instructions for Installation ............................................................................................................................ 21
5.1.1 Reflection Factor of the Target Surface ....................................................................................... 21
5.1.2 Error Influences ........................................................................................................................... 21
5.1.2.1 Light from other Sources ......................................................................................... 21
5.1.2.2 Color Differences ..................................................................................................... 22
5.1.2.3 Temperature Influences ........................................................................................... 22
5.1.2.4 Mechanical Vibration ............................................................................................... 22
5.1.2.5 Movement Blurs ....................................................................................................... 22
5.1.2.6 Surface Roughness .................................................................................................. 23
5.1.2.7 Angle Influences ...................................................................................................... 24
5.1.3 Optimizing the Measuring Accuracy ........................................................................................... 25
5.2 Mounting, Dimensions................................................................................................................................... 26
5.3 Indicator Elements at Sensor ........................................................................................................................ 29
5.4 Electrical Connections................................................................................................................................... 30
5.4.1 Connection Possibilities ............................................................................................................... 30
5.4.2 Pin Assignment............................................................................................................................. 32
5.4.3 Supply voltage.............................................................................................................................. 33

optoNCDT 1750
5.4.4 Laser On ....................................................................................................................................... 34
5.4.5 Analog Output .............................................................................................................................. 35
5.4.6 Multifunction Input........................................................................................................................ 36
5.4.7 RS422 Connection with USB Converter IF2001/USB.................................................................. 36
5.4.8 Digital Output................................................................................................................................ 37
5.4.9 Connector and Sensor Cable....................................................................................................... 38
6. Operation ................................................................................................................................ 40
6.1 Getting Ready for Operation ......................................................................................................................... 40
6.2 Operation via Web Interface.......................................................................................................................... 41
6.2.1 Preconditions................................................................................................................................ 41
6.2.2 Access via Web Interface ............................................................................................................. 42
6.2.3 Measurement Configuration......................................................................................................... 44
6.2.4 Measurement Presentation via Web Browser.............................................................................. 45
6.2.5 Video Signal via Web Browser ..................................................................................................... 47
6.3 Programming via ASCII Commands ............................................................................................................. 49
6.4 Timing, Measurement Value Flux .................................................................................................................. 49
6.5 Menu Structure, Operation via Membrane Keys........................................................................................... 50
7. Setting Sensor Parameters.................................................................................................... 52
7.1 Preliminary remarks about the setting possibilities ...................................................................................... 52
7.2 Overview Parameter....................................................................................................................................... 52
7.3 Inputs ............................................................................................................................................................. 53
7.4 Data Recording.............................................................................................................................................. 54
7.4.1 Preliminary Remark ...................................................................................................................... 54
7.4.2 Measuring Rate ............................................................................................................................ 54
7.4.3 Triggering...................................................................................................................................... 55
7.4.3.1 General...................................................................................................................... 55
7.4.3.2 Triggering Data Recording ....................................................................................... 57
7.4.3.3 Triggering Data Output ............................................................................................. 57
7.4.4 Masking the Evaluation Range, ROI ............................................................................................ 58
7.4.5 Exposure Mode ............................................................................................................................ 59
7.4.6 Peak Selection.............................................................................................................................. 59
7.4.7 Error Processing........................................................................................................................... 60

