Instruction Manual
capaNCDT 6110/6120

Non-contact Capacitive Displacement Measuring
MICRO-EPSILON
MESSTECHNIK
GmbH & Co. KG
Königbacher Strasse 15
94496 Ortenburg / Germany
Tel. [phone] / 168-0
Fax [phone] / 168-90
e-mail [email protected]
www.micro-epsilon.com
Certified acc. to DIN EN ISO 9001: 2008

capaNCDT 6110 / 6120
Contents
1. Safety ........................................................................................................................................ 5
1.1 Symbols Used ................................................................................................................................................. 5
1.2 Warnings.......................................................................................................................................................... 5
1.3 Notes on CE Identification............................................................................................................................... 6
1.4 Proper Use....................................................................................................................................................... 7
1.5 Proper Environment......................................................................................................................................... 7
2. Functional Principle, Technical Data ...................................................................................... 8
2.1 Measuring Principle ......................................................................................................................................... 8
2.2 Structure .......................................................................................................................................................... 9
2.2.1 Sensors......................................................................................................................................... 10
2.2.2 Sensor Cable................................................................................................................................ 12
2.2.3 Controller ...................................................................................................................................... 13
2.3 Technical Data ............................................................................................................................................... 14
3. Delivery .................................................................................................................................. 15
3.1 Unpacking...................................................................................................................................................... 15
3.2 Storage .......................................................................................................................................................... 15
4. Installation and Assembly...................................................................................................... 16
4.1 Precautionary Measures................................................................................................................................ 16
4.2 Sensor............................................................................................................................................................ 16
4.2.1 Radial Point Clamping with Grub Screw, Cylindric Sensors ....................................................... 16
4.2.2 Circumferential Clamping, Cylindric Sensors.............................................................................. 17
4.2.3 Flat Sensors.................................................................................................................................. 17
4.2.4 Dimensional Drawings Sensors ................................................................................................... 18
4.3 Sensor Cable ................................................................................................................................................. 24
4.4 Controller ....................................................................................................................................................... 25
4.5 Ground Connection, Earthing ....................................................................................................................... 26
4.6 Power Supply, Display/Output Device DT6110............................................................................................. 26
4.7 Power Supply, Display/Output Device DT6120............................................................................................. 27
4.8 Sensor Connection........................................................................................................................................ 27

capaNCDT 6110 / 6120
5. RS485 Interface ...................................................................................................................... 28
5.1 Hardware Interface ........................................................................................................................................ 28
5.2 Protocol.......................................................................................................................................................... 28
5.2.1 Reading Measuring Values .......................................................................................................... 29
5.2.2 Scaling the Measuring Values...................................................................................................... 30
5.2.3 Example of the Measuring Value Transmission ........................................................................... 31
5.2.4 Setting the RS485 Address .......................................................................................................... 32
5.3 Commands and Settings............................................................................................................................... 33
6. Operation ................................................................................................................................ 34
7. Maintenance ........................................................................................................................... 35
8. Warranty.................................................................................................................................. 36
9. Decommissioning, Disposal .................................................................................................. 36
Appendix
A 1 Optional Accessories............................................................................................................. 37
A 2 Tilt Angle Influence on the Capacitive Sensor ..................................................................... 38
A 3 Measurement on Narrow Targets .......................................................................................... 39
A 4 Measurements on Balls and Shafts ...................................................................................... 40

Page 5
Safety
capaNCDT 6110 / 6120
1. Safety
Knowledge of the operating instructions is a prerequisite for equipment operation.
1.1 Symbols Used
The following symbols are used in this instruction manual:
Indicates a hazardous situation which, if not avoided, may result in minor or moder-
ate injury.
Indicates a situation which, if not avoided, may lead to property damage.
Indicates a user action.
iIndicates a user tip.
1.2 Warnings
Disconnect the power supply before touching the sensor surface.
> Danger of injury
> Static discharge
Connect the power supply and the display/output device in accordance with the safety regulations for electri-
cal equipment.
> Danger of injury
> Damage to or destruction of the sensor and/or controller
Avoid shock and vibration to the sensor and controller.
> Damage to or destruction of the sensor and/or controller
The power supply may not exceed or continuously fall below the specified limits.
> Damage to or destruction of the sensor and/or controller

Page 6
Safety
capaNCDT 6110 / 6120
Protect the sensor cable against damage
> Destruction of the sensor
> Failure of the measuring device
1.3 Notes on CE Identification
The following applies to the capaNCDT 6110 / 6120:
- EU directive 2004/108/EC
- EU directive 2011/65/EU, “RoHS“ category 9
Products which carry the CE mark satisfy the requirements of the quoted EU directives and the European
standards (EN) listed therein.
The EC declaration of conformity is kept available according to EC regulation, article 10 by the authorities
responsible at
MICRO-EPSILON Messtechnik GmbH & Co. KG
Königbacher Straße 15
94496 Ortenburg / Germany
The system is designed for use in industry and satisfies the requirements of the standards:
- DIN EN 61326-1: 2006
- DIN EN 55011: 2009 + A1: 2010 (group 1, class A)
- DIN EN 50581: 2012
The systems satisfy the requirements if they comply with the regulations described in the instruction manual
for installation and operation.

