Microtronics myDatasensMINI H2S 1000 User manual

User manual for the portable device
myDatasensMINI H2S 1000
Rev. 01 valid from:
lFirmware version: 01v004
lModem version: ---
lServer version: 36.1
lHardware version: 1.4
User manual
300554
Microtronics Engineering GmbH | www.microtronics.at
Hauptstrasse 7 | 3244 Ruprechtshofen | Austria
Tel [phone] | Fax [phone] | [e-mail]

Chapter 1 Inhaltsverzeichnis_en
Chapter 1 Inhaltsverzeichnis_en
User manual for the portable device myDatasensMINI H2S 1000 1
Chapter 1 Inhaltsverzeichnis_en 3
Chapter 2 Declaration of conformity 9
2.1 Declaration of conformity - Appendix 10
Chapter 3 Technical data 11
Chapter 4 General specifications 13
4.1 Translation 13
4.2 Copyright 13
4.3 General descriptive names 13
4.4 Ex protection 14
4.5 Safety instructions 14
4.5.1 Use of the hazard warnings 15
4.5.2 General safety instructions 15
4.5.3 Safety and preventative measures for handling wireless modules 15
4.5.3.1 Safety and precautionary measures for the wireless module installation 16
4.6 Overview 16
4.7 Intended use 17
4.8 General product information 17
4.9 Device labelling 18
4.10 Installation of spare and wear parts 18
4.11 Storage of the product 19
4.12 Obligation of the operator 19
Chapter 5 Functional principle 21
5.1 Determining the H2S concentration 22
5.1.1 Determining the raw value 23
5.1.2 Calculation of the calibrated H2S measurement value 23
5.2 Determining the temperature 24
Chapter 6 Storage, delivery and transport 25
Rev. 01 3

6.1 Inspection of incoming deliveries 25
6.2 Scope of delivery 25
6.3 Storage 25
6.4 Transportation 25
6.5 Return 26
Chapter 7 Installation 27
7.1 Dimensions 27
7.2 Installing the myDatasensMINI H2S 1000 27
7.2.1 Suspended installation 29
Chapter 8 Initial Start-Up 31
8.1 User information 31
8.2 General principles 31
8.3 Commissioning the system 31
8.4 Testing communication with the device 33
8.4.1 Testing communication between myDatasensMINI H2S 1000and DeviceConfig 33
8.4.2 Testing communication between myDatasensMINI H2S 1000and the myDatanet
server 34
Chapter 9 User interfaces 35
9.1 User interface on the myDatasensMINI H2S 1000 35
9.1.1 Operating elements 35
9.1.1.1 Display 36
9.1.1.2 Acceleration sensor 37
9.2 User interface on the myDatanet-Server 37
9.2.1 Site configuration 37
9.2.1.1 Site 38
9.2.1.2 Comments 38
9.2.1.3 Measurement channels 38
9.2.1.3.1 Cross sensitivity of the H2S sensor 39
9.2.1.4 Internal channels 39
9.2.1.5 Basic setting 39
4Rev. 01

Chapter 1 Inhaltsverzeichnis_en
9.2.1.6 FTP export settings 40
9.2.2 Device configuration 40
9.2.2.1 Comments 40
9.2.2.2 Measurement instrument 40
Chapter 10 DeviceConfig 43
10.1 General 43
10.2 Prerequisites 43
10.3 Functional principle 44
10.3.1 USB radio transmitter 45
10.4 Installation 46
10.4.1 Installing the drivers for the USB radio transmitter 47
10.5 Menu of the DeviceConfig 48
10.5.1 Settings 48
10.5.1.1 Options 48
10.6 Establishing a connection to a device with a wireless M-bus interface 49
10.7 "Instrument" tab 52
10.8 "Zero" tab 53
10.9 "Calibration" tab 54
10.9.1 "Protocol Fields" program window 56
10.10 "Sync" tab 58
10.10.1 Existing connection to the myDatasensMINI H2S 1000 59
10.10.2 No connection to a device 60
10.11 "Data" tab 60
10.11.1 "Measurement Data" program window 61
10.11.1.1 "Chart Configuration" program window 63
10.12 Recommended procedure 64
10.12.1 Synchronisation with the DeviceConfig configuration program 64
10.12.2 Synchronisation with the myDatanet server 67
10.12.2.1 Internet connection available when reading out the data 67
10.12.2.2 No Internet connection when reading out the data 72
Rev. 01 5