optoNCDT 1750
7.5 Signal Processing.......................................................................................................................................... 61
7.5.1 Preliminary Remark ...................................................................................................................... 61
7.5.2 Averaging...................................................................................................................................... 61
7.5.2.1 General...................................................................................................................... 61
7.5.2.2 Moving average ........................................................................................................ 62
7.5.2.3 Recursive average .................................................................................................... 63
7.5.2.4 Median ...................................................................................................................... 63
7.5.3 Zeroing and Mastering ................................................................................................................. 64
7.5.3.1 Zeroing, Mastering using the Select Button............................................................. 65
7.5.3.2 Zeroing, Mastering via Hardware Input .................................................................... 66
7.5.4 Output Trigger .............................................................................................................................. 67
7.5.5 Data Reduction, Output Data Rate............................................................................................... 67
7.6 Outputs .......................................................................................................................................................... 68
7.6.1 Overview ....................................................................................................................................... 68
7.6.2 Digital Output, RS422................................................................................................................... 70
7.6.2.1 Values, Ranges ......................................................................................................... 70
7.6.2.2 Behavior of the Digital Output................................................................................... 72
7.6.3 Analog Output .............................................................................................................................. 74
7.6.3.1 Output Scaling .......................................................................................................... 74
7.6.3.2 Output Scaling with the Select Button...................................................................... 75
7.6.3.3 Output Scaling via Hardware Input .......................................................................... 76
7.6.3.4 Calculation of the Measurement Value at the Current Output ................................. 77
7.6.3.5 Calculation of the measurement value from the voltage output .............................. 78
7.6.3.6 Behavior Distance Value and Analog Output ........................................................... 81
7.6.3.7 Analog output mastering and teaching.................................................................... 84
7.6.4 Switching Outputs ........................................................................................................................ 85
7.6.5 Data Output .................................................................................................................................. 86
7.7 System Settings............................................................................................................................................. 87
7.7.1 General ......................................................................................................................................... 87
7.7.2 Unit, Language ............................................................................................................................. 87
7.7.3 Key Lock ....................................................................................................................................... 87
7.7.4 Load and Safe .............................................................................................................................. 88
7.7.5 Import, Export............................................................................................................................... 90
7.7.6 Access Authorization.................................................................................................................... 91
7.7.7 Reset Sensor ................................................................................................................................ 92

optoNCDT 1750
8. Digital Interfaces RS422 ........................................................................................................ 93
8.1 Preliminary Remarks...................................................................................................................................... 93
8.2 Measurement Data Format............................................................................................................................ 93
8.3 Conversion of the Binary Data Format .......................................................................................................... 94
9. Cleaning.................................................................................................................................. 95
10. Protective Housing................................................................................................................. 96
10.1 Versions ......................................................................................................................................................... 96
10.2 Guidelines ..................................................................................................................................................... 96
10.3 Delivery ......................................................................................................................................................... 96
11. Software Support with MEDAQLib ........................................................................................ 99
12. Liability for Material Defects................................................................................................ 100
13. Decommissioning, Disposal................................................................................................ 100
14. Service, Repair ..................................................................................................................... 100
Appendix
A 1 Optional Accessories................................................................................................................................... 101
A 2 Factory Setting............................................................................................................................................. 103
A 3 ASCII Communication with Sensor ............................................................................................................. 104
A 3.1 General ........................................................................................................................................................ 104
A 3.2 Overview Commands .................................................................................................................................. 106
A 3.2.1 General Commands ................................................................................................................... 109
A 3.2.1.1 HELP ....................................................................................................................... 109
A 3.2.1.2 GETINFO, Sensor information ............................................................................... 110
A 3.2.1.3 LANGUAGE, Website.............................................................................................. 111
A 3.2.1.4 RESET, boot sensor ............................................................................................... 111
A 3.2.1.5 RESETCNT, Reset counter...................................................................................... 111
A 3.2.1.6 ECHO, Switching the Command Reply, ASCII Interface........................................ 111
A 3.2.1.7 PRINT, Sensor settings ........................................................................................... 112
A 3.2.1.8 SYNC....................................................................................................................... 113
A 3.2.1.9 TERMINATION ........................................................................................................ 114

