Middle Atlantic Products UPS-EBPR User manual

I-00318 Rev D
UPS-EBPR
EXPANSION BATTERY PACK FOR
USE WITH UPS-1000R Series and
UPS-2200R Series
Instruction Sheet
THANK YOU
Thank you for purchasing the UPS-EBPR Expansion Battery Pack. Please read these instructions
thoroughly before removing the expansion battery pack from the shipping carton and before installing
and making any connections to or from the battery pack.
PRODUCT FEATURES
- Extends runtime of UPS
- Additional output connector allows multiple battery packs to be daisy chained (up to a maximum
of ten) to the UPS for even longer extended runtime operation
- Supports rackmount installation using only 2 rackspaces (2U)
UL
R
C US
LISTED

CAUTION: Do not connect the UPS expansion battery pack into itself, as this will damage the
battery pack.
CAUTION:
Remember the Battery Pack is charged. Before connecting to the UPS, ensure the
circuit breaker/switch on the UPS expansion battery pack is in the OFF position.
READ AND SAVE THESE WARNINGS
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: Remember the Battery Pack is charged. Do not disconnect the UPS expansion battery
pack while the UPS is turned on.
WARNING:
The UPS expansion battery pack must be connected to a grounded AC power outlet with
fuse or circuit breaker protection. Do not plug the UPS expansion battery pack into an
outlet that is not grounded.
WARNING:
Remember the Battery Pack is charged. To reduce the risk of electric shock, do not
remove the cover. There are no serviceable parts inside the product.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the product.
The lightning flash with the arrowhead symbol, within an equilateral triangle, is intended to alert the user
to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
UNPACKING
CAUTION: DO NOT LIFT THE BATTERY PACK OUT OF THE SHIPPING BOX WHILE HOLDING THE
FRONT FACE OF THE BATTERY PACK, AS THIS MAY DAMAGE THE UNIT. LIFT THE
BATTERY PACK OUT OF THE SHIPPING CARTON BY HOLDING IT BY BOTH SIDES.
LIFT OUT OF BOX
WHILE HOLDING
BOTH SIDES OF
BATTERY PACK
LIFT OUT OF BOX
WHILE HOLDING
BOTH SIDES OF
BATTERY PACK
After the product is removed from its packaging, inspect the expansion battery pack before
installing. The shipping carton should contain the following items:
(1) Expansion Battery Pack with a permanently attached output 48 VDC cable, (2) rack mounting ears,
(2) front handles, (14) 10-32 mounting ear screws, (6) 8-32 front handle screws, (1) instruction sheet
CAUTION: The expansion battery pack circuit breaker/switch must be in the OFF position when
either making a connection to or disconnecting from either the battery pack 48 VDC
input/output connectors or the UPS 48 VDC external battery pack connector.
Page 2

Page 3
TABLE OF CONTENTS
Page No.
Important safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
FCC Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation and Mounting . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 6
Connection to UPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2

Page 4
FEATURES
1Reset - Resetable circuit breaker, push to reset.
2AC Input (Charge only) - For optional battery pack charging (faster charge time). Plug an IEC
cordset (not supplied) from battery pack into a wall receptacle (120V, 15A).
3
AC Output - Multiple battery packs can be daisy chained for charging using IEC cordset (not
supplied). A maximum of ten (10) battery packs can be daisy chained for charging.
4
5
Battery Pack 48 VDC Input Connector - Connector allows battery packs to be daisy chained for
extended UPS runtime operation. A maximum of ten (10) battery packs can be daisy chained.
6
12
4
3
REAR VIEW
NOTE: Signal-Safe power cords are available from Middle Atlantic Products in 12” lengths (Part
No. IEC-12xX) for daisy chaining of multiple battery packs.
TM
Circuit Breaker/Switch - Switches battery pack on or off. The circuit breaker/switch must be in the
OFF position when either making a connection to or disconnecting from either the battery pack 48
VDC input/output connectors or the UPS 48 VDC external battery connector.
1778
Output:
48V Input:
48V
Battery
Pack
ON
OFF
REAR VIEW (48 VDC cable and protective cover plate removed for clarity)
RESET
AC Output AC Input
(charge only)
5
6
1778
Output:
48V Input:
48V
Battery
Pack
ON
OFF
RESET
AC Output AC Input
(charge only)
Circuit Breaker/Switch must be in
the off position when connecting or
disconnecting 48V Input/Output.
Circuit Breaker/Switch must be in
the off position when connecting or
disconnecting 48V Input/Output.
Output 48 VDC - 48 VDC external battery connector cable. Connects to UPS 48 VDC connector
for extended UPS runtime and for battery pack charging. Cable connector is color coded (red,
black, green).

Page 5
TECHNICAL SPECIFICATIONS
Dimensions
Weight
Battery
Operating Temperature
Operating Relative
Humidity
2U Rack: 17.05 In. x 3.5 In. x 18.9 In.
(43.3 cm x 8.8 cm x 48 cm)
70.5 Lb. (32 kg.)
Sealed maintenance free lead acid
battery (12V/9.0 AH x 8)
32 F to 104 F (0 C to 40 C)
oooo
0 to 95% non-condensing
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference that
may cause undesired operation.
WARNING!! This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
PRODUCT CHARACTERISTICS VALUE/MEASUREMENT
NOTE:
The battery pack should be located directly below the UPS in the rack in order to connect the
48 VDC output cable to the UPS as shown in Figure A. If installing the battery pack and the UPS
is located in the bottom of the rack, the UPS should be moved before installing the expansion
battery pack.
INSTALLATION AND MOUNTING
1) If using the provided handles install them now
using provided 8-32 screws. (FIGURE A)
NOTE: The handles cannot be installed
after the unit is rack-mounted.
FIGURE A
RACK EAR
RACK EAR
SCREW (6X)
2) Install ears as shown using provided 10-32 screws.
Six screws per ear, one ear per side.