Page 7
Safety
capaNCDT 6110 / 6120
1.4 Proper Use
- The capaNCDT 6110 / 6120 measuring system is designed for use in industrial areas. It is used for
displacement, distance, thickness and movement measurement
position measuring of parts or machine components
- The system may only be operated within the limits specified in the technical data, see Chap. 2.3.
The system should only be used in such a way that in case of malfunction or failure personnel or ma-
chinery are not endangered.
Additional precautions for safety and damage prevention must be taken for safety-related applications.
1.5 Proper Environment
- Protection class: IP 40
- Operating temperature:
Sensor: -50 ... +200 °C (-58 to +392 °F)
Sensor cable: -50 ... +200 C (-58 to +392 °F)
Controller: +10 ... +60 °C (-50 to +140 °F)
- Humidity: 5 - 95 % (non condensing)
- Ambient pressure: Atmospheric pressure
- Storage temperature:
Sensor: -50 ... +200 °C (-58 to +392 °F)
Sensor cable: -50 ... +200 °C (-58 to +392 °F)
Controller: -10 ... +75 °C (+14 to +167 °F)
- EMC: acc. to DIN EN 61326-1: 2006-10
DIN EN 61326-2-3: 2007-05
- The space between the sensor surface and the target must have an unvarying dielectric constant.
- The space between the sensor surface and the target may not be contaminated (for example water,
rubbed-off parts, dust, et cetera

Page 8
Functional Principle, Technical Data
capaNCDT 6110 / 6120
2. Functional Principle, Technical Data
2.1 Measuring Principle
The principle of capacitive distance measurement with the capaNCDT system is based on the principle of the
parallel plate capacitor. For conductive targets, the sensor and the target opposite form the two plate elec-
trodes.
If a constant AC current flows through the sensor capacitor, the amplitude of the AC voltage at the sensor is
proportional to the distance between the capacitor electrodes. The AC voltage is demodulated, amplified and
output as an analog signal.
The capaNCDT system evaluates the reactance XCof the plate capacitor which changes strictly in proportion
to the distance.
X = ; capacitance C =  *  *
c
1
jC
area
distance
ro
iA small target and bent (uneven) surfaces cause a non-linear characteristic.
This theoretical relationship is realized almost ideally in
practice by designing the sensors as guard ring capaci-
tors.
The linear characteristic of the measuring signal is
achieved for electrically conductive target materials
(metals) without any additional electronic linearization.
Slight changes in the conductivity or magnetic proper-
ties do not affect the sensitivity or linearity.
Electrical conductor
Ground
Screening electrode
Measuring electrode
Fig. 1 Functional principle of the guard ring
capacitor

Page 9
Functional Principle, Technical Data
capaNCDT 6110 / 6120
2.2 Structure
The non-contact, single-channel measuring system of capaNCDT 6110 / 6120, installed in an aluminum hous-
ing, consists of:
- Controller
- Sensor
- Sensor cable
- Power supply and signal cable
The signal processing electronics with oscillator, demodulator, AD converter and integrated preamplifier is in
the controller 1.
5-pol. connector
Signal
fOSZ 31kHz
9 ...
36 V
Oscillator
Demodulator Preamplifier
Sensor
Sensor
cable
Voltage
processing
Fig. 2 Block diagram capaNCDT 6110
1) The controller 6120: Contains additionally an AD converter for converting to a RS485 interface.

Page 10
Functional Principle, Technical Data
capaNCDT 6110 / 6120
6 pol. connector
Signal
fOSZ 31kHz
9...28 V
Oscillator
Demodulator Preamplifier
Sensor
Sensor
cable
Voltage
processing
A/D converter
Fig. 3 Block diagram capaNCDT 6120
2.2.1 Sensors
For this measurement system, several sensors can be used.
In order to obtain accurate measuring results, keep the surface of the sensor clean and free from dam-
age.
The capacitive measuring process is area-related. A minimum area (see table) is required depending on the
sensor model and measuring range. In the case of insulators the dielectric constant and the target thickness
also play an important role.
Sensors for electrical conducting targets (metals)
Sensor model Measuring range Min. target diameter
CS02 0.2 mm 5 mm
CSH02 0.2 mm 7 mm
CSH02FL 0.2 mm 7 mm
CS05 0.5 mm 7 mm
CSE05 0.5 mm 6 mm