optoNCDT 1750
A 3.2.2 User Level................................................................................................................................... 114
A 3.2.2.1 LOGIN, Change of the User Level .......................................................................... 114
A 3.2.2.2 LOGOUT, Change into User Level .......................................................................... 114
A 3.2.2.3 GETUSERLEVEL, User Level Request ................................................................... 114
A 3.2.2.4 STDUSER, Set Standard User................................................................................ 114
A 3.2.2.5 PASSWD, Change Password.................................................................................. 115
A 3.2.3 Triggering.................................................................................................................................... 115
A 3.2.3.1 TRIGGERLEVEL, Active level triggering................................................................. 115
A 3.2.3.2 TRIGGERMODE...................................................................................................... 115
A 3.2.3.3 TRIGGERSOURCE, Trigger source ........................................................................ 115
A 3.2.3.4 TRIGGERAT, Effect of the Trigger Input.................................................................. 116
A 3.2.3.5 MFILEVEL, Input Level Multi-Function Input .......................................................... 116
A 3.2.3.6 TRIGGERCOUNT, Number of Output Measurement Values.................................. 116
A 3.2.3.7 TRIGGERSW, Software Trigger Pulse..................................................................... 116
A 3.2.4 Interfaces .................................................................................................................................... 117
A 3.2.4.1 BAUDRATE, RS422 ................................................................................................ 117
A 3.2.4.2 ERROROUT1/2, Activate Switching Output............................................................ 117
A 3.2.4.3 ERRORLEVELOUT1/2, Output Level Switching Output......................................... 117
A 3.2.4.4 ERRORLIMITCOMPARETO1/2................................................................................ 117
A 3.2.4.5 ERRORLIMITVALUES1/2 ........................................................................................ 118
A 3.2.4.6 ERRORHYSTERESIS .............................................................................................. 118
A 3.2.4.7 ERROROUTHOLD .................................................................................................. 118
A 3.2.5 Handling of Setups..................................................................................................................... 118
A 3.2.5.1 IMPORT................................................................................................................... 118
A 3.2.5.2 EXPORT .................................................................................................................. 119
A 3.2.5.3 MEASSETTINGS, Load / Save Measurement Settings.......................................... 119
A 3.2.5.4 BASICSETTINGS, Load / Save Device Settings .................................................... 120
A 3.2.5.5 SETDEFAULT, Factory Settings .............................................................................. 120
A 3.2.6 Analog Output ............................................................................................................................ 120
A 3.2.6.1 ANALOGRANGE ..................................................................................................... 120
A 3.2.6.2 ANALOGSCALEMODE, Scaling the Analog Output .............................................. 120
A 3.2.6.3 ANALOGSCALERANGE, Scaling Limits with Two-Point Scaling ........................... 121
A 3.2.6.4 ANALOGSCALESOURCE ....................................................................................... 121
A 3.2.7 Key Function............................................................................................................................... 122
A 3.2.7.1 KEYLOCK, Set Key lock.......................................................................................... 122

optoNCDT 1750
A 3.2.8 Measurement.............................................................................................................................. 122
A 3.2.8.1 TARGETMODE, Measurement Task ....................................................................... 122
A 3.2.8.2 MEASPEAK, Choice of the Peak in the Video Signal............................................. 122
A 3.2.8.3 MEASRATE, Measuring rate ................................................................................... 122
A 3.2.8.4 SHUTTER, Exposure Time ..................................................................................... 123
A 3.2.8.5 SHUTTERMODE ..................................................................................................... 123
A 3.2.8.6 LASERPOW, Laser Power....................................................................................... 123
A 3.2.8.7 ROI, Video Signal, Masking the Evaluation Range ................................................ 123
A 3.2.8.8 AVERAGE, Averaged Measurements..................................................................... 123
A 3.2.8.9 MASTER.................................................................................................................. 124
A 3.2.8.10 MASTERSIGNAL..................................................................................................... 124
A 3.2.8.11 MASTERSOURCE................................................................................................... 124
A 3.2.9 Data output................................................................................................................................. 125
A 3.2.9.1 OUTPUT, Selection of Measurement Value Output................................................ 125
A 3.2.9.2 OUTREDUCEDEVICE, Output Reduction of Measurement Value Outpu.............. 125
A 3.2.9.3 OUTREDUCECOUNT, Data Output Rate................................................................ 125
A 3.2.9.4 OUTHOLD, Error Processing.................................................................................. 125
A 3.2.9.5 GETOUTINFO_RS422, Query Selected Data......................................................... 126
A 3.2.9.6 OUT_RS422 ............................................................................................................ 126
A 3.3 Example Command Sequence During Selection of Measurement Value.................................................. 127
A 3.4 Error Messages............................................................................................................................................ 128
A 4 Control Menu ............................................................................................................................................... 130
A 4.1 Tab Home..................................................................................................................................................... 130
A 4.2 Tab Settings ................................................................................................................................................. 130
A 4.2.1 Inputs.......................................................................................................................................... 130
A 4.2.2 Data Recording........................................................................................................................... 131
A 4.2.3 Signal Processing....................................................................................................................... 133
A 4.2.4 Outputs ....................................................................................................................................... 134
A 4.2.5 System Settings.......................................................................................................................... 136