Chapter 11 myDatanet server 77
11.1 Overview 77
11.1.1 Explanation of the symbols 77
11.2 "Customer" area 78
11.3 "Site" area at customer level 79
11.3.1 Reports 80
11.3.2 Map view 80
11.4 Recommended procedure 80
11.4.1 Creating the site 80
11.4.2 Assigning a device to the customer 81
Chapter 12 XML interface 83
12.1 General 83
Chapter 13 Maintenance 85
13.1 General maintenance 85
13.2 Maintenance of the H2S sensor 85
13.2.1 Calibration and zero point adjustment 86
13.2.1.1 Safety instructions for handling H2S gas 86
13.2.1.2 Calibration 86
13.2.1.2.1 Calibration guidelines 87
13.2.1.2.2 Calibration room equipment 87
13.2.1.2.3 Calibration process 87
13.2.1.3 Zero point adjustment 94
Chapter 14 Removal/disposal 97
Chapter 15 Troubleshooting and repair 99
15.1 General problems 99
Chapter 16 Spare parts and accessories 101
16.1 Assembly sets 101
16.2 Other accessories 101
Chapter 17 Document history 103
Chapter 18 Glossary 105
6Rev. 01

Chapter 1 Inhaltsverzeichnis_en
Chapter 19 Contact information 107
Rev. 01 7

Chapter 2 Declaration of conformity
Chapter 2 Declaration of conformity
Rev. 01 9

2.1 Declaration of conformity - Appendix
10 Rev. 01

Chapter 3 Technical data
Chapter 3 Technical data
Voltage supply Battery: 2 x Li-SOCl2 cells with a total of 34Ah
Housing Material: Noryl GTX 973 / PC (housing/inspection window)
Weight: 650g (with battery)
Degree of protection: IP66
Dimensions (WHD): 106 x 166 x 61mm (with protective armour)
Ex certification II 3G Ex nA IIB T4 Gc
Operating
temperature
-10...+40°C, 15...90%rH non-condensing
Storage and
transport
temperature
-20...+70°C
Displays 1,5" OLED display with a resolution of 128 x 128 pixels and the ability to
display 262.000 different colours
Operation Acceleration sensor to activate the display
H2S sensor Measurement range: 0-200ppm
Max. overflow: 1000ppm
Resolution: 0,25ppm
Pressure range: Atmospheric +/-10%
T90 response time: <=35s
Calibration cycle: 6 months
Max. service life: 2 years
Repeat accuracy: 1%
Temperature
sensor
Measurement range: -10...+40°C
Resolution: 0,1°C
Data memory Internal flash memory for up to 261.887 measurement cycles
Data type H2S concentration: f32 (32Bit floating point)
Temperature: s16 (16Bit signed)
Data transmission Protocol: Wireless M-bus (868MHz )
Range: 5m (depending on the environmental conditions)
Transmission rate: 16 data records/sec.
Device operating
time
lApprox. t.b.d. days with two-minute measurement cycle
lApprox. t.b.d. days with five-minute measurement cycle
lApprox. t.b.d. days with fifteen-minute measurement cycle
Rev. 01 11

Chapter 4 General specifications
Chapter 4 General specifications
The information in this manual has been compiled with great care and to the best of our knowledge.
The manufacturer, however, assumes no liability for any incorrect specifications that may be
provided in this manual. The manufacturer is not responsible for direct, indirect, accidental or
consequential damages which arise from errors or omissions in this manual even if advised of the
possibility of such damages. In the interest of continuous product development, the manufacturer
reserves the right to make improvements to this manual and the products described in it at any time
and without prior notification or obligation.
Note: The specifications in this manual are valid as of the versions listed on the front page. Revised versions of this
manual, as well as software and driver updates are available in the service area of the myDatanet server.
4.1 Translation
For deliveries to countries in the European Economic Area, the manual must be translated into the
language of the respective country. If there are any discrepancies in the translated text, the original
manual (German) must be referenced or the manufacturer contacted for clarification.
4.2 Copyright
The copying and distribution of this document as well as the utilisation and communication of its
contents to others without express authorisation is prohibited. Contraventions are liable to
compensation. All rights reserved.
4.3 General descriptive names
The use of general descriptive names, trade names, trademarks and the like in this manual does not
entitle the reader to assume they may be used freely by everyone. They are often protected
registered trademarks even if not marked as such.
Rev. 01 13

