Microlife BP A100 User manual

Microlife BP A100
EN Ä1
RU Ä8
IB BP A100-30 EN-RU 4119
Уполномоченный представитель производителя
«Микролайф» в России
ООО «МИП-Тест», 123001 Москва, Ермолаевский пер., д.22-26, стр.1
Телефоны бесплатной горячей линии:
Часы работы: пн.-пт. 09:00 - 17:00 (время московское)
для Москвы: [phone]
для регионов: 8 800 550 10 52
Производитель
Microlife AG, Швейцария
Адрес: Espenstrasse 139, 9443 Widnau, Switzerland
Web-сайт: www.microlife.com
Место производства:
ONBO Electonic (Shenzhen) Co., Ltd., Китай
Адрес: No. 138 Huasheng Road, Langkou Community Dalang Street, Longhua District,
Shenzhen China
Made in China
Microlife AG
Espenstrasse 139
9443 Widnau / Switzerland
www.microlife.com

Microlife BP A100
267 3
I
18 9 5 4
8
II
AT
AK
AL
AM
AN
AP
AO
III IV
AR
AQ
BP A100
Guarantee Card
Name of Purchaser / Ф.И.О. покупателя
Serial Number / Серийный номер
Date of Purchase / Дата покупки
Specialist Dealer /
Специализированный дилер

1BP A100 EN
Display
Intended use:
This oscillometric blood pressure monitor is intended for measuring
non-invasive blood pressure in people aged 12 years or older.
It is clinically validated in patients with hypertension, hypotension,
diabetes, pregnancy, pre-eclampsia, atherosclerosis, end-stage
renal disease, obesity and the elderly.
Dear Customer,
This device was developed in collaboration with physicians and
clinical tests carried out prove its measurement accuracy to be of
a very high standard.*
If you have any questions, problems or want to order spare parts
please contact your local Microlife-Customer Service. Your dealer
or pharmacy will be able to give you the address of the Microlife
dealer in your country. Alternatively, visit the internet at
www.microlife.com where you will find a wealth of invaluable infor-
mation on our products.
Stay healthy – Microlife AG!
* This device uses the same measuring technology as the award
winning «BP 3BTO-A» model tested according to the British and
Irish Hypertension Society (BIHS) protocol.
Table of Contents
1. Explanation of Symbols
2. Important Facts about Blood Pressure and Self-Measure-
ment
• How do I evaluate my blood pressure?
3. Using the Device for the First Time
• Activating the fitted batteries
• Selecting the correct cuff
4. Taking a Blood Pressure Measurement
5. Appearance of the Heart Arrhythmia Indicator for early
Detection
6. Data Memory
• Viewing the stored values
• Memory full
• Clearing all values
7. Replacing the Slot-in Card
8. Battery Indicator and Battery change
• Low battery
• Flat battery – replacement
• Which batteries and which procedure?
• Using rechargeable batteries
9. Using a Mains Adapter
10. Error Messages
11. Safety, Care, Accuracy Test and Disposal
• Safety and protection
•Devicecare
• Cleaning the cuff
• Accuracy test
• Disposal
12. Guarantee
13. Technical SpecificationsGuarantee Card
Microlife BP A100 EN
1ON/OFF button
2Display
3Slot-in Card
4Cuff Socket
5Mains Adapter Socket
6Cuff Compartment
7Battery Compartment
8Cuff
9Cuff Connector
AR M-button (memory)
AT Systolic Value
AK Diastolic Value
AL Pulse Rate
AM Heart Arrhythmia Indicator
AN Pulse
AO Battery Display
AP Stored Value
AQ Memory Number