Page 9
Safety
optoNCDT 1750
1. Safety
The handling of the sensor assumes knowledge of the operating instructions.
1.1 Symbols Used
The following symbols are used in this operating instructions:
Indicates a hazardous situation which, if not avoided, may result in minor or moderate
injury.
Indicates a situation that may result in property damage if not avoided.
Indicates a user action.
iIndicates a tip for users.
Measure Indicates hardware or a software button/menu.
1.2 Warnings
Avoid unnecessary laser radiation to be exposed to the human body.
Switch off the sensor for cleaning and maintenance.
Switch off the sensor for system maintenance and repair if the sensor is integrated into a system.
Caution - use of controls or adjustments or performance of procedures other than those specified may cause
harm.
Connect the power supply and the display-/output device in accordance with the safety regulations for electri-
cal equipment.
> Risk of injury
> Damage to or destruction of the sensor
Avoid shocks and impacts to the sensor.
> Damage to or destruction of the sensor

Page 10
Safety
optoNCDT 1750
Mount the sensor only to the existing holes on a flat surface. Clamps of any kind are not permitted
> Damage to or destruction of the sensor
The power supply may not exceed the specified limits.
> Damage to or destruction of the sensor
Protect the sensor cable against damage. Attach the cable load-free, hold the cable after appr. 25 cm and
hold the pigtail on the connector e.g. zip tie.
> Destruction of the sensor
> Failure of the measuring device
Avoid continuous exposure to fluids on the sensor.
> Damage to or destruction of the sensor
Avoid exposure to aggressive materials (washing agent, penetrating liquids or similar) on the sensor.
> Damage to or destruction of the sensor
1.3 Notes on CE Marking
The following apply to the optoNCDT 1750:
- EU directive 2014/30/EU
- EU directive 2011/65/EU, “RoHS“ category 9
Products which carry the CE mark satisfy the requirements of the EU directives cited and the European
harmonized standards (EN) listed therein. The EU Declaration of Conformity is available to the responsible
authorities according to EU Directive, article 10, at:
MICRO-EPSILON MESSTECHNIK
GmbH & Co. KG
Königbacher Straße 15
94496 Ortenburg / Germany
The sensor is designed for use in industrial environments and meets the requirements.

Page 11
Safety
optoNCDT 1750
1.4 Intended Use
- The optoNCDT 1750 system is designed for use in industrial and laboratory applications.
- It is used
for measuring displacement, distance and position
for in-process quality control and dimensional testing
- The system must only be operated within the limits specified in the technical data, see Chap. 3.3.
- The sensor must be used in such a way that no persons are endangered or machines and other material
goods are damaged in the event of malfunction or total failure of the sensor.
- Take additional precautions for safety and damage prevention in case of safety-related applications.
1.5 Proper Environment
- Protection class: IP 65 (applies only when the sensor cable is plugged in)
Lenses are excluded from protection class. Contamination of the lenses leads to impairment or failure of the
function.
- Operating temperature: 0 °C ... 50 °C (+32 up to +104 °F)
- Storage temperature: -20 °C ... 70 °C (-4 up to +158 °F)
- Humidity: 5 - 95 % (non-condensing)
- Ambient pressure: Atmospheric pressure
iThe protection class is limited to water, no penetrating liquids or similar!