4.4 Ex protection
The portable measurement instrument myDatasensMINI H2S 1000designed for use in areas with a
zone2 explosive atmosphere.
The following conditions must be adhered to:
lOnly the manufacturer is permitted to open the housing to carry out maintenance work, which
must only be completed outside the Ex area.
lOnly the manufacturer's original spare parts must be used.
lThe battery must only be replaced with certified identical products.
lDue to the electrostatic effects, the protective armour must not be rubbed with cloths in the Ex
zone.
II 3G Ex nA IIB T4 Gc
Important note: The Ex approval is only valid if the corresponding marking is provided on
the type plate of the measurement instrument .
Important note: The certificates of conformity and any relevant test certificates from the
respective authorities must be carefully observed during installation and commissioning.
1myDatasensMINI H2S 1000
4.5 Safety instructions
For the connection, commissioning and operation of the myDatasensMINI H2S 1000, the following
information and higher legal regulations of the country (e.g. ÖVE), such as valid EX regulations as
well as the applicable safety and accident prevention regulations for the respective application case
must be observed.
Please read this manual completely before unpacking, setting up or operating this device. Observe
all hazard, danger and warning information. Non-observance can lead to serious injuries to the
operator and/or damage to the device.
14 Rev. 01

Chapter 4 General specifications
Ensure that the safety equipment of this measurement device is not impaired. Install and use the
measuring system only in the manner and method described in this manual.
Important note: The manufacturer's products that are designed for use outdoors include
extensive protection against penetrating moisture and dust.
4.5.1 Use of the hazard warnings
DANGER:
Indicates a potential or threatening hazardous situation that will result in death or serious
injuries if not avoided.
WARNING:
Indicates a potential or threatening hazardous situation that can result in death or serious
injuries if not avoided.
CAUTION:
Indicates a potential hazardous situation that can result in minor or moderate injury.
Note: Indicates a situation that does not result in any injury to persons.
Important note: Indicates a situation that can result in damages to this instrument if it is not
avoided. Information that must be particularly emphasised.
Note: Information that supplements the specifications in the main text.
4.5.2 General safety instructions
WARNING:
Never use this device in areas where the use of wireless equipment is prohibited. This device
must not be used in hospitals and/or in the vicinity of medical equipment, such as heart
pacemakers or hearing aids, as their functionality could be compromised by the wireless
modulecontained in the device.
4.5.3 Safety and preventative measures for handling wireless modules
The following safety and preventative measures must be observed during all phases of installation,
operation, maintenance or repair of a wireless module. The manufacturer is not liable if the
customer disregards these preventative measures.
CAUTION:
The wireless connection must not be used in hazardous environments.
No guarantee of any kind, whether implicit or explicit, is given by the manufacturer and its
suppliers for the use with high risk activities.
In addition to the following safety considerations, all directives of the country in which the device is
installed must be complied with.
Rev. 01 15

4.5.3.1 Safety and precautionary measures for the wireless module installation
lThis device must only be installed by a trained technician who applies the recognised
installation practices for a wireless frequency transmitter including the correct grounding of
external antennas.
lThe device must not be operated in hospitals and/or in the vicinity of medical equipment such
as heart pacemakers or hearing aids.
lThe device must not be subjected to strong vibrations or impacts.
lThe wireless module can cause interferences if it is located in the vicinity of television sets,
radios or computers.
lDo not open the wireless module. Any modification to the equipment is prohibited and will
result in the operating licence being revoked.
lDo not install the device in any other way to the one described in the operating instructions.
Improper use will invalidate the warranty.
4.6 Overview
Front of the myDatasensMINI H2S 1000
(view without protective armour)
Bottom of the myDatasensMINI H2S 1000
(view without protective armour)
1Display 3H2S sensor
2Second sensor slot (reserved for extensions)
16 Rev. 01

