Microtronics myDatalogNANOamr User manual

Manual for the portable device
myDatalogNANOamr
Rev. 01 valid from:
lFirmware version: 03v005
lModem version: 03v005
lServer version: 38.1
lHardware version: 1.1
User manual
300436
Microtronics Engineering GmbH | www.microtronics.at
Hauptstrasse 7 | 3244 Ruprechtshofen | Austria
Tel [phone] | Fax [phone] | [e-mail]

Chapter 1 Table of contents
Chapter 1 Table of contents
Manual for the portable device myDatalogNANOamr 1
Chapter 1 Table of contents 3
Chapter 2 Declaration of conformity 9
Chapter 3 Technical data 11
Chapter 4 General specifications 13
4.1 Translation 13
4.2 Copyright 13
4.3 General descriptive names 13
4.4 Safety instructions 13
4.4.1 Use of the hazard warnings 14
4.4.2 Safety and preventative measures for handling GSM/GPRS modems 14
4.4.2.1 Safety and precautionary measures for the GSM/GPRS modem installation 14
4.4.2.2 Safety measures for installing the antenna 15
4.5 Overview 16
4.6 Intended use 16
4.7 General product information 17
4.8 Device labelling 17
4.9 Installation of replacement and wear parts 18
4.10 Storage of the product 18
4.11 Obligation of the operator 18
Chapter 5 Functioning principle 21
5.1 ALOHA transmission mode 23
5.2 Selection of the GSM network 23
5.2.1 Ban list 24
Chapter 6 Storage, delivery and transport 25
6.1 Inspection of incoming deliveries 25
6.2 Scope of supply 25
6.3 Storage 25
Rev. 01 3

6.4 Transportation 25
6.5 Return 26
Chapter 7 Installation 27
7.1 Dimensions 27
7.2 Installing the myDatalogNANOamr 27
7.2.1 Wall mounting 28
7.2.2 Top-hat rail assembly 29
7.2.3 Pipe assembly 31
7.3 Safety instructions for the cabling 32
7.3.1 Information on preventing electrostatic discharges (ESD) 32
7.4 Electrical installation 32
7.4.1 Connecting the meters 33
7.4.1.1 Connection examples 34
7.4.1.1.1 Elster T-probe 34
7.4.1.1.2 Sensus MS8100 35
7.4.2 Connection of the GSM antenna 35
7.4.3 Optimum antenna positioning for assembly in a shaft 36
7.4.3.1 Influences on the signal quality 36
7.4.3.2 Possibilities for improving the signal quality 37
7.4.3.3 Procedure for determining the optimum position of the antenna 37
7.4.4 Technical details about the meter inputs 37
7.4.5 Technical details about the device operating time 38
Chapter 8 Initial Start-Up 41
8.1 User information 41
8.2 General principles 41
8.3 Placing the system into operation 41
8.4 Testing communication with the device 43
Chapter 9 User interfaces 45
9.1 User interface on the myDatalogNANOamr 45
9.1.1 Operating elements 45
4Rev. 01

Chapter 1 Table of contents
9.1.1.1 Solenoid switch 45
9.1.1.2 Status LED 46
9.2 User interface on the myDataweb-Server 47
9.2.1 Site configuration 47
9.2.1.1 Site 47
9.2.1.2 Comments 47
9.2.1.3 Measurement channels 48
9.2.1.3.1 Basis 48
9.2.1.3.2 Config 49
9.2.1.4 Calculated channels 50
9.2.1.4.1 Basis 50
9.2.1.4.2 Calculation 51
9.2.1.4.3 Alarm 52
9.2.1.5 Internal channels 52
9.2.1.5.1 Basis 52
9.2.1.6 Alarm settings 52
9.2.1.7 Basic setting 53
9.2.1.8 FTP export settings 53
9.2.2 Device configuration 54
9.2.2.1 Comments 54
9.2.2.2 Measurement instrument 54
9.2.2.3 Device-specific settings 55
9.2.2.4 GPRS 56
Chapter 10 myDataweb server 57
10.1 Overview 57
10.1.1 Explanation of the symbols 57
10.2 "Customer" area 58
10.3 "Site" area at customer level 59
10.3.1 Reports 59
10.4 Recommended procedure 60
Rev. 01 5