Page 12
Laser Safety
optoNCDT 1750
Never deliberately look
into the laser beam!
Consciously close
your eyes or turn away
immediately if ever the
laser beam should hit
your eyes.
2. Laser Safety
The optoNCDT 1750 sensors operate with a semiconductor laser with a wavelength of 670 nm (visible/red).
The sensors fall within Laser Class 2 (II). The laser is operated on a pulsed mode, the average power is
≤1mW.Thepulsefrequencydependsontheadjustedmeasuringrate(0.3...7.5kHz).Thepulseduration
of the peaks is regulated depending on the measuring rate and reflectivity of the target and can be 0 up to
3333 µs.
iComply with all regulations on lasers!
Although the laser output is low looking directly into the laser beam must be avoided. Due to the visible light
beam eye protection is ensured by the natural blink reflex. The housing of the optical sensors may only be
opened by the manufacturer, see Chap. 12. For repair and service purposes the sensors must always be sent
to the manufacturer.
Lasers of Class 2 (II) are not subject to notification and a laser protection officer is not required.
The following warning labels are attached to the cover (front and/or rear side) of the sensor housing:
Laser radiation
Do not stare into the beam
Class 2 Laser Product
IEC 60825-1: 2015-07
P 1mW; =670nm≤
Fig. 1 IEC label Fig. 2 Only for USA
During operation of the sensor the pertinent regulations acc. to IEC 60825-1 on „radiation safety of laser
equipment“ must be fully observed at all times. The sensor complies with all applicable laws for the manufac-
turer of laser devices.
Laser operation is indicated by LED, see Chap. 5.3.

Page 13
Laser Safety
optoNCDT 1750
sensor off
RS422 on
output off
analog on
optoNCDT
LASER RADIATION
DO NOT STARE INTO BEAM
CLAS 2 LASER PRODUCT
IEC 60825-1: 2015-07
P 1mW; =670nm≤
THIS PRODUCT COMPLIES
WITH FDA REGULATIONS
21CFR 1040.10 AND 1040.11
Fig. 3 True reproduction of the sensor with its actual location of the warning labels, ILD1750
iIf both warning labels are covered over when the unit is installed the user must ensure that supplemen- tary labels are applied.

Page 14
Functional Principle, Technical Data
optoNCDT 1750
3. Functional Principle, Technical Data
3.1 Short Description
The optoNCDT 1750 uses the principle of optical triangulation, that is, a visible, modulated point of light is
projected onto the target surface.
The diffuse part of the reflection of this point of light is displayed depending on distance on a position-resolv-
ing element (CMOS) by an receiver optic which is arranged to the optical axis of the laser beam in a defined
angle.
A signal processor in the sensor calculates the distance of the point of light on the measuring object to the
sensor by means of the output signal of the CMOS elements. The distance value is linearized and output by
means of the analog or RS422 interface.
SMRRange
sensor off
RS422 on
output off
analog on
optoNCDT
LASER RADIATION
DO NOT STARE INTO BEAM
CLAS 2 LASER PRODUCT
IEC 60825-1: 20xx-xx
P 1mW; =670nm≤
Current Voltage Digital value 1
3 mA 262077
4 mA (SMR) 98232
12 mA (MR) 131000
20 mA (EMR) 163768
3 mA
5.2 V / 10.2 V
0 V
2.5 V / 5 V
5 V / 10 V
5.2 V / 10.2 V 262078
Range = Measuring range
SMR = Start of measuring range
MR = Midrange
EMR = End of measuring range
Fig. 4 Definition of terms
1) For distance
values without zero
setting resp. master-
ing only.

