MicroConnect MDPDVI3B User manual

MINI DISPLAYPORT 1.2 TO DVI CONVERTER
User Manual
P/N: MDPDVI3B

UIOYGOY Mini DisplayPort 1.2 to DVI Converter
2
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this manual
for future reference.
Mini DisplayPort 1.2 to DVI Converter
This is a Mini DisplayPort 1.2 to DVI signal format converter for interfacing next generation DisplayPort
based on PC and notebook computers with high definition displays. The Mini DisplayPort to DVI
Adapter seamlessly connect next generation DisplayPort based MacBook, MacBook Pro, or MacBook
Air with a Mini DisplayPort to conventional DVI displays, such as CRT, LCD monitors and projectors.
Mini DisplayPort offers a unified, scalable, and cost effective interface for embedded and external
display applications. As desktop and notebook PCs are increasingly transitioning from conventional
analog type interfaces to DisplayPort, the converter facilitates the transition by offering seamless
connectivity between new DisplayPort PC and the installed base HDMI monitors and projectors.
It offers solutions for digital entertainment center, HDTV retail and show site, HDTV, STB, DVD and
Projector factory, noise space and security concerns, data center control, information distribution,
conference room presentation, school and corporate training environments.
How It Works
Connect the Mini DisplayPort male to a Mini DisplayPort source device.
Connect the DVI female to display by DVI M/M cable.

FEATURES Mini DisplayPort 1.2 to DVI Converter
2
Supports Mini DisplayPort1.2 and 4 lanes.
Support Mini DisplayPort 1.2a input and DVI output.
Support HDMI highest video resolution 1920x1080@60HZ.
Supports multiple color format: RGB 6/8/10/12-bit per component (bpc) and YCbCr4:4:4,
YCbCr4:2:2,8/10/12bpc.
HDMI 1.4b compliant with maximum data rate 3.0Gbps.
Supports 10/12-bit deep color 1080p up to 2.25Gbps.
Content protection of HDCP Rx and Tx keys to support HDCP repeater.
DVI 1.0 transmitter support.
Integrated both HDCP Rx and Tx keys to support HDCP repeater.
Powered from Mini DisplayPort source.
PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the following items are
contained in the shipping carton:
Main unit
User Manual

SPECIFICATIONS Mini DisplayPort 1.2 to DVI Converter
3
Signal Inputs/Output
Input Video Signal....................................................................................................... 5 Volts p-p (TTL)
Maximum Single Link Range.................................................................................. 1920x1080@60HZ
Output Video................................................................................................................................... DVI
Input Connector.................................................................................................DisplayPort Male 20pin
Output Connector....................................................................................................... DVI Female (24+5)
Vertical Frequency Range....................................................................................................... 50/60Hz
Video Amplifier Bandwidth....................................................................................... 1.62Gbps/2.7Gbps
No 3D Mode.................................................................................................. Up to 1920x1080@60HZ
3D Mode............................................................................................................................ Nonsupport
Weight (Net)..................................................................................................................................... 14g
Operating Temperature.................................................................................................... 0 ℃to +45℃
Operating Humidity....................................................................... 10% to 85 % RH (no condensation)
Storage Temperature...................................................................................................... -10℃to +80℃
Storage Humidity............................................................................ 5% to 90 % RH (no condensation)
External Power Supply................................................................................ No external power needed
Power consumption (Max)............................................................................................................... 1W
Converter Unit.......................................................................................................................... FCC, CE
Power Supply..................................................................................................................... UL, CE, FCC

WIRING DIAGRAM Mini DisplayPort 1.2 to DVI Converter
5
