OWNER’S MANUAL
TOWER FAN
MODEL:FZ10-8HC
Please read the instruction manual carefully before use and safekeeping.
TOWER FAN

1
Read Rules for Safe Operation and Instructions Carefully.
CAUTION
WARNING
1. Never insert fingers, pencils, or any other object through the grille when fan is
running.
2. Disconnect fan when moving from one location to another.
3. Be sure fan is on a stable surface when operating to avoid overturning.
4. DO NOT use fan in window, rain may create electrical hazard.
5. Indoor use only.
RULES FOR SAFE OPERATION
1. If the supply cord is damaged, it must be replaced by manufacturer
or its service agent or a similarly qualified person in order to avoid
a hazard.
2. To protect against the risk of electrical shock, do not immerse the
unit, cord or plug in water or other liquid.
3. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Young children should be
supervised to ensure that they do not play with the appliance.
4. When the appliance is not in use and before cleaning, unplug the
appliance from the outlet.
5. Keep electrical appliances out of reach from Children or infirm
persons. Do not let them use the appliances without supervision.
6. When the fan was assembled, the rotor blade guard shall not be
taken off anymore
- Prior cleaning unplug the fan
- The rotor guard shall not be dissembled/opened to clean the
rotor blades.
- Wipe the fan enclosure and rotor blade guard with a slightly
damp cloth.

2
PART FIGURE
Note: All the pictures in this manual are for explanation purpose only. Any discrepancy between
the real object and the illustration in the drawing shall be subject to the real subject.
1. Body
2. Front base
3. Rear base
4. Plastic nut
5. Power cord
1. Take the chassis, fan body from the packing box and combine two parts of the
chassis with two screws.(See Fig.1)
2. Pass the power cord through the flute, then Insert the fan body in the chassis.
(See Fig.3)
3. Fix the fan body on the chassis with plastic nut. (See Fig.2)
ASSEMBLY INSTRUCTIONS
The outlet trough
Fig.1
Fig.2 Fig.3

3
a. Control parts description:
1. Timer 2. Body oscillating switch 3. Speed switch
b. Instructions:
1. Plug the power cord into a wall outlet.
2. The air flow can be set to oscillate to left or right by
pushing the button of body oscillating switch (2).
If you want to stop oscillation, push it again.
3. Automatic 120-minute timer. Turn the knob of the
timer (1) to the desired time you want, the fan will
stop when the time is over. The longest time set is
120 minutes. If the timer is not required and
constant fan operation is required, then set Timer
to “ON” position.
4. Speed is controlled by selecting the speed switch (3) on the top of the body.
There are 4 positions: OFF ; 1--Low ; 2--Medium ; 3--High
OPERATION INSTRUCTION
0
4080
120
ON
3
2
1
The fan requires little maintenance. Do not try to fix it by yourself. Refer it to
qualified service personnel if service is needed.
1. Before cleaning and assembling, fan must be unplugged.
2. To ensure adequate air circulation to the motor, keep vents at the rear of the
motor free of dust. Do not disassemble the fan to remove dust.
3. Please wipe the exterior parts with a soft cloth soaking a mild detergent.
4. Do not use any abrasive detergent or solvents to avoid scratching the surface.
Do not use any of the following as a cleaner: gasoline, thinner, bending.
5. Do not allow water or any other liquid into the motor housing or interior parts.
MAINTENANCE INSTRUCTION
CLEANING
1. Be sure to unplug from the electrical supply source before cleaning.
2. Plastic parts should be cleaned with a soft cloth moisten with mild soap.
Thoroughly remove soap film with dry cloth.

GD Midea Environment Appliances Manufacturing CO.,LTD.
Midea Industrial Park, Dongfu Road, Dongfeng Town, Zhongshan, Guangdong, China
