Congratulations on your purchase of the ArtixScan 1100 scanner! The ArtixScan 1100 is a single-pass, 36-bit, high-
resolution scanner with dual beds — the upper bed for scanning reflective materials such as photos and prints, and
the lower bed for scanning transparent media such as film, slides, and filmstrips. This manual will help you in the
installation and operation of your scanner, and the information provided covers both Macintosh and PC environ-
ments for Windows 98 / 95, as well as Windows NT 4.0. See the notes below on how to use the manual, based on the
environment in which you operate.
• If you are operating under the Macintosh environment, go to the General Installation section of the manual, then
proceed to Installation on the Macintosh, then go to Operating the Scanner.
• If you are operating under Windows 98 or Windows 95, go to the General Installation section of the manual, then
proceed to Installation on Windows 98 / Windows 95, then go to Operating the Scanner.
• If you are operating under Windows NT 4.0, go to the General Installation section of the manual, then proceed to
Installation on Windows NT 4.0, then go to Operating the Scanner.
The last section of the manual provides information on the Scanner ICC Profiler program, which applies to both
Macintosh and PC environments, and shows you how to use the program to ensure the most accurate color for your
scanner.
1 Introduction

2 ArtixScan 1100 Hardware User’s Guide
English
A
Horizontal ruler
Scanner
cover
Glass surface Vertical ruler
Transparency tray
ArtixScan 1100 Scanner
Power switch
Power LED (green)
Transparency Ready indicator
(orange)
Reflective Ready indicator (orange)
Reflective
Material

ArtixScan 1100 Hardware User’s Guide 3
English
SCSI 50-pin connector
SCSI 25-pin connector
ID switch
Terminator
switch
ArtixScan 1100 Scanner
ON OFF
+
6
Power connector

4 ArtixScan 1100 Hardware User’s Guide
English
2 General Installation
This section provides information on procedures you need to perform or things to check on your ArtixScan 1100
scanner regardless of the environment in which you operate — whether it is on the Macintosh or on the PC. The
general installation procedures cover the following subjects: 1) unpacking your scanner; 2) unlocking the scanner; 3)
resetting the scanner’s SCSI ID if necessary; 4) powering up the scanner; and 5) choosing your scanning station.
1 . UnpackingtheScanner
While unpacking the scanner, inspect the shipping carton
for any signs of mishandling or damage.Your scanner’s
packing carton and padding material has been carefully
chosen to prevent damage to the unit in shipping and can
withstand a reasonable amount of abuse.
Refer to the package contents checklist included with your
scanner to ensure that you received all of the parts
necessary for scanner setup. Should you observe any
damage or missing parts, contact the shipper and your
dealerimmediately.
2 . UnlockingtheCarriage
To prevent damage to the scanner’s moving parts, the
scanner carriage is locked into place prior to shipment.
You must unlock the carriage before powering up the
scanner. Failure to do so may damage the scanner and will
void your warranty. Follow the unlocking instructions
below:
The carriage lock of theArtixScan 1100 is located on the
underside of the scanner.
To unlock the carriage, insert a flathead screwdriver or a
coin into the locking screw slot and turn the screw a
quarter turn counter-clockwise. Once unlocked the screw
head will pop out slightly but will remain in the scanner.
Note: The scanner must be relocked prior to any future
scanner transportation or relocation.

