Microlife WatchBP Home User manual

EN 1
Accurate home and
nocturnal blood pressure
measurements
with the WatchBP Home N.
Instruction Manual

Microlife WatchBP Home N is the device designed to measure daily and nocturnal blood pressure.
It strictly follows European Society of Hypertension (ESH)1, 2 and American Heart Association (AHA)3
recommendations of 7-day home measurement period with two measuremetns in the morning and two
in the evening. Using the WatchBP Home N device helps you collect accurate diurnal and nocturnal blood
pressure measurements. This gives a good insight in your daily blood pressure pattern and therefore
provides valuable information to your doctor. The WatchBP Home N device has been clinically validated
according to the ESH protocol4.
1 O’Brien E, Asmar R, Beilin L, Imai Y, et al. European Society of Hypertension recommendations for conventional, ambulatory and home blood pressure
measurement. European Society of Hypertension Working Group on Blood Pressure Monitoring. J Hypertens 2003;21:821-848.
2 Stergiou GS, et al. A tool for reliable self-home blood pressure monitoring designed according to the European Society of Hypertension
recommendations: The Microlife WatchBP Home monitor. Blood press Monit. 2007;12:127-131.
3 Thomas G. Pickering, Nancy Houston Miller, Gbenga Ogedegbe, Lawrence R. Krakoff, Nancy T. Artinian and David Goff. Call to Action on Use and
Reimbursement for Home Blood Pressure Monitoring: Executive Summary: A Joint Scientic Statement From the American Heart Association, American
Society of Hypertension, and Preventive Cardiovascular Nurses Association. Hypertension 2008;52;1-9
4 Stergiou GS, Giovas PP, Gkinos CP, Patouras JD. Validation of the Microlife WatchBP Home device for self home blood pressure measurement according
to The International Protocol. Blood Press Monit. 2007;12(3):185-188.

EN
Before using WatchBP Home N for the rst time
Product description .....................................................3–4
Activating the device ...................................................... 5
Selecting the correct cuff ................................................ 6
Taking measurements using WatchBP Home N
«USUAL» Mode ............................................................... 7
«DIAG.» Mode ............................................................7–10
«NOCTURNAL» Mode .................................................... 11
Reording medication intake and Memory
Reording medication intake ................................... 12–13
Memory ........................................................................ 14
Eight steps for taking accurate blood pressure
measurements
Blood pressure measurement procedures ............. 15–18
Special function
Atrial Fibrillation Detection .................................... 19–20
Viewing, deleting, and transferring measurement
values
Viewing measurement values ............................... 21–24
Deleting measurement values ..................................... 24
Transferring measurement values.......................... 25–26
Appendix
Batteries and power adaptor ................................. 27–28
Safety, care, accuracy test and disposal ................. 29–30
Error messages ....................................................... 31–32
Important facts ....................................................... 33–34
Technical specications ................................................ 35
Table of Contents

3
SYS
mmHg
mmHg
DIA
PUL
/min
USUAL
DIAG.
NOCTURNAL
M Button (Memory)
N
O
C
T
U
RNA
L
U
SU
A
L
DIA
G
.
Display
ON/OFF Button
Cuff Socket
Power Socket
Serial Port Battery Compartment
Mode Switch
Medication Button

4EN
Mode Indicators
Doctor Symbol
Atrial Fibrillation Detection
Outside Measurement time
Relax
Battery Display
Delete Memory Data
Morning Data
Evening Data
Date/Time
Systolic Value
Diastolic Value
Pulse Indicator
Pulse Rate
Number of Stored Data
USUAL
DIAG.
NOCTURNAL

5
2)Set the month – Press the M button to select the
month. Press the ON/OFF button to conrm.
Before using WatchBP Home N for the rst time
Activating the Device
Pull out the protective strip from the battery
compartment to activate the device.
Press M button to select.
Press ON/OFF button to conrm.
3)Set the day – Press the M button to select the day.
Press the ON/OFF button to conrm.
SYS
mmHg
mmHg
DIA
PUL
/min
USUAL
DIAG.
NOCTURNAL
1)Set the year – Upon removing the protective strip or
installing new batteries, the year number ashes in
the display. Use the M button to select the year. Press
the ON/OFF button to conrm the selection.

EN
6
4)Set the time – Press the M Button to select the time.
Press the ON/OFF button to conrm. When the date
and time are set, the current time is displayed.
5)If you want to change the date and time, take out one
battery from the battery compartment briey and
press ON/OFF button to turn off the device; then put it
back. The year number will ash. Complete the process
as described above.
M (Medium size)
22 - 32 cm (8.7 - 12.6 inches)
M is the correct size for most people.
L (Large size)
32 - 42 cm (12.6 - 16.5 inches)
Selecting the correct cuff
The WatchBP Home N device is available with different
cuff sizes. If the cuff provided with the device is not the
correct size, please consult your doctor.
* please use only Microlife cuffs!