10.4.1 Creating the site 60
10.4.2 Assigning a device to the customer 61
Chapter 11 WebApp 65
11.1 General 65
11.2 Creating a "Direct login" 65
11.2.1 iOS (iPhone) 67
11.2.2 Android2.2 68
11.3 List of sites 69
11.3.1 Determining the position of the site 70
11.4 Site info screen 71
11.4.1 Editing a comment 71
11.4.2 Configuring the measurement channels 72
11.4.2.1 User level1 73
11.4.2.2 User level2 74
Chapter 12 XML interface 75
12.1 General 75
12.2 Structure of the database 75
12.2.1 Generally applicable table identifiers 76
12.2.1.1 mydatalognanoamrid 76
12.2.1.2 geraetid 83
12.2.1.3 bookingline (read only) 85
12.2.1.4 kundeid 85
12.2.2 Device-specific table identifier 87
12.2.2.1 mydatalognanoamr_data 87
12.2.2.2 mydatalognanoamr_channel 88
12.2.2.3 mydatalognanoamr_log 89
12.2.2.4 mydatalognanoamr_user1 89
12.2.2.5 mydatalognanoamr_state 91
12.2.2.6 mydatalognanoamr_aloha 91
12.2.2.7 mydatalognanoamr_pos 91
6Rev. 01

Chapter 1 Table of contents
12.2.2.8 mydatalognanoamr_set 92
12.3 XML export 93
12.3.1 Configuration of a HTTP-GET command 93
12.3.1.1 Syntax of the xPath query 94
12.3.1.1.1 List of the fields in a table 94
12.3.1.1.2 List of site types 94
12.3.1.1.3 Filter conditions 94
12.3.1.1.3.1 Example: 95
12.3.1.1.4 Fields 96
12.3.1.1.4.1 Example 96
12.3.1.1.5 Data retrieval including index specifications 97
12.3.1.1.5.1 Example 97
12.3.1.2 Data record compression 99
12.3.1.3 Updating data fields 100
12.3.1.3.1 Example 100
12.3.2 Format of the XML result 101
12.3.2.1 Example: 102
12.4 XML import 102
12.4.1 Transferring data to the myDataweb server 102
12.4.2 Configuration of a HTTP-POST command 103
12.4.3 Structure of the XML file 104
12.4.3.1 Changing existing data 104
12.4.3.2 Importing data 104
Chapter 13 Maintenance 107
13.1 General maintenance 107
13.2 Replacing the battery pack 107
Chapter 14 Removal/disposal 111
Chapter 15 Troubleshooting and repair 113
15.1 General problems 113
15.2 Log entries and error codes 114
Rev. 01 7

15.2.1 Modem error 117
15.3 Evaluating the device log 120
15.3.1 Evaluating the device log on the myDataweb server 120
15.3.2 Evaluating the device log using myDatanetDeviceConfig 120
Chapter 16 Spare parts and accessories 121
16.1 Assembly sets 121
16.2 Antennas 121
16.3 Battery packs 121
16.4 Other accessories 121
Chapter 17 Document history 123
Chapter 18 Contact information 125
8Rev. 01

Chapter 2 Declaration of conformity
Chapter 2 Declaration of conformity
Rev. 01 9

Chapter 3 Technical data
Chapter 3 Technical data
Voltage supply Battery pack BP434RLC : 2 x Li-SOCl2 cells fully fabricated with 29Ah
Housing Material: Luran/PC
Weight: 600g (incl. battery)
Protection class: IP68
Dimensions (WHD): 86 x 155 x 64mm (without connection cable)
Operating
temperature
-20...+60°C, 15...90%rHnon-condensing
Storage
temperature
-30...+85°C
Display LED for indicating the operating state and error codes
Operation Solenoid switch for initiating ALOHA transmission mode
Antenna
connection
FME-M
Inputs 4 x meters
Minimum pulse length: >1ms
Additional information is provided in "Technical details about the meter inputs"
on page 37.
Data memory Internal flash memory for up to 17.050 measurement cycles
Data type s64 (64 Bit signed)
Data
transmission
By means of GSM/GPRS quad-band modem to the respective myDataweb server
SIM The myDatalogNANOamr is equipped with an integrated SIM chip.
Monthly data
volume
t.b.d. at two-minute measurement cycle and 120-minute transmission cycle
Device operating
time
With the default settings (1channel, 200ms reader type, 6h transmission cycle)
up to 3,76 years
Additional information is provided in "Technical details about the device
operating time" on page 38.
Rev. 01 11