Page 11
Functional Principle, Technical Data
capaNCDT 6110 / 6120
Sensor model Measuring range Min. target diameter
CSH05 0.5 mm 7 mm
CSH05FL 0.5 mm 7 mm
CS08 0.8 mm 9 mm
CS1 1 mm 9 mm
CSE1 1 mm 8 mm
CSH1 1 mm 11 mm
CSH1FL 1 mm 11 mm
CS1HP 1 mm 9 mm
CSH1,2 1.2 mm 11 mm
CSH1.FL 1.2 mm 11 mm
CSH2FL 2 mm 17 mm
CS2 2 mm 17 mm
CSH2 2 mm 17 mm
CSE2 2 mm 14 mm
CS3 3 mm 27 mm
CS5 5 mm 37 mm
CS10 10 mm 57 mm

Page 12
Functional Principle, Technical Data
capaNCDT 6110 / 6120
2.2.2 Sensor Cable
Sensor and controller are connected by a special, double screened sensor cable.
Do not shorten or lengthen these special cables.
Usually, a damaged cable can not be repaired.
Switch off the device when plugging and removing connectors.
Do not crush the sensor cable.
Do not modify to the sensor cable.
> Lost of functionality
Model Cable length 2 axial
connector
1x axial +
1x 90 0
For sensors Min. bending radius
once permanently
CCmxC 1.4/2.8 m •0.05 - 0.8 mm
7 mm 15 mm
CCmxC/90 1.4/2.8 m •0.05 - 0.8 mm
CCmxB 1.4/2.8 m •1 ... 10 mm
CCmxB/90 1.4/2.8 m •1 ... 10 mm
CCgxC 2/4 m •0.05 - 0.8 mm
10 mm 22 mm
CCgxC/90 2/4 m •0.05 - 0.8 mm
CCgxB 2/4 m •1 - 10 mm
CCgxB/90 2/4 m •1 - 10 mm
The sensors of type CSH have integrated a 1.4 long sensor cable. Cable lengths of 2.8 m are available too if
required.
Other cable lengths are also available on request.
The sensor model CSE-1 (measuring range 1 mm) has the connector type C.

Page 13
Functional Principle, Technical Data
capaNCDT 6110 / 6120
2.2.3 Controller
The capaNCDT 6110 / 6120 contains a voltage processing, oscillator, integrated preamplifier, demodulator 2
as well as an output level.
The voltage processing produces all necessary internal voltages from the power supply. The oscillator sup-
plies the sensor with frequency and amplitude-stabilized alternating voltage. The frequency is 31 kHz. The
internal preamplifier generates the distance-dependent measuring signal and amplifies it. Demodulator and
output level convert the measuring signal into a standard voltage signal 3.
The output voltage can reach up to a maximum of 13 VDC when sensor is disconnected or measurement is
exceeded.
> Damage to downstream devices
Sensor
Fig. 4 Controller DT6110 / 6120
2) The controller 6120: Contains additionally an AD converter.
3) An analog-digital converter converts the measuring signal and outputs it to the RS485 interface.

Page 14
Functional Principle, Technical Data
capaNCDT 6110 / 6120
2.3 Technical Data
Controller model DT6110 DT6110/ECL2 DT6120 DT6120/ECL2
Resolution static 0,01 % FSO
Resolution dynamic 0.015 % FSO (1 kHz)
Bandwidth 1 kHz (-3 dB)
Linearity (typical) ±0.05 % FSO
Max. sensitivity deviation ±0.1 % FSO
Long term stability < 0.05 % FSO/month
Synchronous operation no
Isolator measurement no
Temperature stability 200 ppm
Operating temperature, sensor -50 ... +200 °C
Operating temperature, controller +10 … +60° C
Storage temperature -10 … +75° C
Power supply 24 VDC/55 mA (9 - 36 V) 24 VDC/60 mA (9 - 28 V)
Output 0 … 10 V (short-circuit proof), optional: ±5 V, 10 … 0 V
Sensors all sensors suitable
Sensor cable
CC 1 m 2 m 1 m 2 m
CCm 1.4 m 2.8 m 1.4 m 2.8 m
CCg 2 m 4 m 2 m 4 m
Electromagnetic compatibility (EMC) DIN EN 61326-1: 2006-10 and DIN EN 61326-2-3: 2007-5
Protection class Controller IP 40
Sensors when plugged in: IP 54
Weight 165 g
Interface - RS485, 230400 Baud (adjustable), 24 bit measuring
values, max. 2kSamples (adjustable)
FSO = Full Scale Output