ArtixScan 1100 Hardware User’s Guide 5
English
3.Resettingthescanner’sSCSIID
Note: This procedure is provided as a reference, and you
may or may not need to change the SCSI ID on your
scanner.
A SCSI ID is assigned to each SCSI device in your daisy
chain to differentiate the devices from one another. The
SCSI ID for your Microtek scanner is factory-set to 6.
You do not need to change the SCSI ID on your scanner
unless another SCSI device on your system (such as an
external hard drive, additional scanner, etc.) is using the
same number.
To change the SCSI ID: Locate the SCSI ID switch, then
press the upper opening “-” to decrease the SCSI ID
number, or press the lower opening “+” to increase the
number.
6
+
Valid SCSI ID numbers are 0 to 6. Do not use SCSI ID
#7, which is used to carry out a self-test for the
scanner and make the carriage move back and forth.
SCSI ID #8 and #9 are also not used.
4 . Power-uptest
All scanners are factory tested. To ensure that your
scanner has not been damaged during shipment, however,
you will need to perform the following preliminary
power-up test. Contact your dealer immediately if the
scanner is not in proper working condition.
A.OperatingVoltage
Your scanner is preset to the voltage in your area.There is
no need to manually select the voltage; however, make
sure that the label next to the power entry module
indicates the correct voltage. Contact your dealer if the
label indicates an incorrect voltage.
B.ConnectingtheScannertoPowerSource
Caution! Make sure your scanner carriage is unlocked
prior to connecting it to a power source (refer to step 2).
Connect the scanner to a voltage source directly by using
the supplied power cord; do not use extension cords.
Make sure that the power outlet will not be overloaded
when the scanner is turned on, and ensure that other
devices requiring significant power are not plugged into
the same outlet. Ideally, no other devices should share the
scanner’s power source.
C.PoweringuptheScanner
The power switch is located on the scanner’s front panel.
After verifying that the scanner is plugged into a live
outlet, turn on the Power Switch.

6 ArtixScan 1100 Hardware User’s Guide
English
D. Observing the Scanner Boot Process
The following sequence of events should take place after
power up:
•The scanner performs a self-test by homing the
carriages and camera box. Through the platen glass,
you will be able to observe the carriage moving, and
you will hear a series of clicking noises associated
with the operation of the scanner motors. These
“clicking” noises are normal. However, if you hear
loud grinding noises or any other abnormal sound,
turn the scanner off immediately and contact your
dealer.
•The Orange indicator light located on the front panel
will flash, indicating that the scanner is running.
•After the self test is complete, the indicator lights
will shine steadily, and the fluorescent lamp inside
the scanner will light up, indicating that the scanner
is ready.
If an error occurs and the scanner is not able to boot up
properly, the status indicators will display a steady red
light in all three indicators. If this happens, turn the
scanner off immediately and contact your dealer.
5 . Choosing the Scanning Station
If no errors were encountered and the scanner booted up
normally, you are now ready to set it up. Turn off the
power switches and disconnect the cord.
Before you choosea location forthe scanner, pleaseread the operating environment requirements listed
below.
Requirements for the Operating Environment
•Make sure that the operating environment for the
scanner is free of dust and other contaminants.
•Allow adequate ventilation space (no less than ten
inches) around the scanner.
•Place the scanner on a flat, stable surface that is not
subject to vibration.
•Make sure that the scanning surface will not be
exposed to direct sunlight or other sources of bright
light.
•Avoid placing the scanner close to sources of extreme
temperature.
•Try to ensure that the scanner is situated in its ideal
operating temperature range — between 50º and
104ºF (10º and 40ºC).
•Keep the relative humidity in the scanner operating
area between 10% and 85%.
•Avoid connecting the scanner to a power source that
might experience power surges.
•Avoid positioning the scanner in the path of heavy
traffic where it may get bumped.
Once the scanner has been placed in a suitable location
and is ready to be connected to the host computer, it is
time to proceed to installing the necessary hardware and
software components for the scanner. Please go to the
appropriate section in this manual for the installation
procedures to follow, and perform the procedures
corresponding to your environment (Macintosh,
Windows 98 /Windows 95, or Windows NT 4.0).

ArtixScan 1100 Hardware User’s Guide 7
English
3 Installation on the Macintosh
This section provides information on installing the ArtixScan 2020 on the Macintosh. The procedures are divided
into two main sections: 1) Installation for Macintosh computers that feature built-in SCSI ports; and 2) Installation
for the new Macintosh G3 computers (with no SCSI ports). For the new G3 computers, you will be installing the
SCSI interface card included in the scanner package.
A. Installation for Macintosh computers with built-in SCSI ports
1. Connecting the scanner
1. Shut down your computer.
2. Connect the scanner to your computer, using the
SCSI cable provided in the scanner package.
Note: See the next section for details on termination.
3. Plug the power cord to the power connector at the
back panel of the scanner, and plug the other end of
the power cord to your AC power source or wall
outlet.
4. Turn on your scanner and wait for all the lights on
the front panel to stop blinking and stay on steady.
5. Power up your Macintosh.
2. Termination
A terminator is included in your scanner package and
should be installed on your scanner in the following
situations:
• If the scanner is the only SCSI device in your SCSI
chain; or
• If you are daisy chaining the scanner with other
SCSI devices AND the scanner is the last device in
your SCSI chain.
Normally, a terminator is not required is when the
scanner is part of a daisy chain and is NOT the last
device in the SCSI chain.
To install the terminator, plug it into
the SCSI port at the back of the
scanner (beside the cable connecting
the scanner to the computer).

