Microtech 110181027 User manual

MICROTECH
SUB-MICRON INTELLIGENT
COMPUTERIZED MICROMETER HEAD
Calibration ISO 17025:2017 ISO 9001:2015
USER MANUAL

MICROTECH SPECIFICATION
Parameters
LED display color 1,5 inch
Power supply Rechargeable Li-Pol battery
Lifetime >80h (Medium brightness)
Charging port micro-USB
Case material Aluminium
Buttons Switch, Reset
Wireless data transfer 10m without external antenna
50m with external antenna (from set)
PRECISION MEASUREMENTS
MICROTECH computerized micrometer with 0.1
resolution can be used for high precisoт measurements
in manufacturing, automotive medical industry and for
calibration
COLOR GO/NOGO INDICATION
Easy and quick limits control.
It’s possible setup max and min value throw menu.
Color indication reduce possibility of error during
control
INTERNAL MEMORY
Computerized micrometer has memory manger with
possibility saving data to folders. Separate Data’s or Folders
can be transfer Wireless to MICROTECH Software (Windows,
Android,iOS)
FORMULA MODE
In Formula mode we use Ax2+Bx+C
Main using of this function is:
- Preset function
- Magnification of measured value
For customers request Formula can be updated
ERROR COMPENSATION
It’s possible to make mathematical error
compensation. Just re-calibrate micrometer with
gauge block set and save results. Micrometer will
indicate measuring results include re-calibration.
TEMPERATURE COMPENSATION
Temperature compensation function gives
possibility recalculate details sizes with high or low
temperatures to normal (20C conditions). Available
recalculation for 7 materials
Item No Range Resolution Accuracy Data output Data output
mm mm mm USB Wireless
110181027 0-25 0,0001 ±0,002 Error & Temp comp. Preset.
Memory Max/Min Limits + +

MICROTECH
Clean the oil from the measuring surfaces of micrometer by cloth.
Turn on micrometer by pressing SWITCH ON button.
Check the setting display to zero. Contact with each other (or with setting gauge)
measuring surfaces of the anvil and the spindle, using the ratchet and take a
measurement.
Rotation the micrometer screw in the direction of convergence measuring surfaces using
the ratchet.
For zero setting, press the ZERO button on Touchscreen.
SWITCH ON DEVICE - button push (1 sec)
SWITCH OFF DEVICE - auto switch off (configurating throw DISPLAY SETTING menu)
- button push (3 sec)
For charging connect USB cable Charging process indicating
on Battery status
(switch on device)
BUILT-IN BATTERY - rechargeable Li-Pol battery
MAIN INFO
CHARGING
VIDEO INSTRUCTION
Item No Range Resolution Accuracy Data output Data output
mm mm mm USB Wireless
110181027 0-25 0,0001 ±0,002 Error & Temp comp. Preset.
Memory Max/Min Limits + +

MICROTECH
MAIN MENU
LIMITS
color Go/NoGo
MAX/MIN
indicating max or min value
FORMULA MODE
Ax2+Bx+C
TIMER MODE
saving or transfer data on timer
ERROR COMPENSATION
mathematical correction
TEMPERATURE COMPENSATION
manual correction 4 materials
RESOLUTION
selected up to 0.0001mm
AXIS MODE
normal or inverted
WIRELESS
modes of data transmition
USB
USB connection configuration
DEVICE SETTING
autostart, reset, password
SCREEN SETTING
screen rotation, brightness
SOFTWARE
link to download app
MEMORY SETTING
folder configuration
DEVICE INFO
service info about device
MEMORY MANAGER
max 100000 values
folders system
transfering data from memory to PC
color indication Go/NoGo mm/inch
conversion
functions status
CALIBRATION STATUS
calibration date control
ZERO setting
Battery status
MENU NAVIGATION

MICROTECH
DOWNLOAD DOWNLOAD
TRANSFER DATA TO
EXCEL OR OTHER
TABLE EDITORS
TRANSFER DATA TO
CAD, SPC OR OTHER
SOFTWARE
IMPORT FROM FILE OR CAMERA
USB CONNECTION
SAVING
GRAPH
QUALITY
CONTROL
RESULTS
VOICE
MODE
SAVING DATA
TO XLS. CSV
FORMATS
WIRELESS CONNECTION
USB-dONgLE
SAVING DATA
TO XLS. CSV
FORMATS
SAVING DATA
TO XLS. CSV
FORMATS
SAVING
GRAPH
VOICE
MODE
iOS
up to 50m
DATA TRANSFER DISTANCE FOR INTELLIGENT INSTRUMENTS
•All MICROTECH Intelligent instruments has internal memory.
You can collect data to memory and when it will be neccesary
transfer all data to the peripheral device with no data loosing.
•It’s possible transfer data, like in Wireless instruments up to 15 m
or up 50 m with external antenna
•USB port can be used to transfer data directly to Windows PC
DOWNLOAD
CONNECTION

MICROTECH
LIMITS GO/NOGO
MAX - NoGo over MAX value
MIN - NoGo over MIN value
RANGE - selecting GO range
NONE - No active mode
MENU SETTING MAIN SCREEN Status indication
on main screen
FORMULA
Avialable Formulas:
-Ax2+Bx+C
-Radius (for indicators)
-Sphere (for indicators)
TIMER
Saving or transfer data
by Timer
Select timer period
For disactive - reset to zero
Timer indicatiion on
main screen
EXAMPLES:
- for value x2 -
B=2
- set PRESET 100mm
C=100
- square value
A=1
Go
NoGoNoGo
MATH. ERROR COMPENSATION TEMPERATURE COMPENSATION
RESOLUTION EXTRA (Axis mode)
Selecting instrument
resolution Selecting normal or
inverted axis mode
Re-calculation value to calibration conditions 20C
7 types of materilas for selection
Manual temperature setting
Use up&down button to update actual value (green)
to correct value.
For compensation correction - push OK.
After points correction computerized instrument
will recalculate values according corrected points
+/- value indication
FUNCTIONS
MAX/MIN
ENABLE/DISABLE mode
indicating MAX dvalue
indicating MIN value
Red value
- actual value on instrument
Green value
- compensated value

MICROTECH
EXTRA (Axis mode)
FUNCTIONS FUNCTIONS
WIRELESS CONNECTION USB CONNECTION
PIN DISPLAY SETTING
Rotation 0, 90, 180, 270
Sleep mode
Brightness level
WIRELESS status
MEMORY MANAGER SETTINGS LINK TO SOFTWARE
CALIBRATION DATE DEVICE INFO
Saving or transfer data by Timer
Select timer period
For disactive - reset to zero
Information about firmware version
and MAC adress for easy connection
Link to page with MDS Software download
- for Android, iOS, Windows
- Free and Pro versions
- Standard / Folder mode
In Folder mode possible to set qty values
in each folder.
Free Software for Windows, Android, iOS

MICROTECH
Change without prior notice
Edition: M1030_0520
MICROTECH
innovative measuring instruments
61001, Kharkiv, Ukraine, str. Rustaveli, 39
tel.: [phone]
www.microtech.ua
[email protected]
Free Software for Windows, Android, iOS
0.1μm