7
Prior to each measurement, use the Mode Switch
on the right side of the device to select the proper
measurement mode. There are three modes to be
selected:
«USUAL» (Usual) mode,
for a regular single measurement.
«DIAG.» (Diagnostic),
7-day measurement session for diagnosis or follow-up.
«NOCTURNAL» (Nocturnal) mode
for measurements of blood pressure during sleep.
The user should be lying supine in bed when this mode
is selected.
N
O
C
T
U
RNA
L
U
SU
A
L
DIA
G
.
Taking measurements using WatchBP Home N
NOCTURNAL USUAL
NOCTURNAL USUAL
NOCTURNAL USUAL
DIAG.
DIAG.
DIAG.
* The time of taking medication can be recorded in any modes.

EN
8
«USUAL» Mode
In «USUAL» mode, single measurements can be
taken at any time, and the measurement values are
automatically stored for later evaluation by your doctor
Anytime
NOCTURNAL USUAL NOCTURNAL USUAL
NOCTURNAL USUAL
DIAG. DIAG.
DIAG.
«DIAG.» Mode
The «DIAG.» mode should be selected as requested.
The blood pressure can only be measured in
accordance to the 7-day measurement schedule as
prescribed by the European Society of Hypertension
(ESH).
NOCTURNAL USUAL
NOCTURNAL USUAL
NOCTURNAL USUAL
DIAG.
DIAG.
DIAG.

9
Take measurements on 7 consecutive days
In «DIAG.» mode, blood pressure measurements
are taken on 7 consecutive days. ESH1and AHA2
recommend to take a 7-day measurement period with
2 measurements in the morning and 2 measurements
in the evening to get an average of at least 12 morning
and evening measurements for reference. The rst-day
measurments shall be excluded from the analysis.
Two sets of measurements per day
ESH guidelines recommend one double measurement
to be taken in the morning between 06:00 - 09:00 and
one in the evening between 18:00 - 21:00. Always take
the measurements before taking your medication,
unless otherwise directed by your doctor.
Jan
JAN
30 7consecutive
days
X1
X1
06:00 - 09:00
18:00 - 21:00
ESH Guidelines
Taking measurements using WatchBP Home N (cont.)
1 Gianfranco Paratia, et al. European Society of Hypertension guidelines for blood pressure monitoring at home. J Hypertens 2008 26:1505–1530.
2 Thomas G. Pickering, et al. Call to Action on Use and Reimbursement for Home Blood Pressure Monitoring. Hypertension 2008;52;1-9

EN
10
Evaluation
After measurements have been carried out for a total
of 7 working days, bring the device to your doctor for
evaluation of your home blood pressure.
However, for user’s convience,
WatchBP Home N has an extended
measurement period and allows
morning measurements between
04:00 - 12:00 and evening
measurements between 18:00 -
24:00.
If it is not in the
measuring time period,
the symbol will be
displayed and the
measurements can not
be taken.
When measurements
have been carried out
for the full 7 days, the
doctor symbol will
ash on the screen.
USUAL
DIAG.
NOCTURNAL
USUAL
DIAG.
NOCTURNAL
X1
X1
04:00 - 12:00
18:00 - 24:00
Extended Time

11
«NOCTURNAL» Mode
The «NOCTURNAL» mode enables to measure and
record blood pressures during sleep time. It can be used
when requested by your doctor. The starting time of
«NOCTURNAL» mode is restricted between 6:00pm and
4:00am.
NOCTURNAL USUAL
NOCTURNAL USUAL NOCTURNAL USUAL
DIAG.
DIAG. DIAG.
Three measurements during sleep time
Select «NOCTURNAL» mode while you are going to
sleep. Please lie supine in bed then press the start button
for 3 seconds. The device will take one measurement
automatically as baseline to activate the nocturnal
measurements. It will take the rst measurement two
hours later; the second measurement one hour after
the rst measurement; and the third measurement one
hour after the second measurement. The values of 1st,
2nd and 3rd measurement will be averaged. The baseline
readings will not be counted in as average.
1 hour 1 hour
12 3
0
2 hours
Press for
3 seconds
Taking measurements using WatchBP Home N (cont.)
USUAL
DIAG.
NOCTURNAL
*Please lie supine when
«NOCTURNAL» mode is selected.
”Supine”means lying on the back
or having the face upward.
*If it is not in the allowed
measuring time, the symbol
will be displayed and the
measurements can not be taken

EN
12
N
O
C
T
U
RNA
L
U
SU
A
L
DIA
G
.
Saved
The patient can record the time of taking the medicine by
pressing the Medication Button. Press and hold
until beep...
1)Press and hold the Medication Button, the pill icon will
ash. Hold until beep sounds then release it. The Pill icon
and the number of records appear.
2) The Pill icon will ash in alternation with the recorded
time of taking the medicine.
3)The time of taking the medication is saved .
Recording medication intake
* The device saves only the time of taking the medicine, not the
pill’s name or dosage.
N
O
C
T
U
RNA
L
U
SU
A
L
DIA
G
.
* The time of taking medication can be recorded in any modes.

