Trotec BD6A User manual

TRT-BA-BD6A-TC230123TTRT05-001-EN
BD6A
EN
ORIGINAL INSTRUCTIONS
CROSS LINE LASER

2 EN
cross line laser BD6A
Table of contents
Notes regarding the instructions .........................................2
Safety .....................................................................................2
Information about the device................................................4
Available accessories ...........................................................5
Transport and storage...........................................................5
Operation ...............................................................................5
Maintenance and repair ........................................................8
Errors and faults....................................................................8
Disposal .................................................................................9
Notes regarding the instructions
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning of laser radiation
This symbol indicates dangers to the health of persons
due to laser radiation.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
instructions must be observed.
You can download the current version of the instructions and
the EUdeclaration of conformity via the following link:
BD6A
https://hub.trotec.com/?id=47206
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use.
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
• Do not use the device in potentially explosive rooms or
areas and do not install it there.
• Do not use the device in aggressive atmosphere.
• Do not immerse the device in water. Do not allow liquids to
penetrate into the device.
• The device may only be used in dry surroundings and must
not be used in the rain or at a relative humidity exceeding
the operating conditions.
• Protect the device from permanent direct sunlight.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Do not open the device.
• Avoid looking directly into the laser beam.
• Never point the laser beam at people or animals.
• Never charge batteries that cannot be recharged.
• Different types of batteries and new and used batteries
must not be used together.
• Insert the batteries into the battery compartment according
to the correct polarity.
• Remove discharged batteries from the device. Batteries
contain materials hazardous to the environment. Dispose
of the batteries according to the national regulations.
• Remove the batteries from the device if you will not be
using the device for a longer period of time.
• Never short-circuit the supply terminal in the battery
compartment!
• Do not swallow batteries! If a battery is swallowed, it can
cause severe internal burns within2hours! These burns
can lead to death!

EN 3
cross line laser BD6A
• If you think batteries might have been swallowed or
otherwise entered the body, seek medical attention
immediately!
• Keep new and used batteries and an open battery
compartment away from children.
• Only use the device, if sufficient safety precautions were
taken at the surveyed location (e.g. when performing
measurements along public roads, on building sites etc.).
Otherwise do not use the device.
• Observe the storage and operating conditions (see
Technical data).
Intended use
Only use the device BD6A for the projection on non-reflective
surfaces as an aid to determine and check horizontal, vertical
and/ or parallel lines. Observe and comply with the technical
data.
To use the device for its intended use, only use accessories and
spare parts which have been approved by Trotec.
Any use other than the intended use is regarded as misuse.
Foreseeable misuse
Do not use the device BD6A in potentially explosive
atmospheres or in liquids. Never point it at people or animals.
Trotec accepts no liability for damages resulting from improper
use. In such a case, any warranty claims will be voided.
Any unauthorised modifications, alterations or structural
changes to the device are forbidden.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when working with
laser measuring devices.
• have read and understood the instructions, especially the
Safety chapter.
Safety signs and labels on the device
Note
Do not remove any safety signs, stickers or labels from
the device. Keep all safety signs, stickers and labels in
legible condition.
The following safety signs and labels are attached to the device:
Safety symbol Meaning
The warning sign is located on the side of
the device and indicates that the device is
equipped with a class2 laser.
The power is less than 1mW. The
frequency range of the laser is630 to
670nm.
Do not look directly into the laser beam
or the opening from which the laser
beam emerges!
The warning sign is located above the laser.
Do not look directly into the laser beam
or the opening from which the laser
beam emerges!
The warning sign is located on the side of
the device and indicates that the gimbal
suspension of the laser must be disabled
before transport.
To do so, the switch must be set to
the position.

4 EN
cross line laser BD6A
Residual risks
Warning of electrical voltage
There is a risk of a short-circuit due to liquids
penetrating the housing!
Do not immerse the device and the accessories in
water. Make sure that no water or other liquids can
enter the housing.
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning of laser radiation
Laser class2, Pmax.: <1mW, λ: 400-700nm,
EN60825-1:2014
Do not look directly into the laser beam or the opening
from which it emerges.
Never point the laser beam at people, animals or reflective
surfaces. Even brief eye contact can lead to eye damage.
Examining the laser output aperture by use of optical
instruments (e.g. magnifying glass, magnifiers and the
like) entails the risk of eye damage.
When working with a laser of class2, observe the
national regulations on wearing eye protection.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Keep a sufficient distance from heat sources.
Note
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Note
Do not use abrasive cleaners or solvents to clean the
device.
Information about the device
Device description
The cross line laserBD6A projects laser lines on surfaces, e.g.
to drill holes in a straight line– similar to using a spirit level.
The device comes with the following features:
• Projects light-intense laser lines up to a distance of 10m
• Self-levelling up to an inclination of 3.5°
• Laser projection either as cross lines or as individual
horizontal or vertical line
• Battery-operated
• Integrated ¼ inch tripod connection
Device depiction
3
1
2
6
5
7
4
No. Designation
1H button
2V button
3Battery compartment with cover
4Laser
51/4inch tripod connection (bottom)
6On/off/lock switch
7Operating mode LED