Chapter 4 General specifications
Chapter 4 General specifications
The information in this manual has been compiled with great care and to the best of our knowledge.
The manufacturer, however, assumes no liability for any incorrect specifications that may be
provided in this manual. The manufacturer is not responsible for direct, indirect, accidental or
consequential damages which arise from errors or omissions in this manual even if advised of the
possibility of such damages. In the interest of continuous product development, the manufacturer
reserves the right to make improvements to this manual and the products described in it at any time
and without prior notification or obligation.
Note: The specifications in this manual are valid as of the versions listed on the front page. Revised versions of this
manual, as well as software and driver updates are available in the service area of the myDataweb server.
4.1 Translation
For deliveries to countries in the European Economic Area, the manual must be translated into the
language of the respective country. If there are any discrepancies in the translated text, the original
manual (German) must be referenced or the manufacturer contacted for clarification.
4.2 Copyright
The copying and distribution of this document as well as the utilisation and communication of its
contents to others without express authorisation is prohibited. Contraventions are liable to
compensation. All rights reserved.
4.3 General descriptive names
The use of general descriptive names, trade names, trademarks and the like in this manual does not
entitle the reader to assume they may be used freely by everyone. They are often protected
registered trademarks even if not marked as such.
4.4 Safety instructions
For the connection, commissioning and operation of the myDatalogNANOamr , the following
information and higher legal regulations of the country (e.g. ÖVE), such as valid EX regulations as
well as the applicable safety and accident prevention regulations for the respective application case
must be observed.
Please read this manual completely before unpacking, setting up or operating this device. Observe
all hazard, danger and warning information. Non-observance can lead to serious injuries to the
operator and/or damage to the device.
Ensure that the safety equipment of this measurement device is not impaired. Install and use the
measuring system only in the manner and method described in this manual.
Rev. 01 13

Important note: The manufacturer's products that are designed for use outdoors include
extensive protection against penetrating moisture and dust. The operator is responsible for
protecting the joint between the product's sensor cable and the sensor against penetrating
moisture and dust in a suitable way and complying with local safety regulations.
4.4.1 Use of the hazard warnings
DANGER:
Indicates a potential or threatening hazardous situation that will result in death or serious
injuries if not avoided.
WARNING:
Indicates a potential or threatening hazardous situation that can result in death or serious
injuries if not avoided.
CAUTION:
Indicates a potential hazardous situation that can result in minor or moderate injury.
Note: Indicates a situation that does not result in any injury to persons.
Important note: Indicates a situation that can result in damages to this instrument if it is not
avoided. Information that must be particularly emphasised.
Note: Information that supplements the specifications in the main text.
4.4.2 Safety and preventative measures for handling GSM/GPRS modems
Observe the following safety and preventative measures during all phases of installation, operation,
maintenance or repair of a GSM/GPRS modem. The manufacturer shall not be held liable if the
customer disregards these preventative measures.
CAUTION:
The GSM/GPRS modem connection may not be used in hazardous environments.
No guarantee of any kind, whether implicit or explicit, is given by the manufacturer and its
suppliers for the use with high risk activities.
In addition to the following safety considerations, all directives of the country in which the device is
installed must be complied with.
Important note: No liability shall be assumed at any time and under no condition for the
connection via a GSM/GPRS modem for whose use radio signals and networks are utilized,
The GSM/GPRS modem must be switched on and be operated in an area where sufficient
signal strength is present.
4.4.2.1 Safety and precautionary measures for the GSM/GPRS modem installation
lThis device may only be installed by a trained technician who applies the recognised
installation practices for a radio frequency transmitter including the of external antennas.
14 Rev. 01

Chapter 4 General specifications
lThe device may not be operated in hospitals and/or near medical equipment such as heart
pacemakers or hearing aids.
lThe device may not be operated in highly flammable areas such as petrol filling stations, fuel
storage sites, chemical factories and explosion sites.
lDo not operate the device in the vicinity of flammable gases, vapours or dusts.
lDo not subject the device to strong vibrations or impacts.
lThe GSM/GPRS modem can cause interference if it is located near television equipment, radios
or computers.
lDo not open the GSM/GPRS modem. Any modification to the equipment is prohibited and
shall lead to loss of the operating licence.
lThe use of GSM services (SMS messages/data communication/GPRS etc.) may lead to
additional costs. The user alone is responsible for any damages and costs resulting through
this.
lDo not install the device in any other manner than the one described in the operating
instructions. An improper use will invalidate the warranty.
4.4.2.2 Safety measures for installing the antenna
lOnly use antennas that are recommended or supplied by the manufacturer.
lThe antenna must be installed at a distance of at least 20 cm from individuals.
lThe antenna must not be extended outside protected buildings and must be protected against
lightning strikes.
lThe voltage supply must be switched off before replacing the antenna.
Rev. 01 15

4.5 Overview
Overview myDatalogNANOamr
1Antenna connector 3Sensor cable with open ends (channel1 and
channel2)
2Sealed sensor cable (channel3 and
channel4)
4Housing cover
4.6 Intended use
The portable measurement instrument is used to record meter readings. The device can operate
without mains power. The measured and recorded data is stored on a non-volatile memory medium.
This stored data is sent via the mobile network to a central server for further processing. The device
is equipped with an integrated SIM chip for this purpose. The maximum permissible limit values
specified in chapter "Technical data " on page 11 must be observed. The manufacturer shall not be
liable for any operational cases that deviate from these limit values and have not been approved by
the manufacturer in writing.
Note: This device is exclusively intended to be used for the purposes as described above.
Any other use or use beyond what is specified or a modification of the device shall be
deemed to be not for the intended purpose and is not permitted without the express written
consent of the manufacturer. The manufacturer shall not be held liable for any damages that
may result from such unauthorised use or modification. The operator alone bears the
associated risk.
Note: The manufacturer is not liable for data loss of any kind if the device is damaged and
data is not able to be stored correctly.
16 Rev. 01