Chapter 4 General specifications
4.7 Intended use
The portable measurement instrument is used to record H2S concentrations. The device is battery-
operated. The measured and recorded data is stored on a non-volatile storage medium. This stored
data can be transferred to a PC via a wireless connection (wireless M-bus). Using the software
provided by the manufacturer, the data can then be transferred from the PC to a central server for
further processing. The maximum permissible limit values (specified in chapter "Technical data" on
page 11) must be observed. The manufacturer shall not be liable for any operational cases that
deviate from these limit values and have not been approved by the manufacturer in writing.
Note: This device is exclusively intended to be used for the purposes as described above.
Any other use or use beyond what is specified or a modification of the device shall be
deemed to be not for the intended purpose and is not permitted without the express written
consent of the manufacturer. The manufacturer shall not be held liable for any damages that
may result from such unauthorised use or modification. The operator alone bears the
associated risk.
Note: The manufacturer is not liable for data loss of any kind if the device is damaged and
data is not able to be stored correctly.
4.8 General product information
The device is a compact, portable device designed to be operated in wastewater systems to record
and transfer H2S concentrations. The device is equipped with an integrated electrochemical sensor
for this purpose. The sensor is subject to wear and must therefore be calibrated every 6 months.
Depending on the application, the service life of the sensor can be up to 2 years. In addition to the
H2S concentration, the internal measurement values "Int. Temp" (see "Internal channels" on page
39) and "Raw" (raw value of the sensor signal) are determined. All of the generated measurement
data is temporarily saved in an internal data memory at an adjustable interval (see ""Instrument"
tab" on page 52). The stored data can be read out wirelessly (wireless M-bus). The DeviceConfig
configuration program (see "DeviceConfig " on page 43) provided by the manufacturer and the USB
radio transmitter (206.657) included in the scope of delivery are required for this process. In
addition to local processing of the data on the PC, the data can also be transferred to a central
myDatanet server. This server provides a variety of options for managing and displaying the data.
More information is provided in the server manual ("myDatanet Server Manual " 805002).
The myDatasensMINI H2S 1000has a 1,5" OLED display to show the current measurement values
(H2S concentration and temperature) and a variety of status information (e.g. remaining time until
the next calibration, remaining time until the next general overhaul, software version, etc.). The
display is activated by tilting the device by the horizontal axis. Detailed information on this is
provided in chapter "Acceleration sensor" on page 37.
Rev. 01 17

4.9 Device labelling
The specifications in this user manual apply exclusively to the myDatasensMINI H2S 1000 device
type. The type plate is located on the rear side of the device and contains the following
specifications:
lName and address of the manufacturer
lType designation
lDegree of protection
lCE marking
lEnvironmental conditions during operation
lEx protection designation as specified in chapter "Declaration of conformity" on page 9
lSerial number
lHardware revision
lHazard note regarding electrostatic charge
The correct specification of the type designation and serial number is important for all queries and
spare part orders. Only then can we process requests promptly and properly.
Type plate myDatasensMINI H2S 1000
Note: These operating instructions are part of the device and must be available to the user at
all times. The safety instructions contained therein must be observed.
DANGER:
It is strictly prohibited to disable the safety equipment or modify its mode of operation.
4.10 Installation of spare and wear parts
Please be advised that spare and accessory parts that have not been supplied by the manufacturer
have also not been inspected or approved by the manufacturer. The installation and/or use of such
products can possibly have a negative impact on the specified constructional properties of the
device. The manufacturer shall not be liable for any damages that arise from the use of non-original
parts and non-original accessory parts.
Note: The use of spare and wear parts that are not approved by the manufacturer shall void
the Ex approval.
18 Rev. 01

Chapter 4 General specifications
4.11 Storage of the product
The myDatasensMINI H2S 1000does not include a special transport mode. The capacity of the
installed batteries is dimensioned in such a way that the max. service life of the sensor (2 years) is
covered. In the event of unfavourable environmental conditions (high H2S concentrations, low
temperatures), it may occur that either the sensor or the battery capacity is depleted before the 2
years have elapsed. If the capacity of the batteries is completely depleted, the configuration and the
most recently determined data are always retained.
If necessary, before storing the myDatasensMINI H2S 1000in its original packaging, download the
data generated up to the current point in time from the device using the DeviceConfig configuration
program (see "DeviceConfig " on page 43). Do not remove the protective armour during this
process. It is recommended to ensure that the device is transported in a horizontal position (display
horizontal to the base). The firmware includes an algorithm that detects any vibrations if
transported in this position and thus prevents the display from activating.
4.12 Obligation of the operator
WARNING:
In the EEA (European Economic Area), the national implementation of the framework
directive (89/391/EEC) as well as the associated specific directives and from these in
particular, the directive (89/655/EEC) about the minimum safety and health requirements for
use of work equipment by workers at work, each in their respective version are to be
complied with.
The operator must obtain the local operating licence and the associated documents.
In addition, the operator must comply with the local legal requirements for
lthe safety of the personnel (accident prevention measures)
lthe safety of the equipment (protective equipment and maintenance)
lthe product disposal (waste disposal law)
lthe material disposal (waste disposal law)
lthe cleaning (cleaning agents and disposal)
land the environmental protection amendments.
Before commissioning, the operator must ensure that the installation and commissioning –
provided these were performed by the operator himself – are in compliance with the local
regulations.
Rev. 01 19