13
Press and hold for 7 seconds...
Delete stored medication records
To clear the memory of all medication records, press
and hold the Medication button for 7 seconds until
the “CL” symbol ashes. Then press M to delete the
memory or ON/OFF to cancel the deletion .
N
O
C
T
U
RNA
L
U
SU
A
L
DIA
G
.
* Pressing the M Button to delete data will erase all medication
record data in the different mode.
Pill indicator
Due to technical limitation, the character “i” of the word
“pill” is displayed without the “dot” in the “i”.
*indicates the word “pill”

EN
14
In «NOCTURNAL» mode
84 measurements can be stored
* Up to 21 cycles of nocturnal measurements can be stored.
50 medication records can be stored
* When the memory is full, the device will display “Full”.
250
Measurements
In «USUAL» mode
250 measurements can be stored
* When the memory of the device is full, each new
measurement will automatically overwrite the rst
measurement.
In «DIAG>» mode
28 measurements can be stored
28
Measurements
«USUAL»mode «DIAG>» mode
84
Measurements
«NOCTURNAL»mode Medication
Measurements stored automatically

15
Eight steps for taking proper blood pressure
Step 1
Avoid taking measurements directly after eating,
drinking, or smoking. Allow at least one hour between
these activities and measurement of your blood pressure.
1 Hour
Before
* Shorter tube (20 inches) for «USUAL» and «DIAG.» mode.
* Avoid rolling up long sleeves, as this may lead to constriction
of blood ow to the measurement arm.
Step 2
In «USUAL» and «DIAG.» mode
Prepare a chair and table for the
measurement. The chair should have
a vertical back-rest and the table
should allow your upper arm to rest
at the same height as your heart.
Step 3
Remove all clothing constricting the arm to be
measured. Connect the shorter tube to the cuff then
apply the cuff. Make sure the lower edge of the cuff
is exactly 2–3 cm from the inner fold of your arm. The
tube connecting the cuff to the device should be placed
on the inside of the arm. (Additional visual instruction
can be found on the cuff)

EN
16
Step 4
Sit down and relax for at
least ve minutes prior to
the measurement.
Step 5
Sit upright and lean comfortably against the chair’s
backrest. Press the start button, and the device will
start to measure. During the measurement do not
move, cross your legs, or tense your arm muscles.
Breath normally and do not talk.
Step 6
When the measurement is complete, the readings
are stored for future reference by your doctor. If an
error displays after the readings, please repeat the
measurement procedure from step 1 to 5.
SYS
mmHg
mmHg
DIA
PUL
/min
USUAL
DIAG.
NOCTURNAL
Automatically stored

17
Eight steps for taking proper blood pressure (cont.)
Step 7 (in «DIAG.» mode)
In «DIAG.» mode, there is a 60 seconds countdown
before the measurement starts. Two measurements
will be performed subsequently. After the rst
measurement , another 60 seconds countdown starts
before the second measurement. Be relaxed and do
not move during the countdown.
Step 8 (in «DIAG.» mode)
When seven days of measurements have been
collected, the Doctor Symbol will ash on the display.
Do not forget to bring your WatchBP Home N device
with you on your next visit to the doctor. (Note: the
doctor symbol is only displayed for measurements in
«DIAG.» Mode.)
1 2
60 sec.

EN
18
Longer tube (40 inches) for
«NOCTURNAL» mode
In «NOCTURNAL» mode
Change the shorter tube (20 inches) to the
longer tube (40 inches) in «NOCTURNAL» mode;
therefore, the cuff can be securely attached to the
user’s upper arm during sleep. Avoid the tube to
be kinted during sleep.
The user should be lying supine in bed and put the
device on a table by the bed.
Shorter tube (20 inches) for
«USUAL» and «DIAG.» mode
* ”Supine”means lying on the back or having the face
upward.

19
Special Function
The atrial brillation indicator for early
detection
The WatchBP Home N is designed to detect atrial brillation
during blood pressure measurements in the «USUAL» Mode,
«DIAG.» Mode and «NOCTURNAL» Mode. When atrial
brillation is detected, the Ab icon displays. The device can
detect atrial brillation with high accuracy (sensitivity of
95% and specicity of 86%)*. If the atrial brillation icon
is displayed frequently, it is highly recommended to perform
a visit to the doctor.
IAD
* Joseph Wiesel, Lorenzo Fitzig, Yehuda Herschman and Frank
C. Messineo. Detection of Atrial Fibrillation Using a Modied
Microlife Blood Pressure Monitor.
American Journal of Hypertension 2009; 22, 8, 848–852.
doi:10.1038/ajh.2009.98
* Atrial brillation which is a major cause of stroke which
can be detected by this device. However, not all risk factors
for stroke, including atrial utter, may be detected by this
device.
* This device may not detect atrial brillation in people with
pacemakers or debrillators. People with pacemakers or
debrillators should therefore not use this device to detect
atrial brillation.
