Microjack EYES Pro User manual

MicroJack
EYES Pro
Digital Video Surveillance System
User’s Manual
300AABCS/400/0616

MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
FCC NOTICE
This device has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a commercial,
industrial or business environment. This equipment can
generate, use and radiate radio frequency energy and, if not
installed and used in accordance with the instruction, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may
cause undesired operation.
CAUTION ON MODIFICATIONS
To comply with the limits for the Class A digital device,
pursuant to Part 15 of the FCC Rules, this device must be
installed in computer equipment certified to comply with the
Class A limits. All cables used to connect the computer and
peripherals must be shielded and grounded. Operation with
non-certified computers or non-shielded cables may result in
interference to radio or television reception.
Any changes or modifications not expressly approved by the
grantee of this device could void the user's authority to
operate the equipment.
CE NOTICE
This is a Class A product.
ENG 02
MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000

MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
i
Table of Contents
CHAPTER 1 INTRODUCTION....................................................... 1
1.1 Manual Conventions ........................................................... 1
1.2 Video Card Specification ..................................................... 2
1.3 Package Contents .............................................................. 2
1.4 Hardware Recommendations ............................................... 3
1.5 Installing the Video Cards ................................................... 5
1.6 Connecting the MicroJack Video Cards.................................. 8
1.7 Attaching Cameras............................................................. 8
1.8 Connecting External Sensor/Relay........................................ 9
CHAPTER 2 DRIVER INSTALLATION ......................................... 13
2.1 Installing the Driver in Windows 98SE/Me............................13
2.2 Installing the Driver in Windows 2000 .................................18
2.3 Installing the Driver in Windows XP.....................................23
2.4 Remove Your Video Card Driver ..........................................26
CHAPTER 3 SOFTWARE INSTALLATION.................................... 27
3.1 Installing MicroJack EYES Pro/MP2016/MP3000/MP5000
Software ...............................................................................27
3.2 Product Update.................................................................32
MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
ii
3.3 Special Consideration ........................................................33
CHAPTER 4 SYSTEM CONFIGURATION AND OPERATION .......... 34
4.1 System Configuration ........................................................34
System .....................................................................37
Cameras ....................................................................42
Audio ........................................................................45
Monitoring..................................................................47
Sensors .....................................................................50
Relays........................................................................51
Alarms......................................................................53
Networking.................................................................58
Scheduler....................................................................61
Backup .....................................................................67
E-Map ....................................................................72
Users Information.........................................................74
4.2 System Operation .............................................................78
Start / Stop Monitoring ..........................................83
Start / Stop Audio Recording.............83

MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
iii
E-Map..................................................................84
Load / Close Network Server ..................................85
System Configuration.............................................85
Log Viewer ...........................................................86
PTZ Controller.......................................................95
Status Monitoring .............................................................98
Exit / Re-login EYES Pro/MP2016/MP3000/MP5000.....101
CHAPTER 5 USING THE WEBCAM............................................ 102
5.1 Enable WebCam..............................................................102
5.2 Use the WebCam ............................................................104
CHAPTER 6 REMOTEMANAGER ............................................... 106
6.1 Accessing RemoteManager...............................................106
6.2 Setup...................................................................108
6.3 Operating the RemoteManager .........................................115
MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
iv
6.3.1 Center Management.......................................115
6.3.2 Playback.......................................................118
6.3.3 PTZ Control ..................................................123
6.4 Start Recording .....................................................126
6.5 Exit RemoteManager ..............................................126
APPENDIX A REMOTE LOGIN WITH AN MODEM-TO-MODEM
CONNECTION ......................................................................... 127
A.1 Windows 98SE / Windows Me...........................................127
A.2 Windows 2000................................................................132
A.3 Windows XP ...................................................................139
APPENDIX B REGISTERING DOMAIN NAME ON DDNS SERVER148

MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
1
Chapter 1 Introduction
Welcome to the realm of MicroJack. MicroJack EYES Pro /MP2016/
MP2016/MP3000/MP5000, composed of one 32-bit PCI video capture
card, works as a digital video surveillance system. It allows you to
capture true color images and real-time videos from 4/8/16 camera
input(s) simultaneously.
With the latest Motion Detection technology, once any movement
detected in the monitoring area, MicroJack EYES Pro/MP2016/MP3000/
MP5000 automatically starts recording and triggers the alarm. You
don’t need to keep your eyes on the monitor all day long anymore; the
system will alert you automatically when specified events occur.
1.1 Manual Conventions
The following conventions are used throughout this manual.
Type Stands for Example
[paren.] Keys on the keyboard [Enter]
“Quotes” Words to be typed in “MicroJack”
Italic User in each authorization level Administrator
Bold Name of a dialog box,
Sections/Option title in the dialog
box/Field names/Buttons
Schedule
Backup
Underlined Table columns Start
Caution Message: These messages are to advise you to
proceed carefully. Failure to pay attention could result in
damage to the system and may put personnel and
environment at risk.
Informational Message: These messages are intended to
provide additional information for the purpose of clarification.
MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
2
1.2 Video Card Specification
MicroJack has been dedicated to innovating the technology of
digital video surveillance system. We have had a significant
innovation on promoting hardware that is presented as the part
of MP series above.
1.3 Package Contents
Your MicroJack EYES Pro/MP2016/MP3000/MP5000 package includes the
following：
Product Video Card Specifications
4 EYES Pro 1 card Each video capture card with 4 video inputs
8 EYES Pro 2 cards Each video capture card with 4 video inputs
16 EYES Pro 4 cards Each video capture card with 4 video inputs
MP 3004 1 card Each video capture card with 4 video inputs.
MP 3008 1 card w/ 1
daughter card Each video capture card with 4 video inputs.
MP 2016/
MP 3016 1 card w/ 3 daughter cards Each Video capture card with 4 video inputs
MP 5004 1 card Each video capture card with 4 video inputs.
MP 5008 1 card w/ 1
daughter card Each video capture card with 4 video inputs.
MP 5016 2 cards w/2
daughter cards Each video capture card with 4 video inputs.
4 ports

MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
3
•1 / 2 / 4 MicroJack Video Card(s) for EYES Pro
•1/2 MicroJack Video Card(s) and 1/3 daughter card(s) for
MP2016/MP3000/MP5000
•MicroJack EYES Pro/MP2016/MP3000/MP5000 Software CD (Including
Driver, Application Software, and User’s Manual)
•MicroJack EYES Pro/MP2016/MP3000/MP5000
User’s Manual
•Optional external I/O Box and 15-pin
D-type Connector Cable
1.4 Hardware Recommendations
CPU PentiumIII 800MHz or above recommended
Motherboard Intel 815E/815EP (PIII), 845(P4), 845D(P4),
845E(P4), 845G(P4)
List of motherboards tested:
•ASUS P4B
•ASUS P4B266
•ASUS P4B533
•ASUS P4B533-V
•GIGABYTE 8IRX
•GIGABYTE 8IEX
•GIGABYTE 8IEXP
•GIGABYTE 8IGX
•MSI 845E Max2
•MSI 845G Max
(VIA/SiS/ALi chipset motherboards
temporarily not supported)
OS MicrosoftWindows 98SE/Me/2000 Pro. /XP Pro.
Expansion Slots 1 / 2 / 3 / 4 × 32-bit PCI 2.1 compliant slots
RAM
Transcend DDR 256MB (DDR-266)
KingSton DDR 256MB (DDR-266)
KingMax SDRAM 256MB (PC-133)
KingMax DDR 256MB(DDR-333)
MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
4
Hard disk 40 GB of free hard disk space, at least 6GB free
space for each partition.
HDD Seagate ST340016A (40G 72000rpm)
Seagate ST380021A (80G 7200rpm)
Media CD-ROM drive
VGA
16-bit high color SVGA graphic card with
DirectDraw capability
List of VGA Cards tested:
•Leadtek WinFast GeForce2 MX400
•Leadtek WinFast A170 DDR TDH
•Leadtek WinFast 3D S325 32MB
•Leadtek WinFast A250 TD 128MB
•ATI RADEON 8500 64MB/128MB
•ELSA GLADIAC 525 128MB
•ELSA GLADIAC 517 VIVO 64MB
Audio Sound card and speakers
Modem
List of modems tested:
Modem2modem feature
Internal:
•USR 5699A (Chipset: 3COM)
•Creative Lab DI5630 (Chipset: Broadxent)
•SmartLink 5634PSV-R
•QDK Speedcom+ VPI56SP (Chipset: Conexant)
•GVC 56K V.90 Voice/Fax (Chipset: Motorola)
•CyberMarmot Rock Modem (Chipset: Ambient)
•Lemel MD-56KVR4 (Chipset: Conexant)
External:
•USR 5686D (Chipset: USR)
•GVC 56Kbps (Chipset: Rockwell)
•Atrie Explore (Chipset: Conexant)
•Zyxel Omni 56K Data/Voice (Chipset: Zyxel)
•SmartLink 56TS (Chipset: TI)
•SmartLink 56TPC (Chipset: IC+)
•ART NET V1456VQE (Chipset: TOPIC)
•Well USB Soft Modem FM-56USB-ST (USB
interface)

MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
5
Modem Alarm call out feature
Internal:
•Creative Lab DI5630 (Chipset: Broadxent)
•Creative Lab DI5630-5 (Chipset: Broadxent)
For the current update information, please check our website.
1.5 Installing the Video Cards
1.5.1 Installing the MicroJack EYES Pro Video Cards
The following instructions are for installing video cards into the
MicroJack EYES Pro system.
Before installing the video card, turn off the computer’s power,
unplug the power cable and disconnect all other cables
attached to the back of the computer.
Video card
PCI Slot
Video Card
MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
6
1. Remove the computer cover.
2. Remove the I/O brackets for the four PCI expansion slots. Save the
screws.
3. Insert the MicroJack video cards into the available PCI expansion
slots.
4. Replace the computer cover and reconnect all cables.
1.5.2 Installing the MicroJack MP2016/MP3000/MP5000 Video
Cards
The following instructions are for installing video cards into the
MicroJack MP2016/MP3000/MP5000 system.
Before installing the video card, turn off the computer’s power,
unplug the power cable and disconnect all other cables
attached to the back of the computer.
MP3004/MP5004/MP5008
Video card
MP3008/MP5016
Video card

MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
7
MP3016 Video card MP2016 Video card
Fig. 1 Fig. 2
1. Remove the computer cover.
2. Remove the I/O brackets for the four PCI expansion slots. Save the
screws.
3. Align AVerMedia video card connector with the available PCI slots.
4. Screw AVerMedia video card and the 3 daughter cards respectively
into the rear panel with the screws. See the Fig.1.
5. Connect the 3 daughter cards to AVerMedia video card with ribbon
cables. See the Fig.2.
6. Replace the computer cover and reconnect all cables.
NOTE: Orient the
red mark u
p
ward.
PCI Slot
MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
8
1.6 Connecting the MicroJack Video Cards
Up to four cameras can be connected to each MicroJack video card -
one camera per BNC terminal.
1.7 Attaching Cameras
Cameras must be attached to the BNC connectors of the server video
cards in a specific order to avoid transmission problems. Video cards
are stacked vertically into the chassis. If all four video cards are
installed, the rear panel of the server will appear as shown in the
diagrams below.
EYES Pro MP2016/MP3000/MP5000
D-t
yp
e 15-
p
in
Connector Cable
(Optional)
Coaxial Cable
(Not Supplied)
Camera 1
Camera 2
Camera 3
Camera 4
Infrared Sensor
Proximity Sensor
Smoke Detector
Reed Switch
Relay Control
Burglar Alarm
Access Control Lock
Sensor In
p
uts
Rela
y
Out
p
uts
1
5
9
13
2
6
10
14
3
7
11
15
4
8
12
16
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
9
Cameras need to be installed according to the numerical order displayed
on the diagrams above. Whether you have one, two, three or four
video cards, the pattern is the same - cameras will be installed from
left to right starting with the top row for EYES Pro and from top
to bottom beginning with the left-most column for
MP2016/MP3000/MP5000.
1.8 Connecting External Sensor/Relay
Each system can come with optional External I/O Boxes and D-type 15-
pin connector cables enabling you to connect sensor inputs and relay
outputs. The pin signals and specifications for the external I/O Box and
the D-type 15-pin connectors are described below.
D-type 15-pin Connector Cable
External I/O Box
Video Card
External I/O Box
Relay Outputs 3
Sensor Input 3
Rela
y
Out
p
ut 2
Sensor Input 2
Sensor Input 1
Relay Output 1
D-type 15-pin connector
Sensor Input 4
MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
10
Sensor Input Specification
Relay Output Specification
Surge strength: 1500 VAC
Nominal power 200mw ~ 360mw
Operating power 110mw ~ 200mw
COIL RATINGS (at 20 oC)
Coil Nominal
Voltage
(VDC)
Coil
Resistance (
10% )
Pick-up
Voltage
(VDC)
Drop-Out
Voltage
(VDC)
Nominal
Current
(mA)
5125 3.75 0.5 40
* Max Continuous Voltage at 20oC : 110% of Coil Nominal Voltage

MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
11
CONTACT RATINGS
Contact Arrangement 1 Form C (SPDT)
max. Switch Power
max. Switch voltage
max. Switch current
125VA 60W
125VAC 30VDC
2A
Contact Resistance 100m
Resistive Load 1A/125VAC
2A/30VDC
Contact Material AgNi10
External I/O Box Pin Signals
Pin # Definition
1 INPUT SIGNAL 1+
2 INPUT SIGNAL 2+
3 INPUT SIGNAL 3+
4 INPUT SIGNAL 4+
5 OUTPUT 3 – Normally Closed
6 INPUT SIGNAL 1-(GND)
7 INPUT SIGNAL 2-(GND)
8 INPUT SIGNAL 3-(GND)
9 INPUT SIGNAL 4-(GND)
10 OUTPUT 3 – Common
11 OUTPUT 1 – Normally Open
12 OUTPUT 1 – Common
13 OUTPUT 2 – Normally Open
14 OUTPUT 2 – Common
15 OUTPUT 3 – Normally Open
MicroJack User’s Manual
EYES Pro/MP2016/MP3000/MP5000
12
Sensor Inputs
External sensors such as infrared sensors, smoke detectors, proximity
sensors, door sensors, etc., can be attached to the MicroJack EYES Pro/
MP2016/MP3000/MP5000’s input-signal connectors on the External I/O
Box. These devices trigger the system to respond with a predefined
action (e.g. record video)
Relay Outputs
The MicroJack EYES Pro/MP2016/MP3000/MP5000’s output connectors
(relay output) can be attached to external output control devices such
as alarms. The system can be configured to activate or deactivate
these devices. Each MicroJack video card supports three relay outputs.
Two of them are normally open relays with one being a toggle switch.