EN 5
cross line laser BD6A
Technical data
Parameter Value
Model: BD6A
Weight: 274g
Dimensions (length x width
x height):
70.4 x 62.1x 90.5mm
Laser accuracy: ±3mm/10m
Self-levelling function: 3.5° (±1°)
Range: 10 m
Laser output: <1mW (635nm)
Laser class: 2
Operating temperature: -10 °C to 50 °C
Resistant to drop height of: 1.2 m
Tripod 1/4 inch
Protection class IP54
Standby time 12h
Power supply: 2x AlkalineAA, 1.5V batteries
Scope of delivery
• 1x Cross line laser BD6A
• 2x AlkalineAA, 1.5V batteries
• 1x Quick guide
Available accessories
Designation Article number
Combi mount with universal clamp 6,300,000,201
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
When transporting the device, ensure dry conditions and and
protect the device from external influences e.g. by using a
suitable bag.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• the storage temperature complies with the values specified
in the Technical data
• Batteries are removed from the device
Operation
Inserting the batteries
Insert the supplied batteries into the device before first use.
Note
Make sure that the surface of the device is dry and the
device is switched off.
1. Open the cover(3) of the battery compartment.
2. If applicable, remove the old batteries.
3. Insert the new batteries in the battery compartment with
correct polarity.
4. Then close the cover of the battery compartment(3) again.
3

6 EN
cross line laser BD6A
Important information before use
Warning of laser radiation
Laser class2, Pmax.: <1mW, λ: 400-700nm,
EN60825-1:2014
Do not look directly into the laser beam or the opening
from which it emerges.
Never point the laser beam at people, animals or
reflective surfaces. Even brief eye contact can lead to
eye damage.
Examining the laser output aperture by use of optical
instruments (e.g. magnifying glass, magnifiers and the
like) entails the risk of eye damage.
When working with a laser of class2, observe the
national regulations on wearing eye protection.
Selecting the mode
The device comes with two operating modes, a self-levelling
and an inclination mode. In self-levelling mode, the device
automatically compensates for an angle of up to 3.5° and
aligns the laser lines horizontally or vertically. In the inclination
mode, the device can be aligned at any angle. In both modes,
the device is switched on and off differently.
To change the mode, please proceed as follows:
1. Switch off the device according to the current mode.
2. Switch on the device according to the new mode.
Self-levelling function
üThe device stands on a level, horizontal surface.
1. Set the on/off switch(6) to position .
ðThe vertical and horizontal laser lines are switched on.
ðThe operating modeLED(7) is illuminated in green.
+/- 3,5°
6
ðIf the operating modeLED(7) is illuminated in red and
the laser flashes, the permissible inclination range of
3.5° is exceeded. Position the device horizontally.
+/- 3,5°
2. Slide the on/offswitch(6) to the position to switch the
device off.
6

EN 7
cross line laser BD6A
Inclination mode
üThe on/off switch(6) is in the position.
1. Press and hold the H button(1) for approx. 3seconds.
ðThe operating modeLED(7) is illuminated in red.
1
2. Place the device on a surface or tripod, for example, and
position it at the desired angle.
ðBoth laser lines are no longer aligned horizontally, but
follow the inclination angle of the device.
3. Press and hold the H button(1) for approx. 3seconds to
switch the device off.
Switching the laser lines on and off
You can switch the laser lines off and on individually in both
operating modes to work either with cross lines or a single laser
line.
1. Press the Hbutton(1) briefly to switch off the horizontal
laser line.
ðOnly the vertical laser line is visible.
1
2. Press the Hbutton(1) again to switch the horizontal laser
line back on.
ðThe vertical and horizontal laser lines are visible.
1

8 EN
cross line laser BD6A
3. Press the Vbutton(2) to switch off the vertical laser line.
ðOnly the horizontal laser line is visible.
2
4. Press the Vbutton(2) again to switch the vertical laser line
back on.
ðThe vertical and horizontal laser lines are visible.
2
Maintenance and repair
Cleaning
Clean the device with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Do not use any
sprays, solvents, alcohol-based cleaning agents or abrasive
cleaners, but only clean water to moisten the cloth.
Repair
Do not modify the device or install any spare parts. For repairs
or device testing, contact the manufacturer.
Battery change
A battery change is required when the device can no longer be
switched on (see chapter Inserting the batteries).
Errors and faults
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
The laser lines are apparently not aligned horizontally/
vertically:
• The possible range of max.3.5° for automatic levelling
has been exceeded. If necessary, readjust the device.
• The switch(6) is still set to position or has not been
properly opened. Check the switch position.
• The device has been dropped or was subject to a hard
impact. This may have lead to damages on the laser optics
suspended on a pendulum. Send the device to the Trotec
Service for inspection.
Only one of both laser lines is visible:
• Check whether you have activated only one of the two
lasers.
• The device has been dropped or was subject to a hard
impact. This may have lead to damages on the laser optics
suspended on a pendulum. Send the device to the Trotec
Service for inspection.

EN 9
cross line laser BD6A
Disposal
Always dispose of packing materials in an environmentally
friendly manner and in accordance with the applicable local
disposal regulations.
The icon with the crossed-out waste bin on waste
electrical or electronic equipment is taken from Directive
2012/19/EU. It states that this device must not be disposed of
with the household waste at the end of its life. You will find
collection points for free return of waste electrical and electronic
equipment in your vicinity. The addresses can be obtained from
your municipality or local administration. You can also find out
about other return options that apply for many EU countries on
the website https://hub.trotec.com/?id=45090. Otherwise,
please contact an official recycling centre for electronic and
electrical equipment authorised for your country.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.
In the European Union, batteries and accumulators must
not be treated as domestic waste, but must be disposed of
professionally in accordance with Directive 2006/66/EC of the
European Parliament and of the Council of 6September2006
on batteries and accumulators. Please dispose of batteries and
accumulators according to the relevant legal requirements.
Only for United Kingdom
According to Waste Electrical and Electronic Equipment
Regulations 2013 (SI2013/3113) (as amended) and the Waste
Batteries and Accumulators Regulations 2009 (SI2009/890) (as
amended), devices that are no longer usable must be collected
separately and disposed of in an environmentally friendly
manner.

Trotec GmbH
Grebbener Str. 7
D-52525 Heinsberg
[phone]
[phone]
[email protected]
www.trotec.com