8 ArtixScan 1100 Hardware User’s Guide
English
B. Installation for the new G3 Macintosh computers (without built-in SCSI ports)
1. Installing the interface card
Before installing the interface card, make sure you turn
off your computer and peripherals. Then follow the steps
below:
1. Shut down your computer and unplug the power
cord. Next, open your computer.
2. Look for an available PCI card slot (typically white
or ivory) in your computer. Remove the slot cover,
and insert the Adaptec PCI SCSI card into the slot.
Push the card in to make sure it is seated all the way
in the slot. This is important, as an improper card
connection will make you unable to use your scanner,
and you will then have to remove the computer case
and reinsert the card.
3. Close the computer, then plug the power cord back
in.
2.Connectingthescanner
1. Shut down your computer.
2. Connect the scanner to your computer, using the SCSI
cable provided in the scanner package.
Note: See the next section for details on termination.
3. Plug the power cord to the power connector at the
back panel of the scanner, and plug the other end of
the power cord to yourAC power source or wall
outlet.
4. Turn on your scanner and wait for the lights on the
front panel to stop blinking and stay on steady.
5. Power up your Macintosh.

ArtixScan 1100 Hardware User’s Guide 9
English
C. Installing the software
Install all the software in your Artix CD-ROM.
To do this, insert the Artix CD-ROM into your CD-ROM
drive. When the CD-ROM icon appears on your
Macintosh desktop, open the software folders individu-
ally, then double-click the Installer icon on each folder
to install the respective programs one at a time.
3. Termination
A terminator is included in your scanner package and
should be installed on your scanner in the following
situations:
• If the scanner is the only SCSI device in your SCSI
chain; or
• If you are daisy chaining the scanner with other
SCSI devices AND the scanner is the last device in
your SCSI chain.
Normally, a terminator is not required is when the
scanner is part of a daisy chain and is NOT the last
device in the SCSI chain.
To install the terminator, plug it into
the SCSI port at the back of the
scanner (beside the cable connecting
the scanner to the computer).

10 ArtixScan 1100 Hardware User’s Guide
English
4 Installation on Windows 98 / 95
1. Installing the interface card
1. Turn off your PC and peripherals, and unplug the
power cord. Next, remove the cover from your
computer.
2. Before handling the interface card, touch a metal
frame (such as your computer casing) to discharge
any static electricity buildup in your body.
3. Look for an available PCI card slot in your computer,
then insert the Adaptec PCI SCSI card (such as the
Adaptec AVA-2903E or 2906E) into the slot. Push
the card in to make sure it is seated all the way in the
slot, then put the screw back into the bracket.
Proper card connection is important, as an improper
card connection will make you unable to use your
scanner, and you will then have to remove the
computer case and start the process of card insertion
all over again.
SCSI card
4. Replace the cover of the computer, then plug the
power cord back in.
5. Turn your PC back on.
2. Checking the interface card status
When Windows starts with the Adaptec SCSI card
installed in your computer, the card is detected and the
driver automatically installed.You may be asked to
insert your Windows CD-ROM. Do so, and follow the
steps below to check your card status.
1. In Windows, click Start, Settings, and then select
Control Panel.
2. Double-click on the System icon in Control Panel
and select Device Manager from the top.
3. Double-click on SCSI controllers to display the
screen below. The string “Adaptec 7850 PCI SCSI
Controller” indicates that the driver is installed.
The message “Adaptec AIC-7850 PCI SCSI
Controller” displays indicates that the driver is
installed and that the interface card works properly.
If a conflict exists, either of the following will occur:
• a yellow exclamation mark appears next to the
phrase:
Adaptec AIC-7850 PCI SCSI Controller
- or -
• nothing is listed under “SCSI Controllers”. In
either case, refer to the Troubleshooting section.
The result of
the check is
displayed
here