2
1. Explanation of Symbols
Batteries and electronic devices must be disposed of in
accordance with the locally applicable regulations, not with
domestic waste.
Read the instructions carefully before using this device.
Type BF applied part
2. Important Facts about Blood Pressure and Self-
Measurement
Blood pressure is the pressure of the blood flowing in the
arteries generated by the pumping of the heart. Two values, the
systolic (upper) value and the diastolic (lower) value, are
always measured.
The device indicates the pulse rate (the number of times the
heart beats in a minute).
Permanently high blood pressure values can damage your
health and must be treated by your doctor!
Always discuss your values with your doctor and tell him/her if
you have noticed anything unusual or feel unsure. Never rely
on single blood pressure readings.
Enter your readings in the enclosed blood pressure diary.
This will give your doctor a quick overview.
 There are many causes of excessively high blood pressure
values
. Your doctor will explain them in more detail and offer treat-
ment where appropriate. Besides medication, relaxation techniques,
weight loss and exercise can also lower your blood pressure.
 Under no circumstances should you alter the dosages of
drugs or initiate a treatment without consulting your doctor.
 Depending on physical exertion and condition, blood pressure is
subject to wide fluctuations as the day progresses.
You should
therefore take your measurements in the same quiet condi-
tions and when you feel relaxed!
Take at least two measure-
ments per day, one in the morning and one in the evening.
It is quite normal for two measurements taken in quick succes-
sion to produce significantly different results.
Deviations between measurements taken by your doctor or in
the pharmacy and those taken at home are quite normal, as
these situations are completely different.
Several measurements provide a much clearer picture than
just one single measurement.
Leave a small break of at least 15 seconds between two
measurements.
If you are pregnant, you should monitor your blood pressure
regularly as it can change drastically during this time.
If you suffer from an irregular heartbeat (arrhythmia, see
«Section 5.»), measurements taken with this device should only
be evaluated after consultation with your doctor.
The pulse display is not suitable for checking the
frequency of heart pacemakers!
Keep dry
Conformity mark
Type approval of measuring device
Serial number
Catalogue number
Manufacturer
Class II equipment
Operating
Operating temperature restriction
10 - 40 °C
Storage
Storage temperature restriction
-20 - +55 °C
CE Marking of Conformity
S N
N

3BP A100 EN
How do I evaluate my blood pressure?
The higher value is the one that determines the evaluation.
Example: a readout value between 150/85 or 120/98 mmHg indi-
cates «blood pressure too high».
The slot-in card 3on the front of the device shows ranges 1-6 in
the Table.
3. Using the Device for the First Time
Activating the fitted batteries
Pull out the protective strip from the battery compartment 7.
Selecting the correct cuff
Microlife offers different cuff sizes. Select the cuff size to match the
circumference of your upper arms (measured by close fitting in the
centre of the upper arm).
Pre-shaped cuffs are optionally available.
Only use Microlife cuffs.
 Contact your local Microlife Service if the enclosed cuff 8does
not fit.
 Connect the cuff to the device by inserting the cuff connector 9
into the cuff socket 4as far as it will go.
4. Taking a Blood Pressure Measurement
Checklist for taking a reliable measurement
1. Avoid activity, eating or smoking immediately before the
measurement.
2. Sit down on a back-supported chair and relax for 5 minutes.
Keep the feet flat on the floor and do not cross your legs.
3. Always measure on the same arm (normally left).
4. Remove close-fitting garments from the upper arm. To avoid
constriction, shirt sleeves should not be rolled up - they do not
interfere with the cuff if they are laid flat.
5. Always ensure that the correct cuff size is used (marking on the
cuff).
Fit the cuff closely, but not too tight.
Make sure that the cuff is positioned 2 cm above the elbow.
The artery mark on the cuff (ca. 3 cm long bar) must lie over
the artery which runs down the inner side of the arm.
Support your arm so it is relaxed.
Ensure that the cuff is at the same height as your heart.
6. Press the ON/OFF button 1to start the measurement.
7. The cuff will now pump up automatically. Relax, do not move
and do not tense your arm muscles until the measurement
result is displayed. Breathe normally and do not talk.
8. When the correct pressure is reached, the pumping stops and
the pressure falls gradually. If the required pressure was not
reached, the device will automatically pump some more air into
the cuff.
9. During the measurement, the heart symbol AN flashes in the
display and a beep sounds every time a heartbeat is detected.
10.The result, comprising the systolic AT and the diastolic AK
blood pressure and the pulse rate AL is displayed and a long
beep is heard. Note also the explanations on further display
symbols in this booklet.
11.When the measurement has finished, remove the cuff and pack
it into the device as shown in Fig. II.
12.Switch off the device with ON/OFF button 1. (The monitor
does switch off automatically after approx. 1 min.).
You can stop the measurement at any time by pressing the
ON/OFF button (e.g. if you feel uneasy or an unpleasant
pressure sensation).
Table for classifying blood pressure values in adults in accordance
with the World Health Organisation (WHO) in 2003. Data in mmHg.
Range Systolic Diastolic
Recommenda-
tion
1. blood pressure
normal
< 120 < 80 Self-check
2. blood pressure
normal
120 - 129 80 - 84 Self-check
3. blood pressure
slightly high
130 - 139 85 - 89 Consult your
doctor
4. blood pressure
too high
140 - 159 90 - 99 Seek medical
advice
5. blood pressure far
too high
160 - 179 100 - 109 Seek medical
advice
6. blood pressure
dangerously high
≥180 ≥110 Urgently seek
medical advice!
Cuff size for circumference of upper arm
S 17 - 22 cm (6.75 - 8.75 inches)
M 22 - 32 cm (8.75 - 12.5 inches)
L 32 - 42 cm (12.5 - 16.5 inches)
M - L 22 - 42 cm (8.75 - 16.5 inches)