Page 6
Do not lift from the face of the unit, this will detach the face and could cause the unit to drop
One Person Installation:
1) Determine mounting location.
2) Install the Rear Mounting Brackets as shown. One Bracket is longer then the other to provide guidance
when doing a one person installation. These brackets are interchangeable. (FIGURE A)
IMPORTANT NOTE: Rear Mounting Brackets mount between the two corresponding rackspaces in the front
of the enclosure. (FIGURE B)
3) Carefully lift the unit to the mounting position constantly supporting the bottom. Place the slide on the
unit’s ear onto the longer Rear Mounting Bracket then guide the unit onto the other Rear Mounting Bracket.
Once the ears and the Rear Mounting Brackets are fully engaged, slide to unit to the back of the enclosure.
4) Install the front of the unit to the rackrail. (FIGURE C)
Two Person Installation:
1) Determine mounting location.
2) Properly support the unit from the bottom and carefully lift to the mounting location.
3) While adequately supporting the bottom, install the front of the unit to the rackrail. (FIGURE D)
4) Install the Rear Mounting Brackets as shown. Continue to support the bottom of the unit. (FIGURE E)
IMPORTANT NOTE: Rear Mounting Brackets mount between the two corresponding rackspaces in the front
of the enclosure. (FIGURE B)
INSTALLATION AND MOUNTING CONTINUED
CAUTION: THIS UNIT IS HEAVY, LIFT CAREFULLY
FIGURE A
FIGURE B
RACKSCREWS
4X
FIGURE C
RACKSCREWS
4X
FIGURE D
RACKSCREWS
(4X)
RACKSCREWS
(4X)
FIGURE E

Page 7
CONNECTION TO UPS
2) Connect the expansion battery pack 48VDC Output cable to the UPS Input 48VDC connector.
Non-Critical
Load
Surge
Protected
Reset
125V
8A
60Hz
Reset
Critical
Load
Surge
Protected
Input:
48V Expansion Port
XXXX
Primary Secondary
Serial Port
IN OUT
125V
12A
60Hz
750W
1000VA
Wiring Fault
Reset
IN OUT
EPO
FIGURE A. EXPANSION BATTERY PACK TO UPS CONNECTION.
UPS
EXPANSION BATTERY PACK
INPUT 48VDC
CONNECTOR 48VDC OUTPUT
CABLE
1) On the expansion battery pack, ensure the circuit breaker/switch is in the OFF position and the UPS
is also turned off and not plugged into an AC wall receptacle.
REAR VIEW
NOTE: Connectors are color coded (red, black,& green). Ensure connectors are secured to each other
per matching color (red to red, black to black & green to green).
CIRCUIT BREAKER/SWITCH
RESET
AC Output AC Input
(charge only)
1778
Output:
48V Input:
48V
Battery
Pack
ON
OFF
Circuit Breaker/Switch must be in
the off position when connecting or
disconnecting 48V Input/Output.
3) To have the UPS recognize the expansion battery, press and hold the select button until the six
icons appear. Press the select button one time, then press and hold the select button until the six icons
blink. Press the select button to enter the number of expansion battery packs being connected
(ten maximum).
4) To save the value, press and hold the Select button until the LCD displays the General Status Mode
Input Voltage Display.
5) Return the circuit breaker/switch to the ON position.

Page 8
WARRANTY
Middle Atlantic Products, Inc. (the "Company") warrants the UPS-EBPR UPS Expansion Battery
Pack to be free from defects in material or workmanship under normal use and conditions for a
period of (2) two years from date of shipment by the Company.
The Company's entire liability to the purchaser, and the purchaser's (or any other parties) sole and
exclusive remedy, under this warranty shall be limited, at the Company's option, to either (a) return
of and refund of the price paid for, or (b) repair or replacement at the Company's factory of the
products purchased, or any part or parts thereof, which the Company has determined to be
defective after inspection thereof at the Company's factory.
This warranty does not cover damage due to acts of God, accident, misuse, abuse or negligence by
parties other than the Company, or any modification or alteration of the products. In addition, this
warranty does not cover damage due to improper handling, assembly, installation or maintenance.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF ANY KIND, EITHER EXPRESSED OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL THE COMPANY
BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION OR ANY OTHER PECUNIARY LOSS) ARISING OUT OF THE USE OF THE
PRODUCTS PURCHASED, EVEN IF THE COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. THE COMPANY'S LIABILITY TO THE PURCHASER (OR ANY OTHER PARTY)
HEREUNDER, IF ANY, SHALL IN NO EVENT EXCEED THE PURCHASE PRICE OF THE PRODUCTS
PAID TO THE COMPANY.
Corporate Headquarters
Corporate Voice 973-839-1011 - Fax [phone]
International Voice [phone] - Fax [phone]
middleatlantic.com - [email protected]
Middle Atlantic Canada
Voice 613-836-2501 - Fax [phone]
middleatlantic.ca - [email protected]
Factory Distribution
USA: NJ - CA - IL Canada: ON - BC