Page 15
Functional Principle, Technical Data
optoNCDT 1750
3.2 Real Time Control (RTSC)
The CMOS element determines the intensity of incident light during the exposure. This enables the sensor to
compensate for fluctuations in brightness on the object being measured. What is more, it does so in a range
from almost total absorption to almost total reflection. The RTSC (Real-Time-Surface-Compensation) allows
an accurate real-time surface compensation in the measurement process with a high dynamic range.

Page 16
Functional Principle, Technical Data
optoNCDT 1750
3.3 Technical Data
Model ILD1750- 2 10 20 50 100 200 500 750
Measuring range 2 mm 10 mm 20 mm 50 mm 100 mm 200 mm 500 mm 750 mm
Start of measuring range 24 mm 30 mm 40 mm 45 mm 70 mm 70 mm 200 mm 200 mm
Midrange 25 mm 35 mm 50 mm 70 mm 120 mm 170 mm 450 mm 575 mm
End of measuring range 26 mm 40 mm 60 mm 95 mm 170 mm 270 mm 700 mm 950 mm
Linearity 1.6 µm 6 µm 12 µm 30 µm 60 µm 160 µm 350 µm 670 µm
% FSO ≤±0.08 ≤±0.06 ≤±0.08 ≤±0.07 ≤±0.09
Repeatability 2) 0.1 µm 0.4 µm 0.8 µm 2 µm 4 µm 8 µm 20 µm 30 µm
Measuring rate continuously adjustable between 0.3 ... 7.5 kHz
adjustable in 6 steps: 7.5 kHz / 5 kHz / 2.5 kHz / 1.25 kHz / 625 Hz / 300 Hz
Light source Semiconductor laser <1 mW, 670 nm (red)
Permissible ambient light 10,000 lx (with 2.5 kHz)
Laser safety class Class 2 according to DIN EN 60825-1 : 2015-07
Spot diameter
SMR 80 µm 110 µm 320 µm 570 µm 740 µm 1300 µm 1500 µm
MMR 35 µm 50 µm 45 µm 55 µm 60 µm 1300 µm 1500 µm
EMR 80 µm 110 µm 320 µm 570 µm 700 µm 1300 µm 1500 µm
Temperature stability 1) 0.025 %
FSO/°C 0.01 % FSO/°C
Operating temperature 0 ... +50 °C
Storage temperature -20 ... +70 °C
Control inputs/outputs
1x HTL/TTL Laser on/off;
1 x HTL/TTL Multifunction input Trigger in / slave in / (zero setting / mastering / teach
2x error output (error & limit value): npn, pnp, push pull)
1x RS422 synchronization input (trigger in, sync in, master/slave, master/slave alternating)

Page 17
Functional Principle, Technical Data
optoNCDT 1750
Model ILD1750- 2 10 20 50 100 200 500 750
Measurement
value output
analog 4 ... 20 mA (0 ... 5 V / 0 ... 10 V); 16 bit; freely scalable within the measuring range
digital RS422 / 18 bit
Operation
Button Select & function buttons for interface selections, mastering (zero), teach, presets,
quality slider, frequency selection, factory settings
Web
interface
Application-specific presets; peak selection, video signal; freely selectable averaging possibilities;
data reduction; setup management 2)
Power supply 11 ... 30 V DC, 24 V / P <3 W
Sensor cable Standard 0.25 m pigtail with 14-pole ODU connector
Option Extension: 3 / 10 m
Synchronization possible for simultaneous or alternating measurements
Protection class IP 65
Vibration 2 g / 20 ... 500 Hz
Shock 15 g / 6 ms
Weight (with 25 cm cable) appr. 550 g appr. 600 g
Housing size S M
The specified data apply to a white, diffuse reflecting surface (reference: ceramics)
FSO = Full Scale Output
SMR = Start of measuring range; MMR = Midrange; EMR = End of measuring range
1) based on digital output
2) Connection to PC via IF2001/USB (optionally available)