Page 15
Delivery
capaNCDT 6110 / 6120
3. Delivery
3.1 Unpacking
1 Controller
1 Power supply and output cable SCAC3/5 (DT6110) or SCAC3/6 (DT6120)
1 Instruction Manual
Optional accessories:
1 Sensor
1 Sensor cable with connector
1 IF1032/ETH interface converter from analog (DT6110) or RS485 Ethernet (DT6120) on Ethernet/Ether-
CAT
Further optional accessories, see Chap. A 1
Remove the parts of the system carefully from the packaging and transport them in such a way that they
are not damaged.
Check for completeness and shipping damages immediately after unpacking. In case of damage or
missing parts, please contact the manufacturer or supplier.
3.2 Storage
- Storage temperature:
Sensor: -50 ... +200 °C (-58 to +392 °F)
Sensor cable: -50 ... +200 °C (-58 to +392 °F)
Controller: -10 ... +75 °C (+14 to +167 °F)
- Humidity: 5 - 95 % RH (non condensing)

Page 16
Installation and Assembly
capaNCDT 6110 / 6120
4. Installation and Assembly
4.1 Precautionary Measures
No sharp-edged or heavy objects may get into contact with the sensor cable sheath.
Protect the cable against pressure loads in pressurised rooms.
Avoid kinks in any case.
Check the connections for tight fit.
iA damaged cable cannot be repaired.
4.2 Sensor
The sensors may be mounted free-standing or flush.
When assembling, make sure that the polished sensor surface is not scratched.
4.2.1 Radial Point Clamping with Grub Screw, Cylindric Sensors
This simple type of fixture is only recommended for a force and vibration-free installation position. The grub
screw must be made of plastic so that it cannot damage or deform the sensor housing.
Grub screw
Fig. 5 Radial point clamping with grub screw
Do not use metal grub screws!
> Danger of damaging the sensor

Page 17
Installation and Assembly
capaNCDT 6110 / 6120
4.2.2 Circumferential Clamping, Cylindric Sensors
This sensor mounting option offers maximum reliability because the sensor is clamped around its cylindrical
housing. It is absolutely necessary in difficult installation environments, for example on machines, production
plants et cetera.
Mounting with
clamping ring
Fig. 6 Circumferential clamping
A circumferential clamping possible from 2 mm behind the front face.
iTension at the cable is inadmissible!
4.2.3 Flat Sensors
Flat sensors are mounted by means of a tap hole for M2 (in case of sensors 0.2 and 0.5 mm) or by a through
hole for M2 screws. The sensors can be bolted on top or below.
Screwing from above Screwing from bottom

Page 18
Installation and Assembly
capaNCDT 6110 / 6120
4.2.4 Dimensional Drawings Sensors
Cylindric sensors
CS02
12
(.472)
ø6f7 (.236 dia.) ø8f7 (.314 dia.)
CS05
12
(.472)
CSE05
12 (.47)
ø6f7
(.24 dia.)
ø5.7 (.22)
15 (.59)
ø10f7
(.394 dia.)
CS08
9 (.35)
M=1:2
ø20h7 (.79 dia.)
24 -0.2
(.945) -0.008
CS2
CS1 CSE1
12 (0.47)
ø8f7 (0.31 dia.)
ø10f7 (.394 dia)
ø10f7 (.394 dia.)
CS1HP
20 -0.2
(.787 -0.008 )
21 -0.2 (o.83 -0 008)
ø7.7 (0.30 dia.)
9 (0.35)
Connector side
Dimensions in mm
(inches)
Circumferential clamp-
ing possible from 2 mm
behind the front face.
Dimensional drawings
of other sensors are
available on request.

Page 19
Installation and Assembly
capaNCDT 6110 / 6120
ø30h7 (1.18 dia.)
ø20h7 (.79 dia.)
24 -0.2
(.945) -0.008
CS3
M=1:2
ø20h7 (.79 dia.)
ø40h7 (1.58 dia.)
CS5
M=1:2
ø20h7 (.79 dia.)
ø60h7 (2.36 dia.)
M=1:2
CS10
16.5 (.649)
16.5 (.649)
24 -0.2
(.945) -0.008
24 -0.2 (0.94 -0.008)
16.5 (0.65)
Connector side
Dimensions in mm
(inches)
Circumferential clamp-
ing possible from 2 mm
behind the front face.
Dimensional drawings
of other sensors are
available on request.

Page 20
Installation and Assembly
capaNCDT 6110 / 6120
ø12g6 (.473 dia.)
CSH1-CAmx,
CSH1.2-CAmx
14
(.39)
33
(1.30)
ø11.5
(.45 dia.)
10 (.39)
ø 2.2 (.09 dia.)
ca. 37 (1.46)
ca. 9.4 (.37)
ø8g6 (.315 dia.)
CSH02-CAmx,
CSH05-CAmx
ø7.5
(.30 dia.)
14
(.39)
33
(1.30)
10 (.39)
ø 2.2 (.09 dia.)
ca. 37 (1.46)
ca. 9.4 (.37)
Dimensions in mm (inches), not to scale
Circumferential clamp-
ing possible from 2 mm
behind the front face.