Chapter 4 General specifications
Note: The integrated SIM chip provides a mobile communications connection to a variety of
international service providers. In order to be able to utilise all functions of the device, you
must ensure that the device is located in the service area of one of these service providers.
You can find a list of all supported countries and associated service providers under
www.microtronics.at/footprint. A Managed Service contract with Microtronics Engineering
GmbH is required for use of the mobile data transmission (see
www.microtronics.at/managedservice). This includes the provisioning of the mobile
communications connection via the network of the service provider included in the above-
mentioned list.
4.7 General product information
The device is a compact, portable device for recording and transferring meter pulses. The energy
supply is provided via an integrated, replaceable battery pack, that facilitates a device operating
time of up to 3,76 years (see "Technical details about the device operating time" on page 38) using
the default configuration (1channel, 200ms reader type, 6h transmission cycle). 4 inputs are
available to which a meter contact can be connected without an additional energy supply (see
"Technical details about the meter inputs" on page 37). The internal "Battery" and "GSM level"
measurement values (see "Internal channels" on page 52) are also determined. All of the generated
measurement data is temporarily saved on an internal data memory and is then wirelessly
transferred to a central location at a freely selected interval. The device is also configured via this
connection. The device is equipped with an integrated SIM chip.
4.8 Device labelling
The specifications in this user manual apply exclusively to the myDatalogNANOamr device type. The
type plate is located on the top of the device and includes the following specifications:
lType designation
lSerial number
lEnvironmental conditions during operation
lHardware revision
lCE marking
lProtection class
The correct specification of the type designation and serial number is important for all queries and
spare part orders. Only then can we process requests promptly and properly.
Type plate myDatalogNANOamr
Rev. 01 17

Note: These operating instructions are part of the device and must be available to the user at
all times. The safety instructions included therein must be observed.
DANGER:
It is strictly prohibited to disable the safety equipment or modify its mode of operation.
4.9 Installation of replacement and wear parts
Please be advised that replacement and accessory parts that have not been supplied by the
manufacturer have also not been inspected or approved by it. Installing or using such products and
similar can constructively modify the specified properties of the device in a negative way. The
manufacturer shall not be liable for any damages that arise from the use of non-original parts and
non-original accessory parts.
4.10 Storage of the product
To store the myDatalogNANOamr , activate the transport lock, by setting the "Operation mode" in
the input screen of the myDataweb server to configure the device (see "Device-specific settings" on
page 55) to "OFF". Then activate ALOHA transmission mode (see "ALOHA transmission mode" on
page 23) via the solenoid contact so that the amended configuration is transferred to the
myDatalogNANOamr . During this process, all of the data that has not yet been transferred to the
myDataweb server is transferred. The cables and antenna can be removed as soon as the GPRS
connection has been deactivated - indicated by the status LED going out (see "Status LED" on page
46). Store the myDatalogNANOamr in its original packaging. The battery pack remains in the device.
The myDatalogNANOamr is placed in energy-saving mode by activating the transport lock. However,
it may still occur that the battery pack is fully discharged if the device is stored for very long periods.
Although the configuration and the most recently determined data are definitely maintained. The
transport lock is deactivated again by re-initiating ALOHA transmission mode (see "ALOHA
transmission mode" on page 23) and the myDatalogNANOamr resumes operation according to the
configuration.
4.11 Obligation of the operator
WARNING:
In the EEA (European Economic Area), the national implementation of the framework
directive (89/391/EEC) as well as the associated specific directives and from these in
particular, the directive (89/655/EEC) about the minimum safety and health requirements for
use of work equipment by workers at work, each in their respective version are to be
complied with.
The operator must obtain the local operating licence and the associated documents.
18 Rev. 01

Chapter 4 General specifications
In addition, the operator must comply with the local legal requirements for
lthe safety of the personnel (accident prevention measures)
lthe safety of the equipment (protective equipment and maintenance)
lthe product disposal (waste disposal law)
lthe material disposal (waste disposal law)
lthe cleaning (cleaning agents and disposal)
land the environmental protection amendments.
Before commissioning, the operator must ensure that the installation and commissioning –
provided these were performed by the operator himself – are in compliance with the local
regulations.
Rev. 01 19