4
5. Appearance of the Heart Arrhythmia Indicator for
early Detection
This symbol AM indicates that certain pulse irregularities were
detected during the measurement. In this case, the result may
deviate from your normal blood pressure – repeat the measure-
ment. In most cases, this is no cause for concern. However, if the
symbol appears on a regular basis (e.g. several times a week with
measurements taken daily) we advise you to tell your doctor.
Please show your doctor the following explanation:
6. Data Memory
At the end of each measurement, this device automatically stores
the result.
Viewing the stored values
Press the M-button AR briefly, when the device is switched off. The
display first shows the last stored result.
Pressing the M-button again displays the previous value. Pressing
the M-button repeatedly enables you to move from one stored
value to another.
Memory full
When the memory has stored 30 results, the memory is full.
From this point onwards, a new measured value is stored
by overwriting the oldest value.
Clearing all values
All memory data are cleared when batteries are taken out
of the device.
7. Replacing the Slot-in Card
You can replace the slot-in card 3by pulling it out to the side, as
shown in Fig. IV and replacing the paper insert.
It may be helpful to have your doctor note down the medication
dosage or an emergency telephone number on the card. Extra
cards are supplied with the device for this purpose.
8. Battery Indicator and Battery change
Low battery
When the batteries are approximately ¾ empty the battery symbol AO
will flash as soon as the device is switched on (partly filled battery
displayed). Although the device will continue to measure reliably, you
should obtain replacement batteries.
Flat battery – replacement
When the batteries are flat, the battery symbol AO will flash as soon
as the device is switched on (flat battery displayed). You cannot
take any further measurements and must replace the batteries.
1. Open the battery compartment 7at the back of the device by
pushing inwards at the two arrows and pulling out the battery
compartment cover.
2. Replace the batteries – ensure correct polarity as shown by the
symbols in the compartment.
Which batteries and which procedure?
Use 4 new, long-life 1.5 V, size AA alkaline batteries.
Do not use batteries beyond their date of expiry.
Remove batteries if the device is not going to be used for a
prolonged period.
Using rechargeable batteries
You can also operate this device using rechargeable batteries.
Only use «NiMH» type reusable batteries.
Batteries must be removed and recharged when the flat
battery symbol appears. They should not remain inside the
device as they may become damaged (total discharge as a
result of low use of the device, even when switched off).
Always remove the rechargeable batteries if you do not
intend to use the device for a week or more.
Batteries cannot be charged in the blood pressure monitor.
Recharge batteries in an external charger and observe the
information regarding charging, care and durability.
Information for the doctor on frequent appearance of the
Arrhythmia indicator
This device is an oscillometric blood pressure monitor that also
analyses pulse frequency during measurement. The device is
clinically tested.
The arrhythmia symbol is displayed after the measurement, if
pulse irregularities occur during measurement. If the symbol
appears more frequently (e.g. several times per week on
measurements performed daily) we recommend the patient to
seek medical advice.
This device does not replace a cardiac examination, but serves
to detect pulse irregularities at an early stage.

5BP A100 EN
9. Using a Mains Adapter
You can operate this device using the Microlife mains adapter
(DC 6V, 600 mA).