Page 18
Functional Principle, Technical Data
optoNCDT 1750
Model ILD1750- 2LL 10LL 20LL 50LL
Measuring range 2 mm 10 mm 20 mm 50 mm
Start of measuring range 24 mm 30 mm 40 mm 45 mm
Midrange 25 mm 35 mm 50 mm 70 mm
End of measuring range 26 mm 40 mm 60 mm 95 mm
Linearity 1.6 µm 6 µm 12 µm 30 µm
% FSO ≤±0.08 ≤±0.06
Repeatability 2) 0.1 µm 0.4 µm 0.8 µm 2 µm
Measuring rate continuously adjustable between 0.3 ... 7.5 kHz
adjustable in 6 steps: 7.5 kHz / 5 kHz / 2.5 kHz / 1.25 kHz / 625 Hz / 300 Hz
Light source Semiconductor laser <1 mW, 670 nm (red)
Permissible ambient light 10,000 lx (with 2.5 kHz)
Laser safety class Class 2 according to DIN EN 60825-1 : 2015-07
Spot diameter
SMR 85 x 240 µm 120 x 405 µm 185 x 485 µm 350 x 320 µm
MMR 24 x 280 µm 35 x 585 µm 55 x 700 µm 70 x 960 µm
EMR 64 x 400 µm 125 x 835 µm 195 x 1200 µm 300 x 1940 µm
Temperature stability 1) 0.025 % FSO/°C 0.01 % FSO/°C
Operating temperature 0 ... +50 °C
Storage temperature -20 ... +70 °C
Control inputs/outputs
1x HTL/TTL Laser on/off;
1 x HTL/TTL Multifunction input Trigger in / slave in / (zero setting / mastering / teach
2x error output (error & limit value): npn, pnp, push pull)
1x RS422 synchronization input (trigger in, sync in, master/slave, master/slave alternating)

Page 19
Functional Principle, Technical Data
optoNCDT 1750
Model ILD1750- 2LL 10LL 20LL 50LL
Measurement
value output
analog 4 ... 20 mA (0 ... 5 V / 0 ... 10 V); 16 bit; freely scalable within the measuring range
digital RS422 / 18 bit
Operation
Button Select & function buttons for interface selections, mastering (zero), teach, presets,
quality slider, frequency selection, factory settings
Web
interface
Application-specific presets; peak selection, video signal;
freely selectable averaging possibilities;
data reduction; setup management 2)
Power supply 11 ... 30 V DC, 24 V / P <3 W
Sensor cable Standard 0.25 m pigtail with 14-pole ODU connector
Option Extension: 3 / 10 m
Synchronization possible for simultaneous or alternating measurements
Protection class IP 65
Vibration 2 g / 20 ... 500 Hz
Shock 15 g / 6 ms
Weight (with 25 cm cable) appr. 550 g
Housing size S
The specified data apply to a white, diffuse reflecting surface (reference: ceramics)
FSO = Full Scale Output
SMR = Start of measuring range; MMR = Midrange; EMR = End of measuring range
1) based on digital output
2) Connection to PC via IF2001/USB (optionally available)

Page 20
Delivery
optoNCDT 1750
4. Delivery
4.1 Unpacking, Included in Delivery
- 1 Sensor ILD1750
- 1 Assembly instruction
- 1 CD with program <ILD1750 DAQ Tool.exe> and instruction manual
- 1 Calibration protocol
- Laser warning labels acc. IEC norm
Carefully remove the components of the measuring system from the packaging and ensure that the
goods are forwarded in such a way that no damage can occur.
Check the delivery for completeness and shipping damage immediately after unpacking.
If there is damage or parts are missing, immediately contact the manufacturer or supplier.
Optional accessories are available in the appendix, see Chap. A 1
4.2 Storage
Storage temperature: -20 up to +70 °C (-4 °F up to +158 °F)
Humidity: 5 - 95 % (non-condensing)