ArtixScan 1100 Hardware User’s Guide 11
English
3. Installing the software
Install all the software in your Artix CD-ROM, which
includes Microtek ScanWizard Pro and the Microtek
Scanner ICC Profiler programs.
To do this: Insert the Artix CD-ROM into your CD-
ROM drive; the Scanner Software installer should come
up automatically.
Note: If the Scanner Software is not automatically
displayed, click Start, select Run and type d:\cdsetup
(where d: is your CD-ROM drive).
Click on the “Install” option on each software program
in the order that it appears on your screen to install the
software.
During installation of ScanWizard Pro, make sure you
choose Adaptec SCSI Interface Card as your interface
type.
After all the software has been installed, shut down your
computer.
4. Connecting the scanner
1. Turn off your PC.
2. Plug the 25-pin end of the SCSI cable into the
Adaptec card at the back of the computer. Then plug
the 50-pin end of the SCSI cable into the back of the
scanner.
Note: See the next section for details on termination.
3. Plug the power cord into the back of the scanner and
plug the other end of the power cord into a power
source or wall outlet.
4. Press the scanner’s power button on the front panel to
turn the power on, then wait for the Ready indicator
lights also on the front panel of the scanner to stop
blinking and to stay on solid.
5. Turn your PC back on. When Windows starts up, it
will automatically detect the scanner.

12 ArtixScan 1100 Hardware User’s Guide
English
A yellow
exclamation
mark appears
next to the
message
“Adaptec AIC-
7850 PCI SCSI
Controller”.
6. Troubleshooting
After installing the interface card in your computer and
connecting the scanner, you may find yourself unable to
use the scanner. This is usually due to any of the
situations described below:
Situation A Your interface card is not properly seated
in the PCI card slot on your computer.
Situation B Your interface card conflicts with another
device.
Situation C Windows 98 / 95 cannot recognize your
interface card.
Resolving situation A
Power off your computer, then remove the interface card
from your computer. Re-install it and make sure the card
is seated all the way in and secured into the PCI card
slot.
Resolving situation B
1. Click Start, Settings, and select Control Panel.
2. Double-click on the System icon in Control Panel
and select Device Manager from the top.
3. Double-click on “SCSI controllers” to display the
dialog box below.
4. Click on the Adaptec AIC-7850 PCI SCSI Control-
ler option, and then click Properties.
5. Select Resources from the top. The dialog box gives
you information about the 3 resources: Interrupt
Request (IRQ), Memory Range, and Input/Output
range. Any conflict in the 3 resources is detected and
displayed in the “Conflicting device list”.
5. Termination
A terminator is included in your scanner package and
should be installed on your scanner in the following
situations:
• If the scanner is the only SCSI device in your SCSI
chain; or
• If you are daisy chaining the scanner with other
SCSI devices AND the scanner is the last device in
your SCSI chain.
Normally, a terminator is not required is when the
scanner is part of a daisy chain and is NOT the last
device in the SCSI chain.
To install the terminator, plug it into
the SCSI port at the back of the
scanner (beside the cable connecting
the scanner to the computer).

ArtixScan 1100 Hardware User’s Guide 13
English
6. To resolve the conflict, uncheck “Use automatic
settings”, then click to modify the individual
resource, one after another, until the message “No
conflicts” appears in the Conflicting device list.
For example, to resolve the Memory Range conflict,
take these steps:
a) At the Resource type, double-click on the
Memory Range string, the Edit Memory Range
dialog box is displayed.
b) When the next screen appears, go to the Value
box, then use the Up/Down arrow keys to select
a different range.
Uncheck
this option
Error
message
appears
here if
conflict
occurs
Click the
arrows to
select a
different
range