Only use the Microlife mains adapter available as an original
accessory appropriate for your supply voltage, e.g. the
«
Microlife 230V adapter».
Ensure that neither the mains adapter nor the cable are
damaged.
1. Plug the adapter cable into the mains adapter socket 5in the
blood pressure monitor.
2. Plug the adapter plug into the wall socket.
When the mains adapter is connected, no battery current is consumed.
10. Error Messages
If an error occurs during the measurement, the measurement is
interrupted and an error message, e.g. «ERR 3», is displayed.
* Please immediately consult your doctor, if this or any other
problem occurs repeatedly.
If you think the results are unusual, please read through the
information in «Section 2.» carefully.
11. Safety, Care, Accuracy Test and Disposal
Safety and protection
Follow instructions for use. This document provides important
product operation and safety information regarding this device.
Please read this document thoroughly before using the device
and keep for future reference.
This device may only be used for the purposes described in
these instructions. The manufacturer cannot be held liable for
damage caused by incorrect application.
This device comprises sensitive components and must be
treated with caution. Observe the storage and operating condi-
tions described in the «Technical Specifications» section.
Protect it from:
- water and moisture
- extreme temperatures
- impact and dropping
- contamination and dust
- direct sunlight
- heat and cold
The cuffs are sensitive and must be handled with care.
Only pump up the cuff once fitted.
 Do not use this device close to strong electromagnetic fields such
as mobile telephones or radio installations. Keep a minimum
distance of 1 m from such devices when using this device.
Do not use this device if you think it is damaged or notice
anything unusual.
Never open this device.
If the device is not going to be used for a prolonged period the
batteries should be removed.
Read the additional safety information provided within the indi-
vidual sections of this instruction manual.
The measurement results given by this device is not a diag-
nosis. It is not replacing the need for the consultation of a physi-
cian, especially if not matching the patient’s symptoms. Do not
rely on the measurement result only, always consider other
potentially occurring symptoms and the patient’s feedback.
Calling a doctor or an ambulance is advised if needed.
Ensure that children do not use this device unsupervised;
some parts are small enough to be swallowed. Be aware of
the risk of strangulation in case this device is supplied with
cables or tubes.
Error Description Potential cause and remedy
« ERR 1 » Signal too
weak
The pulse signals on the cuff are too weak.
Re-position the cuff and repeat the
measurement.*
« ERR 2 » Error signal During the measurement, error signals
were detected by the cuff, caused for
instance by movement or muscle tension.
Repeat the measurement, keeping your
arm still.
« ERR 3 » Nopressure
in the cuff
An adequate pressure cannot be gener-
ated in the cuff. A leak may have occurred.
Check that the cuff is correctly connected
and is not too loose. Replace the batteries
if necessary. Repeat the measurement.
« ERR 5 » Abnormal
result
The measuring signals are inaccurate and
no result can therefore be displayed. Read
through the checklist for performing reli-
able measurements and then repeat the
measurement.*
« HI » Pulseorcuff
pressure
too high
The pressure in the cuff is too high (over
299 mmHg) OR the pulse is too high
(over 200 beats per minute). Relax for 5
minutes and repeat the measurement.*
« LO » Pulse too
low
The pulse is too low (less than 40 beats
per minute). Repeat the measurement.*

6
Device care
Clean the device only with a soft, dry cloth.
Cleaning the cuff
Carefully remove spots on the cuff with a damp cloth and soapsuds.
WARNING: Do not wash the cuff in a washing machine or
dishwasher!
Accuracy test
We recommend this device is tested for accuracy every 2 years or
after mechanical impact (e.g. being dropped). The verification time
period is 2 years. Verification is carried out in accordance with the
document Р1323565.2.001-2018 «State system for ensuring the
uniformity of measurements. Non-invasive blood pressure meters.
Verification Method» Confirmation of initial verification, an elec-
tronic version of the verification certificate, is on the website of the
Federal Information Fund for Ensuring Uniformity of Measure-
ments - www.fgis.gost.ru
Information on verification is on the company website -
www.microlife.ru
Disposal
When the disposal of this device is required please contact a
specialized organization, authorized to provide utilization
according to the legislation of the Russian Federation.
12.Guarantee
This device is covered by a 5 year guarantee from the date of
purchase. The guarantee is valid only on presentation of the guar-
antee card completed by the dealer (see back) confirming date of
purchase or the receipt.
Batteries, cuff and parts that become worn with use are not
included.
Opening or altering the device invalidates the guarantee.
The guarantee does not cover damage caused by improper
handling, discharged batteries, accidents or non-compliance
with the operating instructions.
Please contact your local Microlife-Service (see foreword).
13. Technical Specifications
This device complies with the requirements of the Medical Device
Directive 93/42/EEC.
Technical alterations reserved.
Date of production: first four digits of the serial number of the
device. First and second digit – the week of the year / third and
fourth digit – the year of production.
Operating conditions: 10 - 40 °C / 50 - 104 °F
15 - 95 % relative maximum humidity
Storage conditions: -20 - +55 °C / -4 - +131 °F
15 - 95 % relative maximum humidity
Weight: 625 g (including batteries)
Dimensions: 160 x 125 x 98 mm
Measuring procedure: oscillometric, corresponding to Korotkoff
method: Phase I systolic, Phase V
diastolic
Measurement range: 20 - 280 mmHg – blood pressure
40 - 200 beats per minute – pulse
Cuff pressure display
range: 0 - 299 mmHg
Resolution: 1 mmHg
Static accuracy: pressure within ± 3 mmHg
Pulse accuracy: ± 5 % of the readout value
Voltage source: 4 x 1.5 V alkaline batteries; size AA
Mains adapter DC 6V, 600 mA (optional)
Battery lifetime: approx. 920 measurements
(using new batteries)
Included accessories: blood pressure monitor, cuff, bag, 4 x AA
batteries, adapter, instruction manual,
guarantee card, blood pressure diary
IP Class: IP20
Reference to
standards:
EN 1060-1 /-3 /-4; IEC 60601-1;
IEC 60601-1-2 (EMC); IEC 60601-1-11
Expected service life: Device: 5 years or 10000 measurements
Accessories: 2 years

7BP A100 EN

8
Дисплей
Предназначение:
Этот осциллометрический тонометр предназначен для неин-
вазивного измерения артериального давления улюдей в
возрасте 12 лет истарше.
Прибор прошел клинические испытания для использования
пациентами сгипертонией, гипотонией, сахарным диабетом,
при беременности, преэклампсии, атеросклерозе, конечной
стадии почечной недостаточности, ожирении иулюдей пожи-
лого возраста.
Уважаемый покупатель,
Прибор был разработан всотрудничестве сврачами, аклини-
ческие тесты подтвердили высокую точность его измерений.*
При возникновении вопросов, проблем или для заказа запа-
сных частей, пожалуйста, обращайтесь вместный сервисный
центр Microlife. Ваш дилер или аптека могут предоставить Вам
адрес дилера Microlife вВашей стране. Вкачестве альтерна-
тивы, посетите вИнтернете страницу www.microlife.ru, где Вы
сможете найти ряд полезных сведений по нашему изделию.
Будьте здоровы – Microlife AG!
* Вприборе использована та же технология измерений, что
ивотмеченной наградами модели «BP 3BTO-A», которая
успешно прошла клинические испытания всоответствии с
протоколом Британского иИрландского Гипертонического
Общества (BIHS).
Оглавление
1. Расшифровка символов
2. Важная информация об артериальном давлении и
самостоятельное измерение
•Как определить артериальное давление?
3. Использование прибора впервый раз
•Активация батарей
•Подбор подходящей манжеты
4. Выполнение измерений артериального давления
5. Появление индикатора аритмии сердца на ранней
стадии
6. Память
•Просмотр сохраненных величин
•Заполнение памяти
•Удаление всех значений
7. Замена сменной карты
8. Индикатор разряда батарей иих замена
•Батареи почти разряжены
•Замена разряженных батарей
•Элементы питания ипроцедура замены
•Использование аккумуляторов
9. Использование блока питания
10. Сообщения об ошибках
11. Техника безопасности, уход, проверка точности и
утилизация
•Техника безопасности изащита
•Уход за прибором
•Очистка манжеты
•Проверка точности
•Утилизация
12. Гарантия
13. Технические характеристики
Гарантийный талон
Прибор для измерения артериального давления ичастоты пульса BP A100 RU
1Кнопка ВКЛ/ВЫКЛ
2Дисплей
3Сменная карта
4Гнездо для манжеты
5Гнездо для блока питания
6Отделение для манжеты
7Отсек для батарей
8Манжета
9Соединитель манжеты
AR Кнопка M (Память)
AT Систолическое давление
AK Диастолическое давление
AL Частота пульса
AM Индикатор аритмии сердца
AN Пульс (индикатор сердца)
AO Индикатор разряда батарей
AP Сохраненное значение
AQ Количество ячеек памяти