14 ArtixScan 1100 Hardware User’s Guide
English
7. When you get a “No conflicts” message in the
Conflicting device list, the Memory Range conflict is
resolved. Take similar steps for the Interrupt Request
(IRQ) and Input/Output Range resources. If all of
IRQs are taken, you need to contact your computer
dealer for help on how to free up an IRQ for you.
8. When the settings are all correct, click OK to save the
modifications. The dialog box should now show the
correct Interrupt Request, Memory Range, and Input/
Output address settings.
If you are asked to shut down your computer, select
No, then click Close.You will be asked whether you
wish to restart your computer. Click Yes and restart
your computer.
No conflicts
found
Resolving situation C
1. Click Start, Settings, and select Control Panel.
2. Double-click Add New Hardware.
3. Click Next and select No for “Do you want Windows
to search for your new hardware?”.
4. From the next menu, select SCSI controllers and
click Next.
5. Select Adaptec on the left and “Adaptec AIC-7850
PCI SCSI Controller” on the right. Click Next.
6. When the “Add New Hardware Wizard” dialog box
appears, click Finish.

ArtixScan 1100 Hardware User’s Guide 15
English
7. When installation is complete, Windows will ask if
you wish to shut down your computer. Select No.
8. Click Start, Settings, and select Control Panel.
9. Double-click on the System icon in Control Panel
and select Device Manager from the top.
10. Double-click on “SCSI controllers” to check
whether conflict happens. If a conflict exists, follow
the steps in Resolving Situation B.
11. When the settings are all correct, click OK to save the
modifications. The dialog box should now show the
correct Interrupt Request, Memory Range, and Input/
Output address settings. If you are asked to shut
down your computer, select No, then click Close.
You will be asked whether you wish to restart your
computer. Click Yes and restart your computer.

16 ArtixScan 1100 Hardware User’s Guide
English
5 Installation under Windows NT 4.0
6. Troubleshooting
After installing the interface card in your computer and
connecting the scanner, you may find yourself unable to
use the scanner. This is usually due to any of the
situations described below:
Situation A Your interface card is not properly seated
in the PCI card slot on your computer.
Situation B The driver for the interface card is not
properly installed on your computer.
Resolving situation A
Power down your computer, remove the interface card
from your computer. Then re-install it, make sure the
card is seated all the way in and secured into the PCI
card slot.
Resolving situation B
1. Restart your computer.
2. In Windows 4.0, click Start,Settings,and select
Control Panel.
3. In the Control Panel window, find SCSI Adapters
and double click it. A window like the following
below will appear.
The Devices screen will list any SCSI controllers that
may already have been installed in your computer.
Note: IDE CD-ROM drives are not SCSI, but
Windows NT 4.0 will still list it on the screen because
1. Installing the interface card
See page 10 for details. Card installation on
Windows NT 4.0 is the same as that under
Windows 98 / 95.
2. Installing the Windows NT driver
a) Start your computer, and log in as Administra-
tor. Note:You must be logged in as Administra-
tor in order to install the scanner software
components and use the scanner.
b) In Windows, go to Start, Settings, then
double-click on Control Panel, and double-
click on the SCSI Adapters icon.
c) Select the Drivers tab in the SCSI Controllers
dialog box, and click on the Add button.
d) From the list of drivers that appear, select
Adaptec for manufacturers on the left, and
Adaptec AIC-78xx PCI SCSI Controller on
the right.You may be asked to insert your
Windows NT CD-ROM at this point; do so.
e) You will be asked to restart your computer.
Click Yes to do so.
3. Installing the software
Make sure you have logged in as Administrator.
Then see page 11 for more details. The software
installation instructions for your scanner under
Windows NT 4.0 are the same as those for
installation under Windows 98 / 95.
4. Connecting the scanner
See page 2-4 for details. Connecting the scanner
on Windows NT 4.0 is the same as that under
Windows 98 / 95.
5. Checking the scanner status
a) Double-click the SCSI Adapters icon in
Control Panel; the string Adaptec AIC-78xx
PCI SCSI Controller should appear on the
list.
b) Double-click on this option, and it should
expand with the scanner listed below it. Close
all dialog boxes to continue.
.
Adaptec
SCSI driver
is not listed
here
